Pipework - Corrugated flexible metallic hose assemblies for the protection of electrical cables in explosive atmosphere (ISO 10807:1994)

Specifies the design characteristics of corrugated flexible metallic hose which can be used to protect electrical wire and cable in explosive atmospheres or atmospheres where there is a risk of fire. These hoses can be used as static protection or for the protection of cables moved infrequently, occasionally, or less than once week. Also provides instructions for the use of these hoses and the tests required for type approval.

Rohrleitungen - Flexible gewellte metallische Schlauchleitungen für den Schutz elektrischer Leitungen in explosionsgefährdeter Atmosphäre (ISO 10807:1994)

Diese internationale Norm gilt für flexible gewellte Metallschläuche, die als Schutz für elektrische Leitungen in explosionsgefährdeten oder feuergefährlichen Atmosphären eingesetzt werden können. Diese Schläuche können als statischer Schutz verwendet werden oder als Schutz für gelegentlich oder weniger als einmal wöchentlich bewegte Leitungen. Diese Internationale Norm gibt Anleitungen für den Gebrauch dieser Schläuche (siehe Anhang A) und die für eine Typ-Zulassung erforderlichen Prüfungen (siehe Anhang B).

Tuyauteries - Tuyauteries métalliques flexibles onduleuses destinées à la protection de câbles électriques dans les atmosphères explosives (ISO 10807:1994)

La présente Norme internationale prescrit les caractéristiques de conception des tuyauteries métalliques flexibles onduleuses pouvant être utilisées comme protection des fils et des câbles électriques dans les atmosphères explosives ou avec risque d'incendie. Ces tuyauteries peuvent être employées comme protection statique ou comme protection des câbles en mouvements peu fréquents, occasionnellement, moins d'une fois par semaine. La présente Norme internationale fournit également des instructions utiles pour l'utilisation de ces tuyauteries (voir annexe A) et prescrit les essais requis pour leur homologation (voir annexe B).

Cevovodi - Valovita sestavljena gibljiva kovinska cev za zaščito električnih vodnikov v eksplozivni atmosferi (ISO 10807:1994)

General Information

Status
Published
Publication Date
19-Nov-1996
Current Stage
9093 - Decision to confirm - Review Enquiry
Start Date
05-Mar-2008
Completion Date
05-Mar-2008

Buy Standard

Standard
EN ISO 10807:2001
English language
12 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.HOHNWULþQLKRohrleitungen - Flexible gewellte metallische Schlauchleitungen für den Schutz elektrischer Leitungen in explosionsgefährdeter Atmosphäre (ISO 10807:1994)Tuyauteries - Tuyauteries métalliques flexibles onduleuses destinées a la protection de câbles électriques dans les atmospheres explosives (ISO 10807:1994)Pipework - Corrugated flexible metallic hose assemblies for the protection of electrical cables in explosive atmosphere (ISO 10807:1994)29.260.20Electrical apparatus for explosive atmospheresICS:Ta slovenski standard je istoveten z:EN ISO 10807:1996SIST EN ISO 10807:2001en01-november-2001SIST EN ISO 10807:2001SLOVENSKI
STANDARD



SIST EN ISO 10807:2001



SIST EN ISO 10807:2001



SIST EN ISO 10807:2001



SIST EN ISO 10807:2001



SIST EN ISO 10807:2001



INTERNATIONAL STANDARD ISO 10807 First edition 1994-08-15 Pipework - Corrugated flexible metallic hose assemblies for the protection of electrical cables in explosive atmospheres Tuyauteries - Tuyauteries m&alliques flexibles onduleuses destinees 4 Ia protection de cables 6lectriques dans /es atmospheres explosives Reference number ISO 10807: 1994(E) SIST EN ISO 10807:2001



ISO 10807:1994(E) Foreword ISO (the International Organization for Standardization) is a worldwide federation of national Standards bodies (ISO member bodies). The work of preparing International Standards is normally carried out through ISO technical committees. Esch member body interested in a subject for which a technical committee has been established has the right to be represented on that committee. International organizations, governmental and non-governmental, in liaison with ISO, also take part in the work. ISO collaborates closely with the International Electrotechnical Commission (1 EC) on all matters of electrotechnical standardization. Draft International Standards adopted by the technical committees are circulated to the member bodies for voting. Publication as an International Standard requires approval by at least 75 % of the member bodies casting a vote. International Standard ISO 10807 was prepared by Technical Committee lSO/TC 5, Ferrous metal pipes and metalic fittings, Subcommittee SC 11, Flexible interlocked and convoluted metallic hoses. Annexes A and B form an integral part of this International Standard. An- nex C is for information only. 0 ISO 1994 All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by any means, electronie or mechanical, including photocopying and microfilm, without Permission in writing from the publisher. International Organization for Standardization Case Postale 56 l CH-l 211 Geneve 20 l Switzerland Printed in Switzerland ii SIST EN ISO 10807:2001



INTERNATIONAL STANDARD 0 ISO ISO 10807:1994(E) Pipework - Corrugated flexible metallic hose assemblies for the protection of electrical cables in explosive atmospheres 1 Scope This International Standard specifies the design char- acteristics of corrugated flexible metallic hose which tan be used to protect electrical wire and cable in explosive atmospheres or atmospheres where there is a risk of fire. These hoses tan be used as static protection or for the protection of cables moved in- frequently, occasionally, or less than once week. This International Standard also provides instructions for the use of these hoses (see annex A) and the tests required for type approval (see annex B). 2 Normative references The following Standards contain provisions which, through reference in this text, constitute provisions of this International Standard. At the time of publi- cation, the editions indicated were valid. All Standards are subject to revision, and Parties to agreements based on this International Standard are encouraged to investigate the possibility of applying the most re- cent editions of the Standards indicated below. Members of IEC and ISO maintain registers of cur- rently valid International Standards. ISO 7-l : 1994, Pipe threads where pressure-tight joints are made on the threads - Part 1: Dimensions, tolerantes and designa tion. ISO 427: 1983, Wrought topper-tin alloys - Chemical composition and forms of wrought products. ISO 683-13:1986, Heat-treatable steels, alloy steels and free-cutting steels - Part 13: Wrough t stainless steels. ISO 1634-1:1987, Wrought topper and topper alloy pla te, shee t and Strip - Part 1: Technical conditions of delivery for plate, sheet and Strip for general pur- poses. ISO 4948-1: 1982, Steels - Classification - Part 1: Classifica tion of steels in to unalloyed and alloy steels based on Chemical composition. ISO 4948-2: 1981, Steels - Classification - Part 2: Classifica tion of unalloyed and alloy steels according to main quality classes and main property or applica- tion charac teris tics. ISO 6708:-‘1, Pipe components - Definition of nominal size (DN). ISO 7369: -*), Pipework - Flexible metallic hoses - Vocabulary of general terms. 3 Definitions For the purposes of this International Standard, the definitions given in ISO 7369 apply. 4 Manufacturing process The process for manufacturing leakproof corrugated flexible metallic hose complying with this International Standard is at the discretion of the manufacturer. 1) To be published. (Revision of ISO 6708:1980) 2) To be published. (Revision of ISO 7369:1983) 1 SIST EN ISO 10807:2001



ISO 10807:1994(E) 0 ISO 5 Materials 5.1 Metallic hose The metallic hose shall be manufactured from either a) topper alloy with topper content 94 % or above, in accordance with ISO 1634, or b) austenitic stainless steel, in accordance with ISO 683-13. 5.2 End fittings End fittings shall be manufactured from either a) steel corresponding to the classification of non- alloy steels given in ISO 4948-1 and ISO 4948-2, or b) austenitic stainless steel, in accordance with ISO 683-13. 5.3 Braiding Braiding shall be carried out using either a) bronze wire in accordance with ISO 427, or b) austenitic stainless steel, in accordance with ISO 683-13. 5.4 Welding Hose components tan be joined by a) braze welding; b) electric welding (MIG, MAG, TIG), microplasma welding (MP) or impulse welding. Adhesive bonding and tin soldering are excluded. 6 Dimensions and Performance 6.1 The dimensions and Performance of corrugated flexible metallic hose complying with this International Standard are given in table 1. 6.2 The dimensions of end fittings and the lengths of hoses are shown in figure 1 and given in table 2. The extemal shape of the end fitting may be polygonal or with notches for a sector wrench. Table 1 - Dimensions and Performance of flexible metallic hose in explosive atmospheres Dimensions in millimetres Nominal Maximum sizel) value of Maximum Minimum minimum value of internal DN diameter dynamic minimum bend static bend radius radius 15 14 270 50 20 18 280 70 25 23 310 90 32 2) 29 320 110 40 37 400 130 50 48 500 175 65 2) 60 600 200 80 75 750 240 100 95 900 300 1) See ISO 6708. 2) DN with limited application. 7 Inspection and testing 7.1 General The hose assemblies shall be subjected by the manufacturer to the inspections and tests specified in 7.2 to 7.4 (see also annex B). 7.2 Dimensional inspection All hose assemblies shall comply with the require- ments of tables 1 and 2. 7.3 Visual examination All hose assemblies shall comply with the require- ments of 8.3. 7.4 Hydraulic test Esch hose assembly shall be subjected to a hydraulic test under a minimum pressure of 40 bar with a nonagressive fluid for a period of at least 60 s. There shall be no leakage. After testing, the hose shall be cleaned and dried. SIST EN ISO 10807:2001



ISO 10807:1994(E) Ring I-- End fitting Figure 1 Table 2 - Dimensions of end fittings and hose lengths Dimensions in millimetres T Total hose lengths*) Nominal size DN Threadl) 15 R 112 20 R 314 25 Rl 32 3) Rl 114 40 Rl 112 50 R2 65 3) R 2 112 80 R3 100 R4 A H 800 900 1 000 1 200 max. max. Ll 700 300 400 425 600 3
...
