Woodworking machines - Safety - Part 16: Table band saws and band re-saws (ISO 19085-16:2021)

This document gives the safety requirements and measures for table band saws and band resaws, with manual loading and/or unloading and suitable for continuous production use, hereinafter referred to as “machines”.
The machines are designed to cut solid wood and material with similar physical characteristics to wood.
It deals with all significant hazards, hazardous situations and events, listed in Annex A, relevant to the machines, when operated, adjusted and maintained as intended and under the conditions foreseen by the manufacturer; reasonably foreseeable misuse has been considered too. Also, transport, assembly, dismantling, disabling and scrapping phases have been taken into account.
It is also applicable to machines fitted with one or more of the following devices/additional working units, whose hazards have been dealt with:
a) device to tilt the table;
b) device to tilt the saw unit.
This document does not apply to:
1)    machines driven by combustion engines or power take offs (PTO);
2)    log band sawing machines;
NOTE Log band sawing machines are covered by EN 1807-2:2013.
3)    horizontal band saws and band resaws;
4)    machines designed for cross-cutting of firewood.
This document does not deal with hazards related to the combination of a single machine being used with any other machine (as part of a line).
This document is not applicable to machines intended for use in potentially explosive atmospheres or to machines manufactured prior to the date of its publication.

Holzbearbeitungsmaschinen - Sicherheit - Teil 16: Tischbandsägemaschinen und Trennbandsägemaschinen (ISO 19085-16:2021)

Dieses Dokument stellt Sicherheitsanforderungen und Maßnahmen zur Verfügung für Tischbandsägemaschinen und Trennbandsägemaschinen mit Handbeschickung und/oder Handentnahme, die für den dauerhaften Einsatz in der Produktion geeignet sind, im Folgenden „Maschinen“ genannt.
Die Maschinen sind für die Verarbeitung von Massivholz und Werkstoffen mit ähnlichen physikalischen Eigenschaften wie Holz konstruiert.
Es behandelt alle im Anhang A aufgeführten signifikanten Gefährdungen, Gefährdungssituationen und Gefährdungsereignisse, die auf diese Maschinen zutreffen, wenn sie bestimmungsgemäß und entsprechend den vom Hersteller vorgesehenen Bedingungen verwendet, eingestellt und gewartet werden; vernünftigerweise vorhersehbare Fehlanwendung wurde ebenfalls berücksichtigt. Ferner werden die Phasen Transport, Montage, Demontage, Rückbau und Verschrottung berücksichtigt.
Es ist auch für Maschinen anwendbar, die mit einer oder mehreren der folgenden Einrichtungen/zusätzlichen Arbeitsaggregaten, deren Gefährdungen behandelt sind, ausgestattet sind:
a)   Einrichtung zum Schrägstellen des Tischs;
b)   Einrichtung zum Schrägstellen des Sägeaggregats.
Dieses Dokument ist nicht anwendbar für:
1)   Maschinen, die von Verbrennungsmotoren oder Zapfwellen (en: power take-off, PTO) angetrieben werden;
2)   Blockbandsägemaschinen;
ANMERKUNG   Blockbandsägemaschinen sind in EN 1807-2:2013 behandelt.
3)   horizontale Bandsägemaschinen und Trennbandsägemaschinen;
4)   Maschinen zum Querschneiden von Brennholz.
Dieses Dokument behandelt nicht die Gefährdungen in Bezug auf das Verbinden einer einzelnen Maschine mit irgendeiner anderen Maschine (als Teil einer Linie).
Dieses Dokument ist nicht anwendbar für Maschinen, die zur bestimmungsgemäßen Verwendung in potentiell explosiven Atmosphären vorgesehen sind oder für Maschinen, die vor dem Datum seiner Veröffentlichung hergestellt wurden.

Machines à bois - Sécurité - Partie 16: Scies à ruban à table et scies à ruban à refendre (ISO 19085-16:2021)

Le présent document donne les exigences et les mesures de sécurité pour les scies à ruban à table et les scies à ruban à refendre à chargement et/ou déchargement manuel et adaptée à l'utilisation en production continue, ci-après désignées «machines».
Les machines sont conçues pour couper du bois massif et un matériau ayant des caractéristiques physiques similaires à celles du bois.
Il traite de tous les phénomènes dangereux, situations et événements dangereux significatifs, énumérés à l’Annexe A, applicables aux machines lorsqu’elles sont utilisées, réglées et entretenues comme prévu et dans les conditions prévues par le fabricant; une mauvaise utilisation raisonnablement prévisible a également été prise en compte. Les phases de transport, d’assemblage, de démontage, de mise hors service et de mise au rebut ont également été prises en compte.
Il est également applicable aux machines équipées d’un ou plusieurs des dispositifs/unités de travail supplémentaires suivants, dont les phénomènes dangereux ont été traités:
a) dispositif d’inclinaison de la table;
b) dispositif d’inclinaison de l’unité de sciage.
Le présent document ne s’applique pas:
1)    aux machines entraînées par des moteurs à combustion ou des prises de force (PTO);
2)    aux machines à scier à ruban pour grumes;
NOTE          Les machines à scier à ruban pour grumes sont couvertes par l’EN 1807‑2:2013.
3)    aux scies à ruban et scies à ruban à refendre horizontales;
4)    aux machines conçues pour le tronçonnage de bûches;
Le présent document ne traite pas des phénomènes dangereux liés à la combinaison d’une machine simple utilisée avec toute autre machine (comme partie d’une ligne de production).
Le présent document n’est pas applicable aux machines prévues pour une utilisation en atmosphères explosibles, ni aux machines fabriquées avant sa date de publication.

Lesnoobdelovalni stroji - Varnost - 16. del: Namizne tračne žage in žage za rezanje desk (ISO 19085-16:2021)

Ta dokument določa varnostne zahteve in ukrepe za stacionarne ter premestljive namizne tračne žage in žage za rezanje desk z ročnim nalaganjem in/ali razlaganjem, ki so zasnovane za rezanje lesa in materialov, ki imajo podobne lastnosti kot les (v nadaljnjem besedilu »stroji«).
OPOMBA 1:   Za definicijo premestljivega stroja glej standard ISO 19085-1:2017, točka 3.5.
Obravnava vse večje nevarnosti, nevarne situacije in dogodke iz točke 4 v zvezi s stroji, kadar se ti uporabljajo, prilagajajo in vzdržujejo v skladu s svojim namenom ter pod pogoji, ki jih je predvidel proizvajalec, vključno z razumno predvideno nepravilno uporabo. Upoštevane so bile tudi faze transporta, sestavljanja, razstavljanja in razrezovanja stroja.
OPOMBA 2:   Za pomembne (ne pa tudi večje) nevarnosti, npr. ostre robove okvirja stroja, glej standard ISO 12100:2010.
Standard se uporablja tudi za stroje, ki so opremljeni z eno ali več naslednjimi napravami/dodatnimi delovnimi enotami, katerih nevarnosti so bile obravnavane:
a)   naprava za nagib mize;
b)   naprava za nagib rezalne enote.
Ta dokument se ne uporablja za:
1)   stroje z motorji z notranjim izgorevanjem ali s priključnimi gredmi (PTO);
2)   tračne žage;
OPOMBA 3:   Tračne žage so obravnavane v standardu EN 1807-2.
3)   stroje, zasnovane za prečno rezanje ovalnih obdelovancev ali obdelovancev nepravilnih oblik;
4)   premične/premestljive stroje z največjo dolžino tračnega rezila ≤ 2700 mm in največjim premerom pogonskega kolesa ≤ 350 mm;
OPOMBA 4:    Premični električni stroji so obravnavani v zahtevah standarda EN 61029-1:2009 skupaj s standardom EN 61029-2-5:2015.
