EN ISO/IEC 11544:1995

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Information technology - Coded representation of picture and audio information - Progressive bi-level image compression (ISO/IEC 11544:1993)Informationstechnik - Codierte Darstellung von Bild und Toninformationen - Progressive Kompression von zweistufigen Bildern (ISO/IEC 11544:1993)Technologies de l'information - Représentation codée de l'image et du son - Compression de l'image progressive a deux niveaux (ISO/IEC 11544:1993)Information technology - Coded representation of picture and audio information - Progressive bi-level image compression (ISO/IEC 11544:1993)35.040Nabori znakov in kodiranje informacijCharacter sets and information codingICS:Ta slovenski standard je istoveten z:EN ISO/IEC 11544:1995SIST EN ISO/IEC 11544:1997en01-december-1997SIST EN ISO/IEC 11544:1997SLOVENSKI
STANDARD



SIST EN ISO/IEC 11544:1997



SIST EN ISO/IEC 11544:1997



SIST EN ISO/IEC 11544:1997



INTERNATIONAL STANDARD ISO/IEC 11544 First edition 1993-12-15 Information technology - Coded representation of picture and audio information - Progressive bi-level image compression Technologies de I’informa tion - Reprbentation cod6e de I son - Compression de I’image progressive & deux niveaux ‘image et du Reference number ISO/IEC 11544:1993(E) SIST EN ISO/IEC 11544:1997



ISO/IEC 11544:1993(E) Contents Page 1 scope . 1 2 Normative references . 1 3 Definitions . 1 4 Symbols and abbreviations . 2 4.1 Acronyms . 2 4.2 Symbolic constants . 2 4.3 Mathematical Symbols, Operators, and indicators . 3 4.4 Variables with mnemonic names . 3 5 Conventions . 3 5.1 Flow diagram conventions and Symbols . 3 5.2 Template graphics . 3 5.3 Spatial Phase . 4 5.4 Data structure graphics . 4 6 Requirements . 7 6.1 General rules . 7 6.2 Data organization . 7 6.3 Resolution reduction . 12 6.4 Differen tial-layer typical predic tion . 13 6.5 Lowest-resolution-layer typical prediction . 16 6.6 Deterministic prediction (DP) . 19 6.7 Model templates and adaptive templates . 23 6.8 Arithmetic coding . 26 7 Test methods and datastream examples . 43 7.1 Arithmetic coding . 44 7.2 Parameterized algorithm . 51 7.3 Datastream examples . 55 @ ISO/IEC 1993 All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by any means, electronie or mechanical, including photocopying and microfilm, without Permission in writing from the publisher. ISO/IEC Copyright Office l Case postale 56 l CH-121 1 Geneve 20 l Switzerland I Printed in S witzerland ii SIST EN ISO/IEC 11544:1997



ISO/IEC 11544:1993(E) Annexes A Suggested minimum support for free Parameters . 56 Design of ehe resolution reduction table . 57 B, 1 Fil tering . 57 .2 Exceptions . 58 C Adaptive template changes . 60 Cl General . 60 C.2 Differential layers . 60 C.3 Lowest resolution layer . 60 D Design of the probability-estimation table . 63 D.l Bayesian estimation . 63 D.2 Multiple contexts . 63 D.3 MPS/LPS parameterization . 63 D.4 Rapid tracking . 64 D.5 Reducing computational burden . 64 E Patents . 68 E.l Introductory remarks . 68 E.2 List of Patents . 68 E.3 Contact addresses for patent information . 69 F Bibliography . 71 . . . 111 SIST EN ISO/IEC 11544:1997



ISO/IEC 11544:1993(E) Foreword ISO (the International Organization for Standardization) and IEC (the International Electrotechnical Commission) form the specialized System for worldwide standardization. National bodies that are members of ISO or IEC participate in the development of International Standards through technical committees established by the respective organization to deal with particular fields of technical activity. ISO and IEC technical committees collaborate in fields of mutual interest. Other international organizations, governmental and non-govemmental, in liaison with ISO and IEC, also take part in the work. In the field of information technology, ISO and IEC have established a joint technical committee, ISO/IEC JTC 1. Draft International Standards adopted by the joint technical committee are circulated to national bodies for voting. Publication as an International Standard requires approval by at least 75 % of the national bodies casting a vote. International Standard ISO/IEC 11544 was prepared by Joint Technical Committee ISO/IEC JTC 1, Information technology, Subcommittee SC 29, Coding of audio, picture, multimedia and hypermedia information, in collaboration with CCITT. The identical text is published as CCITT Recommendation T.82. Annexes A, B, C, D, E and F of this International Standard are for information only. Patents During the preparation of this International Standard, information was gathered on Patents upon which application sf the Standard might depend. Relevant Patents were identified as belonging to the patent holders listed in annex E. However, ISO/IEC cannot give authoritative or comprehensive information about evidente, validity or scope of patent and like rights. The patent holders have stated that licences will be granted under reasonable terms. Communications on this subject should be addressed to the patent holders (see annex E). SIST EN ISO/IEC 11544:1997



ISO/IEC 11544:1993(E) Introduction This Recommendation I International Standard was prepared by the Joint Bi-level Image experts Group (JBIG) of ISO/IEC JTClKC29NVG9 and CCITT SGVIII. The JBIG experts group was formed in 1988 to establish a Standard for the progressive encoding of bi-level images. A progressive encoding System transmits a compressed image by first sending the compressed data for a reduced- resolution version of the image and then enhancing it as needed by transmitting additional compressed data, which builds on that already transmitted. This Recommendation I International Standard defines a coding method having progressive, progressive-compatible sequential, and Single-Progression sequential modes and suggests a method to obtain any needed low-resolution renditions. It has been found possible to effectively use the defined coding and resolution-reduction algorithms for the lossless coding of greyscale and color images as well as bi-level images. 0.1 General characteristics This Specification defines a method for lossless compression encoding of a bi-level image (that is, an image that, like a black-and-white image, has only two colors). The defined method tan also be used for coding greyscale and color images. Being adaptive to image characteristics, it is robust over image type. On scanned images of printed characters, observed compression ratios have been from 1,l to 1,5 times as great as those achieved by the MMR encoding algorithm (which is less complex) described in Recommendations T.4 (G3) and T.6 (G4). On Computer generated images of printed characters, observed compression ratios have been as much as 5 times as great. On images with greyscale rendered by halftoning or dithering, observed compression ratios have been from 2 to 30 times as great. The method is bit-preserving, which means that it, like Recommendations T.4 and T.6, is distortionless and that the final decoded image is identical to the original. The method also has “progressive” capability. When decoding a progressively coded image, a low-resolution rendition of the original image is made available first with subsequent doublings of resolution as more data is decoded. Note that resolution reduction is performed from the higher to lower resolution layers, while decoding is performed from the lower to higher resolution layers. The lowest resolution image sent in a progressive sequence is a sequentially coded image. In a Single-Progression sequential coding application, this is the only image sent. Progressive encodings have two distinct benefits. One is that with them it is possible to design an application with one common database that tan efficiently serve output devices with widely different resolution capabilities. Only that Portion of the compressed image file required for reconstruction to the resolution capability of the particular output device has to be sent and decoded. Also, if additional resolution enhancement is desired, for say, a Paper copy of an image already on a CRT Screen, only the needed resolution-enhancing information has to be sent. The other benefit of progressive encodings is that they tan provide subjectively superior image browsing (on a CRT) for an application using low-rate and medium-rate communication links. A low-resolution rendition is transmitted and displayed rapidly, and then followed by as much resolution enhancement as desired. Esch Stage of resolution enhancement builds on the image already available. Progressive encoding tan make it easier for a user to quickly recognize the image as it is being built up, which in turn allows the user to interrupt the transmission of the image. Let D denote the number of doublings in resolution (called differential layers) provided by the progressive coding. Let 1~ denote the highest resolution image and let its horizontal and vertical dimensions in Pixels be & and YD. Let RD denote the sampling resolution of the image ZD. This Specification imposes almost no restrictions on the parameters RD, XD, YD, or D. Choices such as 400 or 200 dpi (dots-per-inch) for the resolution RD of the highest resolution layer result in a hierarchy of resolutions commensurate with current facsimile Standards. Choosing RD as 600 or 300 dpi gives a progressive hierarchy more compatible with the laser Printer resolutions available as of the writing of this Specification. It is anticipated that D will typically be Chosen so that the lowest resolution is roughly 10 to 25 dpi. Typical bi-level images when reduced to such a resolution are not legible, but nonetheless such low-resolution renditions are still quite useful and function as automatically generated icons. Page layout is usually apparent and recognition of particular pages that have been seen before at higher resolution is often possible. V SIST EN ISO/IEC 11544:1997



ISO/IEC 11544:1993(E) As mentioned above, this Specification does not restritt the number D of resolution doublings. It tan be set to 0 if progressive coding is of no Utility, as is the case, for example, in hardcopy facsimile. Doing so retains JBIG’s compression advantage over MMR (and in fact usually increases it somewhat), while eliminating the need for any buffering and simplifying the algorithm. Single-Progression sequential JBIG coding has potential applications identical to those of MMR coding. Images compressed by a single-progression sequential encoder will be readable by decoders capable of progressive decoding, although only the lowest resolution version sf a progressively encoded image will be decodable by a Single-Progression sequential decoder. It is possible to use this Specification for the lossless coding of greyscale and color images by coding bit-Planes independently as though each were itself a bi-level image. This ap roach to the eoding of greyscale and color images tan be used as an alternative to the photographic encoding specification C%1ITT Rec. T.8 1’ 1 IS /IEC 1093 8- 1 (JPEG) in its lossless mode. Preliminary experimental results have shown that J IG has a compression advantage over JPEG in its lossless mode for greyscale images up to 6 bits-per-pixel. For 6 to bits-oer--pixel the compression results have been IG and JPEG. This Specification makes provision for images ~4th more than one bit plane, but makes no recommendation on how to map greyscale or color Pntensities he bit-planes. E%pe:imentaliy, Bt has been found that for greyscale images a mapping via Gray-coding of intensity is superior to a mappijsag via simple weighted-binary coding of intensity. 0.2 Stripes and data ordering When it is necessary to distinguish progressive coding from the more traditional ferm sf image coding in which the image is coded at full resolution from left to right and top to bottom, this odder ferm of coding will be referred to as “sequential”. The advantage of sequential coding over progressive co&ng is that no page (frarne) buffer is required. Progressive coding does require a page buffer at the next-to-highest resolution because lower resolution Images are used in coding higher resolution images. It is possible to create a JBIG datastream with only a lowes~ resolution layer and is tan be named Single-progression sequential coding. In such coding, a full-resolution image is coded without reference to any differential resolution layers. The Parameters D (mentioned in 0.1) is set equal to Zero. It should be noted that in a progressive encoding of an image, the lowest resolution layer is actually encoded in single-Progression sequential coding. If a full-resolution image is encoded using Single-Progression sequential coding, it. will not be possible to decode the image progressively. Coding in the progressive-compatible sequential mode is said to be “compatible” with coding in the progressive mode because the datastreams created (encoder) or read (decoder) Pn either mode carry exactly the same information. All that changes with a switch from progressive to progressive-compatible sequential encoding is the order in which parts of the compressed data are created by the encoder. All that changes with a switch from progressive to progressive-compatible sequential decoding is the Order in which these parts are used by the decoder. This compatibility is achieved by breaking an image into smaller parts before compression. These parts are created by dividing the image in each of its resolution “layers” into horizontal bands called ‘“stripes.” Progressive-compatible sequential coding does require a “stripe” buffer (much smaller than a page buffer) and additional individual “state” memory used for adaptive entropy coding of each resolution layer and bit plane. Figure Intro. 1 Shows such a decomposition when there are three resolution layers, three stripes per layer, and only one bit plane. Table Intro. 1 Shows defined ways to sequence through the nine stripes. Notice that in addition to the progressive-versus-sequential distinction that is carried by the SEQ bit, there is also a resolution-Order distinction that is carried by the HHTOLO bit. Encoders work from high resolution downward and so most naturally encode the stripes in HITOLO Order. Decoders must build up the image from low resolution and so most naturally process stripes in the opposite Order. When an application uses an encoder that sends progressively coded data directly to a decoder, one or the other must buffer to invert the Order. When an application includes a database, the database (with appropriate set-up) tan be used to buffer and invert the Order (including setting HITOLO correctly) thereby removing this requirement from the encoder and decoder. A stripe has a vertical size that is typically much smaller than that of the entire image. The number &) of lines per stripe at the lowest layer is another free Parameter. As an example, b might be Chosen so that a stripe is about 8 mm. If such a choice is made, the number S of stripes in an image of a business-letter-sized sheet of Paper will be about 35. vi SIST EN ISO/IEC 11544:1997



ISO/IEC 11544:1993(E) s=o s=l s=2 25 dpi d=Q 50 dpi d=l 100 dpi d=2 TO808630-9 1 /DO 1 Figure 0.1 - Decomposition in the special case of 3 layers, 3 stripes, and 1 bit plane Table 0.1 - Possible bi-level data orderings 0,1,2 3,4,5 6,7,8 0,3,6 1,4,7 2,5,8 6,7,8 3,4,5 0,1,2 When there is more than one bit plane, as in Figure 0.2, there are twelve defined stripe orderings. Table 0.2 lists them. As before, the HITOLO bit carries the resolution-Order distinction, and the SEQ bit carries the progressive-versus- sequential distinction. When the ILEAVE bit is 1, it indicates the interleaving of multiple bit planes. When the SMID bit is 1, it indicates S, the index over the stripe, is in the middle as shown more clearly in Table 11 of 6.2.4. p= 1 (MSB) s=o s=l s=2 00 P = 0 (LW _ _ - - -. - - 03 01 - - _ _ - - - - - 04 02 - - 05 25 dpi 50 dpi IOOdpi d=O d=l d=2 . TO808640-9 1 /DO2 Figure 0.2 - Decomposition in the special case of 3 layers, 3 stripes, and 2 bit planes vii SIST EN ISO/IEC 11544:1997



ISO/IEC 11544:1993(E) Table 0.2 - Possible multi-plane data erderings HITOLO SEQ ILEAVE SMID Example Order 0 0 0 0 0 0 1 1 1 1 1 1 0 0 0 1 1 1 0 0 0 1 1 1 0 1 1 0 0 1 0 1 1 0 0 1 0 (00,01,02 06,07,08 12,13,14) (03,04,05 09,10,11 15,16,17) 0 (00,01,02 03,04,05) (06,07,08 09,10,11) (12,13,14 15,16,17) 1 (00,03 01,04 02,05) (06,09 07,lO 08,ll) (12,15 13,16 14,17) 0 (00,06,12 03,09,15) (01,07,13 04,10,16) (02,08,14 05,11,17) 1 (00,06,12 01,07,13 02,08,14) (03,09,15 04,10,16 05,11,17) 0 (00,03 06,09 12,15) (01,04 07,lO 13,16) (02,05 08,ll 14,17) 0 (12,13,14 06,07,08 00,01,02) (15,16,17 09,10,11 03,04,05) 0 (12,13,14 15,16,17) (06,07,08 09,lOJl) (00,01,02 03,04,05) 1 (12,15 13,16 14,17) (06,09 07,lO 08,ll) (00,03 01,04 02,05) 0 (12,06,00 15,09,03) (13,07,01 16,10,04) (14,08,02 17,11,05) 1 (12,06,00 13,07,01 14,08,02) (15,09,03 16,10,04 17,11,05) 0 (12,15 06,09 00,03) (13,16 07,lO 01,04) (14,17 08,ll 02,05) The two new variables ILEAVE and SMID plus the two earlier variables HITOLO and SEQ make it possible to index all twelve of these orders. The other four of the sixteen possible combinations for these four binary variables have no stripe ordering associated with them. If there is only one plane, stripe Order is not dependent on ILEAVE and SMID and their values are inconsequential. The compressed data CS, d, P for stripe s of resolution layer d of bit-plane p is independent of stripe ordering. All that changes as HITOLO, SEQ, IWVE and SMID vary is the Order in which the data is concatenated onto a datastream. This is the compatibility feature noted earlier. For simplicity, the remainder of this introduction will assume there is only one bit plane and the subscript p denoting bit plane will be dropped from CS d P. > > 0.3 Encoder functional. blocks An encoder tan be decomposed as shown in Figure 0.3. (In single;progression sequential coding only the lowest- resolution-layer encoder would be used.) Although conceptually there arc D algorithmically identical differential-layer encoders as shown in Figure 0.3, some implernentations may choose to recursively use only one physical differential-layer encoder. Resolution reduction and differential layer el?COdW ID-1 1 Resolution pL _ - -.L, reduction and differential layer encoder Lowest resolution layer encoder + cO, 0’ c1, 0’ . . . . . cS-1, D T0806280-90/D03 Figure 0.3 - Decomposition of encoder . . . Vlll SIST EN ISO/IEC 11544:1997



ISO/IEC 11544:1993(E) 0.3.1 Resolution reduction and differential layer encoder Esch of the resolution-reduction-and-differential-layer-encoder blocks of Figure 0.3 is identical in function, hence only a description of the Operation .at one layer is needed. For such a description there are only two resolution layers involved. For simplicity in the remainder of this subclause, the incoming image will be referred to as the “high- resolution” image and the outgoing image, as the “low-resolution” image. Note though ‘that the “high” and “10~” resolution images of any particular resolution-reduction-and-differential-layer-encoder block in Figure 0.3 arc not in general the highest and lowest resolution images of the entire System. A resolution-reduction-and-differential-layer-encoder block of Figure 0.3 tan itself be decomposed into sub-blocks as shown in Figure 0.4. Not all sub-blocks need be used in all Systems. Refer to the tables in clause 4 for a -Definition of Signal names. ATMOVE TYPF~ prediction (differential) r Deterministic prediction + Adaptive _ templates , / s, d-l ’ Adaptive I arithmetic T Model templates LNTP TPVALUE DPVALUE i C sr d TO806290-9O/DO4 Figure 0.4 - Resolution reduction and differential layer encoder Acronyms for the processing blocks of this figure and some others to be discussed in this introductory clause are given in Table 0.3. Acronym AAD Adaptive Arithmetic Decoder AAE Adaptive Arithmetic Encoder AT Adaptive Templates DP Deterministic Prediction MT Model Templates RR Resolution Reduction TPE3 Typical Prediction (Bottom) TPD Typical Prediction (Differential) Table 0.3 - Acronyms for processing blocks Meaning iX SIST EN ISO/IEC 11544:1997



ISO/IEC 11544:1993(E) 8.3.1.1 Resolution reduction The resolution-reduction (RR) block performs resolution reduction. This block accepts’ a high-resolution image and creates a low-resolution image with, as nearly as possible, half as many rows and half as many columns as the original. An obvious way to reduce the resolution sf a given image by a factor of two in each dimension is to subsample it by taking every other row and every other column. Subsampling is simple, but creates images of poor subjective quality, especially when the input image is bi-level. For bi-level images containing text and line drawings, subsampling is poor because it frequently deletes thin lines. For bi-level images that contain halftoning or ordered dithering to render greyscale, subsampling is poor because greyness is not well preserved, especially if the dithering period is a power of two, as is frequently the case. This Specification suggests a resolution reduction method. This particular method has been carefullly designed, extensively tested, and found to achieve excellent results for text, Bine art, dithered greyscale, halftoned greyscale, and error-diffused greyscale. 0.3.1.2 ‘.Differential layer typical prediction The differential-layer typical prediction (TP) block provides some coding gain, but its primary purpose is to Speed implernentations. Differential-layer TP looks for regions sf solid color and when it finds that a given current high-resolution Pixel for coding is in such a region, none of the processing normally done’in the DP, AT, MT, and AAE blocks is needed. On text or line-art images, differential-Bayer TP usually makes it possible to avoid coding over 95% of the Pixels. On bi-level images rendering greyscale, processing savings are significantly smaller. 0.3.1.3 Deterministic prediction The purpose of the deterministic-prediction (DP) block is to provide coding gain. On the Set of development of this Specification it provided a ‘7% gain, and such a gain is thought to be ty ,pical. test images used in the When images are reduced in resolution by a particular resolution reduction algorithm, it sometimes happens that the value of a particular current high-resolution Pixel to be coded is inferable from the Pixels already known to both the encoder and decoder, that is, all the Pixels in the low-resolution image and those in the high-resolution image that are causally related (in a raster sense) to the current pixell. When this occurs, the current Pixel is said to be deterministically predictable. The DP block flags any such Pixels and inhibits their coding by the arithmetic coder. DP is a eable driven algorithm. The values of particular surrounding Pixels in the Eow-resolution image and causa1 high- resolution image are used to index into a table to check for determinicity and, when it is present, obtain the deterministic prediction. DP tables are highly dependent on the particular resolution reduction method used. Provision is made for an encoder to download DP tables ao a decoder if it is using a private resolution reduction algorithm. If an application requires default DP, decoders need to always have the default DP tables and no DP tables need be sent. Hence, if the suggested resolution reduction algorithm is used, no DP table need ever be sent. 0.3.1.4 Model templates For each high-resolution Pixel to be coded, the model-templates (MT) block provides the arithmetic coder with an integer called the context. This integer is determined by the colors (binary levels) of particular Pixels in the causa1 high- resolution image, by particular Pixels in the already available low-resolution image, and by the spatial Phase of the Pixel being coded. “Spatial Phase” describes the orientation of the high-resolution Pixel with respect to its corresponding low- resolution Pixel. The arithmetic coder maintains for each context an estimate of the conditional probability of the Symbol given that context. The greatest coding gain is achieved when this probability estimate is both accurate and close to 0 or 1. Thus, good templates have good predictive value so that when the values of the Pixels in the template are known, the value of the Pixel to be coded is highly predictable. 0.3.1.5 Adaptive templates The adaptive-templates (AT) block provides substantial coding gain (sometimes as much as 80%) on images rendering greyscale with halftoning. AT looks for periodicity in the image and on finding it changei the template so that the Pixel preceding the current Pixel by this periodicity is incorporated into the template. Such a Pixel has excellent predictive value. X SIST EN ISO/IEC 11544:1997



ISO/IEC ll544.:1993(E) Suchthanges are infrequent, and when one occurs, a control sequence (indicated symbolically by A!X!MWEi in Figure 0.4) is added to the output datastream. Hence, decoders need not do any processing to search for the correct setting.‘.for AT. 0.3.1.6 Adaptive arithmetic encöder The adaptive-arithmetic-encoder (AAE) block is an entropy coder. It notes the Outputs of the TP and DP blocks to determine if it is even necessary to code a given Pixel. Assuming it is, it then notes the context and uses its internal probability estimator to estimate the conditional probability that the current Pixel will be a given color. Often the Pixel is highly predictable from the context so that the conditional probability is very close to 0 or 1 and a large entropy coding gain tan be realized. Maintaining probability estimates for each of the contexts is a non-trivial statistical Problem. A balance must be struck between obtaining extremely accurate estimates and the conflicting need of adapting quickly to changing unddying statistics. 0.3.2 Lowest resolution layer encoder Figure 0.5 Shows a lowest-resolution-layer encoder. It is conceptually simpler than the differential-layer encoder because the RR and DP blocks are not applicable and the PT, AT, and MT blocks are different since there is no lower resolution layer to be used as input. Refer to the tables in clause 4 for a definition of Signal names. (Not all sub-blocks need to be used in all Systems.) Lowest-resolution-layer TP like differential-layer TP is primarily intended to Speed processing. The algorithms used for the two Versions of TP are quite different, however, and it is not possible to skip as high a percentage of Pixels with lowest-resolution-layer TP a
...
