INTERNATIONAL STANDARD ISO 10300-2:2023(E)
Calculation of load capacity of bevel gears —
Part 2:
Calculation of surface durability (macropitting)
1 Scope
This document specifies the basic formulae for use in the determination of the surface load capacity
of straight and helical (skew), Zerol and spiral bevel gears including hypoid gears, and comprises all
the influences on surface durability for which quantitative assessments can be made. This document is
applicable to oil lubricated bevel gears, as long as sufficient lubricant is present in the mesh at all times.
The formulae in this document are based on virtual cylindrical gears and restricted to bevel gears
whose virtual cylindrical gears have transverse contact ratios of ε < 2. The results are valid within
vα
the range of the applied factors as specified in ISO 10300-1.
The formulae in this document are not directly applicable to the assessment of other types of gear tooth
surface damage, such as plastic yielding, scratching, scuffing or any other type not specified.
NOTE This document is not applicable to bevel gears which have an inadequate contact pattern under load.
The user is cautioned that when the formulae are used for large average mean spiral angles
(β + β )/2 > 45°, for effective pressure angles α > 30° and/or for large facewidths b > 13 m , the
m1 m2 e mn
calculated results of this document should be confirmed by experience.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 701, International gear notation — Symbols for geometrical data
ISO 1122-1, Vocabulary of gear terms — Part 1: Definitions related to geometry
ISO 6336-5, Calculation of load capacity of spur and helical gears — Part 5: Strength and quality of
materials
ISO 10300-1, Calculation of load capacity of bevel gears — Part 1: Introduction and general influence
factors
ISO 17485, Bevel gears — ISO system of accuracy
ISO 23509, Bevel and hypoid gear geometry
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 1122-1 and ISO 23509 and the
following apply.
ISO and IEC maintain terminology databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at https:// www .electropedia .org/
1
© ISO 2023 – All rights reserved

---------------------- Page: 7 ----------------------
ISO 10300-2:2023(E)
3.1
macropitting
material fatigue phenomenon of two meshing surfaces under load
3.2
nominal contact stress
σ
H0
contact stress calculated on the basis of the Hertzian theory at the critical point of load application for
error-free gears loaded by a constant nominal torque
3.3
contact stress
σ
H
determinant contact stress at the critical point of load application including the load factors which
consider static and dynamic loads and load distribution
3.4
allowable stress number (contact)
σ
H,lim
maximum contact stress of standardized test gears and determined at standardized operating
conditions, as specified in ISO 6336-5
3.5
permissible contact stress
σ
HP
maximum contact stress of the evaluated gear set including all influence factors
4 Symbols, general subscripts and abbreviated terms
For the purposes of this document, the symbols given in ISO 701, ISO 17485, ISO 23509 and the following
shall apply.
Table 1 — Symbols
Symbol Description or term Unit
A Auxiliary factor for calculating the dynamic factor K —
v-C
A* Related area for calculating the load sharing factor Z mm
LS
*
Area above the middle contact line mm
A
m
*
Area above the root contact line mm
A
r
*
Area above the tip contact line mm
A
t
b Facewidth mm
b Relative base facewidth —
b
C , C , Constants for determining lubricant film factors —
ZL ZR
C
ZV
d Outer pitch diameter mm
e
d Mean pitch diameter mm
m
d Reference diameter of virtual cylindrical gear mm
v
d Tip diameter of virtual cylindrical gear mm
va
d Base diameter of virtual cylindrical gear mm
vb
2
E Modulus of elasticity, Young’s modulus N/mm
e Exponent for the load distribution along the lines of contact —
LS
F Auxiliary variable for mid-zone factor —
F Nominal tangential force at mid-facewidth of the reference cone N
mt
2
  © ISO 2023 – All rights reserved

---------------------- Page: 8 ----------------------
ISO 10300-2:2023(E)
TTabablele 1 1 ((ccoonnttiinnueuedd))
Symbol Description or term Unit
F Nominal normal force N
n
f Distance from the centre of the zone of action to a contact line mm
f Maximum distance to middle contact line mm
max
g Length of contact line (method B2) mm
c
g Length of path of contact of virtual cylindrical gear in transverse section mm
va
g Relative length of action in normal section —
van
g Relative length of action within the contact ellipse —
η
g Relative length of action at critical point in contact ellipse —
ηI
g Relative length of action considering adjacent teeth —
ηIΣ
HBW Brinell hardness —
K Dynamic factor —
v
K Application factor —
A
K Transverse load factor for contact stress —
Hα
K Face load factor for contact stress —
Hβ
k Positive integer —
k’ Contact shift factor —
l Length of contact line (method B1) mm
b
l Theoretical length of middle contact line mm
bm
m Outer transverse module mm
et
m Mean normal module mm
mn
N Number of load cycles —
L
p Peak load N/mm
p Maximum peak load N/mm
max
p* Relative peak load for calculating the load sharing factor (method B1) —
p Relative mean normal base pitch —
nb
Ra Centre line average (CLA) = AA arithmetic average roughness μm
R Relative mean back cone distance —
mpt
Rz Mean peak-to-valley roughness μm
Rz Equivalent roughness µm
H
Rz Mean roughness for gear pairs with relative curvature radius ρ = 10 mm μm
10 rel
r Relative mean virtual tip radius —
va
r Relative mean virtual pitch radius —
vn
S Safety factor for contact stress (against macropitting) —
H
S Minimum safety factor for contact stress —
H,min
u Gear ratio of bevel gear —
V Ratio of maximum load over the middle contact line and total load —
v Sliding velocity in the mean point P m/s
g
v Sliding velocity parallel to the contact line m/s
g,par
v Sliding velocity vertical to the contact line m/s
g,vert
v Tangential speed at mid-facewidth of the reference cone m/s
mt
v Circumferential velocity at the pitch line m/s
w
v Sum of velocities in the mean point P m/s
Σ
v Sum of velocities in profile direction m/s
Σh
v Sum of velocities in lengthwise direction m/s
Σl
3
© ISO 2023 – All rights reserved

---------------------- Page: 9 ----------------------
ISO 10300-2:2023(E)
TTabablele 1 1 ((ccoonnttiinnueuedd))
Symbol Description or term Unit
v Sum of velocities in lengthwise direction m/s
Σs
v Sum of velocities vertical to the contact line m/s
Σ,vert
w Angle of contact line relative to the root cone °
w Surface velocity m/s
t
w Surface velocity in profile direction m/s
t,h
w Surface velocity in lengthwise direction m/s
t,s
w Surface velocity vertical to the contact line m/s
t,vert
X Intermediate value —
Z Inertia factor (macropitting) —
i
Z Speed factor —
v
Z Contact stress adjustment factor (method B2) —
A
2 1/2
Z Elasticity factor (N/mm )
E
Z Facewidth factor —
FW
Z Hypoid factor —
Hyp
Z Macropitting resistance geometry factor (method B2) —
I
Z Bevel gear factor (method B1) —
KP
Z Lubricant factor —
L
Z Load sharing factor (method B1) —
LS
Z Mid-zone factor —
M-B
Z Life factor (macropitting) —
NT
Z Roughness factor for contact stress —
R
Z Bevel slip factor —
S
Z Work hardening factor —
W
Z Size factor —
X
z Number of teeth —
z Number of teeth of virtual cylindrical gear —
v
α Normal pressure angle at point of load application (method B2) °
L
α Adjusted pressure angle (method B2) °
a
α Normal pressure angle at tooth tip °
an
α Effective pressure angle for drive side/coast side °
eD,C
α Limit pressure angle °
lim
α Generated pressure angle for drive side/coast side °
nD,C
α Transverse pressure angle of virtual cylindrical gears °
vet
β Inclination angle of contact line °
B
β Mean base spiral angle °
bm
β Mean spiral angle °
m
ε Load sharing ratio for macropitting (method B2) —
NI
ζ Pinion offset angle in root plane °
R
ζ Slip vertical to the contact line °
vert
λ Adjustment angle for contact angle of hypoid gears (method B2) °
λ Adjustment angle for virtual spiral angle of hypoid gears (method B2) °
r
3
ρ Density of gear material kg/mm
ρ Local equivalent radius of curvature vertical to contact line mm
rel
ρ Relative radius of profile curvature between pinion and wheel (method B2) —
t
4
  © ISO 2023 – All rights reserved

---------------------- Page: 10 ----------------------
ISO 10300-2:2023(E)
TTabablele 1 1 ((ccoonnttiinnueuedd))
Symbol Description or term Unit
ρ Relative radius of curvature change —
Δred
ρ Relative radius of curvature difference between point of load application and —
Δ1,2
mean point
Σ Shaft angle °
2
σ Contact stress N/mm
H
2
σ Allowable stress number for contact stress N/mm
H,lim
2
σ Permissible contact stress N/mm
HP
v Poisson’s ratio —
2
v , v Nominal kinematic viscosity of the oil at 40 °C and 50 °C respectively mm /s
40 50
ω Angle between surface velocity in lengthwise and profile direction °
wt
ω Inclination angle of the sum of velocities vector results °
Σ
Table 2 — General subscripts
Subscripts Description
0 Tool
1 Pinion
2 Wheel
A, B, B1, B2, C Value according to method A, B, B1, B2 or C
D Drive flank
C Coast flank
T Relative to standardized test gear dimensions
(1), (2) Trials of interpolation
Table 3 — Abbreviated terms
Abbreviated term Material Type
St Wrought normalized low carbon steels
Normalized low carbon steels/cast steels
St (cast.) Cast steels
Black malleable cast iron
GTS (perl.)
(perlitic structure)
Cast iron materials Nodular cast iron
GGG (perl., bai., ferr.)
(perlitic, bainitic, ferritic structure)
GG Grey cast iron

V Through hardened wrought steels Carbon steels, alloy steels
V (cast) Through hardened cast steels Carbon steels, alloy steels
Eh Case-hardened wrought steels
Flame or induction hardened wrought or
IF
cast steels

NT (nitr.) Nitriding steels
Nitrided wrought steels/nitriding steels/
through hardening steels, nitrided
NV (nitr.) Through hardening steels

NV (nitrocar.) Wrought steels, nitrocarburized Through hardening steels
5
© ISO 2023 – All rights reserved

---------------------- Page: 11 ----------------------
ISO 10300-2:2023(E)
5 Macropitting damage — General aspects
5.1 Acceptable versus unacceptable macropitting
When limits of the surface durability of the meshing flanks are exceeded, particles break out of the
flank, thus leaving pits. This damage is called pitting, also known as macropitting. The extent, to which
such pits may be tolerated, in terms of their size and number, varies within wide limits which depend
largely on the field of application. In some fields, extensive macropitting is acceptable; in others, no
macropitting is acceptable. The descriptions in 5.2 and 5.3 are relevant to average working conditions
and give guidelines to distinguish between initial and destructive, and acceptable and unacceptable
macropitting varieties.
A linear or progressive increase in the total area of pits (linear or progressive macropitting) is generally
considered to be unacceptable. However, it is possible that the effective tooth bearing area is enlarged
by initial
...
