EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 14423
June 2013 ICS 23.040.70 Supersedes EN 14423:2004English Version
Clamp type coupling assemblies for use with steam hoses rated for pressures up to 18 bar
Raccords avec colliers de serrage pour tuyaux à vapeur utilisant une pression jusqu'à 18 bar
Schlaucharmaturen mit Klemmfassung für Dampf bis 18 bar This European Standard was approved by CEN on 8 May 2013.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2013 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 14423:2013: ESIST EN 14423:2013

1) 1 bar = 0,1 MPa. SIST EN 14423:2013

2) This document is currently impacted by the corrigendum EN ISO 4287:1998/AC:2008 and the draft amendment EN ISO 4287:1998/A1:2009. SIST EN 14423:2013

Key For 1 to 5 see Table 1 a Connector end b Tail end Figure 1 — Coupling assembly SIST EN 14423:2013

NOTE A distinction is made between the connector end and the tail end of coupling assemblies. The former is the part by which the coupling is connected to an appliance or pipe (for various types of connectors, see Table 2), while the latter (including the tail end fitting and clamp) is fastened to a hose (see 7.2 and 7.4). SIST EN 14423:2013

≈ mm Details
FL PN 40 loose flange with weld-neck collar as in EN 1092-1 15 20 25 32 40 50
110 115 115 125 140 155 See 7.3.1
FV PN 40 weld-neck flange as in EN 1092-1
See 7.3.2
G Union nut with thread gasket, with parallel thread according to EN ISO 228-1a
15 20 25 32 40 50
G ½
G ¾
G 1
G 1¼
G 1½
G 2
90 105 115 See 7.3.4
GA Tapered male thread with external thread according to EN 10226-1a 15 20 25 32 40 50
R ½
R ¾
R 1
R 1¼
R 1½
R 2
95 100 110 125 140 See 7.3.5 a Other threads may be agreed between the purchaser and manufacturer.
Characteristics Coupling assembly EN 14423 — FL
20 — 1.4571 — 1.0038— CW614N EN number Type of connector  FL Weld-neck collar for loose flange  FV Weld-neck flange  G Union nut with parallel thread according
to EN ISO 228-1  GA Tapered stud end according to
EN 10226-1 DN (nominal size) Material designation  for tail end fittings: (according to 9.1)  for type FL only:  for loose flanges: (according to 9.3)  for clamps: (according to 9.7) EXAMPLE 1 Ordering designation for a type FL coupling assembly for use with DN 20 hoses, consisting of a stainless steel tail end fitting with collar (1.4571), a carbon steel (1.0038) loose flange and a wrought copper alloy (CW614N) clamp, with bolts and nuts:
Coupling assembly EN 14423 — FL 20 — 1.4571 — 1.0038 — CW614N EXAMPLE 2 Ordering designation for a type G coupling assembly for use with DN 20 hoses, consisting of a stainless steel tail end fitting, a carbon steel (1.0038) union nut secured by a wire ring, and a wrought copper alloy (CW614N) clamp, with thread gasket, bolts and nuts:
Coupling assembly EN 14423 — G 20 — 1.0038 — CW614N 6 Hose dimensions Careful selection of the hose fittings should be made to ensure that the inner diameter (ID) and outer diameter (OD
...
