EN 16729-3:2018
(Main)Railway applications - Infrastructure - Non-destructive testing on rails in track - Part 3: Requirements for identifying internal and surface rail defects
Railway applications - Infrastructure - Non-destructive testing on rails in track - Part 3: Requirements for identifying internal and surface rail defects
This part of this European Standard specifies the NDT methods used to detect internal and surface rail defects and the suitability of each method for the detection and evaluation of typical rail defects of rails installed in track.
This part of this European Standard does not specify the assessment criteria of rail defects and the derived actions.
This part of this European Standard applies only to rail profiles meeting the requirements of EN 13674-1.
Bahnanwendungen - Infrastruktur - Zerstörungsfreie Prüfung an Schienen im Gleis - Teil 3: Anforderungen zur Identifizierung von inneren Fehlern und Schienenoberflächenfehlern
Dieser Teil dieser Europäischen Norm legt die zerstörungsfreien Prüfverfahren zur Feststellung innerer Fehler und Schienenoberflächenfehler sowie die Eignung des jeweiligen Verfahrens für die Erkennung und Bewertung typischer Schienenfehler an Schienen im Gleis fest.
Dieser Teil dieser Europäischen Norm führt keine Bewertungskriterien für Schienenfehler oder die daraus abzuleitenden Maßnahmen an.
Dieser Teil dieser Europäischen Norm gilt nur für Schienenprofile, die den Anforderungen von EN 13674 1 entsprechen.
Applications ferroviaires - Infrastructure - Essais non destructifs sur les rails de voie - Partie 3 : Exigences pour l'identification des défauts internes et de surface des rails
La présente partie de cette Norme européenne spécifie les méthodes d'essais non destructifs utilisées pour détecter les défauts internes et de surface des rails, ainsi que la pertinence de chaque méthode pour la détection et l'évaluation des défauts affectant couramment les rails en voie.
La présente partie de cette Norme européenne ne spécifie pas les critères d'évaluation des défauts de rails ni les actions effectuées en conséquence.
La présente partie de cette Norme européenne s'applique uniquement aux rails dont les profils répondent aux exigences de l'EN 13674 1.
Železniške naprave - Infrastruktura - Neporušitveno preskušanje na progi - 3. del: Zahteve za ugotavljanje notranjih in površinskih napak na progi
Ta del tega evropskega standarda določa metode neporušitvenega preskušanja (NDT), ki se uporabljajo za zaznavanje notranjih in površinskih napak na progi ter primernost vsake metode za zaznavanje in ocenjevanje običajnih napak na tirih, nameščenih na progi.
Ta del tega evropskega standarda ne določa kriterijev ocenjevanja napak na progi in izpeljanih dejanj.
Ta del tega evropskega standarda se uporablja le za profile tirnic, ki ustrezajo zahtevam standarda EN 13674-1.
General Information
Standards Content (Sample)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Železniške naprave - Infrastruktura - Neporušitveno preskušanje na progi - 3. del: Zahteve za ugotavljanje notranjih in površinskih napak na progiBahnanwendungen - Infrastruktur - Zerstörungsfreie Prüfung an Schienen im Gleis - Teil 3: Anforderungen zur Identifizierung von inneren Fehlern und SchienenoberflächenfehlernApplication ferroviaires - Infrastructure - Contrôle non destructive sur des rails en voie - Partie 3 : Critères pour l'identification des défauts internes et des défauts de surfaces des railsRailway applications - Infrastructure - Non-destructive testing on rails in track - Part 3: Requirements for identifying internal and surface rail defects93.100Gradnja železnicConstruction of railways19.100Neporušitveno preskušanjeNon-destructive testingICS:Ta slovenski standard je istoveten z:EN 16729-3:2018SIST EN 16729-3:2018en,fr,de01-junij-2018SIST EN 16729-3:2018SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 16729-3
April
t r s z ICS
{ uä s r r English Version
Railway applications æ Infrastructure æ Nonædestructive testing on rails in track æ Part
uã Requirements for identifying internal and surface rail defects Applications ferroviaires æ Infrastructure æ Essais non destructifs sur les rails de voie æ Partie
u ã Exigences pour l 5identification des défauts internes et de surface des rails
Bahnanwendungen æ Infrastruktur æ Teil
uã Anforderungen zur Identifizierung von inneren Fehlern und Schienenoberflächenfehlern This European Standard was approved by CEN on
t t January
t r s zä
egulations which stipulate the conditions for giving this European Standard the status of a national standard without any alterationä Upætoædate lists and bibliographical references concerning such national standards may be obtained on application to the CENæCENELEC Management Centre or to any CEN memberä
translation under the responsibility of a CEN member into its own language and notified to the CENæCENELEC Management Centre has the same status as the official versionsä
CEN members are the national standards bodies of Austriaá Belgiumá Bulgariaá Croatiaá Cyprusá Czech Republicá Denmarká Estoniaá Finlandá Former Yugoslav Republic of Macedoniaá Franceá Germanyá Greeceá Hungaryá Icelandá Irelandá Italyá Latviaá Lithuaniaá Luxembourgá Maltaá Netherlandsá Norwayá Polandá Portugalá Romaniaá Serbiaá Slovakiaá Sloveniaá Spainá Swedená Switzerlandá Turkey and United Kingdomä
EUROPEAN COMMITTEE FOR STANDARDIZATION COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre:
Rue de la Science 23,
B-1040 Brussels
t r s z CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Membersä Refä Noä EN
s x y t {æ uã t r s z ESIST EN 16729-3:2018
Relationship between this European Standard and the essential requirements of EU Directive 2008/57/EC aimed to be covered . 35 Bibliography . 37
IEC Electropedia: available at http://www.electropedia.org/
ISO Online browsing platform: available at http://www.iso.org/obp 3.1 damaged rail rail which is neither cracked nor broken, but which has other defects 3.2 cracked area part of the rail with a localized discontinuity of material 3.3 broken rail rail which has separated into two or more pieces; or rail from which a piece of metal becomes detached from the rail head, with a gap of more than 50 mm in length and more than 10 mm in depth resulting in a running band less than 30 mm in width Note 1 to entry: See Figure 1 and Figure 2 for the first part of the definition, and Figure 3 for the second part. SIST EN 16729-3:2018
Figure 1 — Broken rail
Key l visible horizontal length Figure 2 — Example of a broken rail with a gap at the rail end
Key a vertical depth l visible horizontal length c non cracked area Figure 3 — Example of a broken rail with a gap 3.4 rail surface defect defect which initiates on any of the surfaces of the rail 3.5 rail head surface defect defect which initiates on the running surface of the rail SIST EN 16729-3:2018
Key 1 vertical plane 2 transverse plane 3 horizontal plane Figure 4 — Geometrical planes of the rail SIST EN 16729-3:2018
Figure 5 — Principle of automatic visual inspection 5.4.2 Test area Machine Vision Systems for rail inspection and automatic identification are capable of inspecting the head, web and the upper surface of the rail foot for surface-breaking defects and damage. It is possible that the under head/web area is not examined due to line of sight depending upon the system used. 5.4.3 Example applications Examples of fault conditions identified by automatic visual inspection systems are: — horizontal/vertical cracking; — corrosion; — squats; — wheel burns; — head checks; — shelling; — corrugation; — missing or damaged components associated with the rail (for example fish plates, insulated joints, chairs, clips). SIST EN 16729-3:2018
Key 1 probe 2 UT test volume 3 probe angle Figure 6 — Example of test volume for UT angle probe SIST EN 16729-3:2018
Key 1 probe 2 test area Figure 7 — Example of test area for ET probe 5.6.3 Example applications Examples for Eddy-current testing are: — detection and sizing Head Check; — detection of squats; — detection of cracks in machined rails. Inspections can be carried out using: — manual systems using individual hand-held transducers; — trolleys with multiple transducers which are usually pedestrian operated; — vehicle mounted equipment with multiple transducers; to enable detection and sizing of: — RCF cracks (Head Check); — cracks at cross section changes in machined rails (only detection). 5.7 Magnetic particle testing – MT 5.7.1 Description Magnetic particle inspection is a visual inspection method in which the material subjected to an inspection is magnetised either by induced magnetic field or electric current. Strong areas of flux leakage occur at the flaw sites. The component is covered in iron particles (commonly in the form of a magnetic ink). The iron particles will concentrate at the site of the flux leakage (flaw) providing a visible in
...
