EN 1143-1:2012

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Varnostne shranjevalne enote - Zahteve, klasifikacija in metode preskušanja protivlomne odpornosti - 1. del: Blagajne, bankomatne blagajne, vrata trezorskih prostorov in trezorski prostoriWertbehältnisse - Anforderungen, Klassifizierung und Methoden zur Prüfung des Widerstandes gegen Einbruchdiebstahl - Teil 1: Wertschutzschränke, Wertschutzschränke für Geldautomaten, Wertschutzraumtüren und WertschutzräumeUnités de stockage en lieux sûrs - Prescriptions, classification et méthodes de test pour la résistance à l'effraction - Partie 1 : Coffres forts, distributeure automatiques de billets (DAB), portes fortes et chambres fortesSecure storage units - Requirements, classification and methods of test for resistance to burglary - Part 1: Safes, ATM safes, strongroom doors and strongrooms35.220.99Druge naprave za shranjevanje podatkovOther data storage devices13.310Varstvo pred kriminalomProtection against crimeICS:Ta slovenski standard je istoveten z:EN 1143-1:2012SIST EN 1143-1:2012en,fr,de01-oktober-2012SIST EN 1143-1:2012SLOVENSKI
STANDARDSIST EN 1143-1:2005+A1:2009/AC:2010SIST EN 1143-1:2005+A1:20091DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 1143-1
April 2012 ICS 13.310 Supersedes EN 1143-1:2005+A1:2009English Version
Secure storage units - Requirements, classification and methods of test for resistance to burglary - Part 1: Safes, ATM safes, strongroom doors and strongrooms
Unités de stockage en lieux sûrs - Prescriptions, classification et méthodes de test pour la résistance à l'effraction - Partie 1: Coffres forts, distributeurs automatiques de billets (DAB), portes fortes et chambres fortes
Wertbehältnisse - Anforderungen, Klassifizierung und Methoden zur Prüfung des Widerstandes gegen Einbruchdiebstahl - Teil 1: Wertschutzschränke, Wertschutzschränke für Geldautomaten, Wertschutzraumtüren und Wertschutzräume This European Standard was approved by CEN on 16 March 2012.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2012 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 1143-1:2012: ESIST EN 1143-1:2012

Attack tools . 35Bibliography . 41 SIST EN 1143-1:2012

Note 1 to entry: Strongrooms may be cast in-situ, constructed from pre-fabricated elements or a combination of both.
3.5 strongroom door door with lock(s), boltwork and frame intended for giving access to a strongroom 3.6 ATM safe safe forming part of an ATM system 3.7 ATM base integral part of an ATM system located between the ATM safe and the surface to which the safe is to be anchored SIST EN 1143-1:2012

automatic teller machine means for holding and processing cash and/or valuables Note 1 to entry: For the purpose of this standard, automated teller machines, currency exchange machines, currency recycling machines and machines such as teller assist machines are all considered types of ATM.
3.10 ATM-System assembly of sub-units which provides an ATM function and affords security to cash and/or valuables stored within the ATM safe Note 1 to entry: An example of an ATM system is shown in Figure 1.
Figure 1 — Example of an ATM system Note 2 to entry: Of the sub-units shown in Figure 1, the ATM mechanism and the ATM control unit are not tested according to this European Standard. 3.11 accessories installations/devices which are part of the structure or which pass through the structure of the strongroom or strongroom door(s) for ventilation or for deposit of cash and valuables Note 1 to entry: Accessories may be always open, usually open (but can be closed in case of emergency), or closed (but can be opened if necessary).
3.12 operating time time during which a tool is used attempting to create a change in the test specimen Note 1 to entry: In the context of this standard, there are also operating times considered during which no visible modifications/changes are caused to the test specimen. 3.13 resistance unit
RU burglary resistance which results from one minute's use of a tool carrying the coefficient 1 and the basic value 0 SIST EN 1143-1:2012

BV number in resistance units allocated to a particular tool Note 1 to entry: The basic value represents problems in obtaining, transporting, using and operating the relevant tool at the site in question, and the necessary knowledge and experience for its efficient use.
3.17 tool coefficient number in resistance units per minute allocated to a group of tools Note 1 to entry: The tool coefficient represents factors such as noise, smoke, fumes and other effects, which increase the likelihood of a burglary attack being detected.
3.18 boltwork mechanism by which a closed door is held such that, until it is in the withdrawn position, the door cannot be opened 3.19 lock device able to recognize a coded input and which performs a blocking function on the boltwork or the door 3.20 relocking device system comprising blocking and detecting elements which will prevent the boltwork from being withdrawn if a burglary attack is detected
Note 1 to entry: A relocking device can be part of the locking mechanism (e.g. active or live relocker) or an independent unit (e.g. passive relocker). 3.21 to close to move the door so it becomes possible to bolt it 3.22 to bolt to throw the boltwork or the bolt of the lock (if there is no boltwork) to a position where it fixes the door in closed position 3.23 to lock to block a thrown boltwork by action of a lock 4 Classification and requirements 4.1 Classification Safes are classified to a resistance grade according to Table 1. SIST EN 1143-1:2012

4.2 General requirements 4.2.1 Safes, strongroom doors and strongrooms There shall be no holes through the protection material other than those necessary for locks, cables or anchoring, nor for the fitting of accessories to strongroom doors and strongrooms. Cable openings in safes, strongroom doors and strongrooms (with or without a door) shall not exceed 100 mm2. Unused cable entry openings shall be obstructed or plugged by the manufacturer by a means of which cannot be removed from the outside without leaving visible traces.
Free-standing safes with a mass of less than 1 000 kg shall have at least one hole by which they can be anchored. The anchoring assembly for each anchoring hole shall sustain the force given in Table 1. 4.2.2 ATM safes ATM safes shall have means for plugging unused openings. These means shall be impossible to remove from the outside without leaving visible traces. NOTE 1 Openings through the protection material for ATM functioning are permitted in ATM safes. NOTE 2 Cable entry openings in ATM safes may be larger than 100 mm2.
ATM safes, including optional ATM bases, shall have a fixing capability by which they can be anchored, and which shall sustain the required force given in Table 2. 4.2.3 Boltwork cover plate Safes, ATM safes and strongroom doors shall have an internal boltwork cover plate that prevents unauthorized viewing of the locks and boltwork and access to them, when the door is open. Boltwork cover plates shall be secured so that they cannot be opened or removed by an unauthorized person without leaving visible traces. 4.2.4 Cable hole Safes, strongroom doors and strongrooms of grade III and higher shall either have a hole for a cable or a preparation enabling a connection to be made to an alarm system after the secure storage unit has been installed.
4.2.5 User instructions Safes, strongrooms and ATM safes shall be provided with operating and maintenance instructions, including instructions regarding the locks. Free-standing safes and ATM safes shall have instructions for anchoring. For built-in safes, strongroom doors and strongrooms, installation instructions shall be provided.
4.3 Additional requirements for EX designation When tested in accordance with Clause 9, safes of resistance grades II to X designated 'EX' shall achieve the minimum post-detonation resistance values given in Table 1. EX designation is not applicable to safes of resistance grade 0 to I. SIST EN 1143-1:2012

4.4 Additional requirements for GAS designation When tested in accordance with Clause 10, ATM safes of resistance grades II to VIII designated 'GAS' shall achieve the minimum post-detonation resistance values given in Table 2. 'GAS' designation is not applicable to ATM safes of resistance grades L and I. 4.5 Additional requirements for CD designation When tested in accordance with Clause 11, safes of resistance grades IV to X designated ‘CD’ shall achieve the minimum resistance values given in Table 1. 'CD' designation is not applicable to safes of resistance grades 0 to III and ATM safes. When tested in accordance with Clause 11, strongroom doors and strongrooms (with or without a door) of resistance grades VIII to XIII designated 'CD' shall achieve the minimum resistance values given in Table 3. 'CD' designation is not applicable to strongroom doors and strongrooms of resistance grades 0 to VII.
(Clause 9) Additional requirements for CD designation (optional)
(Clause 11)
Resistance value for
Required
force
Quantity
Class according to EN 1300 Post-detonation resistance
valued
Resistance valued
partial access
complete access
RU RU kN
RU RU 0 30 30 50 1 A b c I 30 50 50 1 A b c II 50 80 50 1 A 4 c III 80 120 50 1 B 6 c IV 120 180 100 2 B 9 1 000 V 180 270 100 2 B 14 1 000 VI 270 400 100 2 C 20 1 000 VII 400 600 100 2 C 30 1 000 VIII 550 825 100 2 C 41 1 000 IX 700 1 050 100 2 C 53 1 000 X 900 1 350 100 2 C 68 1 000 a
Applicable only to free-standing safes with a mass less than 1 000 kg.b
EX designation is not permitted for resistance grades 0 and I. c
CD designation is not permitted for resistance grades 0 to III. d
Resistance value for partial access.
Resistance grade
Tool attack test
(Clause 7)
Anchoringstrength (8.2)
Tool attacktest on fixing attachment (Clause 7)
Additional requirements for post-anchoring forcing test (Clause 8)
Locks Additional require- ments for EX and GAS designation(optional) (Clauses 9 and 10) Resistance value for
partial access
complete access
Requiredforce
Resistancevalue
Post-anchoring resistance value
Quan-tity
Class according to EN 1300
Post-detonationresistance valued
general used aperturesb
RU RU RU kN RU RU
RU L body a 20 20 30 50 30 18 1 A c door 30 30 50 I
30 30 50 50 30 18 1 A c II
50 35 80 50 50 22 1 A 4 III
80 65 120 50 50 22 1 B 6 IV
120 100 180 100 50 22 2 B 9 V
180 145 270 100 50 22 2 B 14 VI
270 220 400 100 70 22 2 C 20 VII
400 350 600 100 120 22 2 C 30 VIII
550 500 825 100 160 22 2 C 41 a
Resistance values do not apply to the body of grade L ATM safes which fulfil the requirements of 7.5.5. b
Applies only to apertures actually used; plugged and unused apertures shall satisfy the general values.
c
EX and GAS designation are not permitted for resistance grades L and I. d
Resistance value for partial access.
into resistance grades
Resistance grade
Tool attack test
(Clause 7)
Locksa
Additional requirements for
EX designation (optional) (Clause 9)
Additional requirements forCD designation (optional)
(Clause 11)
Resistance value
for complete access Quantity Class
according to EN 1300 Post-detonation
resistance valuec Resistance valuec
RU
RU RU 0 30 1 A b d I 50 1Ab d II 80 1A4d III 120 1B6d IV 180 2B9d V 270 2B14dVI 400 2C20dVII 600 2C30dVIII 825 2C4110 000IX 1 050 2C5310 000X 1 350 2C6810 000XI 2 000 3C or 100 10 000 2DXII 3 000 3C or 150 10 000 2DXIII 4 500 2D225 10000a
Not applicable for classification of strongrooms without a door. b
EX designation is not permitted for resistance grades 0 and I. c
Resistance value for complete access. d
CD designation is not permitted for resistance grades 0 to VII.
5.2 Statement of the type of product: free-standing safe, built-in safe (floor and wall), ATM safe, strongroom door or strongroom (with or without a door), together with a list of sizes covered by the same design.
5.3 Drawings of the test specimen showing the following:
a) weight, outside and inside dimensions, and the manufacturing tolerances;
b) horizontal and vertical cross sections; c) quantity, layout and features of locks, boltwork and relocking devices; d) quantity, pitch and position of door bolts, their dimensions (e.g. cross section), throw and engagements and their type (e.g. moving or fixed);
e) location and design of any local areas of special protection materials;
f) details of the fastening and/or fitting or anchoring of all elements relevant to physical security; e.g. construction and position of joints and connections, the means by which door and/or frames are joined to walls, the means by which prefabricated panels are joined;
g) marking, position and dimensions of any holes which pass through the protection material with a detailed representation of specially protected areas;
h) details of optional features, e.g. features for time locking and time delay locking;
i) for ATM safes, the ATM base, if any, will be identified by the manufacturer. 5.4 List of all the locks that may be fitted, including the manufacturer and model number.
5.5 Specification of the materials of construction (if not contained in the drawings). 5.6 Statements of details of any materials or device(s) intended to generate gas, smoke, soot, etc. in the event of physical attack, or which could generate harmful substances during testing.
5.7 Statements of the nature and position of any cables and/or facilities for penetration of detection systems, for the mounting of electro-mechanical securing devices, alarm devices, etc. 5.8 Instructions for installation, giving at least the following details: a) method of anchoring free-standing safes with a mass less than 1 000 kg; b) method of encasing built-in safes, i.e. proportion of body which is to be encased; the minimum size and section thickness of the encasement; the minimum quality of encasement material; (types and proportions of aggregates, cement and any other constituents, flowability of the freshly prepared mass and the 28-day cube compression strength together with the relevant methods of test to define these features); any reinforcement or anchoring to be included within the encasing mass;
c) method for the construction of monolithic cast in-situ strongrooms, including the following: minimum quality of concrete (types and proportions of aggregates, cement and any other constituents, flowability of the freshly prepared mass, and the 28-day cube compression strength together with the relevant methods of test to define SIST EN 1143-1:2012

6 Test specimen 6.1 The test specimen shall be a safe, an ATM safe, a strongroom door or a strongroom (with or without a door). The strongroom test specimen shall consist of elements representing all joints and assemblies essential for testing purposes. Optional features (see 5.3 h)) which could decrease the burglary resistance value shall be included in the test specimen. Optional features (see 5.3 h)) and accessories such as time locking and time delay locking which could increase the resistance value in the tool attack test shall be removed or made not operative during the tool attack test. An ATM safe test specimen shall include an ATM base if this is required for any type of installation. If the ATM base is optional, the testing laboratory can choose whether to test with or without the ATM base. 6.2 Cable entrances for detection systems and/or accessories specified in the technical documentation shall be present in the test specimen.
6.3 Test specimens for built-in safes and cast in-situ strongrooms shall be constructed using the components supplied and following the instructions for installation, (see 5.8).
7 Tool attack test 7.1 Principle The test serves to establish the complete access, and for safes and ATM safes also the partial access, minimum resistance values of the test specimen. A testing team (see 7.2) examines a test specimen (see Clause 6) together with the technical documentation (see Clause 5) and devises a programme of attacking the test specimen. The testing team attacks the test specimen. The time taken to gain partial or complete access, assessed by inserting a test block, is recorded and then used to calculate a resistance value. The tools and programme of attack used during testing shall be those most likely, in the opinion of the testing team, to result in the lowest resistance values. Exploratory tests may be made. WARNING: Because some of the tests specified in this European Standard involve the use of processes imposing risk on the persons concerned, use only trained staff and ensure adequate supervision.
7.2 Testing team The testing team shall comprise: a) testing team leader who is responsible for the conduct of the test and whose function is to plan, direct and supervise the testing; b) time keeper whose function is confined to timekeeping and the compiling of the event record;
NOTE Testing should be carried out according to the current state of knowledge. To ensure maximum consistency in test results, testing laboratories should have EN ISO/IEC 17025 accreditation and should participate in audits, cooperative tests, experience-sharing events and other relevant training.
7.3 Apparatus 7.3.1 Attack tools Any tool used for the testing shall be given a coefficient and basic value according to Annex A. Tool category B includes tools of category A. Tool category C includes tools of categories A and B. Tool category D includes tools of categories A, B and C. Tool category S includes tools of categories A, B, C and D. Alterations to tools other than those permitted as 'specially made tools' shall not be made. For instance, it is not permitted to enlarge nozzles, lengthen electrodes, rods or levers etc. SAFETY WARNING: Tool safety devices such as guards, fuses and other current limiting features and/or maximum speed controls, shall not be removed or altered. To protect the operator(s), in the case of combined use of a hand impact tool and a chisel, a specially constructed chisel holder may be used. Such a chisel holder shall be regarded as a hand-gripping tool (see Table A.2). NOTE Testing laboratories should maintain a list of their current tools, together with their categories in accordance with Annex A. 7.3.2 Clock Clock to an accuracy of at least 0,05 min for each 10 min measuring period. The scaling shall be at least 0,01 min. Clocks shall be visible to all observers, and the beginning and end of each operating time shall be indicated by an acoustic or optical signal. 7.3.3 Test blocks 7.3.3.1 General The test blocks shall be made of a rigid material. 7.3.3.2 Test blocks to measure partial access Three test blocks, each with a length of 150 mm, and the following cross sections: a) circle with 125 mm diameter; b) square with 112 mm side length; edges and corners rounded with r = 5 mm; c) rectangle with 100 mm x 125 mm side length; edges and corners rounded with r = 5 mm. SIST EN 1143-1:2012

b) complete access against the body or the door. Additional tool attack tests according to a) and b) are required against the wall, top, base or door if the test specimen has areas or zones of a different construction and for which the resistance value can be reasonably expected to be lower (e.g. in the area of pre-existing holes). SIST EN 1143-1:2012

b) complete access against the door and/or against the body to remove the built-in safe from its encasement. Additional tool attack tests according to a) and b) are required if the test specimen has areas or zones of a different construction and for which the resistance value can be reasonably expected to be lower (e.g. in the area of pre-existing holes). 7.5.3 Strongrooms 7.5.3.1 General The test shall comprise at least one tool attack test for complete access against the strongroom wall and one tool attack test against the strongroom door for complete access. 7.5.3.2 Strongroom without door The test shall comprise at least one tool attack test for complete access. Additional tool attack tests for the complete access are required against ceiling, base and wall segments if the construction of the strongroom has areas or zones of different construction and for which the resistance value can reasonably be expected to be lower (e.g. in the area of pre-existing holes). 7.5.3.3 Strongroom doors The test shall comprise at least one tool attack test for complete access on the door (including frame and adjoining wall sections, if necessary). Additional tool attack tests for the complete access are required if the test specimen has areas or zones of different construction and for which the resistance value can reasonably be expected to be lower (e.g. in the area of pre-existing holes). 7.5.4 Grades I to VIII ATM safes 7.5.4.1 General Testing of grades I to VIII ATM safes shall comprise at least one tool attack test for: a) partial access against the body or door; b) complete access against the body or door; c) cutting or destroying the fixing by attack on any fixing attachment. Additional tool attack tests according to a) and b) shall be made on any area or zone of the test specimen which has a different construction and for which the resistance value can be reasonably expected to be lower (e.g. in the area of pre-existing holes). 7.5.4.2 Partial access testing
Par
...
