European foreword
This document (CEN/TR 14585-3:2017) has been prepared by Technical Committee
CEN/TC 342 “Metal hose, hose assemblies, bellows and expansion joints”, the secretariat of which is
held by SNV.
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CEN shall not be held responsible for identifying any or all such patent rights.
Introduction
Technical Committee CEN/TC 342 “Metal hose, hose assemblies, bellows and expansion joints” is
carrying out a revision of EN 14585-1:2006 and CEN/TR 14585-2:2006 to include calculation methods
for the combined structure of hose and braid for:
— pressure resistance;
— fatigue life;
— allowable displacements.
The selection of materials for corrosive environments and the calculation of fluid pressure drops are
also being included.
It is appreciated that these studies are ambitious and will involve much new analyses so that this
revision will take some time.
Whilst continuing to work on this revision, CEN/TC 342 decided that the key aspects of the calculation
method should be circulated as an informative Technical Report CEN/TR 14585-3, which is limited to
the pressure resistance of the combined structure of hose and braid. This approach will enable
manufacturers and Notified Bodies to use and gain experience of the calculation method and any
feedback can be taken into account in the revision of EN 14585, harmonized to the Pressure Equipment
Directive 2014/68/EU.
1 Scope
This Technical Report provides guidance on the design of corrugated metal hose assemblies for
pressure applications, i.e. maximum allowable pressure PS greater than 0,5 bar. Allowable stresses are
consistent with the requirements of the Pressure Equipment Directive 2014/68/EU.
2 Normative references
Not applicable.
3 Terms and definitions
For the purposes of this document, the terms and definitions given in EN ISO 7369 and the following
apply.
3.1
metal hose assembly
assembly of a corrugated metal hose with its end fittings
Note 1 to entry: In the context of Pressure Equipment Directive [1], a metal hose assembly is a component of
piping and not a PED assembly.
3.2
maximum allowable pressure PS
maximum pressure for which the metal hose assembly is designed
3.3
maximum/minimum allowable temperature TS
maximum and minimum temperature for which the metal hose assembly is designed
3.4
nominal pressure PN
dimensionless alphanumerical designation which is a convenient rounded number commonly used for
reference purposes of piping components and stock parts; for this Technical Report PN represents the
maximum allowable pressure at 20 °C as specified by the metal hose assembly manufacturer
3.5
test pressure PT
pressure at which the pressure metal hose assembly is pressure tested (normally at ambient
temperature)
3.6
main pressure bearing parts
parts, such as corrugated metal hose, braid, pipe ends, the failure of which may result in a sudden
discharge of pressure energy
3.7
pressure bearing parts
parts, such as swivel nuts, flanges, threaded fittings, that are not main pressure bearing parts defined in
3.6 and the failure of which may not lead to a sudden discharge of pressure energy
3.8
attachments to pressure parts
parts, such as ferrules, that are directly welded to parts defined in 3.6 or 3.7
3.9
other parts
parts, such as external protection, anti-kink device, braid protecting spiral, which are not parts
according to 3.6 to 3.8
3.10
equipment manufacturer
natural or legal person responsible for the values of the parameters PS and TS
Note 1 to entry: This may be the manufacturer or planner of the piping for which the metal hose assembly is
designed.
3.11
hose manufacturer
