EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 3682-001
September 2013 ICS 49.060 Supersedes EN 3682-001:2006English Version
Aerospace series - Connectors, plug and receptacle, electrical, rectangular, interchangeable insert type, rack to panel, operating temperature 150 °C continuous - Part 001: Technical specification
Série aérospatiale - Connecteurs électriques rectangulaires rackables, fiches et embases, à inserts interchangeables, température d'utilisation 150 °C continu - Partie 001: Spécification technique
Luft- und Raumfahrt - Elektrischer Rechtecksteckverbinder, freie und feste Bauform, auswechselbare Isolierkörper, Gestell-Einschubsteckverbinder, Betriebstemperatur 150 °C konstant - Teil 001: Technische Lieferbedingungen This European Standard was approved by CEN on 8 May 2013.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2013 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 3682-001:2013: ESIST EN 3682-001:2014

EN 2267-002, Aerospace series — Cables, electrical, for general purpose — Operating temperatures between − 55 °C and 260 °C — Part 002: General EN 2591 (all parts), Aerospace series — Elements of electrical and optical connection — Test methods EN 3155 (all parts), Aerospace series — Electrical contacts used in elements of connection EN 3197, Aerospace series - Design and installation of aircraft electrical and optical interconnection systems
EN 3682 (all parts), Aerospace series — Connectors, plug and receptacle, electrical, rectangular, interchangeable insert type, rack to panel, operating temperature 150 °C continuous EN 3909, Aerospace series — Test fluids and test methods for electric components and sub-assemblies EN 4529-002, Aerospace series — Elements of electrical and optical connection — Sealing plugs — Part 002: Index of product standards EN 9133, Aerospace series — Quality management systems — Qualification procedure for aerospace standard parts MIL-C-83527 (all parts), Connectors, plug and receptacle, electrical, rectangular multiple insert type, rack to panel, environment resisting, 150 °C total continuous operating temperature 1) MIL-L-15719, (Amendment 3), Military specification, lubricating grease (High temperature, electric motor, ball and roller bearings) 1) MIL-STD-454, Military standard — Standard General Requirements for Electronic Equipment 1)
1) Published by: DoD National (US) Mil. Department of Defense http://www.defenselink.mil/ SIST EN 3682-001:2014

Key 1 Grounding spring system 2 Receptacle assembly 3 Plug assembly 4 Metal to metal bottoming on both sides of polarizing key retaining plate 5 Stabilizer 6 X = 21,64 initial engagement max. Figure 1 — Connector mated conditions SIST EN 3682-001:2014

Key 1 Size 22 socket contact - Other size pin contact 2 Mechanical bottom of receptacle 3 Size 22 pin contact - Other size socket contact 4 Mechanical bottom of plug Figure 2 Table 1 — Contact position Contact size Male Female A B A B 22 – 17,20/16,33 11,18/10,56 – 20 12,19/11,12 – – 18,82/17,55 16 a
10,34/9,07 – – 18,31/17,04 12 10,34/9,17 – – 18,14/17,02 Triaxial size 8 b
11,07/10,21 – – 18,44/17,58 Quadrax size 8 b 11,07/10,21 – – 18,44/17,58 Coaxial size 16 c
10,34/9,07 – – 18,31/17,04 Coaxial size 12 12,19/10,97 – – 18,11/16,92 Coaxial size 5 11,18/10,26 – – 18,44/17,58 Coaxial size 1 10,79/9,83 – – 20,34/19,53 a For arrangements 1-126 and 2-62Q2, A = 7,83/7,07 and B = 15,76/15,04. b For arrangements 2-62Q2, A = 8,78/8,04 and B = 15,92/15,13. c For arrangements 1-126 and 2-62Q2, A = 7,98/7,07 and B = 15,76/15,05.
6.2 Receptacle mating dimensions Mating dimensions for sizes 2, 3 and 4 receptacle housings are specified on Figures 3, 4, 5 and 6 and Tables 2, 3 and 4. SIST EN 3682-001:2014

Key 1 18,57 18,37 for size 22 socket inserts 6 Boss (twice) Ø 4,78 Ø 4,70 2 Boss (twice) Ø 3,99 Ø 3,91 7 Type all size 22 contact cavities (see Table 11) 3 Centre line insert 8 Type all other size contact cavities 4 Center line
9 21,03 20,83 for other size pin inserts - To face of rigid 5 Insert assembly
Insert except 1-126 and 2-62Q2 where the distance is 18,37 / 18,57 Figure 3 B SIST EN 3682-001:2014

Key 1 Centre line T Figure 4 Table 2 DATUM T DATUM S 100,71 100,76 100,79 100,81 100,84 100,86 32,94 0,30 0,30 0,28 0,25 0,23 0,20 32,97 0,28 0,28 0,25 0,23 0,23 0,20 32,99 0,25 0,25 0,23 0,23 0,20 0,18 33,02 0,23 0,23 0,23 0,20 0,18 0,18 33,04 0,20 0,20 0,20 0,18 0,18 0,15
Key 1 Centre line T 2 Centre line insert Figure 5 Table 3 DATUM T DATUM S 100,71 100,76 100,79 100,81 100,84 100,86 69,98 0,30 0,30 0,28 0,25 0,23 0,20 70,03 0,30 0,30 0,28 0,25 0,23 0,20 70,05 0,28 0,28 0,25 0,23 0,23 0,20 70,08 0,25 0,25 0,23 0,23 0,20 0,18 70,10 0,23 0,23 0,23 0,20 0,18 0,18 70,13 0,20 0,20 0,20 0,18 0,18 0,15
Key 1 Centre line T 2 Centre line insert Figure 6 Table 4 DATUM T DATUM S 100,71 100,76 100,79 100,81 100,84 100,86 107,06 0,30 0,30 0,28 0,25 0,23 0,20 107,11 0,30 0,30 0,28 0,25 0,23 0,20 107,14 0,28 0,28 0,25 0,23 0,23 0,20 107,16 0,25 0,25 0,23 0,23 0,20 0,18 107,19 0,23 0,23 0,23 0,20 0,18 0,18 107,21 0,20 0,20 0,20 0,18 0,18 0,15
Key 1 Insert location 34,01 33,50 7 Center line insert 2 17,75 17,55 for size 22 pin insert 8 Center line
20,21 20,01 for other size receptacle insert 9 Inserts 3 Center line
Ø 3,99 Ø 3,91 10 Emi feature - The emi spring is removable and replaceable by the users under their responsibilities 4 Type all other size contact cavities 11 Boss (twice)
Ø 4,78 Ø 4,70 5 Type all size 22 contact cavities (see Table 11) 12 2,54 boss (twice) 6 Stabilizer seal 13 Chamfer 0,10 max. - Groove for emi feature Figure 7 S B A SIST EN 3682-001:2014

Key 1 Centre line of datum T Figure 8 Table 5 DATUM T DATUM S 100,51 100,53 100,56 100,58 100,61 100,64 100,66 32,69 0,15 0,18 0,18 0,20 0,20 0,20 0,20 32,72 0,18 0,18 0,20 0,23 0,23 0,23 0,23 32,74 0,18 0,20 0,23 0,23 0,25 0,25 0,25 32,77 0,20 0,23 0,23 0,25 0,28 0,28 0,28 32,79 0,20 0,23 0,25 0,28 0,30 0,30 0,30
Key 1 Centre line of datum T 2 Centre line insert Figure 9 Table 6 DATUM T DATUM S 100,51 100,53 100,56 100,58 100,61 100,64 100,66 69,77 0,15 0,18 0,18 0,20 0,20 0,20 0,20 69,80 0,18 0,18 0,20 0,23 0,23 0,23 0,23 69,82 0,18 0,20 0,23 0,23 0,25 0,25 0,25 69,85 0,20 0,23 0,23 0,25 0,28 0,28 0,28 69,88 0,20 0,23 0,25 0,28 0,30 0,30 0,30 69,90 0,20 0,23 0,25 0,28 0,30 0,30 0,30 69,93 0,20 0,23 0,25 0,28 0,30 0,30 0,30
Key 1 Centre line of datum T 2 Centre line insert Figure 10 Table 7 DATUM T DATUM S 100,51 100,53 100,56 100,58 100,61 100,64 100,66 106,86 0,15 0,18 0,18 0,20 0,20 0,20 0,20 106,88 0,18 0,18 0,20 0,23 0,23 0,23 0,23 106,91 0,18 0,20 0,23 0,23 0,25 0,25 0,25 106,93 0,20 0,23 0,23 0,25 0,28 0,28 0,28 106,96 0,20 0,23 0,25 0,28 0,30 0,30 0,30 106,99 0,20 0,23 0,25 0,28 0,30 0,30 0,30 107,01 0,20 0,23 0,25 0,28 0,30 0,30 0,30
Key 1 Bottom insert 2 R 1,5 max. configuration optional 3 All around Figure 11 Table 8 Cavities D F A, C, E 39,065 39,03 40,45 40,35 B, D, F 27,885 27,85 29,28 29,18
Key 1 Two holes Ø 3,25 Ø 3,10 2 Centre line of datum X 3 2 ½ identical insert retaining plate
Figure 12 Table 9 Insert cavities A B C
max. A, C, E 44,96 50,17 49,91 45,97 B, D, F 33,78 38,99 38,74 34,80
Figure 13 — Size 22 contact cavity
a)
Socket contact cavity b)
Socket cavity size 1 coaxial Figure 14 Table 10 Contact size Dimensions A B
min. 20 2,67 / 2,41 1,27 16 3,38 / 3,12 2,01 12 4,57 / 4,32 2,51 Coaxial 1 13,07 / 12,80 – Coaxial 5 7,29 / 7,04 5,72 Triaxial/quadrax 8 7,49 / 7,24 5,77 SIST EN 3682-001:2014

Key 1 Seal 2 Contact Figure 15 — Interfacial seal Table 11 Contact size Dimensions A B C
max. 22 female 2,29 / 2,13 1,75 / 1,55 2,29 20 male 1,83 / 1,68 2,54 / 2,29 1,83 16 male 2,51 / 2,34 2,67 / 2,41 2,51 12 male 3,33 / 3,15 2,79 / 2,54 3,33 Coaxial 5 male 7,01 / 6,81 2,29 / 2,03 7,01 Triaxial/quadrax 8 male 7,01 / 6,81 2,67 / 2,41 7,01 No interfacial seal for size 1 coaxial.
Key 1 Front face 2 Position Figure 16 Table 12 Contact size Position
Contact size 22
φ 0,06 D F K
Contact size 20
φ 0,10 D F K
Contact size 16
φ 0,10 D F K
Contact size 12
φ 0,10 D F K
Triaxial and quadrax size 8
φ 0,10 D F K
Coaxial size 5
φ 0,10 D F K
Coaxial size 1
φ 0,10 D F K
Figure 17 — Contact arrangement 1-150 Table 13 — Contact arrangement 1-150 Dimensions in millimetres Contact position a Y X − 11,43 − 8,89 − 6,35 − 3,81 − 1,27 + 1,27 + 3,81 + 6,35 + 8,89 + 11,43 + 17,78 1 2 3 4 5 6 7 8 9 10 + 15,24 11 12 13 14 15 16 17 18 19 20 + 12,70 21 22 23 24 25 26 27 28 29 30 + 10,16 31 32 33 34 35 36 37 38 39 40 + 7,62 41 42 43 44 45 46 47 48 49 50 + 5,08 51 52 53 54 55 56 57 58 59 60 + 2,54 61 62 63 64 65 66 67 68 69 70 0 71 72 73 74 75 76 77 78 79 80 − 2,54 81 82 83 84 85 86 87 88 89 90 − 5,08 91 92 93 94 95 96 97 98 99 100 − 7,62 101 102 103 104 105 106 107 108 109 110 − 10,16 111 112 113 114 115 116 117 118 119 120 − 12,70 121 122 123 124 125 126 127 128 129 130 − 15,24 131 132 133 134 135 136 137 138 139 140 − 17,78 141 142 143 144 145 146 147 148 149 150 a Mating face of insert for female contacts is shown.
Table 14 Contacts Size Quantity Location 22 150 1 to 150
Figure
18 — Contact arrangement 1-47T2 Table 15 — Contact arrangement 1-47T2 Dimensions in millimetres Contact position a
Y X − 9,52 − 8,00 − 5,72 − 1,90 0 + 1,90 + 5,72 + 8,00 + 9,52 + 17,14 1 – 2 3 – 4 5 – 6 + 13,34 7 – 8 9 – 10 11 – 12 + 9,52 13 – 14 15 – 16 17 – 18 + 5,72 19 – 20 21 – 22 23 – 24 + 1,90 25 – 26 27 – 28 29 – 30 − 1,90 31 – 32 33 – 34 35 – 36 − 5,72 37 – 38 39 – 40 41 – 42 − 9,52 – – – 43 – 44 – – – − 13,34 – – – – 45 – – – – − 14,22 – 48 – – – – – 49 – − 17,14 – – – 46 – 47 – – – a Mating face of insert for male contacts is shown.
Table 16 Contacts Size Quantity Location 20 47 1 to 47 8 triaxial 2 48 to 49
Figure 19 — Contact arrangement 1-24 Table 17 — Contact arrangement 1-24 Dimensions in millimetres Contact position a
Y X − 9,52 − 3,18 + 3,18 + 9,52 + 15,88 1 2 3 4 + 9,52 5 6 7 8 + 3,18 9 10 11 12 − 3,18 13 14 15 16 − 9,52 17 18 19 20 − 15,88 21 22 23 24 a Mating face of insert for male contacts is shown.
Table 18 Contacts Size Quantity Location 12 24 1 to 24
Figure 20 — Contact arrangement 1-60 Table 19 — Contact arrangement 1-60 Dimensions in millimetres Contact position a
Y X − 9,52 − 5,72 − 1,90 + 1,90 + 5,72 + 9,52 + 17,14 1 2 3 4 5 6 + 13,34 7 8 9 10 11 12 + 9,52 13 14 15 16 17 18 + 5,72 19 20 21 22 23 24 + 1,90 25 26 27 28 29 30 − 1,90 31 32 33 34 35 36 − 5,72 37 38 39 40 41 42 − 9,52 43 44 45 46 47 48 − 13,34 49 50 51 52 53 54 − 17,14 55 56 57 58 59 60 a Mating face of insert for male contacts is shown.
Table 20 Contacts Size Number Cavities 20 60 1 to 60 SIST EN 3682-001:2014

Figure 21 — Contact arrangement 1-70C12 Table 21 — Contact arrangement 1-70C12 Dimensions in millimetres Contact position a
Y X − 11,43 − 9,52 − 8,89 − 6,35 − 3,81 − 3,18 − 1,27 + 1,27 + 3,18 + 3,81 + 6,35 + 8,89 + 9,52 + 11,43 + 17,78 1 – 2 3 4 – 5 6 – 7 8 9 – 10 + 15,24 11 – 12 13 14 – 15 16 – 17 18 19 – 20 + 12,70 21 – 22 23 24 – 25 26 – 27 28 29 – 30 + 10,16 31 – 32 33 34 – 35 36 – 37 38 39 – 40 + 7,62 41 – 42 43 44 – 45 46 – 47 48 49 – 50 + 5,08 51 – 52 53 54 – 55 56 – 57 58 59 – 60 + 2,54 61 – 62 63 64 – 65 66 – 67 68 69 – 70 − 2,30 – 71 – – – 72 – – 73 – – – 74 – − 9,00 – 75 – – – 76 – – 77 – – – 78 – − 15,70 – 79 – – – 80 – – 81 – – – 82 – a Mating face of insert for size 22 female contact is shown.
Table 22 Contacts Size Quantity Location 22 70 1 to 70 12 12 71 to 82 SIST EN 3682-001:2014

Figure 22 — Contact arrangement 1-35 Table 23 — Contact arrangement 1-35 Dimensions in millimetres Contact position a
Y X − 10,16 − 5,08 0 + 5,08 + 10,16 + 15,24 1 2 3 4 5 + 10,16 6 7 8 9 10 + 5,08 11 12 13 14 15 0 16 17 18 19 20 − 5,08 21 22 23 24 25 − 10,16 26 27 28 29 30 − 15,24 31 32 33 34 35 a Mating face of insert for male contacts is shown.
Table 24 Contacts Size Quantity Location 16 35 1 to 35
Figure 23 — Contact arrangement 1-126 Table 25 — Contact arrangement 1-126 Dimensions in millimetres Contact position a
Y X − 11,43 − 10,15 − 8,89 − 6,35 − 6,09 − 3,81 − 2,03 − 1,27 + 1,27 + 2,03 + 3,81 + 6,09 + 6,35 + 8,89 + 10,15 + 11,43 + 16,38 – 1 – – – – 2 – – – – 3 – – – – + 14,10 – – – – 4 – – – – 5 – – – – 6 – + 10,16 7 – 8 9 – 10 – 11 12 – 13 – 14 15 – 16 + 7,62 17 – 18 19 – 20 – 21 22 – 23 – 24 25 – 26 + 5,08 27 – 28 29 – 30 – 31 32 – 33 – 34 35 – 36 + 2,54 37 – 38 39 – 40 – 41 42 – 43 – 44 45 – 46 0 47 – 48 49 – 50 – 51 52 – 53 – 54 55 – 56 − 2,54 57 – 58 59 – 60 – 61 62 – 63 – 64 65 – 66 − 5,08 67 – 68 69 – 70 – 71 72 – 73 – 74 75 – 76 − 7,62 77 – 78 79 – 80 – 81 82 – 83 – 84 85 – 86 − 10,16 87 – 88 89 – 90 – 91 92 – 93 – 94 95 – 96 − 12,70 97 – 98 99 – 100 – 101 102 – 103 – 104 105 – 106 − 15,24 107 – 108 109 – 110 – 111 112 – 113 – 114 115 – 116 − 17,78 117 – 118 119 – 120 – 121 122 – 123 – 124 125 – 126 a Mating face of insert for size 22 female and size 16 male contacts is shown. Table 26 Contacts Size Quantity Location 16 6 1 to 6 22 120 7 to 126 SIST EN 3682-001:2014

Figure 24 — Contact arrangement 1-C12T6 Table 27 — Contact arrangement 1-C12T6 Dimensions in millimetres Contact position a
Y X − 9,84 − 8,13 − 4,92 0 + 4,92 + 8,13 + 9,84 + 14,36 – 1 – – – 2 – + 9,73 – – – 3 – – – + 5,10 – 4 – – – 5 – + 0,47 – – – 6 – – – − 2,26 7 – – – – – 8 − 5,71 – – 9 – 10 – – − 9,16 11 – – 12 – – 13 − 12,61 – – 14 – 15 – – − 16,06 16 – – 17 – – 18 a Mating face of insert for male contacts is shown.
Table 28 Contacts Size Quantity Location 8 triaxial 6 1 to 6 12 coaxial 12 7 to 18 This insert is metallic. SIST EN 3682-001:2014

Figure 25 — Contact arrangement 1-70C1 Table 29 — Contact arrangement 1-70C1 Dimensions in millimetres Contact position a
Y X − 11,43 − 8,89 − 6,35 − 3,81 − 1,27 0 + 1,27 + 3,81 + 6,35 + 8,89 + 11,43 + 17,78 1 2 3 4 5 – 6 7 8 9 10 + 15,24 11 12 13 14 15 – 16 17 18 19 20 + 12,70 21 22 23 24 25 – 26 27 28 29 30 + 10,16 31 32 33 34 35 – 36 37 38 39 40 + 7,62 41 42 43 44 45 – 46 47 48 49 50 + 5,08 51 52 53 54 55 – 56 57 58 59 60 + 2,54 61 62 63 64 65 – 66 67 68 69 70 − 10,16 – – – – – 71 – – – – – a Mating face of insert for size 22 female contacts is shown.
Table 30 Contacts Size Quantity Location 22 70 1 to 70 1 coaxial 1 71
Figure 26 — Contact arrangement 1-Q11 Table 31 — Contact arrangement 1-Q11 Dimensions in millimetres Contact position a
Y X − 8,03 0 + 8,03 + 13,92 AA – CC + 9,27 – BB – + 4,65 DD – FF 0 – EE – − 4,65 GG – JJ − 9,27 – HH – − 13,92 KK – LL a Mating face of insert for male contacts shown.
Table 32 Contacts Size Quantity Location 8 (quadrax) 11 AA to LL This insert is metallic SIST EN 3682-001:2014

Figure 27 — Contact arrangement 1-118Q2 Table 33 — Contact arrangement 1-118Q2 Dimensions in millimetres Contact location a Y X − 11,43 − 8,89 − 8,00 − 6,35 − 3,81 − 1,27 + 1,27 + 3,81 + 6,35 + 8,00 + 8,89 + 11,43 + 17,78 A1 B1 – C1 D1 E1 F1 G1 H1 – J1 K1 + 15,24 A2 B2 – C2 D2 E2 F2 G2 H2 – J2 K2 + 12,70 A3 B3 – C3 D3 E3 F3 G3 H3 – J3 K3 + 10,16 A4 B4 – C4 D4 E4 F4 G4 H4 – J4 K4 + 7,62 A5 B5 – C5 D5 E5 F5 G5 H5 – J5 K5 + 5,08 A6 B6 – C6 D6 E6 F6 G6 H6 – J6 K6 + 2,54 A7 B7 – C7 D7 E7 F7 G7 H7 – J7 K7 0 A8 B8 – C8 D8 E8 F8 G8 H8 – J8 K8 − 2,54 A9 B9 – C9 D9 E9 F9 G9 H9 – J9 K9 − 5,08 A10 B10 – C10 D10 E10 F10 G10 H10 – J10 K10 − 7,62 A11 B11 – C11 D11 E11 F11 G11 H11 – J11K K11 − 10,16 – – – – – E12 F12 – – – – – − 12,70 – – – – – E13 F13 – – – – – − 14,22 – – 1 – – – – – – 2 – – − 15,24 – – – – – E14 F14 – – – – – − 17,78 – – – – – E15 F15 – – – – – a Mating face of insert for male contacts shown. Table 34 Contacts Size Quantity Location 22 118 A1 to K11, E12 to E15, F12 to F15 8 triaxial or quadrax 2 1, 2 SIST EN 3682-001:2014

Figure 28 — Contact arrangement 1-68Q4 Table 35 — Contact arrangement 1-68Q4 Dimensions in millimetres Contact location a Y X − 11,43 − 8,89 − 8,00 − 6,35 − 3,81 − 1,27 0 + 1,27 + 3,81 + 6,35 + 8,00 + 8,89 + 11,43 + 16,51 – – – – – – 5 – – – – – – + 14,22 – – 1 – – – – – – – 2 – – + 11,43 – – – – – – 6 – – – – – – + 7,62 11 12 – 13 14 – – – 15 16 – 17 18 + 6,35 – – – – – – 7 – – – – – – + 5,08 19 20 – 21 22 – – – 23 24 – 25 26 + 2,54 27 28 – 29 30 31 – 32 33 34 – 35 36 0 37 38 – 39 40 41 – 42 43 44 – 45 46 − 2,54 47 48 – 49 50 51 – 52 53 54 – 55 56 − 5,08 57 58 – 59 60 – – – 61 62 – 63 64 − 6,35 – – – – – – 8 – – – – – – − 7,62 65 66 – 67 68 – – – 69 70 – 71 72 − 11,43 – – – – – – 9 – – – – – – − 14,22 – – 3 – – – – – – – 4 – – − 16,51 – – – – – – 10 – – – – – – a Mating face of insert for size 22 female contacts and size 16 and 8 male contacts shown. Table 36 Contacts Size Quantity Location 22 62 11 to 72 16 6 5 to 10 8 triaxial or quadrax 4 1 to 4 SIST EN 3682-001:2014

Figure 29 — Contact arrangement 1-0 Table 37 — Contact arrangement 1-0 Contacts Size Quantity Location – – – This insert is metallic. SIST EN 3682-001:2014

Figure 30 — Contact arrangement 2-100 Table 38 — Contact arrangement 2-100 Dimensions in millimetres Contact position a
Y X − 11,43 − 8,89 − 6,35 − 3,81 − 1,27 + 1,27 + 3,81 + 6,35 + 8,89 + 11,43 + 11,43 1 2 3 4 5 6 7 8 9 10 + 8,89 11 12 13 14 15 16 17 18 19 20 + 6,35 21 22 23 24 25 26 27 28 29 30 + 3,81 31 32 33 34 35 36 37 38 39 40 + 1,27 41 42 43 44 45 46 47 48 49 50 − 1,27 51 52 53 54 55 56 57 58 59 60 − 3,81 61 62 63 64 65 66 67 68 69 70 − 6,35 71 72 73 74 75 76 77 78 79 80 − 8,89 81 82 83 84 85 86 87 88 89 90 − 11,43 91 92 93 94 95 96 97 98 99 100 a Mating face of insert for size 22 female contacts is shown.
Table 39 Contacts Size Quantity Location 22 100 1 to 100
Figure 31 — Contact arrangement 2-11C2 Table 40 — Contact arrangement 2-11C2 Dimensions in millimetres Contact position a
Y X − 9,65 − 9,40 − 6,10 − 3,81 0 + 3,81 + 6,10 + 9,40 + 9,65 + 10,67 1 – – – – – – – 4 + 9,40 – – – 2 – 3 – – – + 5,84 5 – – – – – – – 6 + 2,29 – – – 7 – 8 – – – − 0,76 – 9 – – – – – 10 – − 3,05 – – – – 11 – – – – − 7,87 – – 12 – – – 13 – – a Mating face of insert for male contacts is shown.
Table 41 Contacts Size Quantity Location 20 4 1, 4, 5, 6 16 3 9, 10, 11 12 4 2, 3, 7, 8 5 coaxial 2 12, 13
2-20T4 2-20Q4
8 triaxial 8 quadrax
Figure 32 — Contact arrangement 2-20T4 or 2-20Q4 Table 42 — Contact arrangement 2-20T4 or 2-20Q4 Dimensions in millimetres Contac
...
