ASTM D4659-19

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: D4659 − 14 D4659 − 19
Standard Test Methods for
Polyurethane Raw Materials: Determination of Specific
Gravity of Isocyanates
This standard is issued under the fixed designation D4659; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope*
1.1 These test methods determine the specific gravity of toluenediisocyanate and crude methylene-bis-(4-phenylisocyanate).
toluenediisocyanate, polymeric (methylene phenylisocyanate), and liquid methylene di(phenylisocyanate). These test methods also
are applicable to many other liquids. (See Note 1.)
1.1.1 Test Method A—Specific gravity by pycnometer, for high-accuracy determination.
1.1.2 Test Method B—Specific gravity by hydrometer, for a less accurate, but rapid, determination.
1.2 The values stated in SI units are to be regarded as standard. No other units of measurement are included in this standard.
1.3 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety safety, health, and healthenvironmental practices and determine the
applicability of regulatory limitations prior to use. For specific warning and precautionary statements see Section 7.
NOTE 1—There is no known ISO equivalent to this standard.
NOTE 1—There is no known ISO equivalent to this standard.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2.1 ASTM Standards:
D883 Terminology Relating to Plastics
D891 Test Methods for Specific Gravity, Apparent, of Liquid Industrial Chemicals
D1193 Specification for Reagent Water
D4052 Test Method for Density, Relative Density, and API Gravity of Liquids by Digital Density Meter
E100 Specification for ASTM Hydrometers
E456 Terminology Relating to Quality and Statistics
E202 Test Methods for Analysis of Ethylene Glycols and Propylene Glycols
E2251 Specification for Liquid-in-Glass ASTM Thermometers with Low-Hazard Precision Liquids
E2935 Practice for Conducting Equivalence Testing in Laboratory Applications
3. Terminology
3.1 Definitions—For definitions of terms used in these test methods see Terms used in this standard are defined in accordance
with Terminology D883. , unless otherwise specified. For terms relating to precision and bias and associated issues, the terms used
in this standard are defined in accordance with Terminology E456.
3.2 Definitions of Terms Specific to This Standard:
3.2.1 specific gravity—the ratio of the weight in air of a given volume of the material at a stated temperature to the weight in
air of an equal volume of water at a stated temperature. It shall be expressed as specific gravity, 25/25°C, indicating that the sample
and reference water were both measured at 25°C.
These test methods are under the jurisdiction of ASTM Committee D20 on Plastics and are the direct responsibility of Subcommittee D20.22 on Cellular Materials -
Plastics and Elastomers.
Current edition approved March 1, 2014Aug. 1, 2019. Published March 2014August 2019. Originally approved in 1987. Last previous edition approved in 20092014 as
D4659 - 09.D4659 - 14. DOI: 10.1520/D4659-14.10.1520/D4659-19.
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
D4659 − 19
4. Significance and Use
4.1 These test methods can be used for research or for quality control to characterize isocyanates used in polyurethane products.
4.2 A general test method for specific gravity using a digital density meter, which applies to isocyanates as well as other liquids
is published in Test Method D4052.
TEST METHOD A—SPECIFIC GRAVITY BY PYCNOMETER
5. Apparatus
5.1 Pycnometer, of 25 or 50-mL capacity, conical shape with a capillary side arm overflow tube having a standard-taper 5/12
ground-glass joint and a ground-glass vented cap. A thermometer graduated from 12 to 38°C in 0.2° divisions attached to the neck
of the flask by a standard-taper 10/18 ground-glass joint. This thermometer is to be calibrated using the ASTM thermometer
specified in 5.3.
5.2 Water Bath—A water bath maintained at 25 6 0.05°C.
5.3 Thermometer—An ASTM low-softening point thermometer, calibrated from −2 to +80°C, which meets the requirements for
Thermometer S15C in Specification E2251.
5.4 Analytical Balance—A balance having a sensitivity of at least 0.1 mg.
6. Reagents and Materials
6.1 Purity of Reagents—Use reagent grade chemicals in all tests. Unless otherwise indicated, it is intended that all reagents
conform to the specifications of the Committee on Analytical Reagents of the American Chemical Society where such
specifications are available. Other grades can be used, are acceptable, provided it is ascertained that the reagent is of sufficiently
high purity to permit its use without lessening the accuracy of the determination.
6.2 Purity of Water—Unless otherwise indicated, references to water shall be understood to mean reagent water as defined by
Type IV or better of Specification D1193.
6.3 Chromic Acid Cleaning Solution—Prepare a saturated solution of chromic acid (CrO ) in concentrated sulfuric acid (H SO ,
3 2 4
sp gr 1.84).
7. Sampling
7.1 Since organic isocyanates react with atmospheric moisture, take special precautions in sampling. Usual sampling methods,
even when conducted rapidly, can cause contamination of the sample with insoluble urea. Therefore, blanket the sample with dry
air or nitrogen at all times. (Warning—Many diisocyanates are known or suspected sensitizers. Over-exposure to diisocyanates
can lead to adverse health effects, which may include the development of occupational asthma and other respiratory, skin, and eye
effects. Engineering controls, or Diisocyanates are eye, skin and respiratory irritants at concentrations above the occupational
exposure limit (TLV or PEL). Diisocyanates can cause skin and respiratory sensitization (asthma) in some people. Once sensitized,
it is essential to limit further exposure to diisocyanates. Use a combination of engineering controls and personal protective
equipment, or both, including respiratory, skin,skin and eye protection, are to be used when there is a potential for to prevent
over-exposure to diisocyanates. The Consult the product suppliers’ Material Safety Data Sheet (MSDS) provides(SDS) for more
detailed information about potential adverse health effects and other importantspecific safety and handling information. Always
follow the specific instructions provided on the MSDS.instructions for the product.)
8. Test Conditions
8.1 Since isocyanates react with moisture, keep Keep laboratory humidity low, preferably around 50 % relative humidity.
9. Procedure
9.1 Clean the pycnometer by filling it with chromic acid cleaning solution and by allowing it to stand for a few hours. Empty
the pycnometer and rinse well with distilled water.
9.2 Fill the pycnometer with freshly boiled distilled water that has been cooled to 22 to 24°C. Insert the thermometer into the
pycnometer without trapping air bubbles. Place the pycnometer in a water bath at 25 6 0.05°C and allow it and its contents to
equilibrate for at least 30 min. Wipe the overflow from the side-arm capillary and cover it with the vented cap. Remove the
pycnometer from the bath, wipe dry, and weigh.
Reagent Chemicals, American Chemical Society Specifications, American Chemical Society, Washington, DC. For suggestions on the testing of reagents not listed by
the American Chemical Society, see Analar Standards for Laboratory Chemicals, BDH Ltd., Poole, Dorset, U.K., and the United States Pharmacopeia and National
Formulary, U.S. Pharmaceutical Convention, Inc. (USPC), Rockville, MD.
D4659 − 19
9.3 Empty the pycnometer and rinse it with alcohol, then with ether. Remove the ether and dry the pycnometer under vacuum
for 15 min. (See Note 2.) Weigh the pycnometer. Determine the weight, W, of the water at 25.0°C in air by subtracting the weight
of the empty pycnometer from the weight of the pycnometer filled with water.
NOTE 2—Other drying techniques can be used are acceptable if ether is to be avoided. It must be established that for any alternative drying method,
a clean and dry pycnometer results.
9.4 Carry out the rest of the procedure in a ventilated hood. The The isocyanate sample for testing must be completely liquid.
If the sample contains solid toluene diisocyanate, warm it in its original container until it becomes liquid. Rapidly cool the liquid
to 22 to 24°C and fill the l
...
