Designation: D3649 − 23
Standard Practice for
High-Resolution Gamma-Ray Spectrometry of Water
This standard is issued under the fixed designation D3649; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope mendations issued by the World Trade Organization Technical
Barriers to Trade (TBT) Committee.
1.1 This practice covers the measurement of gamma-ray
emitting radionuclides in water by means of gamma-ray
2. Referenced Documents
spectrometry. It is applicable to nuclides emitting gamma-rays
2.1 ASTM Standards:
with energies greater than 45 keV. For typical counting systems
D1066 Practice for Sampling Steam
and sample types, activity levels of about 40 Bq are easily
D1129 Terminology Relating to Water
measured and sensitivities as low as 0.4 Bq are found for many
D2777 Practice for Determination of Precision and Bias of
nuclides. Count rates in excess of 2000 counts per second
Applicable Test Methods of Committee D19 on Water
should be avoided because of electronic limitations. High
D3370 Practices for Sampling Water from Flowing Process
count rate samples can be accommodated by dilution, by
Streams
increasing the sample to detector distance, or by using digital
D3648 Practices for the Measurement of Radioactivity
signal processors.
D4448 Guide for Sampling Ground-Water Monitoring Wells
1.2 This practice can be used for either quantitative or
D7902 Terminology for Radiochemical Analyses
relative determinations. In relative counting work, the results
E181 Guide for Detector Calibration and Analysis of Radio-
may be expressed by comparison with an initial concentration
nuclides in Radiation Metrology for Reactor Dosimetry
of a given nuclide which is taken as 100 %. For quantitative
measurements, the results may be expressed in terms of known
3. Terminology
nuclidic standards for the radionuclides known to be present.
3.1 Definitions—For definitions of terms used in this
This practice can also be used just for the identification of
practice, refer to Terminology D1129 and Terminology D7902.
gamma-ray emitting radionuclides in a sample without quan-
For terms not defined in this practice or in Terminology D1129
tifying them. General information on radioactivity and the
2 or Terminology D7902, reference may be made to other
measurement of radiation has been published (1,2). Informa-
published glossaries.
tion on specific application of gamma spectrometry is also
available in the literature (3-5). See also the referenced ASTM
4. Summary of Practice
Standards in 2.1 and the related material section at the end of
4.1 Gamma ray spectra are measured with modular equip-
this standard.
ment consisting of a detector, high-voltage power supply,
1.3 This standard does not purport to address the safety
preamplifier, amplifier and analog-to-digital converter (or digi-
concerns, if any, associated with its use. It is the responsibility
tal signal processor), multichannel analyzer, as well as a
of the user of this standard to establish appropriate safety,
computer with display.
health, and environmental practices and determine the appli-
4.2 High-purity germanium (HPGe) detectors, p-type or
cability of regulatory limitation prior to use.
n-type, are used for the analysis of complex gamma-ray spectra
1.4 This international standard was developed in accor-
because of their excellent energy resolution. These germanium
dance with internationally recognized principles on standard-
systems, however, are characterized by high cost and require
ization established in the Decision on Principles for the
cooling. Liquid nitrogen or electromechanical cooling, or both,
Development of International Standards, Guides and Recom-
can be used.
4.3 In a germanium semiconductor detector, gamma-ray
This practice is under the jurisdiction of ASTM Committee D19 on Water and
photons produce electron-hole pairs. The charged pair is then
is the direct responsibility of Subcommittee D19.04 on Methods of Radiochemical
Analysis.
Current edition approved June 1, 2023. Published July 2023. Originally approved
in 1978. Last previous edition approved in 2014 as D3649 – 06 (2014) which was For referenced ASTM standards, visit the ASTM website, www.astm.org, or
withdrawn January 2023 and reinstated in June 2023. DOI: 10.1520/D3649-23. contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM
The boldface numbers in parentheses refer to a list of references at the end of Standards volume information, refer to the standard’s Document Summary page on
this standard. the ASTM website.
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
D3649 − 23
collected by an applied electric field. A very stable low noise both of the 511 keV annihilation quanta may escape from the
preamplifier is needed to amplify the pulses of electric charge detector without interaction. This condition will cause single or
resulting from gamma photon interactions. The output from the double escape peaks at energies of 0.511 MeV or 1.022 MeV
preamplifier is directly proportional to the energy deposited by less than the photopeak energy. In the plot of pulse height
the incident gamma-ray. These current pulses are fed into an versus count rate, the size and location of the photopeak on the
amplifier of sufficient gain to produce voltage output pulses in pulse height axis are proportional to the number and energy of
the amplitude range from 0 V to 10 V. the incident photons, respectively, and are the basis for the
quantitative and qualitative application of the spectrometer.
4.4 A multichannel pulse-height analyzer is used to deter-
The Compton continuum serves no useful purpose in photo-
mine the amplitude of each pulse originating in the detector,
peak analysis and must be subtracted when peaks are analyzed.
and accumulates in a memory the number of pulses in each
amplitude band (or channel) in a given counting time. Com- 4.6 If the analysis is being directed and monitored by an
puterized systems with stored programs and interface hardware online computer program, the analysis period may be termi-
can accomplish the same functions as hardwired multichannel nated by prerequisites incorporated in the program. If the
analysis is being performed with a modern multichannel
analyzers. The primary advantages of the computerized system
include the capability of programming the multi-channel ana- analyzer, analysis may be terminated when a preselected time
lyzer functions and the ability to immediately perform data or total counts in a region of interest or in a specified channel
reduction calculations using the spectral data stored in the is reached. Visual inspection of a display of accumulated data
computer memory or mass storage device. For a 0 MeV to can also be used as a criterion for manually terminating the
2 MeV spectrum, 4000 or more channels are typically needed analysis on either type of data acquisition systems.
in order to fully utilize a germanium detector’s excellent
4.7 Upon completion of the analysis, the spectral data are
energy resolution.
interpreted and reduced to radionuclide activities in becquerels
4.5 The distribution of the amplitudes (pulse heights) of the (Bq) or other units suited to the particular application. At this
pulses can be separated into two principal components. One of time the spectral data may be inspected to identify the
these components has a nearly Gaussian distribution and is the gamma-ray emitters present. This is accomplished by reading
result of total absorption of the gamma-ray energy in the the channel number from the x-axis and converting to gamma-
detector. This peak is normally referred to as the full-energy ray energy by multiplying by the appropriate keV/channel
peak or photopeak. The other component is a continuous one (system gain). In some systems the channel number or gamma-
lower in energy than that of the photopeak. This continuous ray energy in keV can be displayed for any selected channel.
curve is referred to as the Compton continuum and is due to Identification of nuclides may be aided by catalogs of gamma-
interactions wherein the gamma photons deposit only part of ray spectra and other nuclear data tabulations (3, 6 and 7).
their energy in the detector. These two portions of the curve are 4.7.1 Computer programs for data reduction have been used
shown in Fig. 1. Other peaks, such as escape peaks, backscat- extensively although calculations for some applications can be
tered gamma rays or X rays from shields, are often superim- performed effectively with the aid of a scientific calculator.
posed on the Compton continuum. Escape peaks will be Data reduction of spectra taken with germanium spectrometry
present when gamma-rays with energies greater than 1.02 MeV systems is usually accomplished by integration of the photo-
are emitted from the sample. The positron formed in pair peaks above a definable background (or baseline) and subse-
production is usually annihilated in the detector and one or quent activity calculations using a library which includes data
FIG. 1 Cesium-137 Spectrum
D3649 − 23
such as nuclide name, half-life, gamma-ray energies, and be held to less than 1 % by limiting the total counting rate to
–1
absolute gamma intensity. 2000 counts per second (s ). Refer to Test Methods E181 for
more information.
