EN 15501:2013

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Toplotnoizolacijski proizvodi za opremo stavb in industrijske inštalacije - Proizvodi iz ekspandiranega perlita (EPB) in vermikulita (EV) - SpecifikacijaWärmedämmstoffe für die Haustechnik und für betriebstechnische Anlagen - Werkmäßig hergestellte Produkte aus Blähperlit (EP) und expandiertem Vermiculit (EV) - SpezifikationProduits isolants thermiques pour l’équipement du bâtiment et les installations industrielles - Produits manufacturés en perlite expansée (EP) et en vermiculite exfoliée (EV) - SpécificationThermal insulation products for building equipment and industrial installations - Factory made expanded perlite (EP) and exfoliated vermiculite (EV) products - Specification91.100.60Thermal and sound insulating materialsICS:Ta slovenski standard je istoveten z:EN 15501:2013SIST EN 15501:2013en,fr,de01-september-2013SIST EN 15501:2013SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 15501
April 2013 ICS 91.100.60 English Version
Thermal insulation products for building equipment and industrial installations - Factory made expanded perlite (EP) and exfoliated vermiculite (EV) products - Specification
Produits isolants thermiques pour l'équipement du bâtiment et les installations industrielles - Produits manufacturés en perlite expansée (EP) et en vermiculite exfoliée (EV) - Spécification
Wärmedämmstoffe für die Haustechnik und für betriebstechnische Anlagen - Werkmäßig hergestellte Produkte aus Blähperlit (EP) und expandiertem Vermiculit (EV) - Spezifikation This European Standard was approved by CEN on 10 February 2013.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2013 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 15501:2013: ESIST EN 15501:2013

Factory production control . 21 Annex B (normative)
Special conditions for the determination of organic content . 24 B.1 Principle . 24 B.2 Apparatus . 24 B.3 Procedure . 24 SIST EN 15501:2013

Preparation of the test specimens to measure thermal conductivity . 26 C.1 Preparation of the test specimens to measure thermal conductivity . 26 C.2 Ageing . 26 Annex D (informative)
Product specific details for mounting and fixing
for reaction to fire testing . 27 Annex E (informative)
Additional properties . 31 E.1 General . 31 E.2 Coefficient of thermal expansion . 31 E.3 Apparent and true porosity . 31 E.4 Air flow resistance . 31 E.5 Creep in compression . 31 E.6 Permeability to gases . 31 E.7 Bending strength . 31 E.8 Apparent density . 31 Annex ZA (informative)
Clauses of this European Standard addressing the provisions of the EU Construction Products Directive . 33 ZA.1 Scope and relevant characteristics . 33 ZA.2 Procedures for attestation of conformity of factory made expanded perlite and exfoliated vermiculite products . 35 ZA.2.1 Systems of attestation of conformity . 35 ZA.2.2 EC certificate and declaration of conformity . 37 ZA.3 CE Marking and labelling . 38 Bibliography . 41
Figures Figure ZA.1 — Example of CE marking information . 40 Tables Table 1 — Dimensional tolerances. 12 Table 2 — Levels for maximum service temperatures . 14 Table 3 — Levels for compressive stress at 10 % deformation or compressive strength . 15 Table 4 — Test methods, test specimens and conditions
................................................................................. 17 Table A.1 — Minimum product testing frequencies............................................................................................ 21 Table A.2 — Minimum product testing frequencies for the reaction to fire characteristics ................................ 23 Table D.1 — Product parameters for EP / EV - flat products when tested as placed on the market or in standard test configuration of assemblies ................................................................................................... 27 Table D.2 — Installation Parameters for EP / EV - flat products as placed on the market ................................ 28 Table D.3 — Product parameters for EP / EV - pipe insulation products, as placed on the market .................. 28 Table D.4 — Installation Parameters for EP / EV - pipe insulation products, as placed on the market ............. 29 Table D.5 — Installation Parameters for EP / EV - flat products in standard test configuration of assemblies simulating end-use applications
................................................................................................................. 29 SIST EN 15501:2013

 Annex A (normative), Factory production control  Annex B (normative), Special conditions to be used for the determination of organic content  Annex C (informative), Preparation of the test specimens to measure thermal conductivity  Annex D (informative), Product specific details for mounting and fixing for reaction to fire testing NOTE This annex will be transferred to Annex A of EN 15715 when this document is being revised.  Annex E (informative), Additional properties  Annex ZA (informative), Clauses of this European Standard addressing the provisions of the EU Construction Products Directive This document includes a bibliography. This European Standard is one of a series of standards for insulation products used in building equipment and industrial installations, but this standard can be used in other areas, where appropriate. Other standards in the series include the following group of interrelated standards for the specifications of factory made thermal insulation products, all of which come within the scope of CEN/TC 88:  EN 14303, Thermal insulation products for building equipment and industrial installations — Factory made mineral wool (MW) products — Specification
 EN 14304, Thermal insulation products for building equipment and industrial installations — Factory made flexible elastomeric foam (FEF) products — Specification SIST EN 15501:2013

Di is the inside diameter of pipe sections mm
d is the thickness mm
dD is the declared thickness of the product mm
û0b is the relative change in width %
û0d is the relative change in thickness %
û0l is the relative change in length %
Li is the deviation from linearity mm
l is the length mm
λ is the thermal conductivity W/(m·K)
λD is the declared thermal conductivity W/(m·K)
µ is the water vapour diffusion resistance factor —
Sb is the deviation from squareness of boards on length and width mm/m
Sd is the deviation from squareness of boards on thickness mm
Smax is the deviation from flatness mm
110 is the compressive stress at 10 % deformation kPa
1m is the compressive strength kPa
is the deviation from squareness for pipe sections and segments mm
a is the apparent density kg/m3
BS is the symbol of the declared level for bending strength
CS(Y) is the symbol of the declared level for compressive stress at Y % deformation
CS(10) is the symbol of the declared level for compressive stress at 10 % deformation
CL is the symbol of the declared level of soluble chloride ions
F is the symbol of the declared level of soluble fluoride ions
L is the symbol of the declared class for length tolerances
MU is the symbol of the declared value for water vapour diffusion resistance factor
Na is the symbol of the declared level of soluble sodium ions
P is the symbol of the declared value for flatness tolerances
pH is the symbol of the declared level of the pH-value
S is the symbol of the declared class for squareness tolerances
Sl declared level of soluble silicate ions
ST(+) is the symbol of the declared level for maximum service temperature
ST(-) is the symbol of the declared level for minimum service temperature
T is the symbol of the declared class for thickness tolerances
W is the symbol of the declared class for width tolerances
3.2.2 Abbreviated terms EP expanded perlite
EV exfoliated vermiculite
ITT initial type test
ML manufacturer’s literature
FPC factory production control
RtF reaction to fire
4 Requirements 4.1 General Product properties shall be assessed in accordance with Clause 5. To comply with this standard, products shall meet the requirements of 4.2, and the requirements of 4.3 as appropriate. NOTE Information on additional properties is given in Annex E. One test result for a product property is the average of the measured values on the numbers of test specimens given in Table 4. SIST EN 15501:2013

The thermal conductivity values shall be determined by the manufacturer and verified in accordance with EN ISO 13787. They shall be declared by the manufacturer according to the specified measuring standards mentioned above covering the product service temperature range. The following conditions apply:  the measured values shall be expressed with three significant figures;  the declared conductivity curve shall be given as a limit curve, defined in EN ISO 13787;  the values of the declared thermal conductivity, λD, shall be rounded upwards to the nearest 0,001 W/(m·K). The declared equation/limit curve is the "declared reference" with three significant figures, that is to 0,001 W/(m·K) for λ values below 0,1 W/(m·K) and in 0,01 W/(m·K) for λ values above 0,1 W/(m·K). This shall be used as a reference for the verification of the declaration. When thermal conductivity is declared as a table derived from the equation, rounding upwards to the next 0,001 W/(m·K) has to be done for the full range of the thermal conductivity. NOTE Determinations of the declared thermal conductivity of pipe sections, following EN ISO 8497, having joints in the metering area, include the effects of these joints as defined in EN ISO 23993. 4.2.2 Dimensions and tolerances 4.2.2.1 Linear dimensions The length, l, width, b, and thickness, d, for flat products shall be respectively determined in accordance with EN 822 and EN 823. Length, l, thickness, d, and inside diameter, D, for pipe sections shall be determined in accordance with EN 13467. The dimensions of prefabricated and special ware shall be determined by the appropriated standard. No test result shall deviate from the declared values by more than the tolerance given in Table 1. Table 1 — Dimensional tolerances Form of delivery Length Width Thickness Inside diameter Board ± 3 mm or ± 0,4 % a ± 3 mm or ± 0,4 % a + 3 mm - 2 mm
Pipe section or segment ± 3 mm or ± 0,6 % a
+ 3 mm - 2 mm - 0 mm + 5 mm a Whichever gives the greatest numerical tolerance
4.2.2.2 Squareness Deviation from squareness, Sb and Sd, of boards shall be determined in accordance with EN 824. Deviation from squareness, , of pipe sections and segments shall be determined in accordance with EN 13467. The deviation from squareness of boards on length and width, Sb, shall not exceed 6 mm/m and the deviation from SIST EN 15501:2013

EN 1094-6. At the maximum service temperature, ST(+), the relative changes in length, û0l, and in width, û0b, shall not exceed 2 %. The maximum service temperature, ST(+), shall be declared in °C in levels with steps of 50 °C (Table 2). The test specimen shall not exhibit evidence of self-heating. Table 2 — Levels for maximum service temperatures Level Requirement °C ST(+) 650 ≥ 650 ST(+) 700 ≥ 700 ST(+) 750 ≥ 750 ST(+) 800 ≥ 800 ST(+) 850 ≥ 850 ST(+) 900 ≥ 900 ST(+) 950 ≥ 950 ST(+) 1 000 ≥ 1 000 ST(+) 1 050 ≥ 1 050 ST(+) 1 100 ≥ 1 100
4.3.3 Minimum service temperature Minimum service temperature within the scope of this standard, but above 0°C need not be tested. SIST EN 15501:2013

NOTE EN 826 is not applicable to pipe sections, and compression behaviour is not determined. 4.3.5 Trace quantities of water soluble ions and the pH value Trace quantities of water soluble chloride, fluoride, silicate and sodium ions and the pH-value shall be determined in accordance with EN 13468. The manufacturer shall declare one or more as appropriate as levels in mg per kg of product and the pH-value as levels in steps of 0,5. For chloride and fluoride, no test result shall exceed the declared value. For silicate and sodium, no test result shall be below the declared value. For the pH-value, no test result shall deviate from the declared value by more than 1,0. 4.3.6 Water vapour diffusion resistance Expanded perlite / exfoliated vermiculite products are used for applications at high temperatures where high humidity and water adsorption are irrelevant. In exceptional cases, the water vapour diffusion resistance factor, µ, shall be measured in accordance with EN 12086. 4.3.7 Short term water absorption by partial immersion Expanded perlite / exfoliated vermiculite products are used for applications at high temperatures and water absorption is not relevant. The products should always be stored under dry conditions. In exceptional cases, the short-term water absorption by partial immersion shall be tested in accordance with EN 1609. Short-term water absorption by partial immersion of pipe sections shall be determined in accordance with EN 13472. 4.3.8 Dangerous substances National regulations on dangerous substances may require verification and declaration on release, and sometimes content, when construction products covered by this standard are placed on those markets. SIST EN 15501:2013
