EN 2997-001
October 2006 ICS 49.060 Supersedes EN 2997-1:1997 English Version
Aerospace series - Connectors, electrical, circular, coupled by threaded ring, fire-resistant or non fire-resistant, operating temperatures - 65 °C to 175 °C continuous, 200 °C continuous, 260 °C peak - Part 001: Technical specification
Série aérospatiale - Connecteurs électriques circulaires à accouplement par bague filetée, résistant au feu ou non, températures d'utilisation - 65 °C à 175 °C continu, 200 °C continu, 260 °C en pointe - Partie 001 : Spécification technique
Luft- und Raumfahrt - Elektrische Rundsteckverbinder mit Schraubkupplung, feuerbeständig oder nicht feuerbeständig, Betriebstemperaturen - 65 °C bis 175 °C konstant, 200 °C konstant, 260 °C Spitze - Teil 001: Technische Lieferbedingungen This European Standard was approved by CEN on 24 June 2006.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the Central Secretariat or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta,Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre: rue de Stassart, 36
B-1050 Brussels © 2006 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 2997-001:2006: ESIST EN 2997-001:2009

EN 2591-100∗, Aerospace series — Elements of electrical and optical connection — Test methods — Part 100: General.
∗ And all parts quoted in this standard. SIST EN 2997-001:2009

Aerospace series — Installation of aircraft electrical and optical interconnection systems. 1) EN 3660-003, Aerospace series — Cable outlet accessories for circular and rectangular electrical and optical connectors — Part 003: Grommet nut, style A for EN 2997 and EN 4067 — Product standard.
EN 3660-004, Aerospace series — Cable outlet accessories for circular and rectangular electrical and optical connectors — Part 004: Cable outlet, style A, straight, unsealded with clamp strain relief for EN 2997 and EN 4067 — Product standard.
EN 3909, Aerospace series — Test fluids for electric components and sub-assemblies. EN 9133, Aerospace series — Quality management systems — Qualification Procedure for aerospace standard parts. MIL-DTL-83723F, Connectors, electrical, (circular, environment resisting), receptacles and plugs, general specification for. 2) MIL-PRF-7808L, Lubricating oil, aircraft turbine engine, synthetic base, NATO code number O-148. 2) MIL-PRF-7870C, Lubricating oil: general purpose, low temperature, NATO code number O-142. 2) MIL-PRF-23699F, Lubricating oil, aircraft turbine engine, synthetic base, NATO code number O-156. 2) MIL-PRF-87937D, Cleaning compound, aerospace equipment. 2) MIL-HDBK-454A, General guidelines for electronic equipment. 2) QPL-5606-31, Hydraulic fluid, petroleum base; aircraft; missile and ordnance. 2) AS1241C, Fire resistant phosphate ester hydraulic fluid for aircraft. 3) AMS1424D, Fluid, Deicing/Anti-Icing, Aircraft, SAE Type I. 3) 3 Terms and definitions For the purposes of this standard, the terms and definitions given in EN 2591-100 apply.
1) Published as AECMA Pre-standard at the date of publication of this standard. 2) Published by: Department of Defense (DOD), The Pentagon, Washington D.C. 20301, USA. 3) Published by Society of Automotive Engineers Inc. (SAE) 400 Commonwealth Drive, Warrendale, PA 15096-001, USA. SIST EN 2997-001:2009

The receptacles and plugs contain either male contacts or female contacts. The contacts fitted in the classes Y and YE receptacles are exclusively of the male non-removable solder type. The connectors are polarized by means of keyways and keys; polarization shall be obtained before the male contacts enter the insert of the female contacts and before the coupling ring is engaged. The position of the keying arrangement is given in Table 5. Masking of the blue colour band on the receptacle provides visual indication of full coupling. 4.2 Receptacle The receptacle may be attached by:  square flange;  the jam-nut with O-ring sealing; for spare parts, see EN 2997-002;  round flange for attachment by soldering/brazing/welding, classes Y and YE only. The receptacle contains five keyways into which the keys of the plug engage. The main keyway is fixed and is wider than the others. Polarization is ensured by different positions of the secondary keyways. The position of the insert is fixed relative to the main keyway. 4.3 Plug The plug contains five keys, which engage in the keyways of the receptacle. The main key is wider than the others. Polarization is ensured by different positions of the secondary keys. The position of the insert is fixed relative to the main key. The coupling ring permanently fitted on the plug enables the connectors to be coupled and uncoupled. The coupling torque shall be at least 50 % lower than the uncoupling torque. The internal thread of the coupling ring may be treated during manufacture with a suitable lubricant compatible with the performance required in this standard. The plug of classes S, SE, RS and WS is fitted with a grounding spring device ensuring electrical continuity between the coupled connector housings.
4.4 Materials and surface treatment 4.4.1 General When dissimilar metals are in close contact, adequate protection against corrosion shall be used for the electromotive force of the cell not to exceed 0,25 V (see EN 3197). 4.4.2 Housings The material of the housing for the connectors and for the fittings may either be passivated stainless steel or aluminium alloy protected against corrosion by nickel or cadmium plating (see EN 2997-002). SIST EN 2997-001:2009

The cable outlet accessories shall compress the grommet of the connectors without twisting it. A blue colour band indicating that the crimp contacts of the connectors are intended for rear removal shall be provided:  behind the flange of the receptacles with square flange;  on the flange of receptacles for nut attachment;  on the coupling ring of the plugs. The position of the blue colour bands shall be such that at least one of them is visible at all times on the coupling ring of the plug. 5.2 Inserts The insert carrying the male and female contacts shall be in hard material and have a cross section and radii such that no cracks, flaking or breaks can occur in normal operation. The insert for contacts shall be non-removable; it shall be mechanically held in the housing. Sealing shall be provided between the housing and insert. SIST EN 2997-001:2009

Key 1 Thread 2 Blue coloured band minimum width 0,64 3 Seal diameter housing size 08 : 1,42 ± 0,08
housing sizes 10 to 28 : 1,78 ± 0,08 4 Housing 08 : 12123712,,
Other housings : 32125712,, 5 Hard insert 6 Interfacial seal 7 Optional shape 8 Flat ∅ N 9 Blend radius a To rear of colour band b Depth of keyways Figure 1 SIST EN 2997-001:2009

Table 2 Contact size G a
M U b
V W X a max. Z N 20 3,00 2,90 1,50 1,24 1,17 1,07 2,28 2,14 2,38 2,28 3,00 1,04 0,99 0,51 0,13 16 3,81 3,71 2,06 1,80 1,75 1,65 2,88 2,73 2,98 2,88 3,81 1,61 1,56 0,81 0,43 12 5,33 5,22 2,84 2,54 2,57 2,46 3,85 3,68 3,95 3,85 5,33 2,41 2,36 1,57 1,19 a For contact arrangements 08-03 and 10-06, G = 2,34,442,
X max. = 2,44. b Dimension U does not apply to hermetic receptacles.
Key 1 Thread 2 Blue colour band minimum width 0,64 position optional 3 Optional shape 4 See detail D in Figure 1 5 Interfacial seal 6 Hard insert 7 Grounding spring system, see test EN 2591-413 a Thread engagement b Front of the contact c Models S, SE, RS and WS Figure 2 SIST EN 2997-001:2009

B max. H min. J K min. 08 0.5625 - 24 UNEF 7,37 7,47 10,29 10,16 14,61 10 0.6875 - 24 UNEF 9,86 10,87 13,36 13,23 17,96 12 0.8750 - 20 UNEF 14,17 15,19 17,68 17,55 22,73 14 0.9375 - 20 UNEF 15,93 16,94 19,43 19,30 24,31 16 1.0625 - 18 UNEF 19,61 20,17 22,66 22,53 27,53 18 1.1875 - 18 UNEF 21,84 22,86 25,35 25,22 30,71 20 1.3125 - 18 UNEF 25,02 26,04 28,52 28,40 33,88 22 1.4375 - 18 UNEF 28,19 29,21 31,70 31,57 37,06 24 1.5625 - 18 UNEF 31,37 32,38 34,87 34,75 40,23 28 1.8125 - 16 UN 37,52 38,73 41,22 41,09 46,58 a ISO 263
6.4 Receptacle and plug polarization See Figure 3 and Tables 4 and 5. Dimensions and tolerances are in millimetres. SIST EN 2997-001:2009

Key 1 Keyway for main key 2 4 secondary keyways 3 Main key 4 4 secondary keys a 5 keyways b 5 keys Figure 3 ReceptaclePlugSIST EN 2997-001:2009

Housing sizes - Values in degrees Position 08 10 12 to 28
A B C D A B C D A B C D N 105 140 215 265105 140215265105 140 215 265 6 102 132 248 320102 13224832018 149 192 259 7 80 118 230 31280 11823031292 152 222 342 8 35 140 205 27535 14020527584 152 204 334 9 64 155 234 30464 15523430424 135 199 240 Y – – – – 25 11522027098 152 268 338
Table 5 Housing size G H J L M N 08 5,72 5,64 5,92 5,79 10 7,24 7,16 7,45 7,32 12 9,40 9,32 9,60 9,47 14 2,21 2,05 10,29 10,21 2,47 2,31 10,49 10,36 16 11,89 11,81 12,09 11,96 18 13,23 13,15 13,44 13,31 20 14,81 14,73 15,01 14,58 22 16,41 16,33 16,61 16,48 24 17,98 17,90 18,19 18,06 28 3,00 2,84 1,40 1,24 21,16 21,08 3,26 3,10 1,96 1,83 21,42 21,29
6.5 Dimensions of the rear accessory interface The rear dimensions of receptacles and plugs with threads for mounting cable outlet accessories are shown in Figure 4 and in Table 7. Accessory teeth shall be aligned with the centre line of the main key/keyway as shown in Figure 4 within the tolerances shown in Table 6. SIST EN 2997-001:2009

Dimensions are in millimetres.
Key 1 Grommet 2 Thread 3 Master key 4 Crest of tooth Figure 4 SIST EN 2997-001:2009

E max. N Number of teeth 08 7,75 9,40 11,10 0.5000 - 20 UNEF 12,70 12 10 10,29 12,62 14,53 0.6250 - 24 UNEF 15,88 15 12 13,49 15,57 17,45 0.7500 - 20 UNEF 19,05 21 14 16,89 18,75 20,62 0.8750 - 20 UNEF 22,23 24 16 20,07 21,92 23,80 1.0000 - 20 UNEF 25,40 30 18 22,07 23,34 25,20 1.0625 -18 UNEF 26,97 33 20 25,25 26,52 28,37 1.1875 - 18 UNEF 30,18 36 22 28,42 29,69 31,55 1.3125 - 18 UNEF 33,32 39 24 31,60 32,87 34,72 1.4375 - 18 UNEF 36,53 42 28 37,90 39,22 42,67 1.7500 - 18 UN 44,45 54 a ISO 263
6.6 Contact arrangements The contact arrangements in the inserts are specified by Figures 5 to 36, which show the front face of the female inserts. The following tolerances apply to the inserts fitted in the housings (A and B reference Figure 3): • centre of each hole: { ∅ 0,36 AB
• centre of each contact end: { ∅ 0,61 AB
Identification of the contact position shall be permanently applied in contrasting colour on the front face of the insert or interfacial seal and on the rear face of the wire sealing grommet. Identification shall not be recessed or raised on the sealing surfaces. Symbols for contact sizes are given in EN 3155-001. Housing sizes and contact arrangements (see Figures 5 to 36).
08-98 3 contacts size 20
10-02 2 contacts size 20 Contact X mm Y mm
Contact X mm Y mm Contact X mm Y mm 1 0 + 1,91
1 − 1,65 + 0,94
1 0 + 2,11 2 − 1,65 − 0,97
2 0 − 1,91
2 0 − 2,11 3 + 1,65 − 0,97
3 + 1,65 + 0,94
Figure 5
Figure 6
Figure 7
10-05 5 contacts size 20
10-06 6 contacts size 20
12-03 3 contacts size 16
Contact X mm Y mm
Contact X mm Y mm Contact X mm Y mm 1 − 2,72 + 1,04
1 0 0 1 0 + 3,05 2 − 1,88 − 2,16
2 − 3,05 + 1,27 2 − 2,64 − 1,52 3 + 1,88 − 2,16
3 − 1,65 − 2,87 3 + 2,64 − 1,52 4 + 2,72 + 1,04
4 + 1,65 − 2,87
5 0 + 2,90
5 + 3,05 + 1,27
6 0 + 3,30
Figure 8
Figure 9
Figure 10 SIST EN 2997-001:2009

14-04 4 contacts size 12 Contact X mm Y mm Contact X mm Y mm Contact X mm Y mm 1 0 + 1,88 7 − 4,24 + 2,67 1 − 4,29 0 2 − 1,65 − 0,99 8 − 4,95 − 0,84 2 0 − 4,29 3 + 1,65 − 0,99 9 − 3,15 − 3,91 3 + 4,29 0 4 + 4,24 + 2,67 10 0 − 5,00 4 0 + 4,29 5 + 1,65 + 4,75 11 + 3,15 − 3,91
6 − 1,65 + 4,75 12 + 4,95 − 0,84
Figure 11
Figure 12 14-07 7 contacts size 16
14-12 9 contacts size 20 3 contacts size 16
Contact X mm Y mm
ContactX mm Y mm ContactX mm Y mm 1 0 0
1 0 + 2,29 7 − 4,45 + 2,57 2 − 2,41 + 4,17
2 − 1,98 − 1,14 8 − 5,69 − 1,37 3 − 4,83 0
3 + 1,98 − 1,14 9 − 4,04 − 4,24 4 − 2,41 − 4,17
4 + 4,45 + 2,57 10 0 − 5,13 5 + 2,41 − 4,17
5 + 1,65 + 5,61 11 + 4,04 − 4,24 6 + 4,83 0
6 − 1,65 + 5,61 12 + 5,69 − 1,37 7 + 2,41 + 4,17
Figure 13
Figure 14 SIST EN 2997-001:2009

16-10 10 contacts size 16
Contact X mm Y mm ContactX mm Y mm Contact X mm Y mm 1 − 2,34 0 9 − 4,42 − 3,84 1 0 − 2,67 2 0 − 2,44 10 − 1,65 − 5,61 2 0 + 2,16 3 + 2,34 0 11 + 1,65 − 5,61 3 − 6,02 + 3,15 4 0 + 2,44 12 + 4,42 − 3,84 4 − 6,58 − 1,65 5 0 + 5,87 13 + 5,79 − 0,83 5 − 3,81 − 5,64 6 − 3,18 + 4,93 14 + 5,33 + 2,44 6 + 3,81 − 5,64 7 − 5,33 + 2,44 15 + 3,18 + 4,93 7 + 6,58 − 1,65 8 − 5,79 − 0,83
8 + 6,02 + 3,15
9 + 2,41 + 6,38
10 − 2,41 + 6,38 Figure 15
Figure 16
Contact X mm Y mm Contact X mm Y mm Contact X mm Y mm 1 0 + 1,91 9 − 4,50 − 2,59 17 − 2,84 + 6,83 2 − 1,65 − 0,94 10 − 1,65 − 4,24 18 − 5,69 + 5,18 3 + 1,65 − 0,94 11 + 1,65 − 4,24 19 − 7,34 + 2,36 4 + 4,50 + 0,71 12 + 4,50 − 2,59 20 − 7,34 − 0,94 5 + 2,84 + 3,56 13 + 7,34 − 0,94 21 − 4,50 − 5,89 6 0 + 5,18 14 + 7,34 + 2,36 22 − 1,65 − 7,54 7 − 2,84 + 3,56 15 + 5,69 + 5,18 23 + 1,65 − 7,54 8 − 4,50 + 0,71 16 + 2,84 + 6,83 24 + 4,50 − 5,89 Figure 17 SIST EN 2997-001:2009

Contact X mm Y mm 1 0 0 2 − 5,56 + 4,45 3 − 6,93 − 1,57 4 − 3,07 − 6,40 5 + 3,07 − 6,40 6 + 6,93 − 1,57 7 + 5,56 + 4,45 8 0 + 7,11 Figure 18 SIST EN 2997-001:2009

Contact X mm Y mm Contact X mm Y mm 1 − 3,30 0 8 − 6,71 − 4,62 2 0 − 3,58 9 − 2,87 − 7,62 3 + 3,30 0 10 + 2,87 − 7,62 4 0 + 3,58 11 + 6,71 − 4,62 5 − 2,87 + 7,62 12 + 8,15 0 6 − 6,71 + 4,62 13 + 6,71 + 4,62 7 − 8,15 0 14 + 2,87 + 7,62 Figure 19
20-16 16 contacts size 16 Contact X mm Y mm ContactX mm Y mm
Contact X mm Y mm 1 0 0 17 + 6,60 0
1 − 3,91 + 1,57 2 − 1,65 + 2,87 18 + 4,95 + 2,87
2 − 2,39 − 3,10 3 − 3,30 0 19 + 3,30 + 5,74
3 + 2,39 − 3,10 4 − 1,65 − 2,87 20 + 1,65 + 8,61
4 + 3,91 + 1,57 5 + 1,65 − 2,87 21 − 1,65 + 8,61
5 0 + 4,45 6 + 3,30 0 22 − 6,60 + 5,74
6 − 3,00 + 8,18 7 + 1,65 + 2,87 23 − 8,26 + 2,87
7 − 6,88 + 5,36 8 0 + 5,74 24 − 8,26 − 2,87
8 − 8,66 + 0,91 9 − 3,30 + 5,74 25 − 6,60 − 5,74
9 − 7,82 − 3,81 10 − 4,95 + 2,87 26 − 1,65 − 8,61
10 − 4,62 − 7,37 11 − 6,60 0 27 + 1,65 − 8,61
11 0 − 8,71 12 − 4,95 − 2,87 28 + 6,60 − 5,74
12 + 4,62 − 7,37 13 − 3,30 − 5,74 29 + 8,26 − 2,87
13 + 7,82 − 3,81 14 0 − 5,74 30 + 8,26 + 2,87
14 + 8,66 + 0,91 15 + 3,30 − 5,74 31 + 6,60 + 5,74
15 + 6,88 + 5,36 16 + 4,95 − 2,87
16 + 3,00 + 8,18 Figure 20
Figure 21
20-28 24 contacts size 20 4 contacts size 12 Contact X mm Y mm
Contact X mm Y mm 1 0 0
1 − 1,65 + 1,65 2 − 1,68 + 2,90
2 − 1,65 − 1,65 3 − 3,35 0
3 + 1,65 − 1,65 4 − 1,68 − 2,90
4 + 1,65 + 1,65 5 + 1,68 − 2,90
5 − 1,65 + 4,95 6 + 3,35 0
6 − 4,95 + 1,65 7 + 1,68 + 2,90
7 − 4,95 − 1,65 8 0 + 5,79
8 − 1,65 − 4,95 9 − 5,03 + 2,90
9 + 1,65 − 4,95 10 − 5,03 − 2,90
10 + 4,95 − 1,65 11 0 − 5,79
11 + 4,95 + 1,65 12 + 5,03 − 2,90
12 + 1,65 + 4,95 13 + 5,03 + 2,90
13 0 + 8,03 14 + 4,45 + 7,70
14 − 2,95 + 9,91 15 0 + 10,26
15 − 6,30 + 6,30 16 − 4,45 + 7,70
16 − 9,91 + 2,95 17 − 8,89 + 5,13
17 − 8,03 0 18 − 8,89 0
18 − 9,91 − 2,95 19 − 8,89 − 5,13
19 − 6,30 − 6,30 20 − 4,45 − 7,70
20 − 2,95 − 9,91 21 0 − 10,26
21 0 − 8,03 22 + 4,45 − 7,70
22 + 2,95 − 9,91 23 + 8,89 − 5,13
23 + 6,30 − 6,30 24 + 8,89 0
24 + 9,91 − 2,95 25 + 8,89 + 5,13
25 + 8,03 0
26 + 9,91 + 2,95
27 + 6,30 + 6,30
28 + 2,95 + 9,91 Figure 22
Figure 23 SIST EN 2997-001:2009

Contact X mm Y mm Contact X mm Y mm 1 0 − 0,15 21 + 3,89 + 9,14 2 − 2,08 + 2,41 22 0 + 10,54 3 − 3,28 − 0,71 23 − 3,89 + 9,14 4 − 1,65 − 3,61 24 − 7,59 + 7,26 5 + 1,65 − 3,61 25 − 8,00 + 3,99 6 + 3,28 − 0,71 26 −10,39 + 1,70 7 + 2,08 + 2,41 27 − 10,39 − 1,60 8 + 1,65 + 5,69 28 − 9,40 − 4,75 9 − 1,65 + 5,69 29 − 7,47 − 7,42 10 − 4,90 + 5,11 30 − 4,78 − 9,35 11 − 5,38 + 1,83 31 − 1,65 − 10,41 12 − 7,11 − 1,02 32 + 1,65 − 10,41 13 − 6,15 − 4,17 33 + 4,78 − 9,35 14 − 3,58 − 6,27 34 + 7,47 − 7,42 15 0 − 7,42 35 + 9,40 − 4,75 16 + 3,58 − 6,27 36 + 10,39 − 1,60 17 + 6,15 − 4,17 37 + 10,39 + 1,70 18 + 7,11 − 1,02 38 + 8,00 + 3,99 19 + 5,38 + 1,83 39 + 7,59 + 7,26 20 + 4,90 + 5,11
Figure 24 SIST EN 2997-001:2009

Contact X mm Y mm Contact X mm Y mm 1 0 0 22 0 + 8,51 2 − 2,82 + 2,67 23 − 2,95 + 10,03 3 − 3,96 − 0,46 24 − 5,94 + 8,61 4 − 2,44 − 3,40 25 − 8,33 + 6,32 5 + 2,44 − 3,40 26 − 9,88 + 3,40 6 + 3,96 − 0,46 27 − 10,46 + 0,15 7 + 2,82 + 2,67 28 − 10,01 − 3,12 8 0 + 4,37 29 − 8,53 − 6,10 9 − 2,82 + 6,73 30 − 6,22 − 8,46 10 − 5,44 + 4,72 31 − 3,28 − 9,96 11 − 6,99 + 1,80 32 0 − 10,49 12 − 7,11 − 1,50 33 + 3,28 − 9,96 13 − 5,64 − 4,47 34 + 6,22 − 8,46 14 − 3,15 − 6,65 35 + 8,53 − 6,10 15 0 − 5,64 36 + 10,01 − 3,12 16 + 3,15 − 6,65 37 + 10,46 + 0,15 17 + 5,64 − 4,47 38 + 9,88 + 3,40 18 + 7,11 − 1,50 39 + 8,33 + 6,32 19 + 6,99 + 1,80 40 + 5,94 + 8,61 20 + 5,44 + 4,72 41 + 2,95 + 10,03 21 + 2,82 + 6,73
Figure 25 SIST EN 2997-001:2009

22-19 19 contacts size 16 Contact X mm Y mm
Contact X mm Y mm 1 − 3,33 + 1,91
1 0 0 2 0 − 3,84
2 − 4,01 + 4,01 3 + 3,33 + 1,91
3 − 5,49 − 1,45 4 − 6,50 + 7,75
4 − 1,45 − 5,49 5 − 9,96 + 1,75
5 + 4,01 − 4,01 6 − 8,76 − 5,05
6 + 5,49 + 1,45 7 − 3,45 − 9,50
7 + 1,45 + 5,49 8 + 3,45 − 9,50
8 − 5,49 + 9,50 9 + 8,76 − 5,05
9 − 9,50 + 5,49 10 + 9,96 + 1,75
10 − 10,97 0 11 + 6,50 + 7,75
11 − 9,50 − 5,49 12 0 + 10,11
12 − 5,49 − 9,50
13 0 − 10,97
14 + 5,49 − 9,50
15 + 9,50 − 5,49
16 + 10,97 0
17 + 9,50 + 5,49
18 + 5,49 + 9,50
19 0 + 10,97 Figure 26
Figure 27 SIST EN 2997-001:2009

This arrangement is not available for new design. Figure 28 SIST EN 2997-001:2009

Contact X mm Y mm Contact X mm Y mm 1 0 0 17 − 7,80 − 8,48 2 − 5,79 + 1,91 18 − 5,00 − 10,39 3 − 7,80 − 2,62 19 − 1,70 − 11,40 4 − 3,56 − 4,93 20 + 1,70 − 11,40 5 0 − 8,48 21 + 5,00 − 10,39 6 + 3,56 − 4,93 22 + 7,80 − 8,48 7 + 7,80 − 2,62 23 + 9,96 − 5,82 8 + 5,79 + 1,91 24 + 11,23 − 2,62 9 + 4,83 + 6,63 25 + 11,51 + 0,89 10 0 + 6,10 26 + 10,72 + 4,27 11 − 4,83 + 6,63 27 + 8,99 + 7,21 12 − 8,99 + 7,21 28 + 6,48 + 9,55 13 − 10,72 + 4,27 29 + 3,38 + 11,02 14 − 11,51 + 0,89 30 0 + 11,53 15 − 11,23 − 2,62 31 − 3,38 + 11,02 16 − 9,96 − 5,82 32 − 6,48 + 9,55
Figure 29 SIST EN 2997-001:2009

Contact X mm Y mm Contact X mm Y mm 1 0 − 0,71 21 − 6,48 + 9,55 2 − 3,33 + 1,96 22 − 8,99 + 7,21 3 − 3,94 − 2,36 23 − 10,72 + 4,27 4 0 − 4,60 24 − 11,51 + 0,89 5 + 3,94 − 2,36 25 − 11,23 − 2,62 6 + 3,33 + 1,96 26 − 9,96 − 5,82 7 0 + 4,72 27 − 7,80 − 8,48 8 − 1,65 + 8,20 28 − 5,0 − 10,44 9 − 4,85 + 6,05 29 − 1,70 − 11,40 10 − 7,59 + 1,96 30 + 1,70 − 11,40 11 − 7,80 − 2,62 31 + 5,0 − 10,44 12 − 4,42 − 6,60 32 + 7,80 − 8,48 13 0 − 8,48 33 + 9,96 − 5,82 14 + 4,42 − 6,60 34 + 11,23 − 2,62 15 + 7,80 − 2,62 35 + 11,51 + 0,89 16 + 7,59 + 1,96 36 + 10,72 + 4,27 17 + 4,85 + 6,05 37 + 8,99 + 7,21 18 + 1,65 + 8,20 38 + 6,48 + 9,55 19 0 + 11,53 39 + 3,38 + 11,02 20 − 3,38 + 11,02
Figure 30 SIST EN 2997-001:2009

Contact X mm Y mm ContactX mm Y mm Contact X mm Y mm 1 0 0 20 + 1,65 + 8,61 39 0 + 11,48 2 − 1,65 + 2,87 21 − 1,65 + 8,61 40 − 3,30 + 11,48 3 − 3,30 0 22 − 4,95 + 8,61 41 − 8,26 + 8,61 4 − 1,65 − 2,87 23 − 6,60 + 5,74 42 − 9,91 + 5,74 5 + 1,65 − 2,87 24 − 8,26 + 2,87 43 − 11,56 + 2,87 6 + 3,30 0 25 − 9,91 0 44 − 11,56 − 2,87 7 + 1,65 + 2,87 26 − 8,26 − 2,87 45 − 9,91 − 5,74 8 0 + 5,74 27 − 6,60 − 5,74 46 − 8,26 − 8,61 9 − 3,30 + 5,74 28 − 4,95 − 8,61 47 − 3,30 − 11,48 10 − 4,95 + 2,87 29 − 1,65 − 8,61 48 0 − 11,48 11 − 6,60 0 30 + 1,65 − 8,61 49 + 3,30 − 11,48 12 − 4,95 − 2,87 31 + 4,95 − 8,61 50 + 8,26 − 8,61 13 − 3,30 − 5,74 32 + 6,60 − 5,74 51 + 9,91 − 5,74 14 0 − 5,74 33 + 8,26 − 2,87 52 + 11,56 − 2,87 15 + 3,30 − 5,74 34 + 9,91 0 53 + 11,56 + 2,87 16 + 4,95 − 2,87 35 + 8,26 + 2,87 54 + 9,91 + 5,74 17 + 6,60 0 36 + 6,60 + 5,74 55 + 8,26 + 8,61 18 + 4,95 + 2,87 37 + 4,95 + 8,61
19 + 3,30 + 5,74 38 + 3,30 + 11,48
Figure 31 SIST EN 2997-001:2009

Contact X mm Y mm Contact X mm Y mm 1 0 + 3,39 16 + 6,98 + 10,39 2 − 3,37 0 17 + 2,54 + 12,25 3 0 − 3,39 18 − 2,54 + 12,25 4 + 3,37 0 19 − 6,98 + 10,39 5 + 4,42 + 6,30 20 − 10,39 + 6,98 6 0 + 8,20 21 − 12,25 + 2,54 7 − 4,42 + 6,30 22 − 12,25 − 2,54 8 − 7,43 + 2,54 23 − 10,39 − 6,98 9 − 7,43 − 2,54 24 − 6,98 − 10,39 10 − 4,42 − 6,30 25 − 2,54 − 12,25 11 0 − 8,20 26 + 2,54 − 12,25 12 + 4,42 − 6,30 27 + 6,98 − 10,39 13 + 7,43 − 2,54 28 + 10,39 − 6,98 14 + 7,43 + 2,54 29 + 12,25 − 2,54 15 + 10,39 + 6,98 30 + 12,25 + 2,54
Figure 32 SIST EN 2997-001:2009

Contact X mm Y mm Contact X mm Y mm 1 0 0 23 + 8,20 + 3,30 2 − 3,20 + 4,50 24 − 6,40 + 6,07 3 − 5,13 + 1,80 25 + 3,20 + 8,00 4 − 4,47 − 1,42 26 0 + 8,76 5 − 3,20 − 4,47 27 − 4,57 + 12,01 6 0 − 5,92 28 − 8,56 + 9,63 7 + 3,20 − 4,47 29 − 11,58 + 5,69 8 + 4,47 − 1,42 30 − 12,83 + 1,12 9 + 5,13 + 1,80 31 − 12,42 − 3,51 10 + 3,20 + 4,50 32 − 10,29 − 7,77 11 0 + 5,46 33 − 6,78 − 10,92 12 − 3,20 + 8,00 34 − 2,42 − 12,62 13 − 6,40 + 6,07 35 + 2,42 − 12,62 14 − 8,20 + 3,30 36 + 6,78 − 10,92 15 − 8,56 − 0,79 37 + 10,29 − 7,77 16 − 7,42 − 4,78 38 + 12,42 − 3,51 17 − 5,13 − 7,16 39 + 12,83 + 1,12 18 − 2,06 − 8,48 40 + 11,58 + 5,69 19 + 2,06 − 8,48 41 + 8,56 + 9,63 20 + 5,13 − 7,16 42 + 4,57 + 12,01 21 + 7,42 − 4,78 43 0 + 12,88 22 + 8,56 − 0,79
Figure 33 SIST EN 2997-001:2009

21 − 1,65 + 8,61 42 − 8,26 + 8,61
Figure 35 SIST EN 2997-001:2009

Key 1 Optional radius Figure 37 Table 8 Contact size J K L M 20 2,24 1,55 1,22 1,07 4,78 2,77 2,79 1,73 16 2,95 2,44 1,93 1,75 6,38 4,37 3,78 2,77 12 3,81 3,30 3,10 2,84 6,38 4,37 3,58 2,77
7 Tests 7.1 Tests according to EN 2591-100 The tests of EN 2591-100, applicable in the context of this standard as well as the details necessary for implementing them and for inspecting connector characteristics, are given in Table 9. SIST EN 2997-001:2009

For maintenance of qualification only the measurement of inter-changeability dimensions are required except for subclause 6.5. 201 Contact resistance - Low level Crimp contacts Defined by the standards for contacts specified in EN 2997-002. For solder contacts (hermetic connectors): not applicable 202 Contact resistance at rated current Crimp contacts Defined by the standards for contacts specified in EN 2997-002. Solder contacts (hermetic connectors) Measuring points on the cable, nearest to the contacts
Maximum contact resistance in mΩ
Contact size Rated test current A Initial After tests EN 2591-301 and EN 2591-307
20 5 12 15
16 10 8,5 10
12 17 5 6
203 Electrical continuity at microvolt level Not applicable 204 Discontinuity of contacts in the microsecond range Duration of micro-discontinuity: ≤ 1 µs Method B Test time: throughout the duration of tests EN 2591-402, EN 2591-403 and EN 2591-301, method B continued SIST EN 2997-001:2009

Connectors
Max. leakage current Pressure mated V r.m.s. unmated V r.m.s.
Sea level 1 500 1 500
12,1 kPa (15 000 m) 1 000 600
4,7 kPa (21 000 m) 1 000 400
2 mA 1,1 kPa (30 000 m) 1 000 200
208 Temperature rise due to rated current Not applicable 209 Current temperature derating Not applicable for qualification continued
...
