4 CIM specification
4.1 Overview
Replace the existing text of the third bullet point in Subclause 4.1 by the following new text:
• iec61970cim17v40_iec61968cim13v13a_iec62325cim03v17a.eap

– 4 – IEC 61970-301:2020/AMD1:2022
© IEC 2022
Figure 12 – Transformer and Tank model
Replace the existing Figure 12 with the following new figure:

© IEC 2022
Figure 36 – Regulating control models
Replace the existing Figure 36 with the following new figure:

4.5.16 Feeder model
Replace, in the second sentence of the first paragraph of Subclause 4.5.16,
"ConductingEquipment" by "ConnectivityNodeContainer".
4.6.6 CIM profiles
Replace, in footnote 1, "http://www.CIMTool.org" with "https://cimug-org.github.io/CIMTool/".

– 6 – IEC 61970-301:2020/AMD1:2022
© IEC 2022
Table 141 – Attributes of Core::Terminal
Remove, in the first "description" row " GroundSwitch".
Table 151 – Association ends of Wires::AsynchronousMachine with other classes
Replace, in the first column of the fourth row of Table 151 (RegulatingControl), "1" with "0".
Table 186 – Association ends of Wires::ExternalNetworkInjection with other classes
Replace, in the first column of the first row of Table 186 (RegulatingControl), "1" with "0".
Table 188 – Association ends of Wires::FrequencyConverter with other classes
Replace, in the first column of the first row of Table 188, "1" with "0".
Table 204 – Association ends of Wires::LinearShuntCompensator with other classes
Replace, in the first column of the third row of Table 204 (RegulatingControl), "1" with "0".
Table 212 – Association ends of Wires::NonlinearShuntCompensator with other classes
Replace, in the first column of the fourth row of Table 212 (RegulatingControl), "1" with "0".
Table 252 – Association ends of Wires::PowerElectronicsConnection with other classes
Replace, in the first column of the fourth row of Table 252 (RegulatingControl), "1" with "0".
Table 272 – Association ends of Wires::RegulatingCondEq with other classes
Replace, in the first column of the first row of Table 272 (RegulatingControl), "1" with "0".
Table 274 – Association ends of Wires::RegulatingControl with other classes
Replace, in the third column of the second row of Table 274 (RegulatingCondEq), "1" with "0".
Table 279 – Association ends of Wires::RotatingMachi
...
