Designation: A472/A472M − 07 (Reapproved 2022) A472/A472M − 23
Standard Specification for
Heat Stability of Steam Turbine Shafts and Rotor Forgings
This standard is issued under the fixed designation A472/A472M; the number immediately following the designation indicates the year
of original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval.
A superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope Scope*
1.1 This specification covers the determination of heat stability of steam turbine shafts and rotor forgings to ensure stability at
operating temperature. This specification is not ordinarily applicable to generator rotor forgings.
1.2 This specification is expressed in both inch-pound units and in SI units; however, unless the purchase order or contract
specifies the applicable M specification designation (SI units), the inch-pound units shall apply. The values stated in either
inch-pound units or SI units are to be regarded separately as standard. Within the specification, the SI units are shown in brackets.
The values stated in each system are not necessarily exact equivalents; therefore, to ensure conformance with the standard, each
system shall be used independently of the other, and values from the two systems shall not be combined.
1.3 Supplementary requirements of an optional nature are provided for use at the option of the purchaser. The supplementary
requirements shall apply only when specified individually by the purchaser in the purchase order or contract.
1.4 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of
regulatory limitations prior to use.
1.5 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2.1 ASTM Standards:
A788 Specification for Steel Forgings, General Requirements
A941 Terminology Relating to Steel, Stainless Steel, Related Alloys, and Ferroalloys
3. Terminology
3.1 Definitions:
3.1.1 For definitions of terms specific to this standard, refer to Specification A788 and Terminology A941.
This specification is under the jurisdiction of ASTM Committee A01 on Steel, Stainless Steel and Related Alloys and is the direct responsibility of Subcommittee A01.06
on Steel Forgings and Billets.
Current edition approved March 1, 2022Nov. 1, 2023. Published March 2022November 2023. Originally approved in 1962. Last previous edition approved in 20172022
as A472/A472M – 07 (2022).(2017). DOI: 10.1520/A0472_A0472M-07R22.10.1520/A0472_A0472M-23.
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
*A Summary of Changes section appears at the end of this standard
