INTERNATIONAL STANDARD ISO 4152:2021(E)
Glass‐reinforced thermosetting plastics (GRP) pipes —
Determination of the apparent axial long‐term modulus of
pipes subject to beam bending
1 Scope
This document specifies a method for determining the apparent axial long-term modulus of pipes
subject to beam bending deflection between vertically supported end-couplers, which allow rotation of
the pipe relative to the couplers.
In conjunction with ISO 10928, this document expresses the results of the test as an apparent axial
long-term modulus for use in the calculation of mid-span beam deflection and end rotation of GRP pipes
as specified in ISO/TS 10986.
Test conditions and requirements are specified in the referring standard.
For practical reasons, the test method is not suited for diameters greater than DN 600.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated referenc
...
