Resistance welding - Procedures for determining the weldability lobe for resistance spot, projection and seam welding (ISO 14327:2004)

ISO 14327:2004 specifies procedures for determining the weldability lobe for producing quality welds. The tests are used in particular to determine the weldability lobe for coated/uncoated steels, stainless steels and aluminium and its alloys but may also be used for other metallic materials.
The aim of this procedure is to allow determination of the range of welding parameters which give rise to an acceptable weld quality as defined within precise limits. The procedure can be used to determine:
The influence of electrode material, electrode shape and dimensions on the available welding range for a particular material and welding machine.The influence of material type and thickness on the available welding range when using a particular combination of welding electrodes and welding machine.The influence of welding machine type, or electrode cooling on the available welding range for a particular material using a particular electrode shape.The available welding range in a production situation.

Widerstandsschweißen - Verfahren für das Bestimmen des Schweißbereichsdiagramms für das Widerstandspunkt-, Buckel- und Rollennahtschweißen (ISO 14327:2004)

Soudage par résistance - Modes opératoires pour la détermination du domaine de soudabilité pour le soudage par résistance par points, par bossages et à la molette (ISO 14327:2004)

L'ISO 14327:2004 spécifie les modes opératoires pour la détermination du domaine de soudabilité en vue d'obtenir des soudures de qualité. Les essais sont utilisés en particulier pour déterminer le domaine de soudabilité pour les aciers revêtus ou non revêtus, les aciers inoxydables, l'aluminium et ses alliages mais peuvent être également utilisés pour d'autres matériaux métalliques.
L'objet de ce mode opératoire est de déterminer la plage des paramètres de soudage qui permettent d'obtenir une qualité de soudure acceptable telle que définie dans des limites précises. Ce mode opératoire peut être utilisé pour déterminer:
l'influence du matériau constituant l'électrode, de la forme et des dimensions de l'électrode sur la gamme des réglages disponibles pour un matériau et une machine de soudage donnés;l'influence du type et de l'épaisseur du matériau sur la gamme des réglages disponibles pour une combinaison donnée d'électrodes et de machine de soudage;l'influence du type de machine de soudage ou du refroidissement de l'électrode sur la gamme des réglages disponibles pour un matériau donné, en utilisant une forme d'électrode donnée;la gamme des réglages disponibles dans des conditions de production.
