EN 14154-4:2014

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Vodomeri - 4. del: Dodatne funkcijeWasserzähler - Teil 4: Zusätzliche FunktionalitätenCompteurs d'eau - Partie 4: Fonctions additionnellesWater meters - Part 4: Additional functionalities91.140.60Sistemi za oskrbo z vodoWater supply systemsICS:Ta slovenski standard je istoveten z:EN 14154-4:2014SIST EN 14154-4:2015en,fr,de01-februar-2015SIST EN 14154-4:2015SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 14154-4
November 2014 ICS 91.140.60 English Version
Water meters - Part 4: Additional functionalities
Compteurs d'eau - Partie 4: Fonctionnalités additionnelles Wasserzähler - Teil 4: Zusätzliche Funktionalitäten This European Standard was approved by CEN on 6 September 2014.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2014 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 14154-4:2014 ESIST EN 14154-4:2015

Declaration of conformity to EN 14154-4 . 18 Annex B (informative)
Smart Metering, overview, core functionalities and definitions . 19 B.1 General . 19 B.2 M2M Gateway . 19 B.3 Clusters . 20 B.4 Primary Use Cases . 20 B.5 Secondary Use Cases . 20 B.6 Primary Actors . 20 B.7 Actors . 20 B.8 Use Cases . 20 Annex C (informative)
References to EN 14154-1, EN 14154-2 and EN 14154-3 and
EN ISO 4064-1, EN ISO 4064-2, EN ISO 4064-3, EN ISO 4064-4, EN ISO 4064-5 . 21 Bibliography . 23
A manufacturer can claim compliance only for additional functionalities described in this European Standard. It is not mandatory that an AFD complies with all additional functionalities described herein. 2 Normative references The following documents, in whole or in part, are normatively referenced in this document and are indispensable for its application. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 14154-1, Water meters – Part 1: General requirements EN 14154-2, Water meters – Part 2: Installation and conditions of use EN 14154-3, Water meters – Part 3: Test methods and equipment EN ISO 4064-1, Water meters for cold potable water and hot water - Part 1: Metrological and technical requirements (ISO 4064-1) EN ISO 4064-2, Water meters for cold potable water and hot water - Part 2: Test methods (ISO 4064-2) EN ISO 4064-4, Water meters for cold potable water and hot water - Part 4: Non-metrological requirements not covered in ISO 4064-1 (ISO 4064-4) EN ISO 4064-5, Water meters for cold potable water and hot water - Part 5: Installation requirements (ISO 4064-5) EN 60529:1991, Degrees of protection provided by enclosures (IP Code) (IEC 60529:1989) 3 Terms and definitions The terms, definitions and symbols of EN ISO 4064-1, EN ISO 4064-2, EN ISO 4064-4 and EN ISO 4064-5, EN 14154-1, EN 14154-2 and EN 14154-3 apply. NOTE Additionally for the purposes of this part of the European Standard, the following terms and definitions only related to additional functionalities apply. 3.1 functionality process which constantly or at defined intervals, automatically or on demand, performs specific activities such as sampling data, reading a data set, verifying or changing a status, or activating a switch 3.2 additional functionality functionality that a smart meter provides, over and above the metrological functionality covered by the Measuring Instruments Directive SIST EN 14154-4:2015

Figure 1 — Additional functionality devices 4.2 Connection requirements The AFD2 and AFD3 shall be connected to the meter and tested as a combined unit in all the tests given in 4.11.2 to ensure the connection of the AFD to the meter has no metrological influence. The connection of the AFD to the meter or any labelling on the meter or the AFD shall not obscure or damage any metrological seal of the meter. The primary indication on the meter shall not be obscured by the connection of the AFD and the indicating device shall be accessible to the consumer without the use of tools. 4.3 Environmental conditions The AFD shall work with the meter at all operating conditions of the meter as required by the appropriate standards. Any AFD should be suitable to meet one of the environmental classes from EN ISO 4064-1, A.2 and A.3 and the related tests. An AFD3 may have a different environmental class to that of the meter. SIST EN 14154-4:2015
...
