EN 13230-1:2009

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Železniške naprave - Zgornji ustroj - Betonski pragi in kretniški betonski pragi - 1. del: Splošne zahteveBahnanwendungen - Oberbau - Gleis- und Weichenschwellen aus Beton - Teil 1: Allgemeine AnforderungenApplications ferroviaires - Voie - Traverses et supports en béton - Partie 1 : Prescriptions généralesRailway applications - Track - Concrete sleepers and bearers - Part 1: General requirements91.100.30Beton in betonski izdelkiConcrete and concrete products45.080Rails and railway componentsICS:Ta slovenski standard je istoveten z:EN 13230-1:2009SIST EN 13230-1:2009en,de01-september-2009SIST EN 13230-1:2009SLOVENSKI
STANDARDSIST EN 13230-1:2004/AC:2006SIST EN 13230-1:20041DGRPHãþD

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 13230-1June 2009ICS 91.100.30; 93.100Supersedes EN 13230-1:2002
English VersionRailway applications - Track - Concrete sleepers and bearers -Part 1: General requirementsApplications ferroviaires - Voie - Traverses et supports enbéton - Partie 1 : Prescriptions généralesBahnanwendungen - Oberbau - Gleis- undWeichenschwellen aus Beton - Teil 1: AllgemeineAnforderungenThis European Standard was approved by CEN on 13 May 2009.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre:
Avenue Marnix 17,
B-1000 Brussels© 2009 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 13230-1:2009: ESIST EN 13230-1:2009

Test method to determine the Taber Wear index for a fine aggregate . 24A.1General . 24A.2Apparatus . 24A.3Preparation of Mortar Tiles . 24A.3.1Sampling. 24A.3.2Mortar Tile preparation . 24A.3.3Mortar Tile curing . 25A.3.4Grinding of Mortar Tiles . 25A.4Test procedure . 25A.5Calculation of Taber Wear Index . 25Annex B (informative)
Test method for freeze-thaw resistance . 26Annex C (informative)
Test method for measuring the water absorption of concrete at atmospheric pressure . 27C.1Introduction . 27C.2Samples . 27C.3Sequence of test . 27C.4Requirements . 28Annex D (informative)
Definition and recommendation for measurement of rail seat inclination and twist between rail seats . 29Annex E (informative)
Bending moment calculation . 30Annex F (informative)
Surface finish . 31F.1General . 31F.2General information for surface finish . 31F.3Surface finish of the rail seat . 31F.4Surface finish of all other surfaces . 32F.5Detailed procedure for remedial work . 32Annex G (informative)
Quality control during manufacturing – Routine tests and frequency of testing . 33G.1General . 33G.2Data of the sleeper to be checked . 33G.3Examples for frequency of testing . 34Annex ZA (informative)
Relationship between this European Standard and the Essential Requirements of EU Directive 2008/57/EC . 35Bibliography . 39 SIST EN 13230-1:2009

Key 1 Gauge points Figure 1 — Typical prestressed monoblock sleeper
Key 1 Gauge points Figure 2 — Typical twin-block reinforced sleeper SIST EN 13230-1:2009

Figure 3 — Typical prestressed concrete bearer The basic values of the different dimensions shall be determined by the purchaser. The maximum tolerances specified in Table 1 apply to ballasted track and can be varied by the purchaser in the case of special requirements such as dedicated concrete elements for ballastless track or use of a sleeper laying machine, etc. Table 1 — Maximum tolerances Dimensions Description Tolerances L Overall length of the concrete element ± 10 mm b1, b2 Top and bottom width of the concrete element ± 5 mm hr Depth at any position along the total length of the reinforced concrete element measured in accordance with the quality plan −+310 mm hp Depth at any position along the total length of the prestressed concrete element measured in accordance with the quality plan −+35 mm L1 Distance between the rail fastening gauge points −+12 mm L2 Position of the rail fastening gauge point with regard to the end of the concrete element ± 8 mm L3 Total length of reinforced concrete block ± 8 mm i Inclination of the rail seat (see Annex D) ± 0,25° f Planeness of each rail seat area: with regard to 2 points 150 mm apart (monoblock and twin-block sleepers only) 1 mm T Relative twist between rail seats for monoblock sleepers (see Annex D) 0,5° SIST EN 13230-1:2009

The design, dimensions and tolerances of the fastening system shall be defined by the purchaser. The purchaser shall specify the minimum clearances between rail fastening component and reinforcement according to the fastening system to be used, and between reinforcement and connecting bar for twin-block sleepers. 6.1.2 Concrete cover Unless there is an alternative agreement by the purchaser, the minimum concrete cover for prestressing tendons shall be 30 mm from the bottom surface and 20 mm from the other surfaces except at the ends of sleepers and bearers. The minimum concrete cover for reinforcing steels shall be 25 mm from the bottom surface and 15 mm for the rail seat area and 20 mm from the other surfaces, except for the end of spacing bars. 6.1.3 Prestressing system design The supplier shall define all data in relation with the nominal prestressing force, nominal position of each tendon, anchorage system. The position of the centroid of the prestressing shall be within ± 3 mm of the nominal position relative to the rail seat. The individual prestressing tendons shall be within ± 6 mm of the nominal position relative to the rail seat. The total prestressing force shall be applied within ± 5 % of the specified nominal force. 6.1.4 Reinforcing steel design The supplier shall define all data in relation with the design of the reinforcing steel and nominal position in the concrete element. Tolerance for the position of the reinforcing steel shall be within ± 5 mm of the nominal position in all directions. 6.2 Manufacturing process 6.2.1 General requirements Details of production plant and equipment are the responsibility of the supplier. The supplier shall supply to the purchaser a description of the manufacturing process. SIST EN 13230-1:2009

Key 1
Concrete temperature (°C) 2
Time a
Start temperature ≤ 30 °C b
Max. temperature: see Figure 5 0 - c
Waiting time = 2 hours or preset time of concrete whichever is greater c - d
Increase period : max 15 °C/hour and 10 °C/half-hour, in any hour Figure 4 — Maximum temperature curve
Key 1 Concrete temperature (°C) 2 Sulphur trioxide (content of the cement % by mass) Figure 5 — Maximum curing temperature as a function of sulphur trioxide content in the cement SIST EN 13230-1:2009
...
