EN 16296:2012
(Main)Imperfections in thermoplastics welded joints - Quality levels
Imperfections in thermoplastics welded joints - Quality levels
This European Standard provides quality levels for imperfections in thermoplastics welded joints. It applies to material thickness above 2,0 mm.
Three quality levels are given in order to permit application for a wide range of welded fabrication. They are designated by symbols B, C and D, where B is the most stringent. The quality levels refer to production quality and not to the fitness-for-purpose (see 3.2) of the manufactured product.
This European Standard applies to the following thermoplastic materials:
Table 1
Abbreviation Material description
ABS Acrylonitrile-butadiene-styrene plastic
ECTFE Ethylene-chlorotrifluoroethylene copolymer
FEP Fluorinated ethylene propylene
PB Polybutylene
PE Polyethylene
PFA Perfluoroalkoxy
PP-B Polypropylene block copolymer
PP-H Polypropylene homopolymer
PP-R Polypropylene random copolymer
PVC-C Chlorinated polyvinyl chloride
PVC-U Unplasticised polyvinyl chloride (rigid PVC)
PVDF Polyvinylidene fluoride
and to the following welding processes:
- Heated tool welding;
- Electrofusion welding;
- Hot gas welding using filler rod only;
- Extrusion welding;
- Solvent welding of pipes.
Unregelmäßigkeiten an Schweißverbindungen von thermoplastischen Kunststoffen - Qualitätsstufen
Diese Europäische Norm legt Qualitätsstufen für Unregelmäßigkeiten an Schweißverbindungen von thermoplastischen Kunststoffen fest. Sie gilt für Materialdicken über 2,0 mm.
Um eine Anwendung an eine große Auswahl von Schweißerzeugnissen zu ermöglichen, sind drei Qualitäts-stufen festgelegt. Diese sind durch Symbole B, C und D gekennzeichnet, wobei B die höchste Qualitätsstufe ist. Die Qualitätsstufen beziehen sich auf die Fertigungsqualität und nicht auf die Gebrauchstauglichkeit (siehe 3.2) des hergestellten Produkts.
Diese Europäische Norm gilt für folgende thermoplastische Materialien:
und folgende Schweißverfahren:
Heizelementschweißen;
Heizwendelschweißen;
Warmgasschweißen, ausschließlich unter Anwendung von Schweißstab;
Extrusionsschweißen;
Quellschweißen von Rohren.
Défauts dans les assemblages soudés en thermoplastiques - Niveaux de qualité
La présente Norme européenne propose des niveaux de qualité pour évaluer les défauts des assemblages soudés en thermoplastiques. Elle s'applique aux matériaux présentant une épaisseur supérieure à 2,0 mm.
La présente Norme propose trois niveaux de qualité, afin de permettre son application à un vaste éventail d'assemblages soudés. Ils sont désignés par les symboles B, C et D, B étant le niveau le plus contraignant. Les niveaux de qualité s'appliquent à la qualité de la production et non pas à l'aptitude à l'emploi (voir 3.2) du produit fabriqué.
La présente Norme européenne s'applique aux matériaux thermoplastiques suivants :
et aux procédés de soudage suivants :
Soudage par outil chauffant ;
Électrosoudage ;
Soudage au gaz chaud avec baguette d’apport uniquement ;
Soudage par extrusion ;
Collage au solvant de tubes.
Nepravilnosti v zvarjenih spojih plastomerov - Stopnje kakovosti
Ta evropski standard opisuje stopnje kakovosti nepravilnosti v zvarjenih spojih plastomerov. Velja za debelino materiala nad 2,0 mm. Za uporabo širokega nabora varjenih izdelkov so določene tri stopnje kakovosti. Označene so s simboli B, C in D, pri čemer je B najstrožji. Stopnje kakovosti se nanašajo na kakovost izdelave in ne na primernost za namen proizvedenega izdelka. Ta evropski standard velja za naslednje plastomere in postopke varjenja: – varjenje z vročim zrakom; – elektrofuzijsko varjenje; – varjenje z vročimi ploščami z uporabo varilnih elektrod; – ekstrudersko varjenje; – varjenje cevi s topilom.
General Information
Relations
Standards Content (Sample)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Nepravilnosti v zvarjenih spojih plastomerov - Stopnje kakovostiUnregelmäßigkeiten an Schweißverbindungen von thermoplastischen Kunststoffen - QualitätsstufenDéfauts dans les assemblages soudés en thermoplastiques - Niveaux de qualitéImperfections in thermoplastics welded joints - Quality levels83.080.20PlastomeriThermoplastic materials25.160.40Varjeni spoji in variWelded jointsICS:Ta slovenski standard je istoveten z:EN 16296:2012SIST EN 16296:2014en,fr,de01-maj-2014SIST EN 16296:2014SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 16296
October 2012 ICS 25.160.40 English Version
Imperfections in thermoplastics welded joints - Quality levels
Défauts dans les assemblages soudés en thermoplastiques - Niveaux de qualité
Unregelmäßigkeiten an Schweißverbindungen von thermoplastischen Kunststoffen - Qualitätsstufen This European Standard was approved by CEN on 22 September 2012.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2012 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 16296:2012: ESIST EN 16296:2014
The quality levels given in this standard are intended to provide basic reference data and are not specifically related to any particular application. They refer to the types of welded joints in a fabrication and not to the complete product or component itself. It is possible, therefore, that different quality levels are applied to individual welded joints in the same product or component. The choice of quality level for any application should take account of design considerations, subsequent processing, mode of stressing (e.g. static, dynamic), service conditions (e.g. pressure, temperature, environment) and consequences of failure. Economic factors are also important and should include not only the cost of welding but also of inspection, test and repair. Although this European Standard includes types of imperfections relevant to the processes given in Clause 1, only those which are applicable to the process and application in question need to be considered. Imperfections are quoted in terms of their actual dimensions. However their detection and evaluation may require the use of one or more methods of non-destructive testing. It should be noted that the detection and sizing of imperfections is dependent on the inspection methods and the extent of testing specified in the application standard or contract. The need for detection is not the subject of this standard. This European Standard is directly applicable to visual examination of welds or test specimens. It does not include details of recommended methods of detection and sizing. The indication provided by non-destructive testing should not be used directly for the evaluation of quality levels. Therefore, it needs to be supplemented by requirements for examinations, inspection and testing.
PFA Perfluoroalkoxy PP-B Polypropylene block copolymer PP-H Polypropylene homopolymer PP-R Polypropylene random copolymer PVC-C Chlorinated polyvinyl chloride PVC-U Unplasticised polyvinyl chloride (rigid PVC) PVDF Polyvinylidene fluoride
and to the following welding processes: Heated tool welding; Electrofusion welding; Hot gas welding using filler rod only; Extrusion welding; SIST EN 16296:2014
Symbol
Requirement B Stringent C Intermediate D Moderate
The purpose of this standard is to define quality levels based on typical imperfections, which might occur in normal fabrications and are classified in EN 14728. It may be used within a quality system for the production of factory welded joints. It provides three sets of dimensional values from which a selection can be made for a particular application. The quality level necessary in each case should be defined by the application standard or the fabricator in conjunction with the user and/or other parties concerned. The level should be prescribed before the start of production, preferably at the enquiry or order stage. For specific applications, additional requirements not covered by this standard may need to be prescribed. These additional requirements shall be defined as quality level A. SIST EN 16296:2014
diameter ≤ 5 % of wall thickness Permissible if diameter of largest cavity ≤ 10 % of wall thickness Permissible if diameter of largest cavity ≤ 15 % of wall thickness 2DAAA Craze Not permissible Not permissible Not permissible 3AAAA Inclusion
Isolated inclusion permissible if maximum dimension ≤ 5 % of wall thickness Isolated and rows of inclusions permissible if maximum dimension ≤ 10 % of wall thickness Isolated and rows of inclusions permissible if maximum dimension ≤ 15 % of wall thickness 3KAAA Degraded polymer Not permissible Not permissible Not permissible 4BAAA Lack of fusion Not permissible Not permissible
Not permissible 5AAAA Imperfect shape Mechanical testing of sample welds is recommended Mechanical testing of sample welds is recommended Mechanical testing of sample welds is recommended 5EJAA Linear misalignment Permissible if misalignment is not greater than 10 % of the wall thickness Permissible if misalignment is not greater than 15 % of the wall thickness Permissible if misalignment is not greater than 20 % of the wall thickness 5EKAA Angular misalignment Permissible if misalignment is not greater than 0,2°
Permissible if misalignment is not greater than 0,4° Permissible if misalignment is not greater than 0,8° 5HAAA Irregular surface Not permissible Not permissible
Not permissible
6EAAA Excessive upset Not permissible Not permissible Not permissible 6HAAA 6HAAC Excessive asymmetry of welds Permissible if smaller half of weld bead is not less than 70 % of Permissible if smaller half of weld bead is not less than 60 % of Permissible if smaller half of weld bead is not less than 50 % of SIST EN 16296:2014
...
Frequently Asked Questions
EN 16296:2012 is a standard published by the European Committee for Standardization (CEN). Its full title is "Imperfections in thermoplastics welded joints - Quality levels". This standard covers: This European Standard provides quality levels for imperfections in thermoplastics welded joints. It applies to material thickness above 2,0 mm. Three quality levels are given in order to permit application for a wide range of welded fabrication. They are designated by symbols B, C and D, where B is the most stringent. The quality levels refer to production quality and not to the fitness-for-purpose (see 3.2) of the manufactured product. This European Standard applies to the following thermoplastic materials: Table 1 Abbreviation Material description ABS Acrylonitrile-butadiene-styrene plastic ECTFE Ethylene-chlorotrifluoroethylene copolymer FEP Fluorinated ethylene propylene PB Polybutylene PE Polyethylene PFA Perfluoroalkoxy PP-B Polypropylene block copolymer PP-H Polypropylene homopolymer PP-R Polypropylene random copolymer PVC-C Chlorinated polyvinyl chloride PVC-U Unplasticised polyvinyl chloride (rigid PVC) PVDF Polyvinylidene fluoride and to the following welding processes: - Heated tool welding; - Electrofusion welding; - Hot gas welding using filler rod only; - Extrusion welding; - Solvent welding of pipes.
This European Standard provides quality levels for imperfections in thermoplastics welded joints. It applies to material thickness above 2,0 mm. Three quality levels are given in order to permit application for a wide range of welded fabrication. They are designated by symbols B, C and D, where B is the most stringent. The quality levels refer to production quality and not to the fitness-for-purpose (see 3.2) of the manufactured product. This European Standard applies to the following thermoplastic materials: Table 1 Abbreviation Material description ABS Acrylonitrile-butadiene-styrene plastic ECTFE Ethylene-chlorotrifluoroethylene copolymer FEP Fluorinated ethylene propylene PB Polybutylene PE Polyethylene PFA Perfluoroalkoxy PP-B Polypropylene block copolymer PP-H Polypropylene homopolymer PP-R Polypropylene random copolymer PVC-C Chlorinated polyvinyl chloride PVC-U Unplasticised polyvinyl chloride (rigid PVC) PVDF Polyvinylidene fluoride and to the following welding processes: - Heated tool welding; - Electrofusion welding; - Hot gas welding using filler rod only; - Extrusion welding; - Solvent welding of pipes.
EN 16296:2012 is classified under the following ICS (International Classification for Standards) categories: 25.160.40 - Welded joints and welds. The ICS classification helps identify the subject area and facilitates finding related standards.
EN 16296:2012 has the following relationships with other standards: It is inter standard links to EN 16296:2021. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
You can purchase EN 16296:2012 directly from iTeh Standards. The document is available in PDF format and is delivered instantly after payment. Add the standard to your cart and complete the secure checkout process. iTeh Standards is an authorized distributor of CEN standards.
EN 16296:2012は、熱可塑性溶接接合部における欠陥の品質レベルを定めたEU規格であり、その適用範囲は非常に広い。この標準は、最小厚さが2.0mmを超える熱可塑性材料に適用され、ABS、PE、PVC-Uなど複数の材料に関する具体的な指針を提供している。特に、標準は3つの品質レベルを示し、B、C、Dという厳密な評価基準により、さまざまな溶接製品に対する適応性を確保している。Bは最も厳格な品質基準であり、製造の品質に対する明確な基準を提供し、エンジニアリング及び生産現場での信頼性が高まる。 この標準が持つ強みの一つは、熱可塑性材料に特化していることだ。そのため、異なる材料や使用条件に応じた品質評価が可能で、業界全体での一貫性を促進する。また、さまざまな溶接プロセスにも適用可能で、加熱工具溶接やエレクトロフュージョン溶接を含む多様な技術に対応している。この柔軟性は、作業環境や材料特性に応じた適切な品質管理を実現する上で非常に重要である。 さらに、EN 16296:2012は、製造物の用途に対する適合性（フィットネス・フォー・パーパス）を別途規定せず、品質管理に特化している点が特徴である。このアプローチにより、製造業者は製品の信頼性を評価しやすく、顧客も求める基準に基づいた製品を容易に選択できるようになっている。 これらの点を考慮すると、EN 16296:2012は熱可塑性溶接接合部の品質管理における不可欠な基準であり、今後の製造においてますます重要な役割を果たすことが期待される。
Die EN 16296:2012 ist ein bedeutendes europäisches Dokument, das sich mit der Qualität von Unregelmäßigkeiten in geschweißten Verbindungen von Thermoplasten beschäftigt. Der Anwendungsbereich dieser Norm umfasst Materialien mit einer Dicke von über 2,0 mm und definiert drei Qualitätsstufen, die durch die Symbole B, C und D gekennzeichnet sind. Diese Stufen ermöglichen eine breite Anwendung im Bereich der geschweißten Fabrikation, wobei B die strengste Qualitätsstufe darstellt. Ein herausragendes Merkmal der EN 16296:2012 ist die klare Differenzierung zwischen Produktionsqualität und der Eignung für den jeweiligen Verwendungszweck. Diese Unterscheidung ist entscheidend, da sie sicherstellt, dass die Qualität der Schweißnähte den Anforderungen der jeweiligen Anwendung entspricht, ohne die Verwendbarkeit des Endprodukts in Frage zu stellen. Diese Qualitätslevels bieten den Herstellern die Flexibilität, je nach spezifischen Anforderungen und Einsatzgebieten zu wählen, was die Norm besonders relevant macht. Darüber hinaus listet die Norm eine Vielzahl von verwendbaren Thermoplasten, darunter ABS, ECTFE, FEP, PB, PE, PFA, PP-B, PP-H, PP-R, PVC-C, PVC-U und PVDF. Diese umfassende Materialabdeckung zeigt die Vielseitigkeit der Norm und ermöglicht konkrete Anwendung für unterschiedliche Sektoranforderungen. Des Weiteren behandelt die Norm die Anwendung verschiedener Schweißprozesse, einschließlich Heißwerkzeugschweißen, Elektrofusionsschweißen, Heißgasschweißen unter Verwendung eines Füllstifts, Extrusionsschweißen und das Lösemittelverkleben von Rohren. Diese umfangreiche Betrachtung der Schweißtechniken überträgt die Relevanz der Norm auf unterschiedliche industrielle Anwendungen. Insgesamt ist die EN 16296:2012 eine essenzielle Norm, die die Qualität von geschweißten Thermoplastverbindungen regelt und somit einen wertvollen Beitrag zur Verbesserung der Produktsicherheit und -zuverlässigkeit in der Industrie leistet.
La norme EN 16296:2012, intitulée "Imperfections in thermoplastics welded joints - Quality levels", est un document essentiel dans le domaine de la production et de la fabrication de joints soudés en thermoplastiques. Son champ d'application couvre des matériaux d'une épaisseur supérieure à 2,0 mm, ce qui la rend particulièrement pertinente pour des secteurs industrialisés nécessitant des exigences élevées en matière de qualité. L'un des principaux atouts de cette norme réside dans la définition de trois niveaux de qualité pour les imperfections des joints soudés, identifiés par les symboles B, C et D. Ce système hiérarchique permet une large gamme d'applications pour les fabrications soudées. Le niveau B, étant le plus strict, garantit une production conforme aux normes les plus exigeantes, assurant ainsi une durabilité et une performance accrues des produits fabriqués. La norme s'applique à une variété de matériaux thermoplastiques, tels que l’ABS, l'ECTFE, le FEP, le PB, le PE, le PFA, le PP-B, le PP-H, le PP-R, le PVC-C, le PVC-U, et le PVDF. Cette diversifié de matériaux offre une flexibilité dans leur utilisation, pouvant répondre à des besoins spécifiques selon les processus de soudage. En intégrant des procédés tels que le soudage à l'outil chauffé, le soudage par électrofusion, et le soudage à gaz chaud, la norme garantit que les fabricants peuvent choisir la méthode la plus appropriée en fonction de la nature de leur projet. L'importance de cette norme réside également dans le fait qu'elle se concentre sur la qualité de production et non sur la conformité à l'usage de l'objet fabriqué, ce qui permet aux utilisateurs de mieux maîtriser les résultats finaux. En garantissant des niveaux clairs pour les imperfections, EN 16296:2012 aide à minimiser les risques et à améliorer la confiance dans les joints soudés en thermoplastiques. En résumé, la norme EN 16296:2012 constitue un instrument incontournable pour les fabricants travaillant avec des matériaux thermoplastiques, leur permettant d'assurer des normes de qualité élevées tout en s'adaptant à un large éventail d'applications et de procédés de soudage.
The EN 16296:2012 standard provides a comprehensive framework for assessing the quality of imperfections in thermoplastics welded joints, specifically targeting materials with a thickness greater than 2.0 mm. This European Standard is pivotal in establishing uniformity in quality evaluation across various applications of welded fabrication, making it easier for organizations within the industry to adhere to consistent quality criteria. One of the strengths of this standard is its categorization of quality levels into three distinct symbols: B, C, and D. By defining B as the most stringent, the standard allows for a clear understanding of the permissible quality levels for different applications. This structured approach facilitates the identification of acceptable imperfections while ensuring that production quality is front and center, without overriding the fitness-for-purpose requirements. Consequently, manufacturers can select the appropriate quality level based on their specific operational needs and requirements. Additionally, EN 16296:2012 encompasses a wide range of thermoplastic materials including, but not limited to, ABS, PE, PVC-U, and PVDF. This extensive scope enhances its relevance across various sectors, providing guidelines applicable to multiple welding processes such as heated tool welding and electrofusion welding. This versatility ensures that the standard can cater to diverse production techniques and materials, promoting wider adoption and compliance. Overall, the EN 16296:2012 standard stands out for its methodical approach to quality assessment in thermoplastic welded joints. By providing clear quality levels and encompassing a broad spectrum of materials and welding processes, it offers significant value to manufacturers seeking to maintain high-quality standards in their welded products.
EN 16296:2012 표준은 열가소성 용접 이음부의 불완전성에 대한 품질 수준을 규정합니다. 이 표준의 적용 범위는 2.0 mm 이상의 재료 두께에 해당하며, 이는 다양한 용접 제작에서의 적용을 가능하게 합니다. 품질 수준은 세 가지 등급(B, C, D)으로 구분되며, 가장 엄격한 기준을 따르는 B등급부터 상대적으로 완화된 C 및 D등급까지 포함됩니다. 이 품질 수준은 생산 품질을 기반으로 하며, 최종 제품의 목적 적합성과는 직접적으로 연결되지 않음을 명확히 하고 있습니다. 표준은 아크릴로니트릴-부타디엔-스티렌(ABS), 에틸렌-클로로트리플루오르에틸렌(ECTFE), 플루오르화 에틸렌 프로필렌(FEP), 폴리부틸렌(PB), 폴리에틸렌(PE), 페르플루오로알콕시(PFA), 폴리프로필렌 블록 공중합체(PP-B), 폴리프로필렌 동종 중합체(PP-H), 폴리프로필렌 랜덤 공중합체(PP-R), 클로로화 폴리염화비닐(PVC-C), 비가소화 폴리염화비닐(PVC-U), 폴리비닐리덴 플루오르(PVDF)와 같은 여러 열가소성 재료에 적용됩니다. 또한, 이 표준은 가열 도구 용접, 전기융합 용접, 필러봉만을 사용하는 열가스 용접, 압출 용접, 파이프의 용제 용접과 같이 다양한 용접 공정에 대해서도 유효성을 갖습니다. 이는 산업 전반에 걸쳐 필수적인 지침을 제공하여, 품질 관리의 일관성을 보장하고, 다양한 응용 분야에서의 열가소성 용접 품질 향상에 기여하게 됩니다. 결론적으로, EN 16296:2012 표준은 열가소성 용접의 품질 수준을 효과적으로 정의하며, 다양한 재료와 공정에 대한 지침을 제공하여, 산업계에서의 미비점을 줄이고 품질 개선에 중요한 역할을 합니다.
