EN 14067-6:2010
(Main)Railway applications - Aerodynamics - Part 6: Requirements and test procedures for cross wind assessment
Railway applications - Aerodynamics - Part 6: Requirements and test procedures for cross wind assessment
This European Standard applies to the cross wind assessment of railways taking into consideration the recommendations given in Annex M on the application of the standard (migration rule). The methods presented have been applied to passenger vehicles with a maximum speed up to 360 km/h and to freight vehicles with a maximum speed up to 160 km/h. This European Standard applies to coaches, multiple units, freight wagons, locomotives and power cars.
Bahnanwendungen - Aerodynamik - Teil 6: Anforderungen und Prüfverfahren für die Bewertung von Seitenwind
Diese Europäische Norm gilt für die Seitenwindbewertung des Eisenbahnbetriebs unter Berücksichtigung der
in Anhang M aufgeführten Empfehlungen für die Anwendung dieser Norm (Übergangsbestimmungen). Die
dargestellten Verfahren sind für Personenfahrzeuge bis zu 360 km/h Fahrgeschwindigkeit und für
Güterfahrzeuge bis zu 160 km/h Fahrgeschwindigkeit angewendet worden. Diese Europäische Norm gilt für
Reisezugwagen, Triebzüge, Güterwagen, Lokomotiven und Triebköpfe.
Applications ferroviaires - Aérodynamique - Partie 6: Exigences et procédures d'essai pour l'évaluation de la stabilité vis à vis des vents traversiers
La présente Norme européenne traite de l’évaluation de la stabilité des véhicules ferroviaires vis-à-vis des
vents traversiers, en prenant en considération les recommandations présentées dans l’Annexe M (règle de
migration). Les méthodes décrites s’appliquent aux voitures voyageurs dont la vitesse de pointe est inférieure
ou égale à 360 km/h et aux véhicules fret dont la vitesse de pointe est inférieure ou égale à 160 km/h. La
présente Norme européenne s’applique aux voitures voyageurs, unités multiples, wagons, locomotives et
motrices.
Železniške naprave - Aerodinamika - 6. del: Zahteve in preskusni postopki za oceno vpliva bočnega vetra
Ta evropski standard velja za oceno vpliva bočnega vetra pri železnici ob upoštevanju priporočil, podanih v dodatku M, o uporabi tega standarda (pravilo selitve). Predstavljene metode so bile uporabljene pri potniških vozilih z maksimalno hitrostjo do 360 km/h in za tovorna vozila z maksimalno hitrostjo do 160 km/h. Ta evropski standard velja za vagone, večkratne enote, tovorniške vagone, lokomotive in železniške avtomobile.
