CISPR 25:1995

(Main)

Limits and methods of measurement of radio disturbance characteristics for the protection of receivers used on board vehicles

Limits and methods of measurement of radio disturbance characteristics for the protection of receivers used on board vehicles

This standard is designed to protect receivers from disturbances produced by conducted and radiated emissions arising in a vehicle. Test procedures and limits given are intended to provide provisional control of vehicle-radiated emissions, as well as component/module conducted/radiated emissions of long and short duration. The standard: - establishes a test method for measuring the electromagnetic emissions from the electrical system of a vehicle; - sets limits for the electromagnetic emissions from the electrical system of a vehicle; - establishes a test method for testing on-board components and modules independent from the vehicle; - sets limits for electromagnetic emissions from components to prevent objectionable disturbance to on-board receivers; - classifies automotive components by disturbance duration to establish a range of limits.

Limites et méthodes de mesure des caractéristiques des perturbations radioélectriques pour la protection des récepteurs utilisés à bord des véhicules

La présente norme est destinée à protéger les récepteurs des perturbations produites sur un véhicule par induction et par rayonnement. Les procédures d'essais et limites données sont destinées à permettre un contrôle des émissions rayonnées des véhicules et des émissions conduites ou rayonnées de courte ou longue durée des équipements et modules. Cette norme: - définit une méthode d'essai pour la mesure des perturbations électromagnétiques émanant d'un système électrique monté sur véhicule; - établit les limites des perturbations électromagnétiques venant d'un système électrique implanté sur un véhicule; - définit une méthode d'essai des équipements ou des modules installés à bord des véhicules et considérés indépendamment vis-à-vis du véhicule; - établit les limites des perturbations électromagnétiques des équipements en vue de protéger la réception à bord du véhicule des perturbations potentielles; - classifie les équipements automobiles en fonction de la durée des perturbations qu'ils engendrent afin d'établir une échelle de niveaux.

General Information

Status
Published
Publication Date
26-Nov-1995
ICS
33.100.10 - Emission
Technical Committee
CIS/D - Electromagnetic disturbances related to electric/electronic equipment on vehicles and internal combustion engine powered devices
Current Stage
DELPUB - Deleted Publication
Completion Date
20-Aug-2002
Ref Project

Relations

Revised
CISPR 25:2002 - Radio disturbance characteristics for the protection of receivers used on board vehicles, boats, and on devices - Limits and methods of measurement
Effective Date
05-Sep-2023

Buy Standard

CISPR 25:1995 - Limits and methods of measurement of radio disturbance characteristics for the protection of receivers used on board vehicles Released:11/27/1995 Isbn:2831836077CISPR 25:1995 - Limits and methods of measurement of radio disturbance characteristics for the protection of receivers used on board vehicles Released:11/27/1995 Isbn:2831836077
PreviousNext
Standard
CISPR 25:1995 - Limits and methods of measurement of radio disturbance characteristics for the protection of receivers used on board vehicles Released:11/27/1995 Isbn:2831836077
English and French language
93 pages
sale 15% off
Preview
sale 15% off
Preview
