EN 13024-1:2002

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Steklo v stavbah – Toplotno kaljeno borosilikatno varnostno steklo – 1. del: Definicija in opisGlas im Bauwesen - Thermisch vorgespanntes Borosilicat-Einscheiben-Sicherheitsglas - Teil 1: Definition und BeschreibungVerre dans la construction - Verre borosilicate de sécurité trempé thermiquement - Partie 1: Définition et descriptionGlass in building - Thermally toughened borosilicate safety glass - Part 1: Definition and description81.040.20Steklo v gradbeništvuGlass in building01.040.81Glass and ceramics industries (Vocabularies)ICS:Ta slovenski standard je istoveten z:EN 13024-1:2002SIST EN 13024-1:2004en01-september-2004SIST EN 13024-1:2004SLOVENSKI
STANDARD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 13024-1May 2002ICS 81.040.20English versionGlass in building - Thermally toughened borosilicate safety glass- Part 1: Definition and descriptionVerre dans la construction - Verre borosilicate de sécuritétrempé thermiquement - Partie 1: Définition et descriptionGlas im Bauwesen - Thermisch vorgespanntes Borosilicat-Einscheiben-Sicherheitsglas - Teil 1: Definition undBeschreibungThis European Standard was approved by CEN on 27 December 2001.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Management Centre has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Czech Republic, Denmark, Finland, France, Germany, Greece,Iceland, Ireland, Italy, Luxembourg, Malta, Netherlands, Norway, Portugal, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2002 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 13024-1:2002 ESIST EN 13024-1:2004

Determination of U value.23Annex B (informative)
Curved thermally toughened borosilicate safety glass.24SIST EN 13024-1:2004

Example of particle count.25SIST EN 13024-1:2004

When it should be used to offer protectionunder accidental human impact, thermally toughened borosilicate safety glass also should be classifiedaccording to prEN 12600.NOTE
CEN/TC129/WG8 is producing standards for the determination of the design strength of glass and ispreparing a design method.NOTE
CEN/TC129/WG2 is preparing a standard for production control and evaluation of conformity.1ScopeThis European Standard specifies tolerances, flatness, edgework, fragmentation and physical andmechanical characteristics of monolithic flat thermally toughened borosilicate safety glass for use inbuildings.Information on curved thermally toughened borosilicate safety glass is given in annex B, but thisproduct does not form part of this standard.Other requirements, not specified in this standard, can apply to thermally toughened borosilicate safetyglass which is incorporated into assemblies, e.g. laminated glass or insulating units, or undergo anadditional treatment, e.g. coating.
The additional requirements are specified in the appropriate productstandard.
Thermally toughened borosilicate safety glass, in this case, does not lose its mechanical orthermal characteristics.2Normative ReferencesThis European Standard incorporates by dated or undated reference, provisions from other publications.These normative references are cited at the appropriate places in the text, and the publications are listedhereafter. For dated references, subsequent amendments to or revisions of any of these publicationsapply to this European Standard only when incorporated in it by amendment or revision. For undatedreferences, the latest edition of the publication referred to applies (including amendments).EN 673, Glass in building – Determination of thermal transmittance (U value) – Calculation method.EN 1096-1, Glass in building – Coated glass – Part 1: Definitions and classification.EN 1748-1, Glass in building – Special Basic Products – Part 1: Borosilicate glasses.prEN 12600, Glass in building - Pendulum test - Impact test method for flat glass and performancerequirements.SIST EN 13024-1:2004

In the UK, this glass is also known as opaque thermally toughened borosilicate safety glass.3.4horizontal tougheningprocess in which the glass is supported on horizontal rollers3.5vertical tougheningprocess in which the glass is suspended by tongs4Glass productsThermally toughened borosilicate safety glass is made from a monolithic glass generally correspondingto one of the following standards:- borosilicate glass according to EN 1748-1- coated glass according to EN 1096-1Other nominal thicknesses of glass than those covered in the above standards are possible.5Fracture characteristicsIn the event of breakage, thermally toughened borosilicate safety glass fractures into numerous smallpieces, the edges of which are generally blunt.NOTE
Fragmentation in service does not always correspond to that described in clause 8, due to restraint fromfixing or reprocessing (e.g. laminating), or due to the cause of fracture.SIST EN 13024-1:2004

The measurement shall be takenat the centres of the 4 sides, and away from the area of any tong marks (see Figure 3), which may bepresent.NOTE:Table 1a corresponds to EN 1748-1. Table 1b diverges from this standard. Meanwhile it is possibleto produce borosilicate float glass in the same thicknesses and tolerances as soda lime silicate floatglass. This fact is taken into account in this standard. EN 1748-1 will be revised.6.2Width and length (sizes)6.2.1GeneralWhen thermally toughened borosilicate safety glass dimensions are quoted for rectangular panes, thefirst dimension shall be the width, B, and the second dimension the length, H, as shown in Figure 1. Itshall be made clear which dimension is the width, B, and which is the length, H, when related to itsinstalled position.Figure 1 - Examples of width, B, and length, H, relative to the pane shape6.2.2Maximum and minimum sizesFor maximum and minimum sizes, the manufacturer should be consulted.6.2.3Tolerances and squarenessThe nominal dimensions for width and length being given, the finished pane shall not be larger than aprescribed rectangle resulting from the nominal dimensions increased by the tolerance, t, or smaller thana prescribed rectangle reduced by the tolerance, t.
The sides of the prescribed rectangles are parallel toHHBBSIST EN 13024-1:2004

The limits of squarenessare also the prescribed rectangles.
Tolerances are given in Table 2.B+tB-tH+tH-tFigure 2 - Tolerance limits for dimensions of rectangular panesTable 2 - Tolerances on width, B, and length, HDimensions in millimetresNominal dimensionof side, B or HTolerance, t£ 2 000±
...
