ASTM B536-19

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: B536 − 07 (Reapproved 2013) B536 − 19
Standard Specification for
Nickel-Iron-Chromium-Silicon Alloys (UNS N08330 and
N08332) Plate, Sheet, and Strip
This standard is issued under the fixed designation B536; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope*
1.1 This specification covers nickel-iron-chromium silicon alloys (UNS N08330 and UNS N08332)*N08332) plate, sheet, and
strip intended for heat resisting applications and general corrosive service.
1.2 The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical
conversions to SI units that are provided for information only and are not considered standard.
1.3 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to become familiar with all hazards including those identified in the appropriate Material Safety Data
Sheet (MSDS)(SDS) for this product/material as provided by the manufacturer, to establish appropriate safety safety, health, and
healthenvironmental practices, and determine the applicability of regulatory limitations prior to use.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2.1 ASTM Standards:
B899 Terminology Relating to Non-ferrous Metals and Alloys
B906 Specification for General Requirements for Flat-Rolled Nickel and Nickel Alloys Plate, Sheet, and Strip
3. Terminology
3.1 Terms shall be defined in accordance with Terminology B899.
4. General Requirements
4.1 Material furnished under this specification shall conform to the requirements of Specification B906 unless otherwise
provided herein. In the case of conflict, the requirements of this specification shall take precedence.
5. Material and Manufacture
5.1 Annealing Temperature—Alloy UNS N08330 shall be annealed at 1900°F (1040°C) minimum. Alloy UNS N08332 shall be
annealed at 2100°F (1150°C) minimum.
6. Chemical Composition
6.1 The material shall conform to the requirements as to chemical composition specified in Table 1.
7. Mechanical and Other Properties
7.1 The tensile properties of the material at room temperature shall conform to those shown in Table 2.
This specification is under the jurisdiction of ASTM Committee B02 on Nonferrous Metals and Alloys and is the direct responsibility of Subcommittee B02.07 on Refined
Nickel and Cobalt and Their Alloys.
Current edition approved Feb. 1, 2013April 1, 2019. Published February 2013August 2019. Originally approved in 1970. Last previous edition approved in 20072013 as
B536 – 07.B536 – 07 (2013). DOI: 10.1520/B0536-07R13.10.1520/B0536-19.
* New designation established in accordance with ASTM E527 and SAE J1086, Practice for Numbering Metals and Alloys (UNS).
Designation established in accordance with ASTM E527 and SAE J1086, Practice for Numbering Metals and Alloys (UNS).
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
B536 − 19
TABLE 1 Chemical Requirements
Composition
Element
Limits, %
A
C .
Mn 2.00 max
P 0.03 max
S 0.03 max
Si 0.75–1.50
Cr 17.0–20.0
Ni 34.0–37.0
Cu 1.00 max
Pb 0.005 max
Sn 0.025 max
B
Fe remainder
A
Alloy UNS N08330: 0.08 max
Alloy UNS N08332: 0.05–0.10
B
Element shall be determined arithmetically by difference.
TABLE 2 Mechanical Properties
Elongation
Tensile Strength, Yield Strength, 0.2 % in 2 in. or 50
A
Alloy Condition Hardness
min, psi (MPa) offset, min, psi (MPa) mm, or 4D,
min, %
UNS N08330 annealed 70 000 (483) 30 000 (207) 30 70 to 90 HRB
UNS N08332 annealed 67 000 (462) 27 000 (186) 30 65 to 88 HRB
A
Hardness values are informative only and not to be constructed as the basis for acceptance.
7.2 Grain Size—Annealed alloy UNS N08332 shall conform to an average grain size of ASTM No. 5 or coarser. There are no
grain size requirements for UNS N08330.
8. Permissible Variations in Dimensions and Weight
8.1 The tolerances and permissible variations provided in Annex A1, Permissible Variations in Dimensions, Etc.–Inch-Pound
(SI) Units, of Specification B906 shall apply.
9. Keywords
9.1 N08330; N08332; plate; sheet; strip
APPENDIX
(Nonmandatory Information)
X1. FINISHES
X1.1 Scope—This appendix lists the finishes in which plate, sheet, and strip are normally supplied. These are subject to change
and the manufacturer should be consulted for the latest information available.
X1.2 Sheet—The various types of finish procurable on sheet products are:
X1.2.1
...
