INTERNATIONAL STANDARD ISO 3862-1:2001(E)
Rubber hoses and hose assemblies — Rubber-covered spiral-wire-
reinforced hydraulic types — Specification —
Part 1:
Oil-based fluid applications
1 Scope
This part of ISO 3862 specifies requirements for five types of spiral-wire-reinforced hydraulic hoses and hose
assemblies of nominal bore from 6,3 to 51. They are suitable for use with hydraulic fluids HH, HL, HM, HR and HV
in accordance with ISO 6743-4, at temperatures ranging from – 40 °C to + 100 °C for types 4SP and 4SH and
� 40 °Cto+120 °C for types R12, R13 and R15.
This part of ISO 3862 does not include requirements for end fittings. It is limited to requirements for the
performance of hoses and hose assemblies.
NOTE It is the responsibility of the user, in consultation with the hose manufacturer, to establish compatibility of the hose
with the fluid to be used.
2 Normative references
The following normative documents contain provisions which, through reference in this text, constitute provisions of
this part of ISO 3862. For dated references, subsequent amendments to, or revisions of, any of these publications
do not apply. However, parties to agreements based on this part of ISO 3862 are encouraged to investigate the
possibility of applying the most recent editions of the normative documents indicated below. For undated
references, the latest edition of the normative document referred to applies. Members of ISO and IEC maintain
registers of currently valid International Standards.
ISO 1402, Rubber and plastics hoses and hose assemblies — Hydrostatic testing
ISO 1817, Rubber, vulcanized — Determination of the effect of liquids
ISO 4671, Rubber and plastics hose and hose assemblies — Methods of measurement of dimensions
ISO 4672:1997, Rubber and plastics hoses — Sub-ambient temperature flexibility tests
ISO 6803, Rubber or plastics hoses and hose assemblies — Hydraulic pressure impulse test without flexing
ISO 6945, Rubber hoses — Determination of abrasion resistance of the outer cover
ISO 7326:1991, Rubber and plastics hoses — Assessment of ozone resistance under static conditions
ISO 8033:1991, Rubber and plastics hose — Determination of adhesion between components
© ISO 2001 – All rights reserved 1

---------------------- Page: 7 ----------------------

SIST ISO 3862-1:2004
ISO 3862-1:2001(E)
3 Classification
Five types of hose are specified, distinguished by their construction, working pressure and oil resistance:
� Type 4SP: medium-pressure hose with four plies of steel wire spiral
� Type 4SH: high-pressure hose with four plies of steel wire spiral
� Type R12: heavy-duty high-temperature medium-pressure hose with four plies of steel wire spiral
� Type R13: heavy-duty high-temperature high-pressure hose with multiple-steel-wire spiral
� Type R15: heavy-duty high-temperature extra-high-pressure hose with multiple-steel-wire spiral
NOTE Types R12, R13 and R15 are not subjected to abrasion resistance tests.
4 Materials and construction
4.1 Hoses
Hoses
...
