EN ISO 18563-2:2024
(Main)Non-destructive testing - Characterization and verification of ultrasonic phased array equipment - Part 2: Array probes (ISO 18563-2:2024)
Non-destructive testing - Characterization and verification of ultrasonic phased array equipment - Part 2: Array probes (ISO 18563-2:2024)
This document specifies characterization tests to be performed at the end of the fabrication of an array probe. It defines both methodology and acceptance criteria.
This document is applicable to the following array probes used for ultrasonic non-destructive testing [phased array technique or signal processing technique, e.g. full-matrix capture (FMC) and total-focusing technique (TFM)] in contact technique (with or without a wedge or delay line) or in immersion technique, with centre frequencies in the range 0,5 MHz to 10 MHz:
a) array probes with elements in one direction:
— 1-D-linear array (linear array);
— 1-D-curved array;
— annular array;
b) array probes with elements in two directions:
— 2-D-array (matrix array);
— sectorial annular array;
— partial sectorial annular array.
This document does not give methods and acceptance criteria to characterize the performance of an ultrasonic phased array instrument or the performance of a complete system, which are given in ISO 18563–1 and in ISO 18563–3.
Zerstörungsfreie Prüfung - Charakterisierung und Verifizierung der Ultraschall-Prüfausrüstung mit Phased-Array - Teil 2: Array-Prüfköpfe (ISO 18563‑2:2024)
Dieses Dokument legt Abnahmeprüfungen fest, die nach der Herstellung eines Array-Prüfkopfes durchgeführt werden. Es legt sowohl die Vorgehensweise als auch die Zulässigkeitskriterien fest.
Dieses Dokument ist anwendbar für die folgenden Array Prüfköpfe, die für die zerstörungsfreie Prüfung mit Ultraschall (phasengesteuerte Array-Technik oder Signalverarbeitungstechnik, z. B. Erfassung der gesamten Matrix [FMC, en: full-matrix capture] und Technik der vollständigen Fokussierung [TFM, en: total-focusing technique]) mit Kontakttechnik (mit oder ohne Vorsatzkeil oder Vorlaufkörper) oder mit Tauchtechnik mit Mittenfrequenzen zwischen 0,5 MHz und 10 MHz verwendet werden:
a) Array Prüfköpfe mit Elementen in einer Richtung:
lineares 1 D Array (lineares Array);
gekrümmtes 1 D Array;
Ring Array;
b) Array Prüfköpfe mit Elementen in zwei Richtungen:
lineares 2 D Array (Matrix Array);
segmentiertes Ring Array;
segmentiertes partielles Ring Array.
Dieses Dokument enthält keine Verfahren und Zulässigkeitskriterien zur Charakterisierung der Leistung eines Phased-Array-Ultraschallgeräts oder der Leistung eines gesamten Systems, die in ISO 18563 1 und in ISO 18563 3 enthalten sind.
Essais non destructifs - Caractérisation et vérification de l'appareillage de contrôle par ultrasons en multiéléments - Partie 2: Traducteurs multiéléments (ISO 18563-2:2024)
Le présent document spécifie les essais de caractérisation à effectuer à l'issue de la fabrication d'un traducteur multiélément. Il définit à la fois la méthodologie et les critères d'acceptation.
Le présent document s'applique aux traducteurs multiéléments utilisés pour les essais non destructifs par ultrasons [technique multiélément ou technique de traitement du signal, par exemple acquisition de la matrice complète (FMC) et focalisation en tous points (FTP)] selon la technique par contact (avec ou sans sabot ou ligne à retard) ou selon la technique par immersion, ayant une fréquence centrale comprise entre 0,5 MHz et 10 MHz:
a) traducteurs multiéléments avec des éléments dans une direction:
— réseau linéaire 1-D (réseau linéaire);
— réseau courbe 1-D;
— réseau annulaire;
b) traducteurs multiéléments avec des éléments dans deux directions:
— réseau 2-D (réseau matriciel);
— réseau annulaire sectorisé;
— réseau annulaire sectorisé partiel.
Le présent document ne fournit pas les méthodes et critères d'acceptation permettant de caractériser les performances d'un appareil de contrôle par ultrasons en multiéléments ni celles d'un système complet, qui sont indiqués dans l’ISO 18563-1 et l’ISO 18563-3.
Neporušitvene preiskave - Karakterizacija in preverjanje ultrazvočne opreme faznih sistemov - 2. del: Matrične sonde (ISO/DIS 18563-2:2023)
General Information
Relations
Standards Content (Sample)
SLOVENSKI STANDARD
01-januar-2024
Neporušitvene preiskave - Karakterizacija in preverjanje ultrazvočne opreme
faznih sistemov - 2. del: Matrične sonde (ISO/DIS 18563-2:2023)
Non-destructive testing - Characterization and verification of ultrasonic phased array
equipment - Part 2: Array probes (ISO/DIS 18563-2:2023)
Zerstörungsfreie Prüfung - Charakterisierung und Verifizierung der Ultraschall-
Prüfausrüstung mit Phased-Arrays - Teil 2: Prüfköpfe (ISO/DIS 18563-2:2023)
Essais non destructifs - Caractérisation et vérification de l'appareillage de contrôle par
ultrasons en multiéléments - Partie 2: Traducteurs multiéléments (ISO/DIS 18563-
2:2023)
Ta slovenski standard je istoveten z: prEN ISO 18563-2
ICS:
19.100 Neporušitveno preskušanje Non-destructive testing
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
DRAFT INTERNATIONAL STANDARD
ISO/DIS 18563-2
ISO/TC 135/SC 3 Secretariat: DIN
Voting begins on: Voting terminates on:
2023-11-17 2024-02-09
Non-destructive testing — Characterization and
verification of ultrasonic phased array equipment —
Part 2:
Array probes
ICS: 19.100
This document is circulated as received from the committee secretariat.
THIS DOCUMENT IS A DRAFT CIRCULATED
FOR COMMENT AND APPROVAL. IT IS
ISO/CEN PARALLEL PROCESSING
THEREFORE SUBJECT TO CHANGE AND MAY
NOT BE REFERRED TO AS AN INTERNATIONAL
STANDARD UNTIL PUBLISHED AS SUCH.
IN ADDITION TO THEIR EVALUATION AS
BEING ACCEPTABLE FOR INDUSTRIAL,
TECHNOLOGICAL, COMMERCIAL AND
USER PURPOSES, DRAFT INTERNATIONAL
STANDARDS MAY ON OCCASION HAVE TO
BE CONSIDERED IN THE LIGHT OF THEIR
POTENTIAL TO BECOME STANDARDS TO
WHICH REFERENCE MAY BE MADE IN
Reference number
NATIONAL REGULATIONS.
ISO/DIS 18563-2:2023(E)
RECIPIENTS OF THIS DRAFT ARE INVITED
TO SUBMIT, WITH THEIR COMMENTS,
NOTIFICATION OF ANY RELEVANT PATENT
RIGHTS OF WHICH THEY ARE AWARE AND TO
PROVIDE SUPPORTING DOCUMENTATION. © ISO 2023
ISO/DIS 18563-2:2023(E)
DRAFT INTERNATIONAL STANDARD
ISO/DIS 18563-2
ISO/TC 135/SC 3 Secretariat: DIN
Voting begins on: Voting terminates on:
Non-destructive testing — Characterization and
verification of ultrasonic phased array equipment —
Part 2:
Array probes
ICS: 19.100
This document is circulated as received from the committee secretariat.
THIS DOCUMENT IS A DRAFT CIRCULATED
FOR COMMENT AND APPROVAL. IT IS
© ISO 2023
ISO/CEN PARALLEL PROCESSING
THEREFORE SUBJECT TO CHANGE AND MAY
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication may
NOT BE REFERRED TO AS AN INTERNATIONAL
be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying, or posting on STANDARD UNTIL PUBLISHED AS SUCH.
the internet or an intranet, without prior written permission. Permission can be requested from either ISO at the address below
IN ADDITION TO THEIR EVALUATION AS
or ISO’s member body in the country of the requester. BEING ACCEPTABLE FOR INDUSTRIAL,
TECHNOLOGICAL, COMMERCIAL AND
ISO copyright office
USER PURPOSES, DRAFT INTERNATIONAL
CP 401 • Ch. de Blandonnet 8
STANDARDS MAY ON OCCASION HAVE TO
BE CONSIDERED IN THE LIGHT OF THEIR
CH-1214 Vernier, Geneva
POTENTIAL TO BECOME STANDARDS TO
Phone: +41 22 749 01 11
WHICH REFERENCE MAY BE MADE IN
Reference number
Email: copyright@iso.org
NATIONAL REGULATIONS.
Website: www.iso.org ISO/DIS 18563-2:2023(E)
RECIPIENTS OF THIS DRAFT ARE INVITED
Published in Switzerland
TO SUBMIT, WITH THEIR COMMENTS,
NOTIFICATION OF ANY RELEVANT PATENT
RIGHTS OF WHICH THEY ARE AWARE AND TO
ii
PROVIDE SUPPORTING DOCUMENTATION. © ISO 2023
ISO/DIS 18563-2:2023(E)
Contents Page
Foreword .iv
1 Scope . 1
2 Normative references . 1
3 Terms and definitions . 1
4 Symbols . 2
5 General compliance .2
6 Technical information for array probes . 3
7 Test equipment .4
7.1 Electronic equipment . 4
7.2 Test setup . 4
7.2.1 General . 4
7.2.2 Contact technique . 4
7.2.3 Immersion technique . 5
8 Performance tests for array probes . 5
8.1 General . 5
8.2 Physical aspects. 5
8.2.1 Method . . 5
8.2.2 Acceptance criterion . 5
8.3 Relative pulse-echo sensitivity variation . 5
8.3.1 General . 5
8.3.2 Method . . 5
8.3.3 Acceptance criteria . 6
8.4 Frequency, bandwidth and pulse duration . 6
8.4.1 General . 6
8.4.2 Method . . 6
8.4.3 Acceptance criteria . 7
8.5 Array probe sensitivity . 7
8.5.1 General . 7
8.5.2 Method . . 7
8.5.3 Acceptance criteria . 8
8.6 Inter-element cross-talk attenuation (optional) . 8
8.6.1 General . 8
8.6.2 Method . . 8
8.6.3 Acceptance criterion . 8
8.7 Number of elements out of specification . 9
8.7.1 General . 9
8.7.2 Method . . 9
8.7.3 Acceptance criteria . 9
Bibliography .10
iii
ISO/DIS 18563-2:2023(E)
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out
through ISO technical committees. Each member body interested in a subject for which a technical
committee has been established has the right to be represented on that committee. International
organizations, governmental and non-governmental, in liaison with ISO, also take part in the work.
ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of
electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are
described in the ISO/IEC Directives, Part 1. In particular, the different approval criteria needed for the
different types of ISO documents should be noted. This document was drafted in accordance with the
editorial rules of the ISO/IEC Directives, Part 2 (see www.iso.org/directives).
ISO draws attention to the possibility that the implementation of this document may involve the use
of (a) patent(s). ISO takes no position concerning the evidence, validity or applicability of any claimed
patent rights in respect thereof. As of the date of publication of this document, ISO had not received
notice of (a) patent(s) which may be required to implement this document. However, implementers are
cautioned that this may not represent the latest information, which may be obtained from the patent
database available at www.iso.org/patents. ISO shall not be held responsible for identifying any or all
such patent rights.
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
For an explanation of the voluntary nature of standards, the meaning of ISO specific terms and
expressions related to conformity assessment, as well as information about ISO's adherence to
the World Trade Organization (WTO) principles in the Technical Barriers to Trade (TBT), see
www.iso.org/iso/foreword.html.
This document was prepared by the European Committee for Standardization (CEN) Technical
Committee CEN/TC 138, Non-destructive testing, in collaboration with ISO Technical Committee TC 135,
Non-destructive testing, Subcommittee SC 3, Ultrasonic testing, in accordance with the Agreement on
technical cooperation between ISO and CEN (Vienna Agreement).
This second edition cancels and replaces the first edition (ISO 18563-2:2017), which has been
technically revised.
The main changes are as follows:
— terminology and types of array probes modified according to ISO 23423;
— the wording ‘measurement’ is replaced by ‘determination’ or ‘evaluation’, where applicable.
A list of all parts in the ISO 18563 series can be found on the ISO website.
Any feedback or questions on this document should be directed to the user’s national
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
