INTERNATIONAL STANDARD ISO 10300-3:2023(E)
Calculation of load capacity of bevel gears —
Part 3:
Calculation of tooth root strength
1 Scope
This document specifies the fundamental formulae for use in the tooth root stress calculation of straight
and helical (skew), Zerol and spiral bevel gears including hypoid gears, with a minimum rim thickness
under the root of 3,5 m . All load influences on tooth root stress are included, insofar as they are the
mn
result of load transmitted by the gearing and able to be evaluated quantitatively. Stresses, such as those
caused by the shrink fitting of gear rims, which are superposed on stresses due to tooth loading, are
intended to be considered in the calculation of the tooth root stress, σ , or the permissible tooth root
F
stress σ . This document is not applicable in the assessment of tooth flank fracture.
FP
The formulae in this document are based on virtual cylindrical gears and restricted to bevel gears
whose virtual cylindrical gears have transverse contact ratios of ε < 2. The results are valid within the
vα
range of the applied factors as specified in ISO 10300-1. The bending strength formulae are applicable
to fractures at the tooth fillet, but not to those on the active flank surfaces, to failures of the gear rim or
of the gear blank through the web and hub.
3
This document does not apply to stress levels above those permitted for 10 cycles, as stresses in that
range can exceed the elastic limit of the gear tooth.
NOTE This document is not applicable to bevel gears which have an inadequate contact pattern under load.
The user is cautioned that when the formulae are used for large average mean spiral angles
(β + β )/2 > 45°, for effective pressure angles α > 30° and/or for large facewidths b > 13 m , the
m1 m2 e mn
calculated results of this document should be confirmed by experience.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 701, International gear notation — Symbols for geometrical data
ISO 1122-1, Vocabulary of gear terms — Part 1: Definitions related to geometry
ISO 6336-5, Calculation of load capacity of spur and helical gears — Part 5: Strength and quality of
materials
ISO 10300-1:2023, Calculation of load capacity of bevel gears — Part 1: Introduction and general influence
factors
ISO 10300-2:2023, Calculation of load capacity of bevel gears — Part 2: Calculation of surface durability
(macropitting)
ISO 17485, Bevel gears — ISO system of accuracy
ISO 23509:2016, Bevel and hypoid gear geometry
1
© ISO 2023 – All rights reserved

---------------------- Page: 6 ----------------------
ISO 10300-3:2023(E)
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 1122-1, ISO 23509 and the
following apply.
ISO and IEC maintain terminology databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at https:// www .electropedia .org/
3.1
tooth root breakage
failure of gear teeth at the tooth root by static or dynamic overload
3.2
nominal tooth root stress
σ
F0
bending stress in the critical section of the tooth root calculated for the critical point of load application
for error-free gears loaded by a constant nominal torque
3.3
tooth root stress
σ
F
determinant bending stress in the critical section of the tooth root calculated for the critical point of
load application including the load factors which consider static and dynamic loads and load distribution
3.4
nominal stress number
σ
F,lim
maximum tooth root stress of standardized test gears and determined at standardized operating
conditions as specified in ISO 6336-5
3.5
allowable stress number (bending)
σ
FE
maximum bending stress of the un-notched test piece under the assumption that the material is fully
elastic
3.6
permissible tooth root stress
σ
FP
maximum tooth root stress of the evaluated gear set including all influence factors
4 Symbols, general subscripts and abbreviated terms
For the purposes of this document, the symbols given in ISO 701, ISO 17485, ISO 23509, and the
following shall apply.
Table 1 — Symbols
Symbol Description or term Unit
a Auxiliary value —
BS
b Facewidth mm
b Developed length of one tooth as facewidth of the calculation model mm
a
b Auxiliary value —
BS
b Calculated effective facewidth mm
ce
b Mean facewidth mm
k
2
  © ISO 2023 – All rights reserved

---------------------- Page: 7 ----------------------
ISO 10300-3:2023(E)
TTabablele 1 1 ((ccoonnttiinnueuedd))
Symbol Description or term Unit
b Facewidth of virtual cylindrical gears mm
v
b Relative facewidth of virtual cylindrical gear pair —
v,rel
C Conversion factor used in Formula (202), C = 25,4 mm mm
mm mm
c Auxiliary value —
BS
d Tip diameter of virtual cylindrical gear in normal section mm
van
d Base diameter of virtual cylindrical gear in normal section mm
vbn
E, G, H Auxiliary quantities for tooth form factor (method B1) —
F Nominal tangential force at mid-facewidth of the reference cone N
mt
F Nominal tangential force of virtual cylindrical gears N
vmt
g Relative length of action to point of load application (method B2) —
J
g Auxiliary term mm
f0
g Relative distance from blade edge to centre line —
rb
g Relative length of action in normal section —
vαn
g Relative length of action in normal section for hypoid gears —
vαn,hyp
g Auxiliary term —
xb
g Auxiliary term —
yb
g Auxiliary term —
za
g Auxiliary term —
zb
g Relative length of action within the contact ellipse —
η
g Auxiliary term —
0
g Intermediate value mm
1
h Tool addendum mm
a0
h Bending moment arm for tooth root stress (load application at tooth tip) mm
Fa
h Mean dedendum mm
fm
h Mean whole depth used for bevel spiral angle factor mm
m
h Relative load height from critical section (method B2) —
N
h Relative mean virtual dedendum —
vfm
h Auxiliary values —
1,2,3,4
K Application factor —
A
K Transverse load factor for bending stress —
Fα
K Face load factor for bending stress —
Fβ
K Dynamic factor —
v
k' Contact shift factor —
L Factor to calculate the stress correction factor according to Dolan and Broghamer —
L Auxiliary value —
a,D,C
l Part of the model’s facewidth covered by the contact line mm
bb
l Theoretical length of middle contact line mm
bm
M Factor to calculate the stress correction factor according to Dolan and Broghamer —
m Outer transverse module mm
et
m Mean normal module mm
mn
m Mean transverse module mm
mt
N Number of load cycles —
L
O Factor to calculate the stress correction factor according to Dolan and Broghamer —
q Notch parameter —
s
3
© ISO 2023 – All rights reserved

---------------------- Page: 8 ----------------------
ISO 10300-3:2023(E)
TTabablele 1 1 ((ccoonnttiinnueuedd))
Symbol Description or term Unit
R Relative radius from tool centre to critical pinion coast side fillet point —
CL2
R Relative radius from tool centre to critical pinion drive side fillet point —
DL2
R Mean cone distance mm
m
Rz Mean roughness μm
r Relative pinion radius to fillet point —
L1o
r Relative wheel radius to pinion fillet point —
L2o
r Relative tooth fillet radius at the root in mean section —
mf
r Mean pitch radius mm
mpt
r Mean transverse radius to point of load application (method B2) mm
my0
r Relative mean virtual tip radius —
va
r Relative mean virtual pitch radius —
vn
Relative distance from pitch circle to the pinion point of load application and the
Δr —
y0
wheel tooth centre line
S Safety factor for bending stress (against tooth root breakage) —
F
S Minimum safety factor for bending stress —
F,min
s Tooth root chord in calculation section mm
Fn
s Relative horizontal distance from centreline to critical fillet point (method B2) —
N
s Mean normal circular thickness mm
mn
s Amount of protuberance mm
pr
s Relative virtual tooth thickness —
vmn
W Wheel mean slot width mm
m2
x Profile shift coefficient —
hm
x Thickness modification coefficient —
sm
x Tooth strength factor (method B2) —
N
x Distance from mean section to point of load application mm
oo
x Relative horizontal distance from pitch circle to fillet point —
1
Y Root stress adjustment factor (method B2) —
A
Y Bevel spiral angle factor —
BS
Y Tooth form factor for load application at the tooth tip (method B1) —
Fa
Y Combined tooth form factor for generated gears —
FS
Y Stress concentration and stress correction factor (method B2) —
f
Y Bending strength geometry factor (method B2) —
J
Y Load sharing factor (bending) —
LS
Y Life factor (bending) —
NT
Y Combined geometry factor (method B2) —
P
Y Surface condition at the root fillet —
R
Y Surface condition at the test gear —
RT
Y Relative surface condition factor —
R,relT
Y Stress correction factor for load application at the tooth tip —
Sa
Y Stress correction factor for dimensions of the standard test gear —
ST
Y Size factor for tooth root stress —
X
Y Tooth form factor of pinion and wheel (method B2) —
1,2
Y Relative notch sensitivity factor —
δ,relT
Y Contact ratio factor for bending (method B1) —
ε
4
  © ISO 2023 – All rights reserved

---------------------- Page: 9 ----------------------
ISO 10300-3:2023(E)
TTabablele 1 1 ((ccoonnttiinnueuedd))
Symbol Description or term Unit
Relative location of point of load application for maximum bending stress on path
y —
J
of action (method B2)
y Relative vertical distance from pitch circle to fillet point —
1
Relative distance from the beginning of the path of action to the point of load
y —
3
application on path of action for maximum root stress
Z Load sharing factor (method B1) —
LS
z Number of teeth of virtual cylindrical gear in normal section —
vn
α Coast flank pressure angle in wheel root coordinates °
Cnf
α Drive flank pressure angle in wheel root coordinates °
Dnf
α Load application angle at tooth tip of virtual cylindrical gear (method B1) °
Fan
α Normal pressure angle at point of load application (method B2) °
L
α Generated pressure angle at fillet point °
LN
α Adjusted pressure angle (method B2) °
a
α Normal pressure angle at tooth tip °
an
α Effective pressure angle for drive side/coast side °
eD,C
α Limit pressure angle in wheel root coordinates (method B2) °
f
α Auxiliary term °
h
α Limit pressure angle °
lim
α Generated pressure angle for drive side/coast side °
nD,C
β Intermediate angle °
a
β Helix angle of virtual gear (method B1), virtual spiral angle (method B2) °
v
β Helix angle at base circle of virtual cylindrical gear °
vb
γ Auxiliary angle for tooth form and tooth correction factor °
a
ε Load sharing ratio for bending (method B2) —
N
ε Lengthwise load sharing factor —
b
ε Profile load sharing factor —
f
ε Transverse contact ratio of virtual cylindrical gears —
vα
ε Transverse contact ratio of virtual cylindrical gears in normal section —
vαn
Transverse contact ratio of virtual cylindrical gears in normal section for hypoid
ε —
vαn,hyp
gears
ε Face contact ratio of virtual cylindrical gears —
vβ
ε Virtual contact ratio (method B1), modified contact ratio (method B2) —
vγ
θ Auxiliary angle for tooth form and tooth correction factors rad
θ Wheel angle from centreline to pinion tip on drive side rad
D1
Δθ Wheel angle between fillet points °
ϑ Auxiliary value —
µ Relative distance from centreline to tool critical fillet point —
ξ Assumed angle in locating weakest section rad
One half of angle subtended by normal circular tooth thickness at point of load
ξ rad
h
application
ρ Cutter edge radius mm
a0
ρ Fillet radius at point of contact of 30° tangent mm
F
2
σ Tensile strength (corresponds to R of ISO 6892-1) N/mm
B m
2
σ Allowable stress number (bending) N/mm
FE
2
σ Permissible tooth root stress N/mm
FP
5
© ISO 2023 – All rights reserved

---------------------- Page: 10 ----------------------
ISO 10300-3:2023(E)
TTabablele 1 1 ((ccoonnttiinnueuedd))
Symbol Description or term Unit
2
σ Nominal stress number (bending) N/mm
F,lim
ρ Fillet radius at point of contact of 30° tangent in normal section mm
Fn
ρ Root fillet radius of basic rack for cylindrical gears mm
fP
2
σ Yield stress (corresponds to R of ISO 6892-1) N/mm
S p
2
σ Proof stress (0,2 % permanent set) (corresponds to R of ISO 6892-1) N/mm
0,2 p0,2
ρ Radius of curvature change —
Δred
X -1
χ Relative stress drop in notch root mm
X -1
Relative stress drop in notch root of standardized test gear
mm
χ
T
Table 2 — General subscripts
Subscripts Description
0 Tool
1 Pinion
2 Wheel
A, B, B1, B2, C Value according to method A, B, B1, B2 or C
D Drive flank
C Coast flank
T Relative to standardized test gear dimensions
(1), (2) Trials of interpolation
Table 3 — Abbreviated terms in accordance with ISO 6336-5
Abbreviated term Material Type
St Wrought normalized low carbon steels
Normalized low carbon steels/cast steels
St (cast.) Cast steels
Black malleable cast iron
GTS (perl.)
(perlitic structure)
Cast iron materials Nodular cast iron
GGG (perl., bai., ferr.)
(perlitic, bainitic, ferritic structure)
GG Grey cast iron

V Through hardened wrought steels Carbon steels, alloy steels
V (cast) Through hardened cast steels Carbon steels, alloy steels
Eh Case-hardened wrought steels
Flame or induction hard
...
