International Standard ISO 24120-3:2025(en)
Agricultural irrigation equipment — Guidelines on the
implementation of pressurized irrigation systems —
Part 3:
Sprinkler irrigation
1 Scope
This document provides guidelines for the implementation of pressurized sprinkler, micro-sprinkler and
sprayer irrigation systems [hereinafter: system(s)]. It is applicable to both small-scale family agriculture
and large-scale commercial agriculture, in open field or within protected crops structure (e.g., greenhouse,
net-house or tunnel).
This document is intended for the use of agriculture ministries, agronomists, irrigation planners, farmers
and end-users.
This document is not applicable to centre pivots, linear systems, travellers, and side roll sprinkler
irrigation systems.
2 Normative references
There are no normative references in this document.
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminology databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at https:// www .electropedia .org/
3.1
sprinkler
water distribution device of a variety of sizes and types, for example, impact sprinklers, fixed nozzle,
sprayers and irrigation guns
3.2
micro-sprinkler
sprinkler that distributes water in a dynamic or static way, either in circular area or part circular area, with
a flow rate not exceeding 200 l/h
3.3
sprayer
device that discharges water in the form of fine jets or in a fan shape, with or without rotational movement
of its parts
3.4
riser
upright pipe, which is either rigid or flexible

3.5
irrigation lateral
branch supply line in an irrigation system, on which distribution devices are mounted directly or by means
of fittings, riser, or tubes
[1]
[SOURCE: ISO 15886-3:2021 ]
3.6
riser base
structure that connects a riser and an irrigation lateral
3.7
tube
pipe that connects an irrigation lateral to a sprinkler or a micro-sprinkler
3.8
water application rate
mean depth of water applied per unit time
[SOURCE: ISO 15886-3:2021]
3.9
water distribution uniformity
calculation that expresses the distribution of water in a field
3.9.1
distribution uniformity
DU
coefficient using the lowest 25 % of water application depths to characterize the uniformity of field-measured
or simulated water application from a grid of sprinklers
[2]
[SOURCE: ISO 15886-4:2019 ]
3.9.2
Christiansen's uniformity coefficient
UCC
coefficient using deviations from the mean, to characterize the uniformity of field-measured or simulated
water application from a grid of sprinklers
[SOURCE: ISO 15886-3:2021]
3.9.3
scheduling coefficient
SC
coefficient used to characterize the water application uniformity of sprinklers, employing an analysis of
full-grid test data based on a definition of critical dry area
3.10
soil infiltration rate
rate at which soil absorbs rainfall or irrigation water
3.11
head loss
reduction in total energy of fluid as it flows through a pipeline or any other hydraulic system
Note 1 to entry: See also Annex A.
3.12
pressure loss
difference in pressure, due to water flow, between two specified points in a system or in part of a system
Note 1 to entry: See also Annex A.

[3]
[SOURCE: ISO 9644:2018 ]
3.13
evaporation
process by which water droplets change from liquid state to vapour state
3.14
flow rate
volume of water flowing through a device per unit time
[SOURCE: ISO 15886-3:2021]
4 Micro-sprinkler irrigation — Micro-sprinklers, sprayers, misters, foggers
4.1 Agricultural applications of micro-sprinklers
4.1.1 General
Micro-sprinklers are used for the following applications:
— Applications in orchards – Irrigation, frost mitigation, cooling, crop protection.
— Applications in protected crops, such as greenhouse crops, tunnel crops and net-house crops – Irrigation,
germination, rooting, cooling, humidification, soil preparation, cleaning roof and side nets.
For each application, the adequate device which provides the appropriate performance should be selected
according to the manufacturer's recommendations.
— Micro-sprinklers with relatively small droplet size are used for germination.
— Misters and foggers are used for cooling, humidification and rooting.
4.1.2 Micro-sprinkler selection principles
When selecting a micro-sprinkler, the following should be considered:
— crops' needs;
— soil types;
— farmer's objectives;
— layout of the field;
— topography of the field;
— required field application.
4.2 Control head
4.2.1 General
The control head should include: manual valve, air relief valve, hydraulic valve, water meter, pressure gauge,
pressure regulator, filters, controller, fittings and other components, according to their main function. See
[4]
also ISO 11738 .
4.2.2 Water meters
Water meters provide information on water flow rate, which is essential for irrigation scheduling, and
monitoring micro-sprinkler clogging.

[5]
To detect clogging or leaks in the system, the flow rate should be checked often. See also ISO 16399 .
4.2.3 Valves
4.2.3.1 General
Water flow rate and pressure throughout the system should be precisely controlled to ensure efficient and
timely water application. Therefore, valves should be properly selected and installed.
Valves play key roles in controlling pressure and flow under different conditions, in optimizing performance,
facilitating management, and reducing maintenance requirements.
It is not recommended to use oversized valves – due to reduction in flow velocity, or to use undersized valves
– due to restriction of flow rate and resulting excessive pressure loss.
4.2.3.2 Types of valves used in the system
4.2.3.2.1 Manual control valve
The following common types of manual control valves are used in the system.
a) Ball valve
A ball valve is a quarter-turn valve. In a ball valve, the closing mechanism is a sphere (ball) with a port
through the middle, connected to a lever in line with it that shows the valve's position. Rotating the lever
turns the ball so that when the port is in line with the pipe, flow will occur, and when perpendicular to the
pipe, flow is blocked.
b) Butterfly valve
A butterfly valve is a quarter-turn valve. Its operation is similar to that of a ball valve. The closing mechanism
takes the form of a disc positioned in the centre of the valve. A rod, connected to a lever or a wheel, passes
through the middle of the disc, rotates the lever, turning the disc either parallel or perpendicular to the flow.
Unlike a ball valve, the disc in a butterfly valve is always present within the flow, therefore a slight pressure
drop is always induced in the flow, regardless of valve position.
c) Gate valve
Gate (sluice) valve opens by lifting a gate (wedge) out of the path of the fluid. When the gate valve is fully
open, there is no obstruction in the flow path, resulting in very low friction loss.
The gate valve is designed to be fully opened or closed and may not be used to regulate the flow.
d) Globe valve
The globe valve is operated by screw action using a handwheel, and may be used to regulate the flow or the
pressure with minimum friction loss.
It consists of a movable disc plug aligned with a fixed ring located in the stream.
4.2.3.2.2 Check valve (non-return valve)
4.2.3.2.2.1 General
The function of a check valve is to prevent water flow in the opposite direction to that desired.
It serves various purposes.
— When installed at the outlet of a pump that pumps water to a field at a higher elevation, it protects the
pump from the back wave of water hammer.

— When installed at the outlet of a filter, which conveys water to a higher field, it prevents water from
flowing back through the system's head components.
— In irrigation systems, when installed upstream from a dosing unit, it prevents fertilizers and chemicals
infiltration into the water source.
— When installed on the inlet pipe of a pump, as a foot valve, it enables priming of the inlet pipe.
4.2.3.2.2.2 Backflow prevention valve
Backflow is the undesirable reversal of flow of a liquid into the drinking water supply system. A backflow
preventer is designed to keep this from happening.
Reduced pressure zone backflow preventer (RPZ) is used to prevent water with fertilizers or any other
chemicals from flowing back into the drinking water supply system.
4.2.3.2.3 Hydraulically operated, diaphragm-actuated control valves
Hydraulically operated, diaphragm-actuated control valves may serve different purposes, according to the
layout of the valve's control loop.
The following common types of hydraulically operated, diaphragm-actuated control valves are used in the
system.
a) Hydraulic control valve
Hydraulic control valve opens and shuts off in response to a local or remote pressure command.
b) Pressure reducing valve (PRV)
PRV reduces higher upstream pressure to lower preset downstream pressure, regardless of fluctuating
demand, and opens fully upon line pressure drop. For optimal operation, the pressure ratio across a PRV
should not be higher than 1:4.
c) Pressure sustaining valve
Pressure sustaining valve can fulfil either of two separate functions:
— When installed in-line, it sustains minimum preset upstream pressure, regardless of fluctuating flow or
varying downstream pressure.
— When installed as a circulation valve, it relieves line pressure in excess of preset.
d) Pressure reducing and sustaining valve
Pressure reducing and sustaining valve can fulfil two independent functions at the same time.
It sustains minimum preset upstream pressure, regardless of fluctuating flow or varying downstream
pressure, and it prevents downstream pressure from rising above maximum preset, regardless of fluctuating
flow or excessive upstream pressure.
e) Pressure relief valve
Pressure relief valve relieves excessive line pressure when it rises above the preset maximum. It responds to
a rise in system pressure immediately, accurately and with high repeatability, by opening fully.
f) Surge anticipating valve
Surge anticipating valve is an off-line valve, sensing line pressure. It opens in response to pressure drop
associated with abrupt pump stoppage. The pre-opened valve dissipates the returning high pressure wave,
eliminating surge. This valve also relieves excessive system pressure.

4.2.3.2.4 Booster pump control valve
Booster pump control valve is a double chambered, active check valve, that opens fully or shuts off in
...
