EN ISO 16371-2:2017
(Main)Non-destructive testing - Industrial computed radiography with storage phosphor imaging plates - Part 2: General principles for testing of metallic materials using X-rays and gamma rays (ISO 16371-2:2017, Corrected version 2018-05)
Non-destructive testing - Industrial computed radiography with storage phosphor imaging plates - Part 2: General principles for testing of metallic materials using X-rays and gamma rays (ISO 16371-2:2017, Corrected version 2018-05)
ISO 16371-2:2017 specifies fundamental techniques of computed radiography with the aim of enabling satisfactory and repeatable results to be obtained economically. The techniques are based on the fundamental theory of the subject and tests measurements. ISO 16371-2:2017 specifies the general rules for industrial computed X-rays and gamma radiography for flaw detection purposes, using storage phosphor imaging plates (IP). It is based on the general principles for radiographic examination of metallic materials on the basis of films, as specified in ISO 5579. The basic set-up of radiation source, detector and the corresponding geometry are intended to be applied in accordance with ISO 5579 and corresponding product standards such as ISO 17636 for welding and EN 12681 for foundry.
ISO 16371-2:2017 does not lay down acceptance criteria of the imperfections. Computed radiography (CR) systems provide a digital grey value image which can be viewed and evaluated on basis of a computer only. This practice describes the recommended procedure for detector selection and radiographic practice. Selection of computer, software, monitor, printer and viewing conditions are important but not the main focus of ISO 16371-2:2017.
The procedure it specifies provides the minimum requirements and practice to permit the exposure and acquisition of digital radiographs with a sensitivity of imperfection detection equivalent to film radiography and as specified in ISO 5579. Some application standards, e.g. EN 16407, can require different and less stringent practice conditions.
Zerstörungsfreie Prüfung - Industrielle Computer-Radiographie mit Phosphor-Speicherfolien - Teil 2: Grundlagen für die Prüfung von metallischen Werkstoffen mit Röntgen- und Gammastrahlen (ISO 16371-2:2017)
In diesem Teil von ISO 16371 werden grundlegende Techniken für die Computer-Radiographie mit dem Ziel festgelegt, auf wirtschaftliche Art und Weise zufrieden stellende und wiederholbare Ergebnisse zu erreichen. Die Techniken basieren sowohl auf den grundlegenden Theorien als auch auf Testmessungen. Für die industrielle Computer-Radiographie mit Röntgen- und Gammastrahlung zum Nachweis von Werkstofffehlern unter Anwendung von Phosphor-Speicherfolien (en: imaging plate, IP) werden in diesem Teil von ISO 16371 allgemeine Regeln festgelegt. Sie beruht auf den allgemeinen Grundlagen für die radiographische Untersuchung metallischer Werkstoffe mit Hilfe von Filmen, wie in ISO 5579 festgelegt. Die grundlegende Einstellung von Strahlenquelle, Detektor und geeigneten geometrischen Bedingungen soll nach ISO 5579 sowie nach den entsprechenden Produktnormen durchgeführt werden, z. B. ISO 17636 für Schweißverbindungen und EN 12681 für Anwendungen im Gießereiwesen.
In diesem Teil von ISO 16371 werden keine Zulässigkeitsgrenzen für Unregelmäßigkeiten festgelegt. Computer-Radiographiesysteme (CR-Systeme) liefern ein digitales Grauwertbild, das nur mittels Computer betrachtet und ausgewertet werden kann. Diese Anwendungsnorm legt das empfohlene Vorgehen für die Detektorauswahl und die radiographische Anwendung fest. Die Auswahl von Computer, Software, Monitor, Drucker und Betrachtungsbedingungen ist zwar wichtig, aber nicht das Hauptaugenmerk dieser Norm.
In dem hier beschriebenen Verfahren werden die minimalen Anforderungen und die Anwendung festgelegt, um digitale Durchstrahlungsbilder mit einer der Film-Radiographie äquivalenten Empfindlichkeit für die Erkennung von Unregelmäßigkeiten, wie in ISO 5579 spezifiziert, zu belichten und zu erhalten. Einige Anwendungsnormen, z. B. EN 16407, können andere und weniger strenge Vorgehensweisen verlangen
Essais non destructifs - Radiographie industrielle numérisée avec écrans photostimulables à mémoire - Partie 2: Principes généraux de l'essai radiographique des matériaux métalliques au moyen de rayons X et gamma (ISO 16371-2:2017)
L'ISO 16371-2:2017 spécifie les techniques fondamentales de radiographie numérique permettant d'obtenir des résultats satisfaisants et reproductibles de façon économique. Les techniques sont basées sur la théorie fondamentale en la matière et sur des mesurages d'essai. Le présent document spécifie les règles générales pour la radiographie industrielle numérisée par rayons X et gamma à des fins de détection de défauts, à l'aide d'écrans photostimulables à mémoire (IP). Il est basé sur les principes généraux de l'examen radiographique des matériaux métalliques au moyen de films, comme spécifié dans l'ISO 5579. Il est prévu que la disposition de base de la source de rayonnement, du détecteur et la géométrie correspondante soient appliquées conformément à l'ISO 5579 et aux normes de produits correspondantes telles que l'ISO 17636 pour les assemblages soudés et l'EN 12681 pour la fonderie.
L'ISO 16371-2:2017 ne fixe pas les critères d'acceptation des imperfections. Les systèmes de radiographie numérique (CR) fournissent une image constituée de valeurs de gris qui peut être visualisée et évaluée uniquement à l'aide d'un ordinateur. Cette pratique décrit le mode opératoire recommandé pour la sélection du détecteur et les pratiques radiographiques. Le choix de l'ordinateur, des logiciels, de l'écran, de l'imprimante et des conditions de visualisation est important mais n'est pas le sujet principal du présent document.
Le mode opératoire spécifié par le présent document fournit les exigences et les pratiques minimales permettant l'exposition et l'acquisition des radiographies numériques avec une sensibilité pour la détection des imperfections équivalente à la radiographie avec films et telle que spécifiée dans l'ISO 5579. Certaines normes d'application, telles que l'EN 16407, peuvent requérir des conditions pratiques différentes et moins strictes.
Neporušitveno preskušanje - Industrijska računalniška radiografija s hranjenjem na fosfornih ploščah - 2. del: Splošna načela za preskušanje kovinskih materialov z uporabo rentgenskih žarkov in žarkov gama (ISO 16371-2:2017, popravljena verzija 2018-05)
Ta evropski standard določa temeljne tehnike računalniške radiografije z namenom omogočanja zadovoljivih in ponovljivih rezultatov, ki so stroškovno ugodni. Te tehnike temeljijo na osnovni teoriji subjekta in preskusnih meritev. Ta dokument določa splošna pravila za industrijsko računalniško radiografijo z rentgenskimi in gama žarki za namene zaznavanja napak s hranjenjem na fosfornih slikovnih ploščah (IP). Temelji na splošnih načelih za radiografski pregled kovinskih materialov na podlagi filma (ISO 5579). Osnovna priprava vira sevanja, detektorja in ustrezne geometrije naj se uporabi skladno s standardom ISO 5579 ter ustreznimi standardi za izdelke, na primer standard ISO 17636 za varjenje in standard EN 12681 za livarstvo. Ne določa kriterijev sprejemljivosti za nepopolnosti. Digitalni detektorji zagotavljajo digitalno sivinsko sliko, ki jo je mogoče prikazati in oceniti samo prek računalnika. Ta praksa opisuje priporočen postopek za izbiro detektorja in radiografsko prakso. Izbira računalnika, programske opreme, monitorja, tiskalnika in pogojev prikaza je pomembna, vendar ni ključni del tega standarda. Postopek, določen v tem standardu, podaja minimalne zahteve in prakso, ki omogočajo izpostavljenost in pridobivanje digitalnih rentgenskih slik z občutljivostjo zaznavanja napak, enako kot pri radiografskem filmu in kot to določa standard ISO 5579.
