EN 12368:2006

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Traffic control equipment - Signal headsOprema za nadzor in vodenje cestnega prometa - Signalni dajalciEquipement de régulation du trafic - SignauxAnlagen zur Verkehrssteuerung - SignalleuchtenTa slovenski standard je istoveten z:EN 12368:2006SIST EN 12368:2006en93.080.30ICS:SIST EN 12368:20021DGRPHãþDSLOVENSKI
STANDARDSIST EN 12368:200601-julij-2006

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 12368April 2006ICS 93.080.30Supersedes EN 12368:2000
English VersionTraffic control equipment - Signal headsEquipement de régulation du traffic - SignauxAnlagen zur Verkehrssteuerung - SignalleuchtenThis European Standard was approved by CEN on 27 February 2006.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Central Secretariat or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania,Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2006 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 12368:2006: E

Test, declarations and requirements.32

Clauses of this European Standard addressing the provisions of EU Construction Products Directive.34 Bibliography.41

1 Scope This European Standard only applies to red, yellow and green signal lights for road traffic with 200 mm and 300 mm roundels. It defines the requirements for the visual, structural, environmental performances and testing of signal heads for pedestrian and road traffic use. Portable signal lights are specifically excluded from the scope of this European Standard. 2 Normative references The following referenced documents are indispensable for the application of this European Standard. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies.
EN 12767, Passive safety of support structures for road equipment — Requirements and test methods EN 12899-1:2001, Fixed, vertical road traffic signs — Part 1: Fixed signs EN
50293, Electromagnetic compatibility — Road traffic signal systems — Product standard EN 60068-2-1, Environmental testing — Part 2: Tests — Test A: Cold (IEC 60068-2-1:1990) EN 60068-2-2, Basic environmental testing procedures — Part 2: Tests — Test B: Dry heat (IEC 60068-2-2:1974 + IEC 60068-2-2A:1976) EN 60068-2-5, Environmental testing — Part 2: Tests — Test Sa: Simulated solar radiation at ground level (IEC 60068-2-5:1975) EN 60068-2-14, Environmental testing — Part 2: Tests — Test N: Change of temperature (IEC 60068-2-14:1984 + A1:1986) EN 60068-2-30, Environmental testing — Part 2: Tests — Test Db and guidance: Damp heat, cyclic (12+12-hour cycle) (IEC 60068-2-30:1980 + A1:1985) EN 60068-2-64, Environmental testing — Part 2: Test methods — Test Fh: Vibration, broad-band random (digital control) and guidance (IEC 60068-2-64:1993 + Corrigendum 1993) EN 60529, Degree of protection provided by enclosures (IP-Code) (IEC 60529:1989) EN 60598-1:2004, Luminaries — Part 1: General requirements and tests (IEC 60598-1:2003 + Corrigendum 2004, modified) EN ISO 9001, Quality management systems — Requirements (ISO 9001:2000) CIE 17-4:1987, International lighting vocabulary CIE 69, Methods of characterizing illuminance meters and luminance meters — Performance, characteristics and specifications HD 638, Road traffic signal systems

batch quantity of a product manufactured with no change in raw material, equipment, settings or operation as defined in the FPC system manual of the manufacturer 3.11 individual (and non-series) where the manufacturing process is different to the manufacturer’s usual process

Different luminous intensities and luminous intensity distributions are recommended for different locations and situations. 6.2 Diameter of signal lights Roundel signal lights for road traffic conditions shall have a nominal diameter of (200 mm or 300 mm) ± 10 %. NOTE As the requirements for visibility depend on the local conditions of road lay-out and infrastructure, on traffic conditions and light conditions, it is not feasible to give strict rules for the situations where either 200 mm or 300 mm roundel signals should be used. 6.3 Luminous intensities of signal lights The performance levels for signal lights, for both 200 mm and 300 mm roundels, shall be as specified in Table 1. NOTE The standard does not give values for reduced output operation.

class 1 Imax
class 2 400 cd 1 100 cd 800 cd 2 000 cd 1 000 cd 2 500 cd
For example the performance level 2/1 is the designation of a signal light with: Imin = 200 cd; Imax = 800 cd. 6.4 Distribution of luminous intensity In Tables 2, 3, 4 and 5 four angular distributions of luminous intensity for signal lights are specified as minimum luminous intensities, expressed as percentage values dependent on the choice of the following categories: A
as a percentage of the measured values on the axis 0° horizontal and 0° vertical (the reference axis); B
as a percentage of the minimum values as defined in Table 1 required on the axis 0° horizontal and 0° vertical (the reference axis). Outside the area described in Tables 2 to 5 (as applicable) the luminous intensities shall not exceed the maximum of the relevant class of performance level. The Tables 2 to 5 contain the minimum luminous intensities in % of the values in their reference axis. Only the listed combinations of classes and performance levels shall be applied. Within the field of measurement, the light pattern shall be substantially uniform, i. e. the light intensity in each direction at each test point shall meet at least the level achieved by the next consecutive measurement. Table 2 — Extra wide-beam signal (Type E) possible combinations B 1/1, B 2/2 α horiz 0° ±2,5° ±5° ±10° ±15° ±20° ±30° α vert 0° –1,5° –3° –5° –10°
100 – 80 60 50
– – – – –
85 – 75 – –
80 – – 45 –
– – – – –
60 – – – 20
40 – – – – –20° 20 – – – – – 10 –
means no specific values are required

Table 3 — Wide beam signal (Type W) possible combinations A 1/1; A 2/1; A 3/1; B 1/2; B 2/1,B 2/2; B 3/2 α horiz 0° ±2,5° ±5° ±10° ±15° ±20° ±30° α vert 0° –1,5° –3° –5° –10°
100 – 80 60 30
– – – – –
85 – 75 – –
55 – – 35 –
– – – – –
3 – – – 8
1 – – – – –20° 2 – – – – – 2 –
means no specific values are required
Table 4 — Medium wide beam signal (Type M) possible combinations A 2/1; A 3/1; A 2/2; A 3/2 α horiz 0° ±2,5° ±5° ±10° ±15° ±20° ±30° α vert 0° –1,5° –3° –5° –10°
100 – 75 50 12,5
– – – – –
75 – 60 – –
40 – – 20 –
10 – – – –
1 – – – 6
* * * * * –20° 1,5 – – – – – 1 –
means no specific values are required *
means no requirements
Table 5 — Narrow beam signal (Type N) possible combinations A 2/1; A 3/1; B 2/2; B 3/2 α horiz 0° ±2,5° ±5° ±10° ±15° ±20° ±30° α vert 0° –1,5° –3° –5° –10°
100 95 70 40 6
75 90 – – –
65 – 45 – –
15 – – 10 –
1,5 – – – 5
* * * * *
* * * * * –20° * * * * * * * –
means no specific values are required *
means no requirements
6.5 Luminance uniformity The luminance uniformity of the roundel as the ratio of the lowest and greatest luminance Lmin : Lmax shall be ≥1 : 10 for types E, W and M and ≥1 : 15 for type N. 6.6 Maximum phantom signal For each signal colour the maximum phantom signal Iph for light incident at an angle of 10° to the reference axis shall comply with of Table 6, where Is is the actual measured luminous intensity I of the signal light: Table 6 — Requirement for the ratio of Is to Iph Signal light function Class 1 Class 2 Class 3 Class 4 Class 5 red, yellow >1 >5 >4 >8 >16 green >1 >5 >8 >16 >16
6.7 Colours of signal lights The colours of signal lights are red, yellow and green and they shall comply with Table 7 when using anti-phantom devices and including combined colours from real signal and all classes of phantom light, except class 1.

6.8 Signal lights with symbols Symbols shall only be placed on roundels of signal lights which demonstrate compliance with 6.3 to 6.7. The optical performance for symbols is derived by using the performance of the full roundel. Class S1: Symbols placed on roundels meeting 100 % of one of the levels set out in Table 1. Class S2: Symbols placed on roundels meeting 50 % of one of the levels set out in Table 1 (only pedestrian traffic). 6.9 Background screen of signal lights Signal lights shall have an opaque background screen or a rim of 25 mm which gives suitable contrast. The background screen may be incorporated in the housing of the signal head or may consist of a detachable screen. The dimensions of the background screen for three-colour-signal heads shall comply with one of the four classes specified in Table 8. The classes are expressed in the overall dimensions (height and width) of the opaque background screen and for 200 mm and 300 mm roundels.

Table 8 — Dimensions of background screens for three-colour-signal heads Heights Width Class d = 200 mm d = 300 mm d = 200 mm d = 300 mm C 1 ≥647 mm ≥980 mm ≥222 mm ≥336 mm C 2 ≥995 mm ≥1 367 mm ≥350 mm ≥650 mm C 3 ≥982 mm ≥1 517 mm ≥450 mm ≥800 mm C 4 ≥1 000 mm ≥1 500 mm ≥600 mm ≥900 mm
7 Constructional and environmental test methods The test methods for four environmental ranges are detailed in Table 9, Table 10, Table 11 and Table 12. The latter is generally considered an electrical test but in this case ingress of dust and moisture can adversely affect optical performance hence are included in this section. Table 9 — Impact resistance class IR 1 class IR 2 class IR 3 IMPACT test
EN 60598-1:2004, 4.13.4 0,51 kg ball of 50 mm diameter dropped from: 100 mm 400 mm 1 300 mm NOTE Surface cracks are allowed providing complete penetration does not occur, i.e. the integrity of the seal is not broken.
Table 10 — Constructional integrity Random vibration Frequency range: 10 Hz to 200 Hz EN 60068-2-64
Test Fh, class AJ2 ASD levels: 0,02 g2/Hz (10 Hz to 50 Hz) 0,02 g2/Hz (50 Hz to 200 Hz with slope 3 dB/octave). Overall RMS acceleration 1,2 g
Table 11 — Ingress Water penetration and dust
EN 60529, test 13 and 14 As required for the specified IP rating NOTE Ingress is allowed into the signal head provided it does not affect its performance either electrically or optically.

Class A Class B Class C preconditioning none initial examination visual inspection, operational test condition of the specimen during exposure period equipment switched on as specified in 11.1 conditioning temperature 60 °C 55 °C 40 °C conditioning time 16 h loading and measurement during exposure period visual inspection during last hour at expo-sure temperature and during cooling period non-standard recovery none Dry heat EN 60068-2-2 Test Bb final measurement visual inspection, operational test preconditioning none initial examination visual inspection, operational test condition of the specimen during exposure period equipment off until the final hour conditioning temperature –15 °C –25 °C –40 °C conditioning time 16 h loading and measurement during exposure period visual inspection during last hour at expo-sure temperature and during heating periodnon-standard recovery none Cold EN 60068-2-1 final measurement visual inspection, operational test lower temperature TA –15 °C –25 °C –40 °C upper temperature TB +60 °C +55 °C +40 °C rate of change of temperature 1 °C/min number of cycles 1 initial examination visual inspection, operational test exposure time t1 16 h measurements during exposure and time of execution visual inspection, operational test during the last hour of exposure time t1at lower temperature and during cooling period in 5 °C-intervals; during the last hour of exposure time t1 at upper temperature and during heating period in 5 °C-intervals recovery
Change of temperature EN 60068-2-14 Test Nb (This test may be carried out instead of the dry heat and cold test.)
final measurements visual inspection, operational tests

Class A Class B Class C air temperature 40 °C number of cycles 2 initial examination visual inspection, operational test condition of specimens during expo-sure
mounting or support
variant 2 intermediate measurements visual inspection, operational test during first 3 h of both cycles, and cool down period ofthe 2nd cycle recovery at standard atmospheric conditions, 2 h Damp heat, cyclic EN 60068-2-30 Test Db electrical and mechanical final measurement visual inspection, operational test within 30 min after recovery is finished preconditioning
initial examination visual inspection, operational test substrate for specimen, position of the irradiation measurement plane / test procedure and object of the test B equipment on and fully loaded, this test may be carried out as an alternative to the dry heat test Bb air temperature inside the test cham-ber during irradiation 40 °C maximum permissible air velocity inside the test chamber 2 m/s humidity conditions / test duration 1 cycle loading and measurement during exposure (measurement of the tem-perature of the specimen included) equipment on as specified in 11.1 recovery
Solar radiation incidence to the front of the signal under 45° EN 60068-2-5 Test Sa final measurements visual inspection, operational test NOTE Visual inspection means to look for physical problems. Operational test means to look for correct operation of the light source.

f4 ≤ 3  Fatigue error f5 ≤ 0,5  Temperature coefficient – α ≤ 0,2 % / K The signal head shall be operated with the manufacturer's equipment. The supplier of the signal head shall specify the operating voltage for the tests. He shall declare the operational tolerances of this value. For all light sources the specification from the manufacturer shall include nominal flux/luminous intensity relative to the specified voltage/wattage and the position of the source in the optical geometry of the signal. The manufacturer shall provide the signal head with light sources and specifications (for the luminous flux or luminous intensity measurements). 8.2 Measurement of luminous intensities The luminous intensity is measured with the optical unit on a goniometer. The angles in Tables 2, 3, 4 and 5 are chosen to correspond with a goniometer, where the horizontal axis is fixed and the vertical axis is moveable in space, see Figure 1 (type 1 CIE
70:1987). For a goniometer with another arrangement the angles have to be recalculated correspondingly (see CIE 54:2001, Annex B). The distance of measurement shall be such that the inverse square distance law is applicable (I = r2E). The measuring equipment shall be such that the angular aperture of the detector viewed from the reference centre of the lamp is ≤10°. The total effect of systematic and random errors in the goniometer shall not exceed:  For measurement of luminous intensity: 5 % of the actual intensity  For measurement of angular direction: beams with half peak side angle: 2° < α
< 4°: 0,1°
4° < α < 8°: 0,2° 8° < α
: 0,4°
Figure 1 — Goniometer for measuring luminous intensities with fixed horizontal axis X 8.3 Measurement of luminance for uniformity tests The measurement of the luminance is performed in the reference axis over the total area of the light emitting surface of the roundel specified by the manufacturer in a diameter of the roundel. The diameter of the circular measuring area shall be 25 mm. The total effect of systematic and random error of luminance measurements shall not exceed 5 %. By scanning with the luminance meter the minimum and maximum luminance shall be detected. 8.4 Measurement of phantom signal For measurements of phantom signal the signal head shall be fitted with its signal light source. The manufac-turer shall specify the light source(s) in accordance with 10.2. The light source generating a phantom signal according to Figure 2 is a projector simulating CIE illuminant A. The light from the projector shall illuminate the light emitting surface of the optical unit with the illuminance E = 40 000 lx and uniformity of 10 %. No hood shall be fitted. The reference axis of the signal head and the axis of the projector shall form an angle of 10°. The maximum permitted angular spread of illuminating directions is limited to 0,5°. The plane formed from both axes shall be the operational vertical plane. The arrangement shall be in a way that the projector radiates the light as if from above the signal head. To avoid also measuring a frontal phantom signal of a convex polished lens it is necessary to cover the image of the projector on the illuminating surface of the optical unit by means of a mask. The diameter of the mask shall be 30 mm (for 200 mm roundels) or 45 mm (for 300 mm roundels). If the illuminance E = 40 000 lx of the roundel cannot be realized the luminous intensity of the phantom light Iph can also be calculated for the lower illuminances El from the corresponding lower luminous intensity Iphl : E IIlphlphlx
= 00040× (1)
Key 1 projector 2 signal head 3 plane of the light emitting surface 4 photometer Figure 2 — Typical arrangement for the measurement of the luminous intensity of phantom signal
(γ
= photometer head aperture, δ
= source aperture) Measurements of phantom signal depend strongly on the geometry of measurement. 10 m distance for measurements is preferred for obtaining comparable results and it should be used to use the following distances and apertures:  photometer head aperture: γ = 10°, corresponding 2,9 cm diameter effective photometer head opening at 10 m distance;  source aperture: δ
= 10°, corresponding 2,9 cm diameter opening of effective light exit at 10 m distance. The photometer shall be placed so that the reference axis of the signal head and the axis of the photometer coincide. With switched on projector the mean luminous intensity Iph in the plane of the illuminating field of the signal head shall to be measured while the signal is switched off. The ratio between the luminous intensity Is of the real signal and the luminous intensity Iph of the phantom signal shall be as given in 6.6 and Table 6. 8.5 Measurement of the colour For the measurement of the colour the arrangement of Figure 2 shall be altered in a way that a colorimeter replaces the photometer. The chromaticity co-ordinates Ps (xs, ys) of the real signal shall be measured with projector switched off. 8.6 Measurement of combined colours The chromaticity coordinates Ps+ph (xs+ph ys+ph) of the mixed light from real signal and phantom signal shall be measured with projector and signal switched on. The illuminance on the illuminating field of the traffic signal shall be E = 40 000 lx. The chromaticity coordinates Ps+ph can also be calculated for the relevant illuminance from the chromaticity coordination Ps (xs, ys) of the pure signal and Pph (xph, yph) of the pure phantom. The chromaticity coordinates Pph (xph, yph) of the pure phantom signal shall to be measured while the projector is switched on and the signal light switched off according to 8.4. The chromaticity co-ordinates are:

+
+
= yIyI IIy (3) When plotting the colour of the measured mixed signal into the chromaticity diagram shown in Figure 3, they shall be within the recommended regions of Table 13 which are derived from Table 7, unless there are no requirements for combined colours.
Key 1 green 2 yellow 3 red Figure 3 — CIE-chromaticity diagram with boxes for the colours of signal lights and combined colours

Table 13 — Chromaticity co-ordinates of the corners of the recommended chromaticity regions from Table 7 for signal lights 1 2 3 4 Colour x y x y x y x y Red Yellow Green 0,660 0,536 0,009 0,320 0,444 0,720 0,680 0,547 0,284 0,320 0,452 0,520 0,710 0,613 0,209 0,290 0,387 0,400 0,690 0,593 0,028 0,290 0,387 0,400 9 Tolerances 1) Measurement tolerances shall be for each unit of optical measurement as detailed in Clause 8. 2) Test arrangements for optical measurement shall be set up for angles if not otherwise quoted to 0,1°. 3) The operating tolerances of all components for optical measurement which affect the performance parameters shall be stated in supplier documentation. 4) All items selected from general suppliers data but used to closer tolerances to achieve the performance levels shall be declared in documentation supplied with the test unit. The testing authority shall test the unit within those operating tolerances, these will be noted and become part of the detail included in the certification. 10 Marking, labelling and product information 10.1 Marking and labelling The finished equipment which contains any electrical, electronic or optical parts shall be clearly and durably marked with the information a) to e). The marking may be inside the unit to provide an acceptable external appearance but it shall be visible when access is obtained to the internal parts. a) Power rating (voltage, current and frequency) b) Manufacturer's name, trademark or identification mark c) Manufacturer's model or type reference d) Date of manufacture (month and year) e) Details of the classes of construction, i.e.  Performance level on luminous intensity including maximum luminous intensity  Luminous intensity distribution classification  Phantom classification  Symbol classification  Environmental classification

667/1/20345/001 Manufactured 94-12 Performance level class A 2/2 Luminous intensity distribution M Phantom class 2 Symbol class S2 Impact resistance IR1 Ingress protection IP55 Environmental class B
Marking and labelling shall be affixed in such a way that the visibility and legibility of the regulatory marking is not reduced and provided that such marks are not likely to deceive third parties as to the meaning and form of the regulatory marking. Marking required under this clause which is also required for regulatory purposes need not be repeated [for this clause] and is deemed to satisfy the requirements of this clause. 10.2 Product information The manufacturer or vendor shall provide the information a) to f): a) definition of the reference axis; b) instructions on the assembly and mounting of the signal head and pole in relation to the reference axis; c) details of any limitations in location or usage; d) instructions of the light source to be used; e) instructions on the operation, maintenance and cleaning of the signal head; f) for each standard signal head the measurement data to prove compliance with the relevant requirements of this standard. 11 Evaluation of conformity 11.1 General To establish conformity against a product class in this European Standard a test module shall pass a series of optical, constructional and environmental tests. In addition, the supplier shall declare that the module meets the requirements for size, for electrical safety, EMC, background screens and symbols set out in the standard. Details of the requirements to be tested and to be declared are given in Annex A. To demonstrate conformity against the standard the supplier shall provide a fully constructed signal head with three optical units (test module). The supplier may submit at the same time or subsequently, optical/constructional variants of the original for certification, including individual optical units. He shall not,
...
