IEC 60966-2-4:2009

IEC 60966-2-4 ®
Edition 3.0 2009-01
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
colour
inside
Radio frequency and coaxial cable assemblies –
Part 2-4: Detail specification for cable assemblies for radio and TV receivers –
Frequency range 0 MHz to 3 000 MHz, IEC 61169-2 connectors

Cordons coaxiaux et cordons pour fréquences radioélectriques –
Partie 2-4: Spécification particulière relative aux cordons pour récepteurs TV ou
radio – Plage de fréquences de 0 MHz à 3 000 MHz, connecteurs CEI 61169-2

All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form
or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from
either IEC or IEC's member National Committee in the country of the requester. If you have any questions about IEC
copyright or have an enquiry about obtaining additional rights to this publication, please contact the address below or
your local IEC member National Committee for further information.

Droits de reproduction réservés. Sauf indication contraire, aucune partie de cette publication ne peut être reproduite
ni utilisée sous quelque forme que ce soit et par aucun procédé, électronique ou mécanique, y compris la photocopie
et les microfilms, sans l'accord écrit de l'IEC ou du Comité national de l'IEC du pays du demandeur. Si vous avez des
questions sur le copyright de l'IEC ou si vous désirez obtenir des droits supplémentaires sur cette publication, utilisez
les coordonnées ci-après ou contactez le Comité national de l'IEC de votre pays de résidence.

IEC Central Office Tel.: +41 22 919 02 11
3, rue de Varembé Fax: +41 22 919 03 00
CH-1211 Geneva 20 info@iec.ch
Switzerland www.iec.ch
About the IEC
The International Electrotechnical Commission (IEC) is the leading global organization that prepares and publishes
International Standards for all electrical, electronic and related technologies.

About IEC publications
The technical content of IEC publications is kept under constant review by the IEC. Please make sure that you have the
latest edition, a corrigenda or an amendment might have been published.

IEC Catalogue - webstore.iec.ch/catalogue Electropedia - www.electropedia.org
The stand-alone application for consulting the entire The world's leading online dictionary of electronic and
bibliographical information on IEC International Standards, electrical terms containing more than 30 000 terms and
Technical Specifications, Technical Reports and other definitions in English and French, with equivalent terms in 14
documents. Available for PC, Mac OS, Android Tablets and additional languages. Also known as the International
iPad. Electrotechnical Vocabulary (IEV) online.

IEC publications search - www.iec.ch/searchpub IEC Glossary - std.iec.ch/glossary
The advanced search enables to find IEC publications by a More than 55 000 electrotechnical terminology entries in
variety of criteria (reference number, text, technical English and French extracted from the Terms and Definitions
committee,…). It also gives information on projects, replaced clause of IEC publications issued since 2002. Some entries
and withdrawn publications. have been collected from earlier publications of IEC TC 37,

77, 86 and CISPR.
IEC Just Published - webstore.iec.ch/justpublished

Stay up to date on all new IEC publications. Just Published IEC Customer Service Centre - webstore.iec.ch/csc
details all new publications released. Available online and If you wish to give us your feedback on this publication or
also once a month by email. need further assistance, please contact the Customer Service
Centre: csc@iec.ch.
A propos de l'IEC
La Commission Electrotechnique Internationale (IEC) est la première organisation mondiale qui élabore et publie des
Normes internationales pour tout ce qui a trait à l'électricité, à l'électronique et aux technologies apparentées.

A propos des publications IEC
Le contenu technique des publications IEC est constamment revu. Veuillez vous assurer que vous possédez l’édition la
plus récente, un corrigendum ou amendement peut avoir été publié.

Catalogue IEC - webstore.iec.ch/catalogue Electropedia - www.electropedia.org
Application autonome pour consulter tous les renseignements
Le premier dictionnaire en ligne de termes électroniques et
bibliographiques sur les Normes internationales,
électriques. Il contient plus de 30 000 termes et définitions en
Spécifications techniques, Rapports techniques et autres
anglais et en français, ainsi que les termes équivalents dans
documents de l'IEC. Disponible pour PC, Mac OS, tablettes
14 langues additionnelles. Egalement appelé Vocabulaire
Android et iPad.
Electrotechnique International (IEV) en ligne.

Recherche de publications IEC - www.iec.ch/searchpub
Glossaire IEC - std.iec.ch/glossary
La recherche avancée permet de trouver des publications IEC Plus de 55 000 entrées terminologiques électrotechniques, en
en utilisant différents critères (numéro de référence, texte, anglais et en français, extraites des articles Termes et
comité d’études,…). Elle donne aussi des informations sur les Définitions des publications IEC parues depuis 2002. Plus
projets et les publications remplacées ou retirées. certaines entrées antérieures extraites des publications des

CE 37, 77, 86 et CISPR de l'IEC.
IEC Just Published - webstore.iec.ch/justpublished

Service Clients - webstore.iec.ch/csc
Restez informé sur les nouvelles publications IEC. Just
Published détaille les nouvelles publications parues. Si vous désirez nous donner des commentaires sur cette
Disponible en ligne et aussi une fois par mois par email. publication ou si vous avez des questions contactez-nous:
csc@iec.ch.
IEC 60966-2-4 ®
Edition 3.0 2009-01
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
colour
inside
Radio frequency and coaxial cable assemblies –

Part 2-4: Detail specification for cable assemblies for radio and TV receivers –

Frequency range 0 MHz to 3 000 MHz, IEC 61169-2 connectors

Cordons coaxiaux et cordons pour fréquences radioélectriques –

Partie 2-4: Spécification particulière relative aux cordons pour récepteurs TV ou

radio – Plage de fréquences de 0 MHz à 3 000 MHz, connecteurs CEI 61169-2

INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
COMMISSION
ELECTROTECHNIQUE
PRICE CODE
INTERNATIONALE
CODE PRIX G
ICS 33.120.10 ISBN 978-2-8322-1355-1

– 2 – 60966-2-4  IEC:2009
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
RADIO FREQUENCY AND COAXIAL CABLE ASSEMBLIES –

Part 2-4: Detail specification for cable
assemblies for radio and TV receivers –
Frequency range 0 MHz to 3 000 MHz, IEC 61169-2 connectors

FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
in the subject dealt with may participate in this preparatory work. International, governmental and non-
governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
with the International Organization for Standardization (ISO) in accordance with conditions determined by
agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence
between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
the latter.
5) IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with an IEC Publication.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of
patent rights. IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 60966-2-4 has been prepared by IEC technical committee 46:
Cables, wires, waveguides, R.F. connectors, R.F. and microwave passive components and
accessories.
This bilingual version (2014-01) corresponds to the monolingual English version, published in
2009-01.
This third edition cancels and replaces the second edition published in 2003 and constitutes a
technical revision.
The major change with respect to the second edition is the reference to IEC 62153 and the
requirement for class B screening attenuation.

60966-2-4  IEC:2009 – 3 –
The text of this standard is based on the following documents:
FDIS Report on voting
46/303/FDIS 46/315/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
The French version of this standard has not been voted upon.

This detail specification is to be read with IEC 60966-1:1999, with IEC 60966-2-1:2008 and
with IEC 60966-2-2:2003.
A list of all parts of the IEC 60966 series, under the general title: Radio frequency and coaxial
cable assemblies, can be found on the IEC website.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 2.
The committee has decided that the contents of this publication will remain unchanged until
the maintenance result date indicated on the IEC web site under "http://webstore.iec.ch" in
the data related to the specific publication. At this date, the publication will be
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.
IMPORTANT – The 'colour inside' logo on the cover page of this publication indicates
that it contains colours which are considered to be useful for the correct
understanding of its contents. Users should therefore print this document using a
colour printer.
– 4 – 60966-2-4  IEC:2009
INTRODUCTION
This detail specification applies to flexible coaxial cables described in IEC 60096-2. It relates
to cable assemblies for radio and TV receivers, and in particular to the cable assemblies
subfamily 9,52. (IEC 61169-2). These cable assemblies are used as described in
IEC 60728-4.
This detail specification gives subfamily requirements and severities which shall be applied.
Under qualification approval, the qualification will be conducted in accordance with 12.2 of
IEC 60966-2-1 taking into account the specified variants. Only the tests whose results might
depend on the variants will be repeated.
Under capability approval, the qualification will be conducted on the relating CQCs as defined
in 12.3 of IEC 60966-2-1 and described in the CM. Unless otherwise specified in the CM, only
lot-by-lot tests from groups Ba and Eb will be conducted on delivered products, all other tests
will be performed on CQCs as defined in 12.3 of IEC 60966-2-1 and described in the CM.
Reference documents
IEC 60728-4, Cable networks for television signals, sound signals and interactive services –
Part 4: Passive wideband equipment for coaxial cable networks
IEC 60966-1:1999, Radio frequency and coaxial cable assemblies – Part 1: Generic
specification – General requirements and test methods
IEC 60966-2-1:2008, Radio frequency and coaxial cable assemblies – Part 2-1: Sectional
specification for flexible coaxial cable assemblies
IEC 60966-2-2:2003, Radio frequency and coaxial cable assemblies – Part 2-2: Blank detail
specification for flexible coaxial cable assemblies
IEC 61169-2, Radio-frequency connectors – Part 2: Sectional specification – Radio frequency
coaxial connectors of type 9,52
IEC 61196-6, Coaxial communication cables – Sectional specification for CATV drop cables
IEC 62153-4-3, Metallic communication cable test methods – Part 4-3: Electromagnetic
compatibility (EMC) – Surface transfer impedance – Triaxial method

60966-2-4  IEC:2009 – 5 –
RADIO FREQUENCY AND COAXIAL CABLE ASSEMBLIES –

Part 2-4: Detail specification for cable
assemblies for radio and TV receivers –
Frequency range 0 MHz to 3 000 MHz, IEC 61169-2 connectors

[1] Prepared by [2] Document No.  60966-2-4

Issue: Third Issue
IEC TC 46
Date:
[3] Available from:
[4] Generic specification:  IEC 60966-1
IEC
3 rue de Varembé Sectional Specification:  IEC 60966-2-1

Genève
Blank detail specification:  IEC 60966-2-2
Suisse
[5] Additional references:
Detail specification for coaxial cable assemblies for radio and TV receivers

NOTE Example diagram, manufacturer to insert actual diagram
A or B Type
C or D Type
L
IEC  2299/08
[6] Maximum diameter < 16,6 mm
[7] Characteristic impedance: 75 Ω [8] Frequency range: 0 MHz to 3 000 MHz
[9] Weight: 40 g/m + 50 g (typically) [10] Minimum inside radius:
for static bending: 25 mm
for dynamic bending: 75 mm
[11] Climatic category: 40/70/21 [12] Applicable test group: Ba, Eb, Eh, Ee, Mn
A B C D
[13] Connector type IEC 61169-2 (9.52) IEC 61169-2 (9.52) IEC 61169-2 (9.52) IEC 61169-2 (9.52)
Straight plug Straight socket Right angled plug Right angled socket
Cable type IEC 61196-6,   IEC 61196-6
...
