IEC 60981:2004

INTERNATIONAL IEC
STANDARD 60981
Second edition
2004-05
Extra-heavy duty electrical
rigid steel conduits
Reference number
Publication numbering
As from 1 January 1997 all IEC publications are issued with a designation in the

60000 series. For example, IEC 34-1 is now referred to as IEC 60034-1.

Consolidated editions
The IEC is now publishing consolidated versions of its publications. For example,

edition numbers 1.0, 1.1 and 1.2 refer, respectively, to the base publication, the

base publication incorporating amendment 1 and the base publication incorporating

amendments 1 and 2.
Further information on IEC publications
The technical content of IEC publications is kept under constant review by the IEC,
thus ensuring that the content reflects current technology. Information relating to
this publication, including its validity, is available in the IEC Catalogue of
publications (see below) in addition to new editions, amendments and corrigenda.
Information on the subjects under consideration and work in progress undertaken
by the technical committee which has prepared this publication, as well as the list
of publications issued, is also available from the following:
• IEC Web Site (www.iec.ch)
• Catalogue of IEC publications
The on-line catalogue on the IEC web site (www.iec.ch/searchpub) enables you to
search by a variety of criteria including text searches, technical committees
and date of publication. On-line information is also available on recently issued
publications, withdrawn and replaced publications, as well as corrigenda.
• IEC Just Published
This summary of recently issued publications (www.iec.ch/online_news/ justpub)
is also available by email. Please contact the Customer Service Centre (see
below) for further information.
• Customer Service Centre
If you have any questions regarding this publication or need further assistance,
please contact the Customer Service Centre:

Email: custserv@iec.ch
Tel: +41 22 919 02 11
Fax: +41 22 919 03 00
INTERNATIONAL IEC
STANDARD 60981
Second edition
2004-05
Extra-heavy duty electrical
rigid steel conduits
 IEC 2004  Copyright - all rights reserved
No part of this publication may be reproduced or utilized in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without permission in writing from the publisher.
International Electrotechnical Commission, 3, rue de Varembé, PO Box 131, CH-1211 Geneva 20, Switzerland
Telephone: +41 22 919 02 11 Telefax: +41 22 919 03 00 E-mail: inmail@iec.ch Web: www.iec.ch
PRICE CODE
Commission Electrotechnique Internationale P
International Electrotechnical Commission
МеждународнаяЭлектротехническаяКомиссия
For price, see current catalogue

– 2 – 60981  IEC:2004(E)
CONTENTS
FOREWORD.3

1 Scope.5

2 Normative references.5

3 Terms and definitions .5

4 General requirements.6

4.1 Tests.6

4.2 Circular cross-section.6
4.3 Wall thickness.6
4.4 Surface condition.6
4.5 Welding.6
4.6 Cleaning.6
4.7 Protective coating.6
5 Dimensions.7
5.1 Dimensions.7
5.2 Threads.7
6 Zinc coating.7
7 Threading and chamfering .7
8 Couplings.8
8.1 General.8
8.2 Coupling threads.8
9 Elbows and nipples .8
10 Ductility.8
10.1 Bending properties.8
10.2 Ductility of zinc coating .8
11 Marking.9
11.1 General.9
11.2 Required information.9

Annex A (normative) Test for thickness of zinc coating on extra heavy-duty electrical
rigid steel (EHDERS) conduits.15

Figure 1 – Dimensions of threads for EHDERS conduit.11
Figure 2 – Basic form of taper thread .12
Figure 3 – Limits on crest and root truncation of external and internal threads .13
Figure 4 – Dimensions of a ferrous metal coupling.14

Table 1 – Dimensions and mass of EHDERS conduit.9
Table 2 – Dimensions of couplings .10
Table 3 – Dimensions of 90° elbows .10

60981  IEC:2004(E) – 3 –
INTERNATIONAL ELECTROTECHNICAL COMMISSION

____________
EXTRA HEAVY-DUTY ELECTRICAL RIGID STEEL CONDUITS

FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote

international co-operation on all questions concerning standardization in the electrical and electronic fields. To

this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
in the subject dealt with may participate in this preparatory work. International, governmental and non-
governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
with the International Organization for Standardization (ISO) in accordance with conditions determined by
agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence
between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
the latter.
5) IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with an IEC Publication.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of
patent rights. IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 60981 has been prepared by subcommittee 23A: Cable
management systems, of IEC technical committee 23: Electrical accessories.

This second edition cancels and replaces the first edition published in 1989. This edition
constitutes a technical revision. It incorporates two main changes to the first edition, including:
– the addition of provisions for alternative coatings to zinc, and
– revisions to ductility requirements.
The text of this standard is based on the following documents:
FDIS Report on voting
23A/443/FDIS 23A/445/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 2.

– 4 – 60981  IEC:2004(E)
The committee has decided that the contents of this publication will remain unchanged until
2007. At this date, the publication will be

• reconfirmed;
• withdrawn;
• replaced by a revised edition, or

• amended.
A bilingual version of this publication may be issued at a later date.

60981  IEC:2004(E) – 5 –
EXTRA HEAVY-DUTY ELECTRICAL RIGID STEEL CONDUITS

1 Scope
This International Standard specifies requirements for EHDERS (extra heavy-duty electrical

rigid steel) conduits, couplings, nipples and elbows for electrical installations, including

communications and fibre optics. This standard also specifies threads for these components.

It is not applicable to the conduits specified in IEC 60423.

2 Normative references
The following referenced documents are indispensable for the application of this document. For
dated references, only the edition cited applies. For undated references, the latest edition of
the referenced document (including any amendments) applies.
IEC 61950, Cable management systems – Specification for conduit fittings for electrical
installations for extra-heavy duty metal conduit
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
3.1
extra heavy-duty electrical rigid steel conduit (EHDERS)
part of a closed wiring system of circular cross-section made of welded steel construction
capable of providing extra heavy mechanical protection to conductors or cables in electrical
installations and used as an equipment earthing conductor when installed utilizing appropriate
fittings
3.2
straight conduit
straight length of EHDERS without a coupling
3.3
finished conduit
straight length of EHDERS with one coupling attached

3.4
threaded coupling
internally threaded steel cylinder for connecting two sections of EHDERS conduit.
3.5
elbow
curved section of EHDERS conduit threaded at each end
3.6
nipple
straight section of EHDERS conduit not more than 0,6 m long and threaded at each end
3.7
type test
test made on a specimen for the conformity of the design of a given product to the
requirements of the relevant standard

– 6 – 60981  IEC:2004(E)
4 General requirements
4.1 Tests
Tests according to this standard shall be type tests.

Unless otherwise specified, the tests shall be carried out at an ambient temperature of

(20 ± 5) °C.
Unless otherwise specified, each test shall be carried out on two new samples. If a sample

tested in accordance with this standard fails, two additional samples shall be tested, both of

which shall comply with all the requirements of this standard.
4.2 Circular cross-section
An EHDERS conduit shall have a circular cross-section sufficiently accurate to permit the
cutting of threads in accordance with Figure 1.
4.3 Wall thickness
The wall thickne
...
