EN 3475-810:2025 - "Aerospace series - Cables, electrical, aircraft use - Test methods - Part 810: Structural return loss" defines methods for measuring the structural return loss (SRL) of symmetrical cables used for digital data transmission in aerospace applications. The standard explains how to derive SRL from measured complex impedance (open/short) and fitted characteristic impedance, and it gives practical guidance for high-frequency measurements and specimen preparation.
Key topics and requirements
- Scope: Measurement methods for SRL of balanced cable pairs/quad for digital data transmission; intended to be used together with EN 3475-100 and EN 50289-1-11.
- Structural return loss (SRL): A parameter that quantifies reflected signal level due to structural effects of the cable relative to its characteristic impedance (Zc). SRL is sensitive to how characteristic impedance is centered about the load impedance.
- Specimen preparation: Test specimens shall be at least 100 m long. Cable ends must be prepared so pair/quad assembly is maintained. Measurements may be taken on production drums or final delivery packages from one direction.
- Apparatus: Typical equipment includes a HF network analyser and an appropriate impedance transformer (balun) to allow balanced measurements representative of the pair under test.
- Measurement method: SRL is a calculated parameter based on measured complex impedance from open and short circuits (see EN 3475-805 Method C). The fitted characteristic impedance is computed from measured points across frequency, then SRL is calculated using the specified formula.
- Corrections: Correction procedures in EN 50289-1-11:2016, Annex B are recommended to minimize negative effects of cable preparation during high-frequency measurements.
- Requirements: Measured SRL values shall not exceed limits specified in the applicable product standard.
Applications and users
This standard is essential for:
- Aerospace cable manufacturers performing production and acceptance testing.
- Test laboratories and OEMs conducting quality assurance and performance validation of data cables for aircraft.
- Design and systems engineers validating signal integrity for high-speed digital links in avionics.
- Certification and procurement teams verifying compliance with product standards and procurement specifications.
Practical uses include production-line quality control, acceptance testing of drums and delivered cable, troubleshooting signal reflections at high frequency, and validating characteristic impedance and return loss performance for avionics data links.
Related standards
- EN 3475-100 - Test methods - General
- EN 3475-805 - Characteristic impedance (method references used for SRL calculation)
- EN 50289-1-11:2016 - Communication cables - Test methods (characteristic/input impedance, return loss) - includes Annex B correction procedures
Keywords: EN 3475-810:2025, structural return loss, SRL, aerospace cables, cable test methods, characteristic impedance, HF network analyser, balun, return loss measurement.
