EN 14420-1:2013
(Main)Hose fittings with clamp units - Part 1: Requirements, types of fixing and connection, designation and testing
Hose fittings with clamp units - Part 1: Requirements, types of fixing and connection, designation and testing
This European Standard specifies requirements, types of fixing and connection, designation and testing for hose fittings with clamp units for hoses made of rubber/plastics or thermoplastics preferably for use with flammable and non flammable products. It contains requirements for hose fittings to ensure that, when used appropriately, the user or third persons are not exposed to hazards from fire, explosions or acid burns, for example from mineral oils or chemicals, and that the environment is protected from pollution and other detritus.
For maximum working pressure (WP) and temperature see 4.3.
WARNING - Before decoupling of the quick coupling connections according to Parts 6, 7 and 8, the assembly should be at atmospheric pressure.
Schlaucharmaturen mit Klemmfassungen - Teil 1: Anforderungen, Arten der Befestigung und Verbindung, Bezeichnung und Prüfung
Diese Europäische Norm legt die Anforderungen, Arten der Befestigung und Verbindung, Bezeichnung und Prüfung für Schlaucharmaturen mit Klemmfassungen für Schläuche aus Gummi/Kunststoff oder Thermoplast fest, die vorzugsweise für brennbare und nicht brennbare Produkte verwendet werden. Sie enthält Anforderungen an Schlaucharmaturen, um sicherzustellen, dass bei bestim¬mungsgemäßem Gebrauch Benutzer oder Dritte keinen Gefahren durch Brand, Explosionen oder Verätzungen, z. B. durch Mineralöle oder Chemikalien, ausgesetzt sind und die Umwelt vor Verunreinigungen und Beeinträchtigungen geschützt ist.
Höchst zulässige Arbeitsdrücke und -temperaturen siehe 4.3.
WARNUNG — Vor dem Entkuppeln der Schnellkupplungen nach den Teilen 6, 7 und 8 sollte die Leitung drucklos sein.
Raccords pour flexibles avec demi-coquille - Partie 1: Exigences, types de fixation et connexion, désignation et essais
La présente Norme européenne spécifie les exigences, les types de fixation et de connexion, la désignation et les essais applicables aux raccords pour flexibles avec demi-coquille, fabriqués en caoutchouc/plastique ou de préférence en thermoplastique, destinés à être utilisés avec des produits inflammables ou ininflammables. Elle contient des exigences relatives aux raccords pour flexibles pour s'assurer que, lorsqu'ils sont utilisés correctement, ils n'exposent pas l'utilisateur ou des tierces personnes à des risques d'incendie, d'explosion ou de brûlure par acides, par exemple dus à des huiles minérales ou à des produits chimiques, et que l'environnement est protégé contre la pollution et autres effets préjudiciables.
Pour la pression maximale de service (PS) et la température maximale voir 4.3.
AVERTISSEMENT — Il convient de dépressuriser l'assemblage à la pression atmosphérique avant de découpler les raccords rapides conformes aux Parties 6, 7 et 8.
Cevni fitingi z objemkami - 1. del: Zahteve, pregled, označevanje in preskušanje
Ta evropski standard določa zahteve za cevne fitinge z objemkami za cevi iz gume/polimerov ali plastomerov, po možnosti za uporabo z vnetljivimi in nevnetljivimi izdelki. Navaja zahteve za cevne fitinge, da se zagotovi, da uporabnik ali tretje osebe pri ustrezni uporabi niso izpostavljeni tveganjem za nastanek požara, eksplozijam ali kemičnim opeklinam, na primer zaradi mineralnih olj ali kemikalij, ter da je okolje zaščiteno pred onesnaženjem in drugo škodo. V tej seriji standardov je priporočena uporaba neazbestnih materialov pri tesnilih v cevnih fitingih. Za največji delovni tlak (WP) in temperaturo glej 4.3.
General Information
Relations
Standards Content (Sample)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Schlaucharmaturen mit Klemmfassungen - Teil 1: Anforderungen, Übersicht, Bezeichnung und PrüfungRaccords pour flexibles avec demi-coquille - Partie 1: Prescription, présentation générale, désignation et essaisHose fittings with clamp units - Part 1: Requirements, survey, designation and testing23.040.60Prirobnice, oglavki in spojni elementiFlanges, couplings and jointsICS:Ta slovenski standard je istoveten z:EN 14420-1:2013SIST EN 14420-1:2013en,fr,de01-september-2013SIST EN 14420-1:2013SLOVENSKI
STANDARDSIST EN 14420-1:2005+A1:20071DGRPHãþD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 14420-1
July 2013 ICS 23.040.70 Supersedes EN 14420-1:2004+A1:2007English Version
Hose fittings with clamp units - Part 1: Requirements, types of fixing and connection, designation and testing
Raccords pour flexibles avec demi-coquille - Partie 1: Exigences, types de fixation et connexion, désignation et essais
Schlaucharmaturen mit Klemmfassungen - Teil 1: Anforderungen, Arten der Befestigung und Verbindung, Bezeichnung und Prüfung This European Standard was approved by CEN on 15 May 2013.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2013 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 14420-1:2013: ESIST EN 14420-1:2013
For maximum working pressure (WP) and temperature see 4.3. WARNING — Before decoupling of the quick coupling connections according to Parts 6, 7 and 8, the assembly should be at atmospheric pressure. 2 Normative references The following documents, in whole or in part, are normatively referenced in this document and are indispensable for its application. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 10204, Metallic products — Types of inspection documents EN 14420-2, Hose fittings with clamp units — Part 2: Hose side parts of hose tail EN 14420-3, Hose fittings with clamp units — Part 3: Clamp units, bolted or pinned EN 14420-4, Hose fittings with clamp units — Part 4: Flange connections EN 14420-5, Hose fittings with clamp units — Part 5: Threaded connections EN 14420-6, Hose fittings with clamp units — Part 6: TW tank truck couplings EN 14420-7, Hose fittings with clamp units — Part 7: Cam locking couplings EN 14420-8, Hose fittings with clamp units — Part 8: Symmetrical half coupling (Guillemin system) EN ISO 228-1, Pipe threads where pressure-tight joints are not made on the threads — Part 1: Dimensions, tolerances and designation (ISO 228-1) EN ISO 8330:2008, Rubber and plastics hoses and hose assemblies — Vocabulary (ISO 8330:2007) ISO 2859-1, Sampling procedures for inspection by attributes — Part 1: Sampling schemes indexed by acceptance quality limit (AQL) for lot-by-lot inspection 3 Terms and definitions For the purposes of this document, the terms and definitions given in EN ISO 8330:2008 and the following apply. 3.1 DN (nominal size) alphanumeric designation of size for components of a pipework system, which is used for reference purposes. It comprises the letters DN followed by a dimensionless whole number which is indirectly related to the physical size, in millimetres, of the bore or outside diameter of the end connections Note 1 to entry: The number following the letters DN does not represent a measurable value and should not be used for calculation purposes except where specified in the relevant standard. SIST EN 14420-1:2013
All hose fittings according to EN 14420-6 and EN 14420-7 shall be applicable to the working pressure range from -0,8 bar to 16 bar. Exceptions hereof are the aluminium cast fittings in EN 14420-7, whose maximum working pressure is limited to 10 bar.
Only hose fittings according to EN 14420-8 having elongation values of more than 4 % are applicable to the working pressure range of –0,8 bar to 16
...
