EN 61120-5:1995
(Main)Digital audio tape recorder reel-to-reel system, using 6,3 mm magnetic tape, for professional use - Part 5: Reels
Digital audio tape recorder reel-to-reel system, using 6,3 mm magnetic tape, for professional use - Part 5: Reels
Applies to reels used in digital audio reel-to-reel recording and reproducing systems using 6,3 mm magnetic tape for professional use.
Digitales Tonbandgerät - Spulensystem mit Magnetband 6,3 mm für Studioanwendung - Teil 5: Spulen
Système d'enregistrement à bande audionumérique, bobine à bobine, utilisant une bande magnétique de 6,3 mm, à usage professionnel - Partie 5: Bobines
S'applique aux bobines utilisées dans les systèmes d'enregistrement et de lecture audionumérique, bobine à bobine, utilisant une bande magnétique de 6,3 mm, à usage professionnel.
Digital audio tape recorder reel-to-reel system, using 6,3 mm magnetic tape, for professional use - Part 5: Reels (IEC 61120-5:1995)
General Information
- Status
- Published
- Publication Date
- 08-Oct-1995
- Withdrawal Date
- 30-Jun-1996
- Technical Committee
- CLC/TC 100X - Audio, video and multimedia systems and equipment and related sub-systems
- Drafting Committee
- IEC/TC 100 - IEC_TC_100
- Parallel Committee
- IEC/TC 100 - IEC_TC_100
- Current Stage
- 6060 - Document made available - Publishing
- Start Date
- 09-Oct-1995
- Completion Date
- 09-Oct-1995
Overview
EN 61120-5:1995 is an international standard developed by the International Electrotechnical Commission (IEC) and adopted by the European Committee for Electrotechnical Standardization (CLC). It specifies the requirements for reels used in professional digital audio tape recorder reel-to-reel systems utilizing 6.3 mm magnetic tape. This standard is part 5 of the EN 61120 series and focuses exclusively on the mechanical and dimensional specifications for reels, ensuring compatibility and interoperability within professional audio recording environments.
This standard applies to reels designed for use in digital audio tape recorder systems that enable high-quality sound recording and playback in professional studio settings and broadcasting. It supports the international unification of reel design, enhancing program exchange and equipment interchangeability across manufacturers and regions.
Key Topics
Scope of Application
EN 61120-5 outlines the requirements for reels compatible with digital audio tape recorders using 6.3 mm magnetic tape. It ensures reels meet professional use criteria, primarily targeting sound recording and reproducing systems.Reel Types and Center Holes
The standard specifies two types of reels based on center-hole diameter:- Reels with an 8 mm center hole
- Reels with a 76 mm center hole
These variations accommodate different machine designs and user preferences within professional environments.
Mechanical Requirements and Dimensions
The standard provides detailed mechanical and dimensional requirements, such as:- Diameter and width measurements
- Symmetrical design to allow mounting from either side
- Limitations on flange curvature, ribbing, or raised designs to ensure smooth operation
- Maximum moment of inertia values related to reel size for mechanical stability and tape tension management
Construction and Design Notes
Reels must ensure the tape width of 12.2 mm is accommodated within the specified diameter, with allowances for flange designs that do not extend beyond certain limits to avoid interference or tape damage.Normative References
EN 61120-5 builds upon other relevant IEC standards, including those covering magnetic tape properties and reel-to-reel mechanical systems, reinforcing a cohesive framework for digital audio tape recording systems.
Applications
EN 61120-5 is essential for manufacturers and users of professional digital audio recording equipment. Its applications include:
Broadcasting and Studio Recording
Enables reliable, high-fidelity sound recording and playback by specifying standard reels that ensure consistent tape handling across equipment.Program Exchange
Facilitates international interchange of prerecorded tapes by standardizing reel dimensions, minimizing compatibility issues between different recording systems.Equipment Manufacturing
Provides manufacturers with precise technical criteria for producing reels that fit seamlessly into 6.3 mm professional reel-to-reel digital audio tape recorders.Archiving and Preservation
Assists archives and libraries in preserving digital audio content on standardized reels, ensuring longevity and compatibility with playback systems.
Related Standards
- IEC 1120-1:1991 - General requirements for digital audio tape recorder reel-to-reel systems using 6.3 mm tape
- IEC 1120-2:1991 - Format A specifications for digital reel-to-reel systems
- IEC 1120-3:1991 - Format B specifications for digital reel-to-reel systems
- IEC 1120-4:1992 - Definitions and measurement methods for magnetic tape properties
- IEC 94-6:1985 - Magnetic tape sound recording and reproducing systems - Reel-to-reel systems
- IEC 50(806):1975 - International Electrotechnical Vocabulary relating to recording and reproduction of sound and video
These standards collectively establish a robust framework for professional digital audio tape recorder systems, ensuring consistent performance, reliability, and interoperability within the audio industry.
Keywords: EN 61120-5, digital audio tape recorder, reel-to-reel system, 6.3 mm magnetic tape, professional audio recording, IEC standard, reel specifications, magnetic tape reels, audio studio equipment, broadcasting tape standards, professional sound recording reels
Frequently Asked Questions
EN 61120-5:1995 is a standard published by CLC. Its full title is "Digital audio tape recorder reel-to-reel system, using 6,3 mm magnetic tape, for professional use - Part 5: Reels". This standard covers: Applies to reels used in digital audio reel-to-reel recording and reproducing systems using 6,3 mm magnetic tape for professional use.
Applies to reels used in digital audio reel-to-reel recording and reproducing systems using 6,3 mm magnetic tape for professional use.
EN 61120-5:1995 is classified under the following ICS (International Classification for Standards) categories: 33.160.30 - Audio systems. The ICS classification helps identify the subject area and facilitates finding related standards.
