Normative Annex B of EN 13126-1:2006 gives schedules of the elements of components used on the 21 types of window opening functions. Normative and informative annex to all parts of this European Standard are indicated in the content of the several parts. The performance tests incorporated in this standard are considered to be reproducible and as such will provide a consistent and objective assessment of the performance of these products throughout CEN Member States. According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.

2 Normative references
The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 1670, Building hardware — Corrosion resistance — Requirements and test methods EN 12519:2004, Windows and pedestrian doors – Terminology EN 13126-1:2006, Building hardware — Requirements and test methods for windows and doors height windows - Part 1: Requirements common to all types of hardware ISO 4520, Chromate conversion coatings on electroplated zinc and cadmium coating 3 Terms and definitions For the purposes of this document the terms and definitions given in EN 13126-1:2006 and EN 12519:2004 and the following apply. NOTE The following terms and definitions apply to Tilt&Slide windows and door height windows made of wood, PVC-U, aluminium or steel and their appropriate material combinations. 3.1 roller assembly of one or more rolls in a single or multiple casing which supports Tilt&Slide windows and door height windows which may be aligned in a straight line or rotate about an axis for Tilt&Slide windows and door height windows. Otherwise known as a bogey 3.2
roll singular wheel in a roller 3.3 lateral guide hardware component that guides the lateral movement of the Tilt&Slide windows and door height windows 3.4 guide track track fixed on the top (top guide track) or bottom (bottom guide track) which enables a lateral guide to run 3.5 rail rail fixed on the top (top rail) or bottom (bottom rail) which enables the rollers to run 3.6 positive control sash operation via the hardware which enables the sash to be moved from the closed position into the tilted position, and from the tilted position into the closed position.

3.7 locked closed position position in which the active sash lies up against the frame on all sides, the hardware is locked and the window unit is completely closed 3.8 closed position position in which the active sash lies up against the frame on all sides, while the hardware is not yet locked and in which the window unit is not completely closed 3.9 tilted position
position in which the bottom of the active sash rests on the frame NOTE
The top area is held in the final tilt position by means of the projecting mechanism 3.10 sliding position
position in which the active sash is disengaged on all sides, so that it can be moved in-line 3.11 opening position
position in which the active sash is at the end of the sliding position (the largest possible opening width) 4 Classification 4.1 General The classification of hardware for Tilt&Slide windows and doors shall be in accordance with the requirements of clause 4 EN 13126-1:2006. 4.2 Category of use (1 – first digit) No marking is required for the category of use in accordance with 4.2 of EN 13126-1:2006. 4.3 Durability (2 – second digit) Grades shall be in accordance with 4.3 of EN 13126-1:2006. 4.4 Mass (3 – third digit) Grades shall be in accordance with 4.4 of EN 13126-1:2006. 4.5 Fire resistance (4 – fourth digit) One grade shall be identified in accordance with 4.5 of EN 13126-1:2006  grade 0: no requirements. 4.6 Safety in use (5 – fifth digit) One grade is identified in accordance with 5.6 of EN 13126-1:2006.

(or S.R.H.2)) as specified by the hardware manufacturers appropriate documentation and a S.R.H.2) (or S.R.W.1)) in a ratio of 2 000/1 200 mm (factor ≈ 1,67). NOTE 2 This means that if the specified test sizes are larger than those which can be manufactured, the test specimens shall be tested using the largest possible S.R.W.1)
or S.R.H.2) in accordance with the manufacturer's documentation and using a S.R.H.2) to S.R.W.1) ratio of 2 000/1 200 mm (factor ≈ 1,67). Example 1 largest possible S.R.W.1)
= 800 mm
=
S.R.W.1) of the test specimen
800 mm X 2 000/1 200 = 1 333 mm
S.R.H.2)
= 1 333 mm =
S.R.H.2) of the test specimen Example 2 largest possible S.R.H.1)
= 1 600 mm =
S.R.H.1) of the test specimen
1 600 mm X 1 200/2 000 = 960 mm
S.R.W.2)
= 960 mm
=
S.R.W.2) of the test specimen NOTE 3 The missing dimensions in each case (S.R.H1) or S.R.W2)) should be calculated in accordance with example 1 or 2 with the objective of establishing the maximum test-format, which lies within the hardware manufacturers application range.
1 S.R.W. = sash rebate width 2 S.R.H. = sash rebate height

4.11 Example of classification for hardware for Tilt&Slide windows and doors
1 2 3 4 5 6 7 8 9 - 4 120 0 1 3 - 17 1 200/2 000
This denotes hardware for Tilt&Slide windows and doors, which have: Digit 1 category of use
- (no requirements) Digit 2 durability
grade 4 (15 000 cycles) Digit 3 mass
120 kg Digit 4 fire resistance
grade 0 (no requirements) Digit 5 safety in use
grade 1 Digit 6 corrosion resistance
grade 3 Digit 7 security
- (no requirements) Digit 8 applicable part
tested according to part 17 of this standard Digit 9 test sizes
S.R.W1) = 1 200 mm, S.R.H2) = 2 000 mm 1) S.R.W. = sash rebate width 2) S.R.H. = sash rebate height 5 Requirements 5.1 General Hardware for Tilt&Slide windows and doors shall conform to clause 5 of EN 13126-1:2006. 5.2 Additional requirements 5.2.1 Handle operation tolerance The maximum torque Th which is the result of a force of 100 N applied at a distance of 20 mm from the end point of the handle shall not be exceeded in conjunction with a counteracting force of 20 N 5,20+N per locking point. The length of the handle used during the test or the length of the handle intended for the hardware set shown in the hardware manufacturer’s documentation shall be recorded in the test report. The torque Th resulting from the length of the used handle (key 3 in Figure 1 minus 20 mm) and the force of 100 N shall be calculated and recorded in the test report.
For example: length of the handle = 220 mm
operative length (key 4, figure 1) =
220 mm – 20 mm = 200 mm
torque Th = operative length X force F =
200 mm X 100 N
=
20 Nm
Key
1 location for the force l1 length of the handle l2 operative length 2 force F = 100 N Figure 1 — Handle length 5.2.2 Locking point variable tolerance Before and after the durability test in accordance with 7.3, the distance “X” between the frame surface and the sash-overlap-begin shall be measured in conjunction with a counteracting force of 2010+N per locking point. The results shall not differ by more than 1 mm (see Figure 2).

Key
1 frame 2 sash x measurement Figure 2 — Measurement of locking point variable tolerance 5.2.3 Sliding operation crash-tests After the sliding operation crash test in accordance with 7.4.1 and 7.4.2:
 active sash shall not drop and shall still be constrained by its fixings  active sash shall function correctly NOTE After the sliding operation crash-test all adjustment possibilities may be used to operate the sash. 5.2.4 Minimum closing device resistance 5.2.4.1 Hardware without positive control The closing device shall withstand a torque Thr of 25 Nm. Upon completion of the test in accordance with 7.5.1, the closing device shall operate. 5.2.4.2 Hardware with positive control The hardware shall withstand a torque Thr, which is the threefold torque Th as calculated and recorded in accordance with 5.2.1. For example: length of the handle = 220 mm
operative length (key 4, Figure 1) = 220 mm – 20 mm = 200 mm
torque Th = operative length X force F = 200 mm X 100 N
= 20 Nm
torque Thr = 3 X Th
= 3 X 20 Nm = 60 Nm
The closing device shall operate upon completion of the test in accordance with 7.5.2.1 and 7.5.2.2. 5.2.5 Resistance to additional loading After the additional loading test in accordance with 7.6 the active sash shall not drop and shall still be constrained by its fixings. NOTE It is not necessary for the sash to operate during and after the additional loading test.

–
durability test sample A2 –
static endurance test at ambient temperature
sample B
–
corrosion test sample C
–
retained for reference control NOTE 1 Alternatively sample A.1 and A.2 may be the same.
...
