EN 16712-2:2015
(Main)Portable equipment for projecting extinguishing agents supplied by fire fighting pumps - Portable foam equipment - Part 2: Pick-up tubes
Portable equipment for projecting extinguishing agents supplied by fire fighting pumps - Portable foam equipment - Part 2: Pick-up tubes
1.1 This European Standard specifies performance requirements and test methods for pick-up tubes.
This European Standard applies to pick-up tubes from DN 20 to DN 50 which are used for the suction of foam concentrate or additives and defines their requirements and test procedures.
Pick-up tubes are especially used with inductors in accordance with prEN 16712-1.
NOTE Pick-up tubes can also be used for the suction of other substances (e.g. absorbents).
1.2 This European Standard is not applicable to pick-up tubes which have been manufactured before its date of publication as European Standard.
Tragbare Geräte zum Ausbringen von Löschmitteln, die mit Feuerlöschpumpen gefördert werden - Tragbare Schaumgeräte - Teil 2: Ansaugschlauch
1.1 Diese Europäische Norm legt Leistungsanforderungen und Prüfverfahren für Ansaugschläuche fest.
Diese Europäische Norm gilt für Ansaugschläuche von DN 20 bis DN 50, die zum Ansaugen von Schaummittel oder Zusätzen dienen und legt deren Anforderungen und Prüfverfahren fest.
Ansaugschläuche werden insbesondere mit Zumischern nach prEN 16712-1 verwendet.
ANMERKUNG Ansaugschläuche können auch zum Ansaugen anderer Stoffe (z. B. Absorbtionsmittel) verwendet werden.
1.2 Diese Europäische Norm gilt nicht für Ansaugschläuche, die vor dem Veröffentlichungsdatum dieser Europäischen Norm hergestellt wurden.
Equipement portable de projection d’agents d’extinction alimenté par des pompes à usage incendie - Equipements mousse portables - Partie 2 : Flexibles d'aspiration
1.1 La présente Norme européenne spécifie les prescriptions de performances et les méthodes d’essais des flexibles d’aspiration.
La présente Norme européenne s’applique aux flexibles d’aspiration de DN 20 à DN 50, utilisés pour l’aspiration d’émulseurs ou d’additifs, et définie leurs prescriptions et les méthodes d’essais correspondantes.
Les flexibles d’aspiration sont particulièrement utilisés en association avec les proportionneurs conformes à l’EN 16712 1.
NOTE Les flexibles d’aspiration peuvent également être utilisés pour l’aspiration d’autres substances (par exemple : les absorbants).
1.2 La présente Norme européenne ne s'applique pas aux flexibles d’aspiration qui ont été fabriqués avant sa date de publication en tant que Norme européenne.
Prenosna oprema za črpanje in uporabo gasilnih sredstev iz gasilskih črpalk - Prenosna oprema za izdelavo gasilne pene - 2. del: Sesalna cev za penilo
1.1 Ta dokument določa zahteve za delovanje in preskusne metode za sesalne cevi za penilo. Ta dokument se uporablja za sesalne cevi za penilo velikosti od DN 20 do DN 50, ki se uporabljajo za sesanje penil ali aditivov, ter določa njihove zahteve in preskusne postopke.
OPOMBA 1: Sesalne cevi za penilo se uporabljajo zlasti za sesanje penil ali aditivov s primešalniki penil v skladu s standardom prEN 16712-1.
OPOMBA 2: Sesalne cevi za penilo je mogoče uporabiti tudi za sesanje drugih snovi (npr. vpojnih sredstev).
1.2 Ta evropski standard se ne uporablja za sesalne cevi za penilo, ki so bili izdelane, preden je bil ta dokument objavljen kot evropski standard.
General Information
- Status
- Published
- Publication Date
- 08-Sep-2015
- Withdrawal Date
- 30-Mar-2016
- Technical Committee
- CEN/TC 192 - Fire service equipment
- Drafting Committee
- CEN/TC 192/WG 8 - Hand-held branchpipes for fire service use
- Current Stage
- 9093 - Decision to confirm - Review Enquiry
- Start Date
- 10-Jan-2024
- Completion Date
- 14-Apr-2025
Overview
EN 16712-2:2015 - Portable equipment for projecting extinguishing agents - Portable foam equipment - Part 2: Pick-up tubes - is a CEN European Standard that specifies performance requirements and test methods for pick-up tubes used with portable foam systems. The standard covers pick-up tubes with nominal diameters from DN 20 to DN 50 intended for suction of foam concentrate, additives (and optionally other substances such as absorbents) into inductors or proportioning devices.
Key topics and requirements
- Scope and designation
- Applies to pick-up tubes DN 20–DN 50 and defines naming format (e.g., Pick-up tube EN 16712‑2 - DN 38 - 1500).
- Components and dimensions
- Semi‑rigid translucent tube connectable to an inductor; options include riser pipes, strainers, foot valves and couplings.
- Example DN 20 total lengths and max masses shown in the standard (e.g., 1500 ± 50 mm / 1 kg; 2500 ± 50 mm / 2 kg).
- Material
- Semi‑rigid thermoplastic, optionally reinforced; must be translucent to observe flow and foam concentrate presence and ideally UV‑resistant.
- Connection and retention
- Wall thickness and fixing methods (clamp, adhesive) must ensure tube remains permanently fixed to the coupling. A defined traction test at elevated temperature verifies attachment.
- Leakage and pressure tests
- Tightness requirements are specified with pressure retention checks (verification uses a vacuum/negative pressure condition around -0.8 bar).
- Performance under temperature and deformation
- Cross‑section stability: outer diameter must not reduce by more than 20% under specified test conditions.
- Collapse resistance: tube must not collapse after cold conditioning and bending (specified low temperature and bend radius).
- Safety and end‑finish
- Riser pipe end shapes are prescribed to avoid user injury.
Practical applications
- Use with portable inductors (see EN 16712‑1) and proportioning devices for firefighting operations.
- Typical applications: suction of foam concentrates and additives from containers during fire response, training, and equipment testing.
- Also suitable for suction of compatible liquids or absorbents where agreed between supplier and purchaser.
Who should use this standard
- Manufacturers of portable foam equipment and pick‑up tubes
- Fire‑fighting equipment specifiers and procurement officers
- Test laboratories and conformity assessment bodies
- Fire and rescue services and safety managers drafting equipment requirements
Related standards
- EN 16712‑1 (Inductors PN 16)
- EN 1568 series (foam concentrate specifications)
- EN ISO 7010 (safety signs)
Keywords: EN 16712-2:2015, pick-up tubes, portable foam equipment, inductors, foam concentrate, performance requirements, test methods, DN 20 DN 50.
Frequently Asked Questions
EN 16712-2:2015 is a standard published by the European Committee for Standardization (CEN). Its full title is "Portable equipment for projecting extinguishing agents supplied by fire fighting pumps - Portable foam equipment - Part 2: Pick-up tubes". This standard covers: 1.1 This European Standard specifies performance requirements and test methods for pick-up tubes. This European Standard applies to pick-up tubes from DN 20 to DN 50 which are used for the suction of foam concentrate or additives and defines their requirements and test procedures. Pick-up tubes are especially used with inductors in accordance with prEN 16712-1. NOTE Pick-up tubes can also be used for the suction of other substances (e.g. absorbents). 1.2 This European Standard is not applicable to pick-up tubes which have been manufactured before its date of publication as European Standard.
1.1 This European Standard specifies performance requirements and test methods for pick-up tubes. This European Standard applies to pick-up tubes from DN 20 to DN 50 which are used for the suction of foam concentrate or additives and defines their requirements and test procedures. Pick-up tubes are especially used with inductors in accordance with prEN 16712-1. NOTE Pick-up tubes can also be used for the suction of other substances (e.g. absorbents). 1.2 This European Standard is not applicable to pick-up tubes which have been manufactured before its date of publication as European Standard.
EN 16712-2:2015 is classified under the following ICS (International Classification for Standards) categories: 13.220.10 - Fire-fighting. The ICS classification helps identify the subject area and facilitates finding related standards.
EN 16712-2:2015 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
Standards Content (Sample)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Tragbare Geräte zum Ausbringen von Löschmitteln, die mit Feuerlöschpumpen gefördert werden - Tragbare Schaumgeräte - Teil 2: AnsaugschlauchEquipement portable de projection d’agents d’extinction alimenté par des pompes à usage incendie - Equipements mousse portables - Partie 2: Flexibles d'aspirationPortable equipment for projecting extinguishing agents supplied by fire fighting pumps - Portable foam equipment - Part 2: Pick-up tubes13.220.10Gašenje požaraFire-fightingICS:Ta slovenski standard je istoveten z:EN 16712-2:2015SIST EN 16712-2:2015en,fr,de01-november-2015SIST EN 16712-2:2015SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 16712-2
September
t r s w ICS
s uä t t rä s r English Version
Portable equipment for projecting extinguishing agents supplied by fire fighting pumps æ Portable foam equipment æ Part
tã Pickæup tubes Equipement portable de projection d 5agents d 5extinction alimenté par des pompes à usage incendie æ Equipements mousse portables æ Partie
t ã Flexibles d 5aspiration
Tragbare Geräte zum Ausbringen von Löschmittelná die mit Feuerlöschpumpen gefördert werden æ Tragbare Schaumgeräte æ Teil
tã Ansaugschlauch This European Standard was approved by CEN on
s August
t r s wä
egulations which stipulate the conditions for giving this European Standard the status of a national standard without any alterationä Upætoædate lists and bibliographical references concerning such national standards may be obtained on application to the CENæCENELEC Management Centre or to any CEN memberä
translation under the responsibility of a CEN member into its own language and notified to the CENæCENELEC Management Centre has the same status as the official versionsä
CEN members are the national standards bodies of Austriaá Belgiumá Bulgariaá Croatiaá Cyprusá Czech Republicá Denmarká Estoniaá Finlandá Former Yugoslav Republic of Macedoniaá Franceá Germanyá Greeceá Hungaryá Icelandá Irelandá Italyá Latviaá Lithuaniaá Luxembourgá Maltaá Netherlandsá Norwayá Polandá Portugalá Romaniaá Slovakiaá Sloveniaá Spainá Swedená Switzerlandá Turkey andUnited Kingdomä
EUROPEAN COMMITTEE FOR STANDARDIZATION COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre:
Avenue Marnix 17,
B-1000 Brussels
t r s w CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Membersä Refä Noä EN
s x y s tæ tã t r s w ESIST EN 16712-2:2015
...
