ASTM D3344-90(2021)

This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation: D3344 − 90 (Reapproved 2021)
Standard Test Method for
Total Wax Content of Corrugated Paperboard
This standard is issued under the fixed designation D3344; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope 3. Summary of Test Method
3.1 The total quantity of wax associated with the corrugated
1.1 This test method covers the determination of the weight
board specimen is determined by extracting the wax from the
of wax that is present in a specimen of wax-treated corrugated
paperboard. The test method is applicable to specimens that board and evaporating the extract to dryness.
have been waxed by either impregnation (saturation) opera-
4. Significance and Use
tions or coating operations, or combinations of such operations.
4.1 Many of the functional properties of wax-treated corru-
1.2 The values stated in SI units are to be regarded as the
gated paperboard and cartons are dependent on the amount of
standard. The values given in parentheses are for information
wax present.
only.
4.2 In the case of wax-saturated, or wax-impregnated,
1.3 This standard does not purport to address all of the
paperboard the principal concern is with the weight of wax
safety concerns, if any, associated with its use. It is the
used relative to the weight of paperboard present, that is, the
responsibility of the user of this standard to establish appro-
weight percent content or pickup. In some applications the
priate safety, health, and environmental practices and deter-
saturating wax may be deposited in the three elements of the
mine the applicability of regulatory limitations prior to use.
corrugated board in such a way as to individually control the
For precautionary statement, see 5.4 and 7.2.
amount in each element, that is, the medium and the two
1.4 This international standard was developed in accor-
facings.
dance with internationally recognized principles on standard-
4.3 In the case of wax-coated corrugated paperboard the
ization established in the Decision on Principles for the
principal concern is the weight of wax on the board surface per
Development of International Standards, Guides and Recom-
unit area. The functional values of the wax coating as a barrier
mendations issued by the World Trade Organization Technical
or a decorative coating are dependent, in part, on the amount of
Barriers to Trade (TBT) Committee.
wax in the continuous surface layer, relative to the area
covered. The weight of coating relative to the weight of
2. Terminology
substrate is not usually a concern with regard to product
2.1 Definitions:
quality.
2.1.1 weight of applied wax coating, n—the weight of wax
that has been applied to the corrugated board as a coating,
5. Apparatus
expressed as weight per unit area, usually grams of coating per
5.1 Sample Trimming Equipment—A suitable trimming
square metre or pounds of coating per thousand square feet of
board or template arrangement equipped with a razor edge
board covered.
knife for even cutting of specimens so that they have parallel
NOTE 1—When it is known that a wax-coated specimen has no sides and are of the right size. (A guillotine-type paper cutter is
impregnating wax present, this extraction procedure is normally calcu-
not recommended.)
lated to express the data as “weight of applied wax coating.”
5.2 Measuring Rule, steel-edged, rule for measuring the size
2.1.2 weight percent wax content, n—the weight percent of
of specimen to within 0.5 mm.
wax present in and on corrugated board relative to the weight
5.3 Beakers, 1000 cm , Griffin-type.
of unwaxed board substrate measured at 23 °C (73 °F) and
5.4 Solvent —Chlorinated hydrocarbon solvent, 1,1,1-
50 % relative humidity.
trichloroethane. (Warning—May cause irritation. Avoid con-
tact with the eyes, skin, and clothing. Use only with adequate
This test method is under the jurisdiction of ASTM Committee D02 on
Petroleum Products, Liquid Fuels, and Lubricants and is the direct responsibility of
Subcommittee D02.10 on Properties of Petroleum Waxes and Alternative Wax-like The sole source of supply of the apparatus known to the committee at this time
Materials. is Inhibisol (Brand), Amerace-Esna Corp., Chemical Specialties Division, Tenafly,
Current edition approved Jan. 1, 2021. Published February 2021. Originally NJ 07670. If you are aware of alternative suppliers, please provide this information
approved in 1974. Last previous edition approved in 2015 as D3344 – 90 (2015). to ASTM International Headquarters. Your comments will receive careful consid-
DOI: 10.1520/D3344-90R21. eration at a meeting of the responsible technical committee , which you may attend.
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
D3344 − 90 (2021)
ventilation. Avoid prolonged breathing of vapor or spray mist. 7.3 Repeat the solvent extraction using 250 cm of fresh
Avoid prolonged or repeated contact with skin. Do not take solvent, boiling for 1 h and rinsing with 30 cm of hot solvent.
internally.) The solvent used should be residue-free, and should Combine all extracts and rinsings in the same tared beaker.
be checked for a residue upon evaporation before using.
7.4 Evaporate the combined solvent extracts on a steam bath
5.5 Steel Screen, 325-mesh, approximately 150 mm in
or, optionally, overnight in the air current of a hood. Evapora-
diameter, to fit into a funnel.
tion may be hastened by use of a stream of nitrogen. For the
final stages of evaporation, place the beaker on a hot plate at
5.6 Glass Funnel, approximately 100 mm in diameter.
about 300 °F to completely dissipate solvent vapors or mois-
5.7 Watch Glasses.
ture. Confirm that evaporation is complete when no solvent
5.8 Steam Bath or Hot Plate in Hood.
odor can be detected. Cool and reweigh the tared beaker.
Record the weight of wax extracted, to the nearest 1 mg.
5.9 Laboratory Hot Plate.
NO
...
