EN 15341:2019+A1:2022

SLOVENSKI STANDARD
01-september-2022
Vzdrževanje - Ključni kazalniki učinkovitosti in uspešnosti vzdrževanja
Maintenance - Maintenance Key Performance Indicators
Instandhaltung - Wesentliche Leistungskennzahlen für die Instandhaltung
Maintenance - Indicateurs de performance clés pour la maintenance
Ta slovenski standard je istoveten z: EN 15341:2019+A1:2022
ICS:
03.100.99 Drugi standardi v zvezi z Other standards related to
organizacijo in vodenjem company organization and
podjetja management
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

EN 15341:2019+A1
EUROPEAN STANDARD
NORME EUROPÉENNE
June 2022
EUROPÄISCHE NORM
ICS 03.100.99 Supersedes EN 15341:2019
English Version
Maintenance - Maintenance Key Performance Indicators
Maintenance - Indicateurs de performance clés pour la Instandhaltung - Wesentliche Leistungskennzahlen für
maintenance die Instandhaltung
This European Standard was approved by CEN on 14 July 2019 and includes Amendment 1 approved by CEN on 20 April 2022.

CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this
European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references
concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN
member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by
translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management
Centre has the same status as the official versions.

CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia,
Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway,
Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and
United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION

EUROPÄISCHES KOMITEE FÜR NORMUNG

CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2022 CEN All rights of exploitation in any form and by any means reserved Ref. No. EN 15341:2019+A1:2022 E
worldwide for CEN national Members.

Contents Page
European foreword . 3
Introduction . 4
1 Scope . 5
2 Normative references . 5
3 Terms and definitions . 5
4 Maintenance function . 6
5 KPIs and their objectives . 8
5.1 General . 8
5.2 Influencing factors . 9
5.3 Maintenance Resources . 9
5.4 Maintenance Processes . 10
6 Maintenance KPIs Matrix . 10
7 KPIs of “Maintenance within Physical Asset Management” . 11
8 KPIs of Sub-function “Health-Safety-Environment (HSE)” on Maintenance . 16
9 KPIs of Sub-function “Maintenance Management” . 20
10 KPIs of Sub-function “People Competence” . 26
10.1 General . 26
10.2 Qualification . 27
11 KPIs of Sub-function “Maintenance Engineering” . 30
12 KPIs of Sub-function “Organization and Support” . 33
13 KPIs of Sub-function “Administration and Supply”. 39
14 KPIs of Sub-function “Information and Communication Technology” . 44
15 Process to improve maintenance performance . 47
15.1 Use of KPI . 47
15.2 Classification of Maintenance Indicators . 47
15.3 Steps for an Improvement Process . 48
15.4 Maintenance assessment . 49
Bibliography . 51

European foreword
This document (EN 15341:2019+A1:2022) has been prepared by Technical Committee CEN/TC 319
“Maintenance”, the secretariat of which is held by UNI.
This European Standard shall be given the status of a national standard, either by publication of an
identical text or by endorsement, at the latest by December 2022, and conflicting national standards shall
be withdrawn at the latest by December 2022.
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CEN shall not be held responsible for identifying any or all such patent rights.
This document includes Amendment 1 approved by CEN on 20 April 2022.
This document supersedes !EN 15341:2019".
The start and finish of text introduced or altered by amendment is indicated in the text by tags !".
The main technical changes compared to the previous EN 15341:2007 are the following:
— the standard was fully revised;
— the vision on all the Maintenance Components was enlarged, structuring the standard in a more
complete way maintaining the economical, technical, organizational KPI of the previous edition.
Any feedback and questions on this document should be directed to the users’ national standards body.
A complete listing of these bodies can be found on the CEN website.
According to the CEN-CENELEC Internal Regulations, the national standards organisations of the
following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Croatia,
Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland,
Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Republic of North
Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and the United
Kingdom.
Introduction
Maintenance Key Performance Indicators (KPI) of the Maintenance Function apply to all the physical
assets either industrial, infrastructures or civil buildings or transportation systems, etc.
These indicators should be used to:
a) measure the status;
b) compare (internal and external benchmarks);
c) diagnose (analysis of strengths and weaknesses);
d) identify objectives and define targets to be reached;
e) plan improvement actions;
f) regular measurement of changes over time.
Maintenance of software alone is not covered in this document. However, maintenance of items and
systems containing software is considered.
1 Scope
This document lists Key Performance Indicators (KPIs) of the Maintenance Function and gives guidelines
to define a set of suitable indicators, to appraise and to improve effectiveness, efficiency and
sustainability in the maintenance of the existing physical assets either industrial, infrastructures,
facilities, civil buildings or transportation systems, etc. in the framework of the external and internal
influencing factors.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
EN 13306:2017, Maintenance — Maintenance terminology
EN 15628:2014, Maintenance — Qualification of maintenance personnel
IEC 60050-192:2015, International Electrotechnical Vocabulary (IEV) — Part 192: Dependability
3 Terms and definitions
For the purposes of this document, the terms and definitions given in EN 13306:2017 and in
IEC 60050-192:2015, and the following apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— IEC Electropedia: available at https://www.electropedia.org/
— ISO Online browsing platform: available at https://www.iso.org/obp
3.1
asset
item that has potential or actual value for the organization
[SOURCE: EN 13306:2017, 3.2]
3.2
main area
fundamental part of a management discipline, which represents the more important knowledge and
competence to achieve and maintain an excellent status within existing influencing factors
3.3
indicator
quantitative or qualitative measure of a characteristic or a set of characteristics of a phenomenon or
performance of activities, according to defined criteria or a given formula or questionnaire
Note 1 to entry: The indicator is a tool for development and implementation of a strategy for monitoring progress
towards the goals outlined in the strategy.
3.4
item
part, component, device, subsystem, functional unit, equipment that can be individually described and
considered
[SOURCE: EN 13306:2017, 3.1]
3.5
key performance indicator
KPI
indicator considered significant
3.6
time
generally used to describe time units related to the physical assets-equipment and its performance
3.7
man-hour
points the hours of labour spent in delivering maintenance activities
3.8
work order
document used by the maintenance function
Note 1 to entry: It specifies the deliverables, scope and cost of the approved work.
Note 2 to entry: It contains a pre-defined set of activities with specified materials, spare parts, tools and labour
required to complete the job.
4 Maintenance function
The Maintenance Function is operating in various industrial plants, facilities, infrastructures, acting in
different frameworks and contexts with different sizes, structures, objectives, specific constraints and
influencing factors (see 5.2 and 5.3).
In this context, it is suitable to define an organizational Model of Maintenance Function, as standard
reference to be implemented in relation with required objectives, available resources, and existing
constraints.
This Model of Maintenance Function is reported in Figure 1.
The Model considers that for the Maintenance function to achieve the assigned objectives and excellence,
it shall use an appropriate combination or parts of the various disciplines as HSE (Health Safety
Environment), Administration, ICT (Information and Communication Technology), etc.
It is Management task:
a) to implement the appropriate resources, knowledge, rules, procedures activities;
b) to select how the maintenance needs to build and organize the various matters and disciplines in the
following Sub Functions/Areas:
— HSE on Maintenance;
— Maintenance Management;
— Maintenance People Competence;
— Maintenance Engineering;
— Organization and Support for Maintenance;
— Administration and Supply.
The maintenance function maintains the physical assets so that it can perform the required functions and
consequently, the management shall act in a core framework that involves:
— The company
— The available resources
— The application of ICT and Enabling Technologies (e.g. Industry 4.0)
Acknowledging the fast development within maintenance, both from organizational and technological
point, this document provides an overview of the content of sub-functions, activities, and tools to be
considered when establishing activities and indicators to reach the targets.
It is suitable to use all the disciplines of Maintenance Function in the integrated framework to achieve the
objectives assigned to the Maintenance of the Physical Assets with th
...
