(Main)Electromagnetic compatibility and Radio spectrum Matters (ERM) - Short Range Devices - Road Transport and Traffic Telematics (RTTT) - Short range radar equipment operating in the 24 GHz range - Part 1: Technical requirements and methods of measurement
Electromagnetic compatibility and Radio spectrum Matters (ERM) - Short Range Devices - Road Transport and Traffic Telematics (RTTT) - Short range radar equipment operating in the 24 GHz range - Part 1: Technical requirements and methods of measurement
The present document specifies the technical requirements and methods of measurement for Short Range Devices (SRD) working as UWBdevices with at least 500 MHz bandwidth in the 22,000 GHz to 26,65 GHz frequency range intended for Road Transport and Traffic Telematics (RTTT) applications, such as automotive 24 GHz Short Range Radar (SRR) for e.g. obstacle detection, stop and go, blind spot detection, parking aid, back up aid, precrash and other automotive applications.
The present document covers transmitters intended to operate in a temporary frequency designation under the 24 GHz ECC decision CEPT/ECC/DEC/(04)10 [i.7], the EU Commission decision on 24 GHz SRR 2005/50/EC [i.1] and the amendment as presented in RSCOM11-07 21 [i.8].
The operating frequency range for intentional UWB emissions with at least 500 MHz bandwidth in the 22,000 GHz to 26,65 GHz range until 30th June 2013 as given in annex D and from 24,25 GHz to 26,65 GHz until 1st January 2018 as given in annex E. However, the date of 1 January 2018 will be extended by 4 years for automotive short-range radar equipment mounted on motor vehicles for which a type approval application has been submitted pursuant to Article 6(6) of Directive 2007/46/EC [6] and has been granted before 1 January 2018.
The present document applies to:
a) Transmitters in the range from 22,000 GHz to 26,65 GHz operating as UWB devices over the specific bandwidth defined for the individual devices.
b) Receivers operating in the range from 22,000 GHz to 26,65 GHz.
c) Integrated transceivers.
The present document contains the technical characteristics and test methods for short range radar equipment fitted with integral antennas.
The present document does not necessarily include all the characteristics which may be required by a user, nor does it necessarily represent the optimum performance achievable.
The present document covers short range radar mobile applications. The present document covers only SRR equipment for road vehicles.
The present document complies with field limits for human exposure to electromagnetic fields as provided by the EC Recommendation 1999/519/EC [i.2] and the methods for compliance demonstration in EN 50371 [i.3].
Elektromagnetna združljivost in zadeve v zvezi z radijskim spektrom (ERM) - Naprave kratkega dosega - Cestna transportna in prometna telematika (RTTT) - Oprema za radar kratkega dosega, ki deluje v frekvenčnem območju 24 GHz - 1. del: Tehnične zahteve in merilne metode
Ta dokument določa tehnične zahteve in merilne metode za naprave kratkega dosega (SRD), ki delujejo kot ultra širokopasovne naprave s pasovno širino vsaj 500 MHz v frekvenčnem območju od 22,000 GHz do 26,65 GHz, ki je namenjen napravam za cestno transportno in prometno telematiko (RTTT), kot je avtomobilski radar kratkega dosega (SRR) s frekvenco 24 GHz, na primer za zaznavanje ovir, zagotavljanje funkcije »ustavi in spelji«, zaznavanje mrtvih točk, pomoč pri parkiranju, podporo, opozarjanje na nesreče in druge avtomobilske naprave.
Ta dokument zajema oddajnike, ki so namenjeni delovanju pri začasno določeni frekvenci 24 GHz v skladu s sklepom Odbora za elektronske komunikacije CEPT/ECC/DEC/(04)10 [i.7], Odločbo Komisije 2005/50/ES [i.1] o uporabi radarjev kratkega dosega 24 GHz in spremembo iz dokumenta RSCOM11-07 21 [i.8].
Frekvenčno območje delovanja za namerne emisije UWB s pasovno širino vsaj 500 MHz v območju od 22,000 GHz do 26,65 GHz se uporablja do 30. junija 2013, kot je navedeno v dodatku D, v območju od 24,25 GHz do 26,65 GHz pa do 1. januarja 2018, kot je navedeno v dodatku E. Vendar bo datum 1. januar 2018, ki velja za avtomobilsko radarsko opremo kratkega dosega, nameščeno na motorna vozila, za katera je bila vloga za homologacijo vložena v skladu s členom 6(6) Direktive 2007/46/ES [6], pri čemer je bila vloga odobrena pred 1. januarjem 2018, podaljšan za 4 leta.
Ta dokument se uporablja za:
a) Oddajnike v območju od 22,000 GHz do 26,65 GHz, ki delujejo kot ultra širokopasovne naprave v določeni pasovni širini, opredeljeni za posamezne naprave.
b) Sprejemnike, ki delujejo v območju od 22,000 GHz do 26,65 GHz.
c) Integrirane oddajnike in sprejemnike.
Ta dokument vsebuje tehnične karakteristike in preskusne metode za radarsko opremo kratkega dosega, opremljeno z vgrajenimi antenami.
Ta dokument ne vključuje nujno vseh karakteristik, ki bi jih lahko potreboval uporabnik, in ne predstavlja nujno najboljšega mogočega delovanja.
Ta dokument zajema mobilne aplikacije za radar kratkega dosega. Ta dokument zajema le radarsko opremo kratkega dosega za cestna vozila.
Ta dokument je skladen s terenskimi omejitvami izpostavljenosti elektromagnetnim poljem, kot je določeno v priporočilu Sveta 1999/519/ES [i.2], in z metodami za dokazovanje skladnosti iz standarda EN 50371 [i.3].
