ASTM E1775-20

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: E1775 − 16 E1775 − 20
Standard Guide for
Evaluating Performance of On-Site Extraction and Field-
Portable Electrochemical or Spectrophotometric Analysis
for Lead
This standard is issued under the fixed designation E1775; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope
1.1 This guide provides guidelines for determining the performance of field-portable quantitative lead analysis instruments.
1.2 This guide applies to field-portable electroanalytical and spectrophotometric (including reflectance and colorimetric)
analyzers.
1.3 Sample matrices of concern herein include paint, dust, soil, and airborne particles.
1.4 This guide addresses the desired performance characteristics of field-based sample extraction procedures for lead, as well as
on-site extraction followed by field-portable analysis.
1.5 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety safety, health, and healthenvironmental practices and determine the
applicability of regulatory limitations prior to use.
1.6 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2.1 ASTM Standards:
D1356 Terminology Relating to Sampling and Analysis of Atmospheres
D5438 Practice for Collection of Floor Dust for Chemical Analysis
D6785 Test Method for Determination of Lead in Workplace Air Using Flame or Graphite Furnace Atomic Absorption
Spectrometry
D6966 Practice for Collection of Settled Dust Samples Using Wipe Sampling Methods for Subsequent Determination of Metals
D7035 Test Method for Determination of Metals and Metalloids in Airborne Particulate Matter by Inductively Coupled Plasma
Atomic Emission Spectrometry (ICP-AES)
D7144 Practice for Collection of Surface Dust by Micro-vacuum Sampling for Subsequent Metals Determination
This guide is under the jurisdiction of ASTM Committee D22 on Air Quality and is the direct responsibility of Subcommittee D22.12 on Sampling and Analysis,Analysis
of Lead,Lead for Exposure and Risk Assessment.
Current edition approved March 1, 2016Sept. 1, 2020. Published April 2016September 2020. Originally approved in 1996. Last previous edition approved in 2016 as
E1775 – 07 (2016).E1775 – 16. DOI: 10.1520/E1775-16.10.1520/E1775-20.
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’sstandard’s Document Summary page on the ASTM website.
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
E1775 − 20
D7439 Test Method for Determination of Elements in Airborne Particulate Matter by Inductively Coupled Plasma–Mass
Spectrometry
E1583 Practice for Evaluating Laboratories Engaged in Determination of Lead in Paint, Dust, Airborne Particulates, and Soil
Taken From and Around Buildings and Related Structures
E1605 Terminology Relating to Lead in Buildings
E1613 Test Method for Determination of Lead by Inductively Coupled Plasma Atomic Emission Spectrometry (ICP-AES),
Flame Atomic Absorption Spectrometry (FAAS), or Graphite Furnace Atomic Absorption Spectrometry (GFAAS) Techniques
E1644 Practice for Hot Plate Digestion of Dust Wipe Samples for the Determination of Lead
E1645 Practice for Preparation of Dried Paint Samples by Hotplate or Microwave Digestion for Subsequent Lead Analysis
E1726 Practice for Preparation of Soil Samples by Hotplate Digestion for Subsequent Lead Analysis
E1728/E1728M Practice for Collection of Settled Dust Samples Using Wipe Sampling Methods for Subsequent Lead
Determination
E1727 Practice for Field Collection of Soil Samples for Subsequent Lead Determination
E1729 Practice for Field Collection of Dried Paint Samples for Subsequent Lead Determination
E1792 Specification for Wipe Sampling Materials for Lead in Surface Dust
E3193 Test Method for Measurement of Lead (Pb) in Dust by Wipe, Paint, and Soil by Flame Atomic Absorption
Spectrophotometry (FAAS)
E1864E3203 Practice for Evaluating Quality Systems of Organizations Conducting Facility and Hazard Assessments for Lead
in Paint, Dust, Airborne Particulate, and Soil in and around Buildings and Related StructuresTest Method for Determination
of Lead in Dried Paint, Soil, and Wipe Samples by Inductively Coupled Plasma-Optical Emission Spectroscopy (ICP-OES)
(Withdrawn 2011)
2.2 U.S. EPA Documents:
EPA 600/R-93/200 Standard Operating Procedure for the Field Analysis of Lead in Paint, Bulk Dust, and Soil by Ultrasonic,
Acid Digestion and Colorimetric Measurement (1993)
EPA 747-R-92-001 Laboratory Accreditation Guidelines: Measurement of Lead in Paint, Dust, and Soil (1992)
2.3 ISO Document:
ISO Guide 30 Reference materials --— Selected terms and definitions
3. Terminology
3.1 Definitions—For definitions of terms not listed here, see TerminologyTerminologies D1356 and E1605.
3.2 anodic stripping voltammetry—an electroanalytical technique in which the concentration of analyte metal species dissolved
in solution is determined.
3.2.1 Discussion—
The analyte is first deposited (preconcentrated) electrochemically by reducing the dissolved ion in solution to immobilized metal
species at an electrode surface (such as mercury or bismuth). The metal is deposited at an applied potential (voltage) which is
negative of the standard oxidation potential for the metal/ion redox couple. After deposition, the preconcentrated metal species is
then stripped from the electrode by applying a positive potential sweep, which causes anodic oxidation of the analyte metal species
to dissolved ion. The current associated with this reoxidation is measured. The peak current is proportional to the original
concentration of dissolved analyte species over a wide range of concentrations.
3.2 Definitions of Terms Specific to This Standard:
3.2.1 anodic stripping voltammetry, n—an electroanalytical technique in which the concentration of analyte metal species
dissolved in solution is determined.
3.2.1.1 Discussion—
The analyte is first deposited (preconcentrated) electrochemically by reducing the dissolved ion in solution to immobilized metal
species at an electrode surface (such as mercury or bismuth). The metal is deposited at an applied potential (voltage) which is
negative of the standard oxidation potential for the metal/ion redox couple. After deposition, the preconcentrated metal species is
then stripped from the electrode by applying a positive potential sweep, which causes anodic oxidation of the analyte metal species
to dissolved ion. The current associated with this reoxidation is measured. The peak current is proportional to the original
concentration of dissolved analyte species over a wide range of concentrations.
Available from United States Environmental Protection Agency (EPA), William Jefferson Clinton Bldg., 1200 Pennsylvania Ave., NW, Washington, DC 20460,
http://www.epa.gov.
Available from International Organization for Standardization (ISO), ISO Central Secretariat, BIBC II, Chemin de Blandonnet 8, CP 401, 1214 Vernier, Geneva,
Switzerland, http://www.iso.org.
E1775 − 20
3.2.2 colorimetry, n—an analytical technique in which ultraviolet-visible light of a single, narrow wavelength range is passed
through a sample cell containing dissolved analyte, and the absorption measured.
3.2.3 reflectance, n—a measurement technique in which light reflected off of a surface containing the analyte of interest is
measured by a detector.
3.2.4 spectrophotometry, n—an analytical technique in which a spectrum of a sample containing the analyte of interest is obtained
and used to determine the analyte concentration.
3.2.4.1 Discussion—
Light is directed onto or through analyte species, and the absor
...
