ASTM A847/A847M-21

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: A847/A847M − 20 A847/A847M − 21
Standard Specification for
Cold-Formed Welded and Seamless High-Strength, Low-
Alloy Structural Tubing with Improved Atmospheric
Corrosion Resistance
This standard is issued under the fixed designation A847/A847M; the number immediately following the designation indicates the year
of original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval.
A superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope*
1.1 This specification covers cold-formed welded and seamless high-strength, low-alloy round, square, rectangular, or special
tubular shapes for welded, riveted, or bolted construction of bridges and buildings and for general structural purposes where high
strength and enhanced atmospheric corrosion resistance are required (Note 1). The atmospheric corrosion resistance of this steel
in most environments is substantially better than carbon steel with or without copper addition (Note 2). When properly exposed
to the atmosphere, this steel can be used bare (unpainted) for many applications. When this steel is used in welded construction,
the welding procedure shall be suitable for the steel and the intended service.
1.2 This tubing is produced in welded sizes with a maximum periphery of 88 in. [2235 mm] and a maximum wall of 1 in. [25.4
mm], and in seamless with a maximum periphery of 32 in. [813 mm] and a maximum wall of 0.500 in. [12.7 mm]. Tubing having
other dimensions may be furnished provided such tubing complies with all other requirements of this specification.
NOTE 1—Products manufactured to this specification may not be suitable for those applications where low temperature notch toughness properties may
be important, such as dynamically loaded elements in welded structures, unless ordered with toughness tests. See the Supplementary Requirements.
NOTE 2—For methods of estimating the atmospheric corrosion resistance of low alloy steels, see Guide G101 or actual data.
1.3 The values stated in either SI units or inch-pound units are to be regarded separately as standard. Within the text, the SI units
are shown in brackets. The values stated in each system may not be exact equivalents; therefore, each system shall be used
independently of the other. Combining values from the two systems may result in non-conformance with the standard.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2.1 ASTM Standards:
A370 Test Methods and Definitions for Mechanical Testing of Steel Products
A700 Guide for Packaging, Marking, and Loading Methods for Steel Products for Shipment
A751 Test Methods and Practices for Chemical Analysis of Steel Products
This specification is under the jurisdiction of ASTM Committee A01 on Steel, Stainless Steel and Related Alloys and is the direct responsibility of Subcommittee A01.09
on Carbon Steel Tubular Products.
Current edition approved Nov. 1, 2020Sept. 1, 2021. Published November 2020September 2021. Originally approved in 1985. Last previous edition approved in 20142020
as A847/A847M – 14.A847/A847M – 20. DOI: 10.1520/A0847_A0847M-20.10.1520/A0847_A0847M-21.
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
A847/A847M − 21
A1058 Test Methods for Mechanical Testing of Steel Products—Metric
G101 Guide for Estimating the Atmospheric Corrosion Resistance of Low-Alloy Steels
2.2 Steel Tube Institute Standard:
Methods to Check Dimensional Tolerances on Hollow Structural Sections
3. Ordering Information
3.1 Orders for material under this specification should include the following, as required, to describe the desired material
adequately:
3.1.1 ASTM specification number,
3.1.2 Quantity (feet, metres, or number of lengths),
3.1.3 Name of material (cold-formed tubing),
3.1.4 Method of manufacture (welded or seamless),
3.1.5 Size (outside diameter and nominal wall thickness for round tubing and the outside dimensions and nominal wall thickness
for square and rectangular tubing),
3.1.6 Length (specific or random, see 10.3),
3.1.7 End condition (see 14.2),
3.1.8 Burr removal (see 14.2),
3.1.9 Certification (see Section 17),
3.1.10 Specific weld location,
3.1.11 End use, and
3.1.12 Special or supplementary requirements.
4. Process
4.1 The steel shall be made by one or both of the following processes: basic oxygen or electric furnace.
5. Manufacture
5.1 The tubing shall be made by a welded or seamless process.
5.2 Welded tubing shall be made from flat-rolled steel by the electric-resistance welding or electric-fusion welding process. The
longitudinal butt joint shall be welded across its thickness in such a manner that the structural design strength of the tubing section
is assured. The weld shall not be located within the radius of the corners of any square, rectangular, or other tubular shapes unless
specified by the purchaser.
5.2.1 Structural tubing welded by the electric-resistance method is normally furnished without removal of inside flash.
5.3 The tubing may be stress relieved or annealed, as is considered necessary by the tubing manufacturer, to conform to the
requirements of this specification.
6. Chemical Composition
6.1 The choice and use of alloying elements combined with carbon, manganese, phosphorus, sulphur, and copper shall be within
Available from the Steel Tube Institute (STI), 2516 Waukegan Rd., STE 172, Glenview, IL 60025-1774, https://steeltubeinstitute.org.
A847/A847M − 21
the limits prescribed in Section 7 to give the mechanical properties prescribed in Table 1 and to provide the atmospheric corrosion
resistance of 1.1. The choice and use of these elements shall be made by the manufacturer and included and reported in the heat
analysis to identify the type of steel applied. Elements commonly added include chromium, nickel, silicon, vanadium, titanium,
and zirconium. For Specification A847/A847M material, the atmospheric corrosion-resistance index, calculated on the basis of the
chemical composition of the steel as described in Guide G101, shall be 6.0 or higher. The amount of nickel, silicon, and chromium
present shall be reported due to their use calculating the atmospheric corrosion index.
NOTE 3—The user is cautioned that the Guide G101 predictive equation for calculation of an atmospheric corrosion-resistance index has been verified
only for the composition limits stated in that guide.
7. Heat Analysis
7.1 Each heat analysis shall conform to the requirements given in Table 2 for heat analysis.
8. Product Analysis
8.1 The tubing shall be capable of conforming to the requirements given in Table 2 for product analysis.
8.2 If product analyses are made, they shall be made using test specimens taken from two lengths of tubing from each lot of 500
lengths, or a fraction thereof, or two pieces of flat-rolled stock from each lot of a corresponding quantity of flat-rolled stock.
Methods and practices relating to chemical analysis shall be in accordance with Test Methods, Practices, and Terminology A751.
Such product analyses shall conform to the requirements specified in Table 2 for product analysis.
8.3 If both product analyses representing a lot fail to conform to the specified requirements, the lot shall be rejected.
8.4 If only one product analysis representing a lot fails to conform to the specified requirements, product analyses shall be made
using two additional test specimens taken from the lot. Both additional product analyses shall conform to the specified
requirements or the lot shall be rejected.
9. Tensile Requirements
9.1 The material, as represented by the test specimen, shall conform to the tensile property requirements prescribed in Table 1.
10. Permissible Variations and Dimensions
10.1 Outside Dimensions:
10.1.1 Round Structural Tubing—The outside diameter shall not vary from the specified outside diameter by more than 6 0.5 %,
rounded to the nearest 0.005 in. [0.1 mm], for specified outside diameters 1.900 in. [48.3 mm] and smaller; 6 0.75 %, rounded
to the nearest 0.005 in., for specified outside diameters 2 in. [50 mm] and larger. The outside diameter measurements shall be made
at positions at least 2 in. [50 mm] from either end of the tubing.
10.1.2 Square and Rectangular Structural Tubing—The specified dimensions, measured across the flats at a position at least 2 in.
[50 mm] from either end of the tubing and including an allowance for convexity or concavity, shall not exceed the plus and minus
tolerances shown in Table 3.
10.2 Wall Thickness—The minimum wall thickness at any point of measurement on the tubing shall be not more than
10 % less than the specified wall thickness. The maximum wall thickness, excluding the weld seam of welded tubing, shall be not
more than 10 % greater than the specified wall thickness. The wall thickness on square and rectangular tubing is to be measured
at the center of the flat.
TABLE 1 Tensile Requirements
Tensile strength, min, psi [MPa] 70 000 [485]
Yield strength, min, psi [MPa] 50 000 [345]
A
Elongation in 2 in. or [50 mm] min, % 19
A
Applies to specified wall thicknesses 0.120 in. [3.0 mm] and over. For lighter wall
thicknesses, elongation shall be by agreement with the manufacturer.
A847/A847M − 21
TABLE 2 Chemical Requirements
Elements Heat Analysis Product Analysis
Carbon, max 0.20 0.24
Manganese, max 1.35 1.40
Phosphorus, max 0.04 0.04
Sulphur, max 0.035 0.045
A A
Copper, min 0.20 0.18
B B
Nickel . . . . . .
B B
Silicon . . . . . .
B B
Chromium . . . . . .
A
If chromium and silicon contents are each 0.50 minimum, then the copper
minimums do not apply.
B
The amount of nickel, silicon, and chromium present must be reported, but there
are no minimum requirements.
TABLE 3 Outside Dimension Tolerances for Square and
Rectangular Tubing
Largest outside dimension
A
Tolerance, ± in. [mm]
across flats, in. [mm]
2 ⁄2 [63.5] and under 0.020 [0.5]
1 1
Over 2 ⁄2 [63.5] to 3 ⁄2 [88.9], incl 0.025 [0.6]
1 1
Over 3 ⁄2 [88.9] to 5 ⁄2 [139.7], incl 0.030 [0.7]
Over 5 ⁄2 [139.7] 1 %
A
Tolerances include allowance for convexity or concavity. For rectangular
sections, the tolerance calculated for the larger flat dimension shall also apply to
the smaller flat dimension. This tolerance may be increased 50 % when applied to
the smaller dimension if the ratio of the external sides is in the range of 1.5 to 3,
inclusive; the tolerance may be increased 100 % when the ratio exceeds 3.
10.3 Length—Structural tubing is normally produced in random mill lengths 5 ft [1.5 m] and over, in multiple lengths, and in
specified mill lengths (see Section 3). When specified mill lengths are ordered, the length tolerance shall be in accordance with
Table 4.
10.4 Straightness—The permissible variation for straightness of structural tubing shall be ⁄8 in. times the number of feet [10.4 mm
times the number of metres] of total length divided by 5.
10.5 Squareness of Sides—For square and rectangular structural tubing, adjacent sides may deviate from 90° by a tolerance of
6 2° maximum.
10.6 Radius of Corners—For square or rectangular structural tubing, the radius of any outside corner of the section shall not
exceed three times the specified wall thickness.
10.7 Twist—The tolerances for twist, or variation with respect to axial alignment of the section, for square and rectangular
structural tubing shall be as shown in Table 5. Twist is measured by holding down on a flat surface plate one end of a square or
rectangular tube, with the bottom side of the tube parallel to the surface plate and either (1) noting the difference in height above
the surface plate of the two corners at the opposite end of the bottom side of the tube, or (2) by measuring this difference on the
heavier sections by a suitable measuring device. The difference in the height of the corners shall not exceed the values of Table
5. Twist measurements are not to be taken within 2 in. [50 mm] of either end of the product.
TABLE 4 Specified Mill Length
Tolerances for Structural Tubing
22 ft [6.7 m] and under Over 22 ft [6.7 m]
Over Under Over Under
1 1 3 1
Length tolerance ⁄2 ⁄4 ⁄4 ⁄4
for specified mill [12.7] [6.4] [19.0] [6.4]
length, in. [mm]
A847/A847M − 21
TABLE 5 Twist Tolerances for Square and Rectangular Structural
Tubing
Specified dimension Maximum twist in the first 3 ft [1 m]
of longest side, in. [mm] and in each additional 3 ft
in. mm
1 ⁄2 [38.1] and under 0.050 1.4
1 1
Over 1 ⁄2 [38.1] to 2 ⁄2 [63.5], incl 0.062 1.7
Over 2 ⁄2 [63.5] to 4 [101.6], incl 0.075 2.1
Over 4 [101.6] to 6 [152.4], incl 0.087 2.4
Over 6 [152.4] to 8 [203.2], incl 0.100 2.8
Over 8 [203.2] 0.112 3.1
11. Special Tubular Shapes
11.1 The dimensions and tolerances of special tubular shapes are available by inquiry and negotiation with the manufacturer.
12. Flattening Test, Flaring Test, and Wedge Crush Test
12.1 The flattening test shall be made on round structural tubing. A flaring test or a wedge crush test on round tubing up to and
including 10 in. in diameter can be made if stated in the purchase order. Either a flattening test, a flaring test, or a wedge crush
test shall be made on square, rectangular, or other tubular shapes with a maximum side up to and including 10 in. except when
the customer specifies the weld to be located in the corner.
12.2 For welded structural tubing, a test specimen at least 4 in. [100 mm] in length shall be flattened
...
