EN ISO 8987:1998

SLOVENSKI STANDARD
SIST EN ISO 8987:1999
01-maj-1999
3ROLPHUQLPDWHULDOL±)HQROQHVPROH±'RORþHYDQMHUHDNWLYQRVWLQDSUHVNXVQL
SORãþL]DSUHKRGQRVWDQMH%%þDV,62
Plastics - Phenolic resins - Determination of reactivity on a B-transformation test plate
(ISO 8987:1995)
Kunststoffe - Phenolharze - Bestimmung der Reaktivität auf einer B-Zeit-Prüfplatte (ISO
8987:1995)
Plastiques - Résines phénoliques - Méthode d'évaluation de la réactivité sur plaque
d'essai de transformation au stade B (ISO 8987:1995)
Ta slovenski standard je istoveten z: EN ISO 8987:1998
ICS:
83.080.10 Duromeri Thermosetting materials
SIST EN ISO 8987:1999 en
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

---------------------- Page: 1 ----------------------

SIST EN ISO 8987:1999

---------------------- Page: 2 ----------------------

SIST EN ISO 8987:1999

---------------------- Page: 3 ----------------------

SIST EN ISO 8987:1999

---------------------- Page: 4 ----------------------

SIST EN ISO 8987:1999
IS0
INTERNATIONAL
8987
STANDARD
Second edition
1995-l 2-15
Phenolic resins -
Plastics -
Determination of reactivity on a
B-transformation test plate
Mkthode d ’&aluation de la r6activit6
P/as tiques - R&ines phbnoliques -
sur plaque d ’essai de transformation au stade B
Reference number
IS0 89877 995(E)

---------------------- Page: 5 ----------------------

SIST EN ISO 8987:1999
IS0 8987:1995(E)
Foreword
IS0 (the International Organization for Standardization) is a worldwide
federation of national standards bodies (IS0 member bodies). The work of
preparing International Standards is normally carried out through IS0
technical committees. Each member body interested in a subject for
which a technical committee has been established has the right to be
represented on that committee. International organizations, governmental
and non-governmental, in liaison with ISO, also take part in the work. IS0
collaborates closely with the International Electrotechnical Commission
(IEC) on all matters of electrotechnical standardization.
Draft International Standards adopted by the technical committees are
circulated to the member bodies for voting. Publication as an International
Standard requires approval by at least 75 % of the member bodies casting
a vote.
International Standard IS0 8987 was prepared by Technical Committee
lSO/TC 61, Plastics, Subcommittee SC 12, Thermosetting materials.
This second edition cancels and replaces the first edition (IS0 8987:1988)
which has been revised so that, in both method A and method B, the test
plate may be fitted with an integral heater.
0 IS0 1995
All rights reserved. Unless otherwise specified, no part of this publication may be
reproduced or utilized in any form or by any means, electronic or mechanical, including
photocopying and microfilm, without permission in writing from the publisher.
International Organization for Standardization
Case Postale 56 l CH-1211 Geneve 20 l Switzerland
Printed in Switzerland

---------------------- Page: 6 ----------------------

SIST EN ISO 8987:1999
IS0 8987:1995(E)
INTERNATIONAL STANDARD @ IS0
Plastics - Phenolic resins - Determination of reactivity on
a B-transformation test plate
3.1.3 Glass rod, 5 mm in diameter, tapering to about
1 Scope
2 mm in diameter at one end.
This International Standard specifies methods for the
determination of the B-transformation time of phenolic 3.1.4 Balance, scale interval 0,Ol g.
resins at a specified temperature and under specified
conditions on a heated test plate.
3.1.5 Syringe.
Two methods are described, each with a different test
plate:
3.1.6 Stopwatch, with at least 1 s sub-divisions.
Method A - plate with depressions in the form
of segments of spheres;
3.1.7 B-transformation test plate, with depressions
as shown in figure 1, with or without an integral heater.
Method B - flat plate without depressions.
3.2 Number of tests
2 Principle
Conduct one or more tests, depending on the re-
quirements of the appropriate International Standard
or as agreed between the parties concerned.
The condensation of the phenolic resin is carried out
to the B-stage on one of two types of test plate, de-
pending on the method.
3.3 Procedure
Bring the B-transformation test plate (3.1.7) to the re-
3 Method A: Determination on a plate quired temper
...
