EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 13598-1September 2003ICS 93.030English versionPlastics piping systems for non-pressure underground drainageand sewerage - Unplasticized poly(vinyl chloride) (PVC-U),polypropylene (PP) and polyethylene (PE) - Part 1:Specifications for ancillary fittings including shallow inspectionchambersSystèmes de canalisations en plastique pour lesbranchements et les collecteurs d'assainissement enterréssans pression - Poly(chlorure de vinyle) non plastifié (PVC-U), polypropylène (PP) et polyéthylène (PE) - Partie 1:Spécifications pour raccords auxiliaires y compris leschambres d'inspection peu profondesKunststoff-Rohrleitungssysteme für erdverlegte druckloseAbwasserkanäle und -leitungen - WeichmacherfreiesPolyvinylchlorid (PVC-U), Polypropylen (PP) undPolyethylen (PE) - Teil 1: Anforderungen an Schächte undZubehörteileThis European Standard was approved by CEN on 3 March 2003.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Management Centre has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Czech Republic, Denmark, Finland, France, Germany, Greece,Hungary, Iceland, Ireland, Italy, Luxembourg, Malta, Netherlands, Norway, Portugal, Slovakia, Spain, Sweden, Switzerland and UnitedKingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2003 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 13598-1:2003 ESIST EN 13598-1:2004

outside the building structure (application area code “U”), reflected in the marking of products by “U”, andb)
both buried in ground within the building structure (application area code “D”) and outside the building structure(application area code “U”), reflected in the marking of products by “UD”.It also specifies the test parameters for the test methods referred in this standard.The ancillary fittings covered by this standard are the following:— sealed access fittings;— rodding point covers;— rodding tees;— mechanical saddles;— inspection chambers for shallow non- roadway applications to a maximum depth of 1,25 m.NOTE 1Inspection chambers as defined in 6.1.3 of EN 476:1997 have a riser with a DN/ID less than 800 mm.The fittings can be manufactured by various methods e.g. injection moulding, rotational moulding, spiral winding orfabricated from components made to other standards.The jointing can be with:— elastomeric ring seal joint;— cemented joint for PVC-U;— welded joint for PP and PE.NOTE 2Pipes, fittings and other components conforming to any of the plastics products standards listed in clause 2 can be used withancillary fittings conforming to this standard, provided they conform to the requirements for joint dimensions given in clause 6 and to therequirements of Table 5.2 Normative referencesThis European Standard incorporates by dated or undated reference, provisions from other publications. Thesenormative references are cited at the appropriate places in the text, and the publications are listed hereafter. Fordated references, subsequent amendments to or revisions of any of these publications apply to this EuropeanStandard only when incorporated in it by amendment or revision. For undated references the latest edition of thepublication referred to applies (including amendments).EN 295-3:1991,
Vitrified clay pipes and fittings and pipe joints for drains and sewers — Part 3: Test methods.EN 476:1997,
General requirements for components used in discharge pipes, drains and sewers for gravitysystems.EN 681-1,
Elastomeric seals — Material requirements for pipe joint seals used in water and drainage applications— Part 1: Vulcanized rubber.EN 681-2,
Elastomeric seals — Material requirements for pipe joint seals used in water and drainage applications— Part 2: Thermoplastics elastomers.EN 681-3,
Elastomeric seals — Material requirements for pipe joint seals used in water and drainage applications— Part 3: Cellular materials of vulcanized rubber.EN 681-4,
Elastomeric seals — Material requirements for pipe joint seals used in water and drainage applications— Part 4: Cast polyurethane sealing elements.SIST EN 13598-1:2004

Plastics piping systems — Thermoplastics piping systems for soil and waste discharge insidebuildings — Test method for resistance to elevated temperature cycling.EN 1253-1:2003,
Gullies for buildings — Part 1: Requirements.EN 1253-2:1998,
Gullies for buildings — Part 2: Test methods.EN 1277:1996,
Plastics piping systems — Thermoplastics piping systems for buried non-pressure applications —Test methods for leaktightness of elastomeric sealing ring type joints.EN 1401-1:1998,
Plastics piping systems for non-pressure underground drainage and sewerage — Unplasticizedpoly(vinyl chloride) (PVC-U) — Part 1: Specifications for pipes, fittings and the system.EN 1852-1:1997,
Plastics piping systems for non-pressure underground drainage and sewerage — Polypropylene(PP) — Part 1: Specifications for pipes, fittings and the system.EN 1989,
Thermoplastics piping and ducting systems
— Joints for buried non pressure sewerage applications —Test method for long-term sealing performance of joints with thermoplastics elastomer (TPE) seals by estimatingthe sealing pressure.EN 12256,
Plastics piping systems — Thermoplastics fittings — Test method for mechanical strength or flexibilityof fabricated fittings.prEN 12666-1:2001,
Plastics piping systems for non-pressure underground drainage and sewerage —Polyethylene (PE) — Part 1: Specifications for pipes, fittings and the system.prEN 13476-1:2002,
Plastics piping systems for non-pressure underground drainage and sewerage — Structured-wall piping systems of unplasticized poly(vinyl chloride) (PVC-U), polypropylene (PP) and polyethylene (PE) — Part1: Specifications for pipes, fittings and the system.EN ISO 472:2001,
Plastics — Vocabulary (ISO 472:1999).EN ISO 1043-1:2001,
Plastics — Symbols and abbreviated terms — Part 1: Basic polymers and their specialcharacteristics (ISO 1043-1:2001).EN ISO 3126
Plastics piping systems — Plastics components — Determination of dimensions (ISO 3126:2003).EN ISO 9969,
Thermoplastics pipes — Determination of ring stiffness (ISO 9969:1994).3 Terms, definitions, symbols and abbreviationsFor the purposes of this standard, the following definitions, symbols and abbreviations and those given inEN 1401-1:1998, EN 1852-1:1997, prEN 12666-1:2001, prEN 13476-1:2002, EN ISO 472:2001 andEN ISO 1043-1:2001 apply.3.1 Terms and definitions3.1.1sealed access fittingsfitting that permits entry into the system for rodding or inspection and that has a sealed cover3.1.2rodding point coverfitting installed at ground level with a removable cover that permits the introduction of equipment for inspection andthe clearance of blockages. The riser shafts connected to these fittings do not exceed 200 mm outside diameterand are not less than 100 mm inside diameter3.1.3rodding teefitting installed in a drainage or sewerage system that connects to a rodding point at ground level by means of avertical shaft that permits the introduction of equipment for the clearance of blockages, and also equipment for theinspection of the connecting pipe work in one or more directions. The riser shafts connected to these fittings do notexceed 200 mm outside diameter and are not less than 100 mm inside diameterSIST EN 13598-1:2004
...
