TECHNICAL SPECIFICATION ISO/TS 19321:2015(E)
Intelligent transport systems — Cooperative ITS —
Dictionary of in-vehicle information (IVI) data structures
1 Scope
This Technical Specification specifies the in-vehicle information (IVI) data structures that are required by
different ITS services (for example, refer to ISO/TS 17425 and ISO/TS 17426) for exchanging information
between ITS Stations. A general, extensible data structure is specified (see Clause 5). This is split into
structures called containers to accommodate current-day information (see Clause 6). Transmitted
information includes IVI such as contextual speed, road works warnings, vehicle restrictions, lane
restrictions, road hazards warnings, location-based services, re-routing, etc. The information in the
containers is organized in sub-structures called data frames and data elements which are described in
terms of its content (see Clause 7) and its syntax (see Annex A).
The data structures are specified as communications agnostic. This Technical Specification does not
provide the communication protocols. This Technical Specification then provides scenarios for usage of
the data structure, e.g. in case of real time, short-range communications.
2 Normative references
The following documents, in whole or in part, are normatively referenced in this document and are
indispensable for its application. For dated references, only the edition cited applies. For undated
references, the latest edition of the referenced document (including any amendments) applies.
ISO 639-1:2002, Codes for the representation of names of languages — Part 1: Alpha-2 code
ISO 3166-1, Codes for the representation of names of countries and their subdivisions — Part 1: Country codes
ISO 14816:2005, Road transport and traffic telematics — Automatic vehicle and equipment identification —
Numbering and data structure
ISO 14906:2011, Electronic fee collection — Application interface definition for dedicated short-range
communication
ISO/IEC 8824-1:2008, Information technology — Abstract Syntax Notation One (ASN.1): Specification of
basic notation
ISO/TS 14823, Traffic and travel information — Messages via media independent stationary dissemination
systems — Graphic data dictionary for pre-trip and in-trip information dissemination systems
ETSI/TS 102 894-2 V1.1.12, Intelligent Transport Systems (ITS); Users and applications requirements;
Part 2: Applications and facilities layer common data dictionary
3 Terms and definitions
3.1
application data unit
data unit exchanged between ITS-S applications
3.2
container
group of data frames (3.4) and data elements semantically belonging together in one place in the IVI structure
3.3
data element
data type that contains one single data
[SOURCE: ETSI/TS 102 894-2 V1.1.1]
3.4
data frame
data type that contains more than one data element (3.3) in a predefined order
[SOURCE: ETSI/TS 102 894-2 V1.1.1]
3.5
detection zone
part of the road network that is passed by a vehicle in approach of the relevance zone (3.12)
3.6
driver awareness zone
parts of road network on which a message is presented to inform drivers about upcoming situations
Note 1 to entry: This definition will be aligned with ISO/TS 17425.
3.7
in-vehicle information
information contained in the In-vehicle Information (IVI) data structure that is required by different
ITS services
3.8
in-vehicle signage
ITS service that provides static, as well as dynamic road sign and message sign information to drivers
Note 1 to entry: This definition will be aligned with ISO/TS 17425.
3.9
International Terrestrial Reference Frame
realisation of the ITRS
[SOURCE: ISO 17572-1:2008]
3.10
International Terrestrial Reference System
reference system for the earth derived from precise and accurate space geodesy measurements not
restricted to GPS Doppler measurements which is periodically tracked and revised by the International
Earth Rotation Service
[SOURCE: ISO 17572-1:2008]
3.11
Minimum Dissemination Area
parts of the road network where the IVS message can be received by the potentially targeted vehicles
Note 1 to entry: This definition will be aligned with ISO/TS 17425.
3.12
Relevance Zone
parts of the road network for which the information in an Application Container is valid
[SOURCE: ISO/TS 17425]
3.13
road hazard warning
ITS service that provides road hazard information to drivers
2 © ISO 2015 – All rights reserved

3.14
Road Works Warning
alerts for routing road users around road construction and/or road repair
3.15
Variable Message Sign
electronic sign board presenting text, symbols, or a combination of them
4 Abbreviated terms
The following abbreviations are used in this document.
ADR European Agreement concerning the International Carriage of Dangerous Goods by Road
ASN.1 Abstract Syntax Notation One
BLOB Binary Large Object
DAZ Driver Awareness Zone
DE Data Element
DENM Decentralized Environmental Notification Message
DF Data Frame
ETRF European Terrestrial Reference Frame
HOT High-Occupancy Toll (lane)
HOV High-Occupancy Vehicle
ID Identification
ITRF International Terrestrial Reference Frame
ITRS International Terrestrial Reference System
ITS Intelligent Transport Systems
ITS-S ITS Station
IVI In-vehicle Information
IVS In-vehicle Signage
MDA Minimum Dissemination Area
OEM Original Equipment Manufacturer
POI Point of Interest
RZ Relevance Zone
RWW Road Works Warning
VMS Variable Message Sign
5 In-vehicle Information (IVI) data structure
5.1 Structural model
5.1.1 General model
The IVI Structure represents the Application Data Unit to be transmitted and received by an ITS-
Station (ITS-S). The IVI Structure shall comply with the syntax defined in Annex A as the data type
IviStructure. This means that it shall be composed of Containers defined in this Technical
Specification and follow the form depicted in Figure 1.
Figure 1 — IVI Structure
The IVI Structure is extensible and other containers can be added in the future.
The IVI Structure is intended to be encapsulated in a message with the appropriate ITS Common Header,
for example, the ItsPduHeader of ETSI/TS 102 894-2. The header structure and contents are out of the
scope of this Technical Specification
The IVI Structure shall contain a Management Container. The information in the IVI Management Container
is applicable to the entire IVI Structure. This Container is mandatory to be present and provides a receiving
ITS-S with enough information to handle the IVI Structure and decide on its further processing.
The IVI Structure can contain one or more Location Container(s). The Location Container describes the
essential information for applications in the receiving ITS-S. Applications can use the location information
to understand how to apply information provided by IVI Application Containers. Location Containers
can carry information relevant for different IVI Application Containers or carry the same content, but
expressed in different forms (see 5.2). This enables a receiving ITS-S to choose the appropriate location
referencing system that the ITS-S supports.
The IVI Structure can contain one or more IVI Application Container(s). The IVI Application Container
provides IVI information for use by an application. Application information is self-contained and refers
to the location information for its spatial validity. Application information of the same type shall not
refer to overlapping Reference Zones. Each Application Container refers to zones defined in the Location
Container identified by their IDs for the following usage: 1) Detection Zone, 2) Relevance Zone, and
3) Driver Awareness Zone. An Application Container may optionally provide information about the
minimum awareness time, that is, the minimum time that the IVI should be available before the vehicle
enters the Relevance Zone. This MinimumAwarenessTime information can be used by the receiving
ITS-S to determine the appropriate Driver Awareness Zone.
5.1.2 Conceptual zones
When an ITS-S receives the IVI Structure, the ITS-S is able to interpret the application information in the
context of the appropriate location information. Principally, there are four conceptual zones:
1) Minimum Dissemination Area (MDA);
2) Detection Zone;
4 © ISO 2015 – All rights reserved

3) Driver Awareness Zone (DAZ);
4) Relevance Zone (RZ).
The MDA refers to the minimum area where the IVI Structure is disseminated by an ITS-S based on
application requirements. The MDA is defined in the relevant application standards or specification(s)
and is therefore out of scope of this Technical Specification.
In some situations, a vehicle ITS-S must be able to detect whether or not it is approaching a Relevance
Zone at a certain minimum time before it enters the Relevance Zone. This is, for example, to guarantee
that the Relevance Zone is detected immediately at its entry (e.g. in case of a very small Relevance Zone)
or to guarantee that the Relevance Zone is correctly detected (in case it is near to other road segments,
e.g. parallel or on different altitude level). Therefore, a Detection Zone occurs in approach to a Relevance
Zone. If a receiving ITS-S moves through the Detection Zone, then the received IVI will be enabled for
further usage in the receiving ITS-S.
The IVI can be used to inform drivers about upcoming situations in the DAZ. The DAZ can be determined
by the receiving ITS-S because the DAZ can be based on the dynamic status of the receiving ITS-S and
can depend on the presence of other higher priority information to be presented. Alternatively, the DAZ
can be provided by the sending ITS-S for usage by the receiving ITS-S.
The final zone and the Relevance Zone covers the area where the IVI is applicable.
Examples of the Detection and Relevance Zones for the spatial validity of the IVI Structure are illustrated
in Figure 2. The Driver Awareness Zone (outside the scope of this Technical Specification) can be
physically overlapping with the Detection Zone (but is not necessarily equal in size).
Key
minimum dissemination area (not transmitted)
detection zone
driver awareness zone
relevance zone
Figure 2 — Spatial validity for IVI: Detection and Relevance Zones
The Location Container always contains a definition of one or more zones which can represent a Detection
Zone, a Relevance Zone, or both. In Figure 2, from left to right, the first zone represents a Detection Zone
and the second zone represents a Relevance Zone.
In Figure 3, from left to right, the first zone represents a Detection Zone. The second zone then represents
Relevance Zone 1, but this same zone also serves as a Detection Zone for Relevance Zone 2.
Figure 3 — Concatenated Relevance Zones
5.2 Location referencing
5.2.1 General
There are essentially two different ways of referencing road locations. It is called map-based location
referencing in this Technical Specification when referencing attributes of the road network itself. It is
called geographic location referencing in this Technical Specification when referencing a regular or
irregular division of space which exists independent of the representation of the road network.
5.2.2 Geographic positioning
Geographic location systems or coordinate systems are location maps composed of imaginary,
intersecting lines forming a grid. Coordinate values of the grid, expressed as numeric or alphanumeric
characters, are used to describe a position.
To translate position data expressed in longitude, latitude, and height to the corresponding real position
on earth or vice-versa, the earth-centred, earth-fixed, polar-coordinate geodetic datum WGS84 (G1150)
according to NIMA TR8350.2 Version 3 shall be used. Alternatively, any earth-centred, earth-fixed polar
coordinate geodetic datum can be used as long as the maximum datum displacement relative to the geodetic
datum agreed on, or relative to WGS84 (G1150) in case of no agreement, is acceptable to the application.
NOTE A suggested tolerance of 0.3 meters in datum displacement (also called datum shift) is intended, for
example, to allow for using the International Terrestrial Reference Frame (ITRF) or the European Terrestrial
Reference Frame (ETRF) geodetic datum as alternative to the WGS84. Datum displacements are suggested to be
calculated according to the definitions in ASME Y14.5 – 2009.
An ITS-S sending an IVI Structure provides one or more Reference Point(s). The Reference Point can be
the reference for the description of a static zone or a dynamic (moving) zone. The zone can be described
by a polygonal line which delineates a segment or an area, or can be described by a distance value
indicating the extension of the relevance zone from the Reference Position and the heading relative to
the Reference Position.
The detection zone can optionally be provided as a polygonal line in approach to the Reference Position.
If the Reference Position is the position of a moving object, the polygonal line is represented by the last
positions of the path of the moving object (e.g. the trace of a roadworks vehicle).
Determining the relevance of IVI is carried out by referencing the location of a receiving ITS-S relative
to a reference in a coordinate-based system.
6 © ISO 2015 – All rights reserved

As a vehicle progresses, its motion creates a series of points. The series, when assembled as a set, trace
the path of the vehicle. The path enables a receiving ITS-S to detect the applicability of a Relevance Zone
and the approach into a Relevance Zone.
5.2.3 Map-based location referencing
Determining the relevance of IVI can also be carried out by referencing the location of a receiving ITS-S
relative to a map reference (refer to ISO 17572-1). This can be a global map available in the receiving
ITS-S or it can be a local map distributed in the same dissemination area as IVI.
Map-based location referencing can be incorporated in future revisions of this Technical Specification.
6 IVI Containers
6.1 IVI Management Container
6.1.1 Definition
IVI Management Container contains information regarding the management of the IVI Structure which
supports the receiving ITS-S to deal with the lifecycle of the IVI. It includes information which allows
receiving ITS stations to identify further processing. Table 1 describes the contents for inclusion in the
IVI Management Container. The syntax is defined in Annex A as mandatory component of the data type
IviStructure.
Table 1 — IVI Management Container
a
Container Component M/O Description
serviceProviderId
IVI Management M Identifies the organization that provided the IVI
Container by using the DE Provider; contains a country
code according to ISO 3166-1. Numbers shall be
assigned on national basis. See ISO 14816 for
registration.
iviIdentificationNumber
M Identifier of the IVI Structure, as assigned by the
Service Provider using the DE
IviIdentificationNumber.
timestamp
O Timestamp of the generation or last change of
information content.
validFrom
O Start time of the validity period of the message.
validTo
O End time of the validity period of the message.
connectedIviStructures
O List of other iviIdentificationNumber
identifying other IVI Structures of the same
authority which are connected to the IVI
Structure using the DE
IviIdentificationNumber.
iviStatus
M Status of the IVI Structure using the DE
IviStatus.
a
Mandatory (M) shall be included in the container. Optional (O) may be included in the container.
6.1.2 Usage — IVI Management Container
The sending ITS-S shall include the component serviceProviderId, iviIdentificationNumber,
and can include the component timeStamp. The organization providing the IVI (e.g. the Service
Provider, as defined in ISO/TS 17427) should apply for a serviceProviderId.
NOTE 1 For detailed information, see http://www.itsstandards.eu/index.php?option=com_
content&view=article&id=186&Itemid=151
The iviIdentificationNumber in the IVI Management Container is assigned by the Service Provider
and should be retained as long as the IVI Structure exists throughout its various updates and changes.
The component timeStamp should identify different versions of the IVI Structure due to updates
managed by the Service Provider. This component should be included if the sending ITS-S foresees to
send updates of the IVI Structure.
The sending ITS-S can include the components validFrom and validTo.
The sending ITS-S shall include the component iviStatus.
The optional components validFrom and validTo indicate the overall validity of the IVI Structure as
provided by the service provider. If validFrom is not present, the IVI Structure is valid when received.
If validTo is not present, no information about the expiration of the information is given.
A receiving ITS-S should check whether the status of the IVI Structure is any one of the following:
— new, that is, if the iviStatus is “new” and/or if the combination of serviceProviderId and
iviIdentificationNumber is different from other received messages;
— update of a received IVI Structure, that is, if the iviStatus is “update” and/or if the combination of
serviceProviderId and iviIdentificationNumber equals to those from another received
structure and the timestamp is more recent;
— duplicate of a received structure, that is, if the iviStatus is “update” and/or if the combination of
serviceProviderId and iviIdentificationNumber equals to those from another received
structure and the timestamp is the same;
— cancellation, that is, if the iviStatus is “cancellation”;
— negation, that is, if the iviStatus is “negation”.
The definition of any actions for IVI handling based on the status and validity of the IVI Structure is
outside the scope of this Technical Specification.
The Service Provider can divide the IVI in structures of appropriate size in relation to the capabilities of
the communication technology and connect those IVI Structures belonging together.
A sending ITS-S can include the component connectedIviStructures to connect the IVI Structure
to other IVI Structures provided by the same Service Provider that have been transmitted previously or
by other ITS-S.
EXAMPLE Vehicles to which special regulations apply (such as heavy vehicles) may need to observe national
regulations rather than a specific contextual regulation in place (e.g. a limitation to 100 km/h due to congestion
does not apply to heavy vehicles which must observe the national limit of 80 km/h). For this purpose, the IVI
Structure transmitted for contextual speed purposes can be connected to a different IVI carrying the national
speed regulation in force for all vehicles.
NOTE 2 The identification of the ITS-S (ITS-S ID) is not contained in the IVI Management Container because it
is protocol layer information which is contained, for example, in the ITS PDU Header. Additionally, since the IVI
Structure can be signed at the Service Provider before transmission, it is not possible to add the ID of the sending
ITS-S to the IVI Structure.
6.2 IVI Location Container
6.2.1 General
The IVI Structure can include several Location Containers. The Location Container contains information
on the zones to support the Application Containers.
8 © ISO 2015 – All rights reserved

6.2.2 Geographic Location Container
6.2.2.1 Definition
The Location Container is built up of a common content that provides information about the
common Reference Position and the repetition of n parts which define the zones with reference to
that Reference Position. Having in common only the Reference Position, the zones can be defined
independently from each other.
The data elements for inclusion in the Location Container are described in Table 2. The syntax is then
defined in Annex A as the data type GeographicLocationContainer.
Table 2 — Geographic Location Container
a
Container parts Component M/O Description
referencePosition
Common location M Any suitable position which serves as reference for
Container content the polygonal line, using the DE
ReferencePosition.
referencePositionTime
O Time at which the Reference Position, if dynamic,
was valid.
referencePositionHead-
O Direction of the Reference Position, if dynamic,
ing
using the DE Heading.
referencePositionSpeed
O Actual speed of the Reference Position, if dynamic,
using the DE Speed.
zoneId
Location M Identifier of the definition of the zone, using the DE
Container Part Zid.
(n parts)
laneNumber
O Identification of the lane represented by the
Location Container using the DE LaneNumber.
zoneExtension
O Extension of the zone as a circular area around the
Reference Position in 10m units.
zoneHeading
O Applicable heading of the zone, e.g. the effective
direction of applicability of the sign, at the
Reference Position, using the DE Heading.
zone
O Definition of a zone using the DF Zone.
a
Mandatory (M) shall be included in the container. Optional (O) may be included in the container.
6.2.2.2 Usage
The sending ITS-S shall define, in one or more of the Location Container(s), the zones referred to by
the Application Containers. All definitions of zones that are based on the sa
...
