(Main)Acoustics - Determination of acoustic properties in impedance tubes - Part 2: Two-microphone technique for normal sound absorption coefficient and normal surface impedance (ISO 10534-2:2023)
Acoustics - Determination of acoustic properties in impedance tubes - Part 2: Two-microphone technique for normal sound absorption coefficient and normal surface impedance (ISO 10534-2:2023)
This test method covers the use of an impedance tube, two microphone locations and a frequency
analysis system for the determination of the sound absorption coefficient of sound absorbing materials
for normal incidence sound incidence. It can also be applied for the determination of the acoustical
surface impedance or surface admittance of sound absorbing materials. As an extension, it can also be
used to assess intrinsic properties of homogeneous acoustical materials such as their characteristic
impedance, characteristic wavenumber, dynamic mass density and dynamic bulk modulus.
The test method is similar to the test method specified in ISO 10534-1[1] in that it uses an impedance
tube with a sound source connected to one end and the test sample mounted in the tube at the other
end. However, the measurement technique is different. In this test method, plane waves are generated
in a tube by a sound source, and the decomposition of the interference field is achieved by the
measurement of acoustic pressures at two fixed locations using wall-mounted microphones or an intube
traversing microphone, and subsequent calculation of the complex acoustic transfer function and
quantities reported in the previous paragraph. The test method is intended to provide an alternative,
and generally much faster, measurement technique than that of ISO 10534-1[1].
Normal incidence absorption coefficients coming from impedance tube measurements are not
comparable with random incidence absorption coefficients measured in reverberation rooms according
to ISO 354[2]. The reverberation room method will (under ideal conditions) determine the sound
absorption coefficient for diffuse sound incidence. However, the reverberation room method requires
test specimens which are rather large. The impedance tube method is limited to studies at normal and
plane incidence and requires samples of the test object which are of the same size as the cross-section
of the impedance tube. For materials that are locally reacting only, diffuse incidence sound absorption
coefficients can be estimated from measurement results obtained by the impedance tube method (see
Annex E).
Through the whole document, a e+ j t time convention is used.
Akustik - Bestimmung der akustischen Eigenschaften in Impedanzrohren - Teil 2: 2‑Mikrofontechnik für Schallabsorptionsgrad und Oberflächenimpedanz bei senkrechtem Einfall (ISO 10534‑2:2023)
Dieses Prüfverfahren behandelt die Bestimmung des Schallabsorptionsgrades von schallabsorbierenden Werkstoffen bei senkrechtem Schalleinfall unter Anwendung eines Impedanzrohres, zweier Mikrofonorte sowie eines Frequenzanalysesystems. Es kann auch zur Bestimmung der akustischen Oberflächenimpedanz oder Oberflächenadmittanz von schallabsorbierenden Werkstoffen angewendet werden. In Erweiterung kann es auch angewendet werden, um intrinsische Eigenschaften von homogenen akustischen Werkstoffen, wie z. B. deren charakteristische Impedanz, die charakteristische Wellenzahl, die dynamische Massendichte und den dynamischen Kompressionsmodul, zu beurteilen.
Das Prüfverfahren ist dem in ISO 10534 1 [1] festgelegten insofern ähnlich, als ein Impedanzrohr verwendet wird, an dessen einem Ende eine Schallquelle angeschlossen ist und an dessen anderem Ende der Prüfkörper befestigt wird. Das Messverfahren ist jedoch ein anderes. Bei diesem Prüfverfahren werden mit Hilfe einer Schallquelle ebene Wellen im Rohr erzeugt und die Zerlegung des Interferenzfeldes durch Messung des akustischen Druckes an zwei festen Orten erreicht, wobei an der Wand befestigte Mikrofone oder ein im Rohr verfahrbares Mikrofon verwendet werden bzw. wird; anschließend werden die komplexe akustische Übertragungsfunktion und die vorstehend genannten Größen berechnet. Dieses Prüfverfahren dient er Bereitstellung eines alternativen und im Vergleich zu dem in ISO 10534 1 [1] behandelten im Allgemeinen viel schnelleren Messverfahrens.
Die sich bei Impedanzrohrmessungen mit senkrechtem Schalleinfall ergebenden Absorptionsgrade sind nicht mit den in Hallräumen bei zufälligem Schalleinfall nach ISO 354 [2] gemessenen Absorptionsgraden vergleichbar. Mit Hilfe des Hallraumverfahrens wird (unter Idealbedingungen) der Schallabsorptionsgrad bei diffusem Schalleinfall bestimmt. Für das Hallraumverfahren werden jedoch verhältnismäßig große Probekörper benötigt. Das Impedanzrohrverfahren ist auf Untersuchungen bei senkrechtem und ebenem Schalleinfall begrenzt und erfordert Proben des Prüfgegenstandes, die die gleiche Größe wie der Querschnitt des Impedanzrohres besitzen. Bei ausschließlich lokal wirkenden Werkstoffen können die Schallabsorptionsgrade bei diffusem Einfall aus den Messergebnissen geschätzt werden, die mit dem Impedanzrohrverfahren gewonnen wurden (siehe Anhang E).
Im gesamten Dokument wird eine e^(+jωt) Zeitkonvention verwendet.
Acoustique - Détermination des propriétés acoustiques aux tubes d’impédance - Partie 2: Méthode à deux microphones pour le coefficient d’absorption acoustique normal et l’impédance de surface normale (ISO 10534-2:2023)
Akustika - Ugotavljanje akustičnih lastnosti v Kundtovi cevi - 2. del: Dvomikrofonska tehnika za določanje normalnega koeficienta absorpcije zvoka in normalne površinske impedance (ISO 10534-2:2023)
Ta preskusna metoda zajema uporabo Kundtove cevi, mest postavitve dveh mikrofonov in sistema analize frekvence za določanje koeficienta absorpcije zvoka absorpcijskih materialov za
normalni vpad zvoka. Uporabiti jo je mogoče tudi za ugotavljanje akustične površinske impedance ali površinske vpojnosti zvoka absorpcijskih materialov. V razširitvenih izvedbi jo je mogoče uporabiti tudi za ocenjevanje intrinzičnih lastnosti homogenih akustičnih materialov, npr. značilna
impedanca, značilno valovno število, dinamična masna gostota in dinamični stisljivostni modul.
Preskusna metoda je podobna tisti, določeni v standardu ISO 10534-1[1], in sicer v uporabi Kundtove cevi z virom zvoka, povezanim na en konec cevi, in preskusnim vzorcem, nameščenim na drug konec cevi. Vseeno pa metodi uporabljata različno merilno tehniko. Ravne valove v cevi pri tej preskusni metodi ustvarja
vir zvoka, razgradnja interferenčnega polja pa nastane z merjenjem zvočnih tlakov na dveh določenih lokacijah, in sicer z uporabo stenskih mikrofonov oziroma prehodnega mikrofona v cevi, in nadaljnjim izračunom kompleksne funkcije prenosa zvoka in količin iz prejšnjega odstavka. Ta preskusna metoda je namenjena zagotavljanju alternative
in je običajno precej hitrejša merilna tehnika v primerjavi s tisto iz standarda ISO 10534-1[1].
Normalni koeficienti absorpcije pojavnosti iz merjenja Kundtove cevi niso primerljivi z naključnimi koeficient absorpcije pojavnosti, merjenimi v odmevnicah v skladu s standardom ISO 354[2]. Metoda odmevnice bo (v idealnih pogojih) določila koeficient absorpcije zvoka za pojav difuznega zvoka. Vendar pa je treba pri metodi odmevnice uporabiti sorazmerno velike preskušance. Metoda Kundtove cevi je omejena na študije normalne in ravninske pojavnosti in zahteva vzorce predmeta preskusa, ki so enako veliki kot presek Kundtove cevi. Za materiale, ki reagirajo samo lokalno, je mogoče koeficiente absorpcije pojavnosti difuznega zvoka oceniti iz rezultatov merjenja z metodo Kundtove cevi (glej dodatek E).
V celotnem dokumentu se uporablja konvencija o času a e+ j t.
