EN 15657-1:2009

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Akustische Eigenschaften von Bauteilen und von Gebäuden - Messung des Luft- und Körperschalls von haustechnischen Anlagen im Prüfstand - Teil 1: Vereinfachte Fälle, in denen die Admittanzen der Anlagen wesentlich höher sind als die der Empfänger am Beispiel von WhirlwannenPropriétés acoustiques des éléments de construction et des bâtiments - Mesurage en laboratoire des bruits aériens et de structure des éléments de construction - Partie 1: Cas simplifiés prenant comme exemple les bains bouillonnantsAcoustic properties of building elements and of buildings - Laboratory measurement of airborne and structure borne sound from building equipment - Part 1: Simplified cases where the equipment mobilities are much higher than the receiver mobilities, taking wirlpool baths as an example91.120.20L]RODFLMDAcoustics in building. Sound insulation17.140.01Acoustic measurements and noise abatement in generalICS:Ta slovenski standard je istoveten z:EN 15657-1:2009SIST EN 15657-1:2009en,de01-september-2009SIST EN 15657-1:2009SLOVENSKI
STANDARD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 15657-1June 2009ICS 91.120.20 English VersionAcoustic properties of building elements and of buildings -Laboratory measurement of airborne and structure borne soundfrom building equipment - Part 1: Simplified cases where theequipment mobilities are much higher than the receivermobilities, taking wirlpool baths as an examplePropriétés acoustiques des éléments de construction etdes bâtiments - Mesurage en laboratoire des bruits aérienset de structure des éléments de construction - Partie 1: Cassimplifiés prenant comme exemple les bains bouillonnantsAkustische Eigenschaften von Bauteilen und vonGebäuden - Messung des Luft- und Körperschalls vonhaustechnischen Anlagen im Prüfstand - Teil 1:Vereinfachte Fälle, in denen die Admittanzen der Anlagenwesentlich höher sind als die der Empfänger am Beispielvon WhirlwannenThis European Standard was approved by CEN on 20 May 2009.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre:
Avenue Marnix 17,
B-1000 Brussels© 2009 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 15657-1:2009: ESIST EN 15657-1:2009

List of symbols . 15Annex B (informative)
Link to EN 12354-5 . 16B.1General . 16B.2Airborne sound . 16B.3Structure borne sound . 16SIST EN 15657-1:2009

Calculation of the reference structure borne sound pressure level . 18C.1Reference building configuration . 18C.2Transmission functions . 18C.3Reference structure borne sound pressure level . 19Annex D (informative)
Example of an existing test rig . 20Annex E (informative)
Measurement procedure for the tub filling phase, using a reference water jet . 23E.1General . 23E.2Specification for a defined water jet . 23E.3Test procedure . 24Bibliography . 25 SIST EN 15657-1:2009

NOTE See 9.5.3. 3.8 installed power component structural power (calculated) injected to each building element to which the equipment is connected (input datum for the prediction method) 3.9 reference structure borne sound pressure level structure borne sound pressure level obtained when mounting the equipment in the reference building 3.10 reference building well defined building configuration in which the equipment is fictively mounted and used when comparing products 4 Symbols A list of the symbols and units used in this European Standard is given in Annex A. 5 Principle of the test method 5.1 Airborne sound measurement The specimen is mounted inside the test room. The sound in the test room, produced as airborne sound radiated from the object, is measured. The source sound power is then estimated from the measured sound corrected for background noise, and from the measured reverberation time of the test room. Later in the process of calculation, a single value descriptor for the source sound power is calculated (see Clause 10). SIST EN 15657-1:2009

NOTE Guidance for airborne sound measurements at 1/3 octaves 50 Hz, 63 Hz and 80 Hz is given in
EN ISO 140-3:1995, Annex F. 6.2 Requirements for the acoustic measuring equipment The measuring equipment shall comply with the requirements of EN ISO 140-3:1995, Clause 4. 6.3 Requirement for the vibration measuring equipment The vibration transducers used shall be calibrated according to ISO 16063-21:2003 and fixed according to ISO 5348:1998. 7 Test facilities 7.1 Test room 7.1.1 Construction requirements For airborne sound measurements, the test room shall have a volume of at least 50 m3. Each of the test room walls shall not be less than 3,5 m wide and shall have a minimum mass per surface area of 230 kg/m2 if the equipment is directly connected to it. 7.1.2 Acoustic requirements According to EN ISO 140-1:1997, the reverberation time shall be in the range 1s - 2s. SIST EN 15657-1:2009

Key 1 Resilient material Figure 1 — Schematic drawing of the three plate test rig The three plates shall be isolated from each other (see Figure 1), the corresponding velocity level difference, measured according to EN ISO 10848-1 without the equipment installed, being greater than 10 dB in each frequency band. The three plates shall be made of concrete (density of 2300 ± 200 kg/m3), have a thickness of 10 ± 1 cm, a minimum surface area of 5 m2 and preferably more than 7 m2, a ratio length/width close to 2 and a minimum loss factor at low frequencies (50-100 Hz) of 8 %. The loss factor η can be estimated from the structural reverberation time Ts of the plate using: η = 2,2 / (f Ts) (1) The minimum dimension of the plates must be equal or greater than the maximum dimension of the specimen. The specimen must not overhang the edge of the reception plate when installed. The example of an existing three plate test rig is given in Annex D. 8 Mounting of the specimen The mounting is performed exactly according to the instructions given by the manufacturer (or distributor or other interested party) of the product; it shall be described in full detail in the test report. The bathtub is measured with skirt according to the instructions given by the manufacturer. If the three plate test rig is located in the test room, the measurement of airborne and structure borne sound power can be made sequentially on the same setup of the specimen; the bathtub is connected to the three plate test rig as in real building, according to the instructions given by the manufactur
...
