STANDARD(istoveten EN 62330-3:2004)Digitalni videokasetni snemalni sistem z zapisovanjem s poševnimi sledmi na magnetnem traku, širokem 12,65 mm (0,5 in) – Format HD-D5 – 3. del: Podatkovno-tokovni format (IEC 62330-3:2003)Helical-scan digital video cassette recording system using 12, 65 mm (0, 5 in) magnetic tape - Format HD-D5 - Part 3: Data stream format (IEC 62330-3:2003)©
Standard je založil in izdal Slovenski inštitut za standardizacijo. Razmnoževanje ali kopiranje celote ali delov tega dokumenta ni dovoljenoReferenčna številkaSIST EN 62330-3:2005(en)ICS33.160.40

EUROPEAN STANDARD
EN 62330-3 NORME EUROPÉENNE EUROPÄISCHE NORM
March 2004 CENELEC European Committee for Electrotechnical Standardization Comité Européen de Normalisation Electrotechnique Europäisches Komitee für Elektrotechnische Normung
Central Secretariat: rue de Stassart 35, B - 1050 Brussels
© 2004 CENELEC - All rights of exploitation in any form and by any means reserved worldwide for CENELEC members.
Ref. No. EN 62330-3:2004 E
ICS 33.160.40; 35.240.99
English version
Helical-scan digital video cassette recording system
using 12,65 mm (0,5 in) magnetic tape -
Format HD-D5 Part 3: Data stream format (IEC 62330-3:2003)
Système de magnétoscope numérique
à cassette à balayage hélicoïdal sur bande magnétique de 12,65 mm (0,5 in) - Format HD-D5 Partie 3: Format de flux de données (CEI 62330-3:2003)
Videokassettensystem mit Schrägspuraufzeichnung auf Magnetband 12,65 mm (0,5 in) -
HD-D5-Format Teil 3: Datenstromformat (IEC 62330-3:2003)
This European Standard was approved by CENELEC on 2004-03-01. CENELEC members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the Central Secretariat or to any CENELEC member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CENELEC member into its own language and notified to the Central Secretariat has the same status as the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.

The following dates were fixed:
– latest date by which the EN has to be implemented
at national level by publication of an identical
national standard or by endorsement
(dop) 2005-03-01
– latest date by which the national standards conflicting
with the EN have to be withdrawn
(dow) 2007-03-01
Annex ZA has been added by CENELEC. __________
Endorsement notice
The text of the International Standard IEC 62330-3:2003 was approved by CENELEC as a European Standard without any modification. __________

- 3 - EN 62330-3:2004
Annex ZA
(normative)
Normative references to international publications
with their corresponding European publications The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. NOTE When an international publication has been modified by common modifications, indicated by (mod), the relevant EN/HD applies. Publication Year Title EN/HD Year SMPTE 259M - 1) Television - 10-Bit 4:2:2 Component and 4fsc Composite Digital Signals - Serial Digital Interface
- - SMPTE 272M - 1) Television - Formatting AES/EBU Audio and Auxiliary Data into Digital Video Ancillary Data Space
- -
1) Undated reference.
INTERNATIONALSTANDARDIEC62330-3First edition2003-05Helical-scan digital video cassette recordingsystem using 12,65 mm (0,5 in) magnetic tape –Format HD-D5 –Part 3:Data stream format IEC 2003

Copyright - all rights reservedNo part of this publication may be reproduced or utilized in any form or by any means, electronic ormechanical, including photocopying and microfilm, without permission in writing from the publisher.International Electrotechnical Commission,
3, rue de Varembé, PO Box 131, CH-1211 Geneva 20, SwitzerlandTelephone: +41 22 919 02 11
Telefax: +41 22 919 03 00
E-mail: inmail@iec.ch
Web: www.iec.chKFor price, see current cataloguePRICE CODECommission Electrotechnique InternationaleInternational Electrotechnical Commission

– 2 –62330-3  IEC:2003(E)CONTENTSFOREWORD.31Scope.52Normative references.53DIF block mapping.53.1DIF block and DIF slice.53.2Mapping of DIF blocks over SDI.64Audio Data.9Bibliography.10Figure 1 – DIF block.5Figure 2 – DIF slice structure.6Figure 3 – Slice sell structure over SDI.7Figure 4 – DIF area type and byte allocation of DIF blocks.8Figure 5 – Bit allocation.9
