INTERNATIONAL STANDARD ISO 12030:2010(E)

Tobacco and tobacco products — Non-destructive
determination of strips density variation ratio in case —
Ionizing radiation method
1 Scope
This International Standard specifies a method for determining density variation ratio (DVR) of strips in the
case.
2 Normative references
The following referenced documents are indispensable for the application of this document. For dated
references, only the edition cited applies. For undated references, the latest edition of the referenced
document (including any amendments) applies.
ISO 6488, Tobacco and tobacco products — Determination of water content — Karl Fischer method
ISO 16632, Tobacco and tobacco products — Determination of water content — Gas-chromatographic
method
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
3.1
non-destructive determination
determination without any damage to the objects under study
3.2
density variation ratio
DVR
relative standard deviation of the strips density in case
4 Principle
The X-rays penetrate the tobacco strips in the case and lose their intensity depending on the density of the
strips. The measured intensity of X-rays can thus be related to strips density according to Equation (1).
1 I
i
ρ =− ln (1)
Ud××I B
m0
© ISO 2010 – All rights reserved 1

---------------------- Page: 6 ----------------------
ISO 12030:2010(E)
where
ρ i
...
