FDIS prEN/ISO 1288-5
Glass in building — Determination of the bending strength of
glass — Part 5: Coaxial double ring test on flat specimens with
small or medium test surface areas
1 Scope
This International Standard specifies a method for determining the comparative bending strength of glass for use in
buildings, excluding the effects of the edges.
NOTE See 5.1.4 in ISO 1288-1 for an explanation as to why this test method should only be used for comparing the
strength of types of glass, and not for assessing strength for design purposes.
The limitations of this part of this International Standard are described in ISO 1288-1.
ISO 1288-1 should be read in conjunction with this part of this International Standard.
This test method is not suitable for patterned glass.
2 Normative references
The following normative documents contain provisions which, through reference in this text, constitute provisions of
this part of ISO 1288. For dated references, subsequent amendments to, or revisions of, any of these publications
do not apply. However, parties to agreements based on this part of ISO 1288 are encouraged to investigate the
possibility of applying the most recent editions of the normative documents indicated below. For undated
references, the latest edition of the normative document referred to applies. Members of ISO and IEC maintain
registers of currently valid International Standards.
ISO 48, Rubber, vulcanised or thermoplastic - Determination of hardness (hardness between 10 IRHD and 100 IRHD)
ISO 1288-1, Glass in building - Determination of the bending strength of glass - Part 1: Fundamentals of testing glass
ISO 16293-1: Glass in building – Basic soda lime silicate glass products – Part 1: Definitions and general physical
and mechanical properties
3 Terms and definitions
For the purposes of this part of ISO 1288, the following terms and definitions apply.
3.1
bending stress
the tensile bending stress induced in the surface of a specimen
NOTE For testing purposes, the bending stress should be uniform over a specified part of the surface.
-----------------
...
